ZTE MF91D

Quick Guide

ZTE CORPORATION

NO. 55, Hi-tech Road South, ShenZhen, P.R.China

Postcode: 518057

Tel: +86-755-26779999

URL: http://www.zte.com.cn

E-mail: [email protected]

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated

or utilized in any form or by any means, electronic or mechanical, in-

cluding photocopying and microlm, without the prior written permis-

sion of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve the right

to make modications on print errors or update specications without

prior notice.

Version No. : R1.0

Edition Time: 201302

Manual No: 079584505407

Introduction

ZTE MF91D is a 4G mobile hotspot device, working in GSM/GPRS/

EDGE/WCDMA/HSPA/HSPA+ /LTE network. The client devices can

connect to the device via USB or Wi-Fi interface. The device supports

data services, enabling you to communicate anytime and anywhere.

Specication

Data Service

LTE FDD:

DL 100 Mb/s

UL 50 Mb/s

HSPA+:

DL 42 Mbps,

UL 5.76 Mbps

WCDMA CS: 64 kbps UL/DL

WCDMA PS: 384 kbps UL/DL

Interface USB and Wi-Fi

Wi-Fi Standard 802.11 b/g/n(1*1 11n features)

Wi-Fi Security WEP/WPA/WPA2

USB Version USB 2.0 HIGH SPEED

USB Interface Type Micro USB

Weight 105 g

Dimensions (W×H×D): 100 mm x 58 mm x 16 mm

microSD card Support up to 32 GB microSD card

Battery 2300 mAh

*Standby time 150 hours

*Working time 4 hours

Operate system

Windows XP (SP2 or later), Windows

Vista(32bit or 64bit), Windows 7, Windows

8, MAC (10.4 or later)

Web Browser

IE (7.0 or later), Firefox (3.0 or later),

Opera (10.0 or later), Safari (4.0 or later),

Chrome (10.0 or later)

Operating temperature 0°C ~ +40°C

Storage temperature -20°C ~ +50°C

Charging temperature 0°C ~ +45°C

Humidity 5%~ 95%

Notes:

microSD is a trademark of SD Card Association.

The device’s standby and working time are only for your reference,

and based on ideal working environment.

Getting to Know Your Device

The following gure shows the appearance of the device. It is only for

your reference. The actual device may be different.

Right Side Front Left Side

Interface and Buttons

1. External Antenna

Connector

• It is used to connect an external antenna

to enhance the signal strength.

2. WPS

• This button is used to start/end Wi-Fi

Protected Setup authentication process

and enable/disable the Wi-Fi function.

• Hold it for 3 seconds to activate the WPS

function.

• When the WPS function is available,

press it to deactivate the WPS function.

• Press it to enable/disable Wi-Fi function.

3. OLED Screen • It indicates the network type, signal

strength, battery, Wi-Fi, etc.

4. Power • Hold the Power button to switch on/off

the device.

5. Memory card slot

(microSD card)

• It is where you insert the memory card

(microSD card).

6. Charger/USB port

• Charge your device.

• Connect the client to your device via

USB cable.

Indicators

When the device is powered on, the following icons will appear on the

OLED screen, with the corresponding indications listed in the table

below:

Icon Indication

Network signal strength.

2G / 3G / 4G

Network type. 2G, 3G or 4G icon will appear on

the OLED screen according to the connected

network.

Roaming network indication.

Connect to the Internet automatically.

Wi-Fi status and number of the connected users.

Battery power indication.

Connected

/Disconnected

The device connects or disconnects to the Inter-

net.

Hardware Installation

Inserting SIM Card, Memory Card and Battery

1. Use the thumb catch on the device to open the battery cover.

2. Insert SIM Card into the slot.

Warning:

Please power off the device and remove the external power adapter

before removing or inserting the SIM card, if not, the device or SIM

card may be damaged.

3. Insert the battery as shown with the contacts located against the

gold springs.

4. Line the battery cover up correctly and press gently to close the

case.

Inserting microSD Card

1. Pull the microSD cover out of the card slot.

Notes:

Do not pull the cover rudely, as it is connected with the device.

2. Insert the microSD card into the microSD slot. The following

picture shows the correct inserting direction. You will hear a click

when the microSD card locks in place.

3. Close the microSD cover.

Switching On/Off Your Device

Press and hold the Power button to switch on/off the device.

Notes:

• Please install battery before power on.

• The device is powered on when the OLED Screen lights up.

Charging Your Device

1. Insert the charger lead carefully with the correct orientation to the

charger port.

The plug only ts one way. Do not use excessive force to insert

the plug.

2. Connect the charger to a main socket.

3. Disconnect when the battery is fully charged.

Working Mode

Your device supports three working modes. For the client, we only

use PC or laptop as the example in this document.

USB Mode: Connect the device to your PC or laptop via the included

USB cable, then power on your device. And the following picture is

one application example:

Wi-Fi Mode: Power on directly, and then connect the device to your

PC or laptop via Wi-Fi. And the following picture is one application

example:
