Zte MF286R Manuel utilisateur
Confidential and Proprietary Information of ZTE CORPORATION 1
MF286R
Let’s go
Getting started with your device.
ZTE CORPORATION
NO. 55, Hi-tech Road South, Shenzhen, P.R.China
Postcode: 518057
2
LEGAL INFORMATION
Copyright © 2019 ZTE CORPORATION.
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means,
electronic or mechanical, including photocopying and microfilm, without the prior written permission of
ZTE Corporation.
The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors
or update specifications without prior notice.
Version No. : R1.0
Edition Time: October 23, 2019
3
Getting to Know Your Device
External View
NOTE:
Please use the original external antenna if necessary.
Indicators
Indicator State Description
POWER
Blue on Power is on and external power supply is
workin
g
normall
y
.
Off Power is off or external power supply is
workin
g
abnormall
y
.
WIFI
Blue on Wi-Fi works normally with no data
transmission.
Blue Blinkin
g
Wi-Fi works normall
y
with
d
ata transmission.
Off Wi-Fi works abnormally or the Wi-Fi function
is disabled.
PHONE
Off The phone is not in use.
Blue Blinkin
g
The
p
hone is rin
g
in
g
.
Blue on The
p
hone is in callin
g
.
3G/4G
Red
The device is turned on but not registered to
the mobile network. No (U)SIM card is
inserted or there is no network service
available.
Blue Blinking The device is connected to the LTE network
and data is being transferre
d
.
Blue Soli
d
The device is
r
egiste
r
e
d
to the LTE network.
4
Indicator State Descri
p
tion
Green Blinking The device is connected to the 2G/3G network
and data is being transferre
d
.
Green Soli
d
The device is
r
egiste
r
e
d
to the 2G
/
3G network.
SIG
Blue on Signal level panel. Strength is from weak to
strong.
Off There is no signal or no (U)SIM card is
inserte
d
.
NOTE:
The phone function needs the network support.
Buttons
Button Description
RESET Press and hold for about 3 seconds to restore factory default configurations.
WLAN Press to turn off/on the Wi-Fi function.
WPS Press to activate the WPS function.
Installing the (U)SIM card
Hold the (U)SIM card with the cut corner oriented as shown and slip it into the card slot until you
hear a click.
WARNINGS!
• Before installing the (U)SIM card, power off your device and remove the external power adapter.
• Your device does not support micro-SIM and nano-SIM card or any other nonstandard (U)SIM cards. To
avoid device damage, please do not use them or any card holders.
Getting Started With Your Device
Connecting Your Device
Follow the number to connect your device.
5
If you want to use the mobile network to connect to the Internet or use your home phone, you
need to insert your (U)SIM card first.
Starting Your Device
CAUTION:
Your device must be placed in a well-ventilated environment. Do not cover the device.
Slide the on/off switch to start your device. After the device is initialized, make sure the LED
indicators are in normal status.
NOTE:
After your device is powered off, if you are called, the caller will hear a prompt tone like “The subscriber
you are dialing cannot be reached now.”
Configuring Your PC
The following procedure describes how to configure the Internet Protocol in Windows for your
Wi-Fi connection.
1. Right-click Network and select Properties.
2. Select Change adapter settings.
3. Right-click Wireless Network Connection and select Properties.
NOTE:
If you use a network cable to connect your PC to your device, you need to right-click Local Area
Connection and select Properties.
4. Select Internet Protocol Version 4 (TCP/IPv4) and click Properties.
5. Select Obtain an IP address automatically and Obtain DNS server address
automatically, and click OK.
6
Wireless Connection
If you want to use Wi-Fi to connect to your device, please refer to the following steps.
1. Make sure that the Wi-Fi works normally. Please check the WIFI indicator.
2. Use your normal Wi-Fi application on the client to search for the available wireless network.
NOTE:
Please set the client to obtain an IP address automatically, and the client will get an IP address like
“192.168.0.101”. For the detailed procedure, refer to Configuring Your PC.
3. Select the SSID (Wi-Fi name) of your device, and then click Connect.
NOTE:
Please check the label on your device to get the default SSID.
4. Enter the password and then click OK.
NOTE:
Please c
heck the label on your device to get the default password.
5. Wait until the client device is connected to your device successfully.
Accessing the Internet
Before accessing the Internet, please make sure that the following operations are finished.
Your device is connected to the terminal device via a network cable or Wi-Fi.
The terminal device is set to obtain an IP address automatically.
To access the Internet:
1. Launch the Internet browser and enter http://192.168.0.1 in the address bar. The login page
appears.
2. Input the Username and Password and then click Login.
NOTE:
View the label on your device to get the default username and password.
3. Select Settings > Network Settings > Dial-up Settings and then change the WAN
Connection Mode if necessary. The default mode is Automatic.
7
4. Begin to enjoy your Internet service.
Telephone Function
Your device supports the telephone function. Before using the telephone function, connect the
telephone and insert the (U)SIM card.
To make a call:
1. Pick up the handset.
2. Key in the telephone number.
3.
Press the # key on the telephone to send the call, or wait 4~8 seconds for the call to be dialed
automatically.
NOTE:
If there is no signal indication, the radio signal is unavailable. Change the location of the device and make
sure nothing is blocking it.
WPS Function
Your device supports WPS function. You can use this function to connect the client to your
device.
1.
Power on your device, and start the WPS function.
2.
Press the WPS button on your device to activate the WPS function.
3. Enable the WPS function on your client. Follow the system prompts on your client to finish the
connection.
NOTE:
For detailed operations on the client, refer to the corresponding product instructions.
8
Troubleshooting
Voice Related Problems
Symptoms Possible Problems/ Solutions
There is no dial tone. Please wait for 1~2 minutes after the router is turned
on.
If signal strength is weak, you have no good RF
reception. Change the location of the router.
There is a prompt / phone alert / announcement as soon as
I lift the phone off the hook.
Make sure your (U)SIM card is inserted correctly and
the PIN number has been entered. If the PIN number has
been entered incorrectly then you will need to enter the
PUK code when prompted.
The line is noisy/distorted when I lift the phone off the
hook.
Remove any electrical appliance which is too close to
the phone or your device.
The cable or phone set might be faulty.
I hear a rapid engaged tone as soon as I lift the phone off
the hook.
Put the phone on the hook and try again.
Please contact with your servicer provider.
After dialing the last digit I hear nothing/silence. When you have finished dialing you can press the # key
or wait 4~8 seconds to connect the call.
Internet Related Problems
Symptoms Possible Problems/ Solutions
I cannot access the Internet at all. Please check your configuration settings.
Please wait 1~2 minutes for the router to initialize.
Check your service indicators.
The download or upload speed is very slow. The speed is dependent on signal strength. Check your
signal strength and network type.
I cannot visit the Claro 4GMax page. Enter the correct address. The default address is
http://192.168.0.1.
Only use one network adapter in your PC.
Do not use any proxy server.
I cannot establish the Wi-Fi connection between my device
and the client.
Make sure the Wi-Fi function is active.
Refresh network list and select the correct SSID.
Check the IP address to make sure your client can
obtain an IP address automatically in the Internet
protocol (TCP/IP) properties.
Type the correct network key (Wi-Fi password) when
you connect to the device.
Others
Symptoms Possible Problems/ Solutions
About the password For the Wi-Fi connection password, please check the
9
Symptoms Possible Problems/ Solutions
label on the device.
Please check the label on the device to get the default
username and password of the Claro 4GMax page.
If you changed the password and forgot the new
password, you need to restore the device to the factory
default settings.
10
Warning and Notice
Safety Precautions
Some electronic devices may be susceptible to electromagnetic interference. Locate the router away
from TV set, radio and other electronic equipment to avoid electromagnetic interference.
The router may interfere with medical devices like hearing aids and pacemakers. Consult a physician
or the manufacturer of the medical device before using the router.
Please keep yourself at least 20 centimeters away from router.
Do not use your router in dangerous environments such as oil terminals or chemical factories where
there are explosive gases or explosive products being processed.
Please use original accessories or accessories that are authorized by ZTE. Unauthorized accessories
may affect the router performance, damage the router or cause danger to you.
Do not attempt to dismantle the router. There are no user serviceable parts.
Do not allow the router or accessories to come into contact with liquid or moisture at any time. Do not
immerse the router in any liquid.
Do not place objects on top of the router. This may lead to overheating of the device.
The device must be placed in ventilation environment for use.
Do not expose the router to direct sunlight or store it in hot areas. High temperature can shorten the life
of electronic devices.
Do not allow children to play with the router or charger.
Keep the length of the cable between the router and the phone less than 10 meters.
The router is for indoor use only. Do not use the router outside. Do not connect telephone extensions
which run outside of the building. These can result in lightning damage to your unit.
For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be
easily accessible.
Cleaning and Maintaining
Use an antistatic cloth to clean the router. Do not use chemical or abrasive cleanser as these could
damage the plastic case. Turn off your router before you clean it.
Use the router within the temperature range of -20℃ ~ +55℃, and the storage temperature range is -
40℃ ~ +70℃. The humidity range is 5%~95%.
Do not use your router during a thunderstorm. Remove the mains power pack from the wall socket.
Do not take out your (U)SIM card unnecessarily. The (U)SIM card may be easily lost or it can be
damaged by static electricity.
Autres manuels pour MF286R
1
Table des matières
Autres manuels Zte Routeur réseau
Zte
Zte MF65 Manuel utilisateur
Zte
Zte MC801A1 5G Manuel utilisateur
Zte
Zte WF821 Manuel utilisateur
Zte
Zte MC801A Manuel utilisateur
Zte
Zte ZXR10 ZSR Manuel utilisateur
Zte
Zte ZXHN H168M Manuel utilisateur
Zte
Zte MF65M Manuel utilisateur
Zte
Zte MC8010CA Manuel utilisateur
Zte
Zte OPTUS MF920V Manuel utilisateur
Zte
Zte ZXR10 3800-8 Instructions d'installation
Zte
Zte MF971V Manuel utilisateur
Zte
Zte ZXDSL-531B Manuel utilisateur
Zte
Zte MC801A Manuel utilisateur
Zte
Zte ZXR10 GER Manuel utilisateur
Zte
Zte ZXHN F680 Manuel utilisateur
Zte
Zte ZTE3200 Manuel utilisateur
Zte
Zte ZXR10 3800-8 Instructions d'installation
Zte
Zte ZXR10 3800-8 Manuel utilisateur
Zte
Zte ZXR10 3800-8 Instructions d'installation
Zte
Zte MF971R Manuel utilisateur
Manuels Routeur réseau populaires d'autres marques
NETGEAR
NETGEAR FS526T - Switch Manuel utilisateur
Korenix
Korenix JetNet 5710G Series Manuel utilisateur
Automated Logic
Automated Logic ZN551 Manuel du propriétaire
Cisco
Cisco ASR 1000 Series Manuel de l'opérateur
EnGenius
EnGenius ESR-9710 Manuel utilisateur
Cisco
Cisco 805 Series Instructions d'utilisation et de sécurité
