Xtreme Power Conversion TX90-1000 Mode d’emploi

TX90 Isolated Online UPS

1000VA, 2000VA, 3000VA, 5000VA Models

User & Installaon Manual

Xtreme Power Conversion Corporaon

TX90 User’s Manual

Page 2

Uninterrupble Power Supply

Table of Contents

Important Safety Warning............................................................................4

Transportaon.................................................................................................................................4

Preparaon......................................................................................................................................4

Installaon........................................................................................................................................4

Operaon........................................................................................................................................4

Installaon And Setup..................................................................................6

Rear Panel View...............................................................................................................................6

Setup the UPS..................................................................................................................................8

Operaons.................................................................................................10

Buon Operaon...........................................................................................................................10

LCD Panel.......................................................................................................................................11

Audible Alarm................................................................................................................................12

LCD Display Wordings Index..........................................................................................................12

UPS Seng....................................................................................................................................13

Operang Mode Descripon.........................................................................................................17

Faults Reference Code...................................................................................................................18

Warning Indicator..........................................................................................................................18

Troubleshoong.........................................................................................19

Storage And Maintenance Operaon..........................................................21

Specicaons.............................................................................................22

Obtaining Service.......................................................................................23

Xtreme Power Conversion Limited Warranty..............................................24

Xtreme Power Conversion Load Protecon Policy.......................................25

Xtreme Power Conversion Corporaon

TX90 User’s Manual

Page 3

Uninterrupble Power Supply

Important Safety Warning

Please comply with all warnings and operang instrucons in this manual strictly. Save this manual properly and

read carefully the following instrucons before installing the unit. Do not operate this unit before reading through

all safety informaon and operang instrucons carefully.

Transportaon

• Please transport the UPS system only in the original package to protect against shock and impact.

Preparaon

• Condensaon may occur if the UPS system is moved directly from cold to warm environment. The UPS

system must be absolutely dry before being installed. Please allow at least two hours for the UPS system

to acclimate the environment.

o Do not install the UPS system near water or in moist environments.

• Do not install the UPS system where it would be exposed to direct sunlight or near heater.

• Do not block venlaon holes in the UPS housing.

Installaon

• Do not connect appliances or devices which would overload the UPS system to the UPS output sockets.

o Place cables in such a way that no one can step on or trip over them.

o The UPS can be operated by any individuals with no previous experience.

• Connect the UPS system only to an earthed shockproof outlet which must be easily accessible and close

to the UPS system.

• Please use only VDE-tested, CE-marked mains cable (e.g. the mains cable of your computer) to connect the

UPS system to the building wiring outlet (shockproof outlet).

• Please use only VDE-tested, CE-marked power cables to connect the loads to the UPS system.

• When installing the equipment, it should ensure that the sum of the leakage current of the UPS and the

connected devices does not exceed 3.5mA.

Operaon

• Do not disconnect the mains cable on the UPS system or the building wiring outlet (shockproof socket

outlet) during operaons since this would cancel the protecve earthing of the UPS system and of all con-

nected loads.

• The UPS system features its own, internal current source (baeries). The UPS output sockets or output ter-

minals block may be electrically live even if the UPS system is not connected to the building wiring outlet.

o In order to fully disconnect the UPS system, rst press the OFF/Enter buon to disconnect the

mains.

o Prevent no uids or other foreign objects from inside of the UPS system.

Maintenance, Service, and Faults

• The UPS system operates with hazardous voltages. Repairs may be carried out only by qualied mainte-

nance personnel.

• Cauon - risk of electric shock. Even aer the unit is disconnected from the mains (building wiring outlet),

components inside the UPS system are sll connected to the baery and electrically live and dangerous.

• Before carrying out any kind of service and/or maintenance, disconnect the baeries and verify that no

Xtreme Power Conversion Corporaon

TX90 User’s Manual

Page 4

Uninterrupble Power Supply

current is present and no hazardous voltage exists in the terminals of high capability capacitor such as

BUS-capacitors.

• Only persons are adequately familiar with baeries and with the required precauonary measures may

replace baeries and supervise operaons. Unauthorized persons must be kept well away from the bat-

teries.

• Cauon - risk of electric shock. The baery circuit is not isolated from the input voltage. Hazardous volt-

ages may occur between the baery terminals and the ground. Before touching, please verify that no

voltage is present!

• Baeries may cause electric shock and have a high short-circuit current. Please take the precauonary

measures specied below and any other measures necessary when working with baeries:

o Remove wristwatches, rings and other metal objects

o Use only tools with insulated grips and handles.

• When changing baeries, install the same number and same type of baeries.

• Do not aempt to dispose of baeries by burning them. This could cause baery explosion.

• Do not open or destroy baeries. Escaping electrolyte can cause injury to the skin and eyes. It may be

toxic.

• Please replace the fuse only with the same type and amperage in order to avoid re hazards.

• Do not dismantle the UPS system.

Xtreme Power Conversion Corporaon

TX90 User’s Manual

Page 5

Uninterrupble Power Supply

Installaon And Setup

Note: Before installaon, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep

the original package in a safe place for future use.

Rear Panel View

TX90-1000

TX90-2000

Xtreme Power Conversion Corporaon

TX90 User’s Manual

Page 6

Uninterrupble Power Supply

TX90i-5000

1. Output receptacles

2. AC input

3. Input circuit breaker

4. External baery connecon (only available for L model)

5. RS-232 communicaon port

6. Modem/Phone line/Network surge protecon

7. Intelligent slot

8. Output circuit breaker

Xtreme Power Conversion Corporaon

TX90 User’s Manual

Page 7

Uninterrupble Power Supply

Setup the UPS

Step 1: UPS input connecon

Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords (The long run

model should be connected well the proper capacity of baery with the ups).

Step 2: UPS output connecon

Simply plug devices to output sockets. During power failure, UPS will provide power to connected devices.

Step 3: Communicaon connecon

RS-232 Port

Intelligent Slot

To allow for unaended UPS shutdown/start-up and status monitoring, connect the communicaon cable one end

to the RS-232 port and the other to the communicaon port of your PC. With the monitoring soware installed,

you can schedule UPS shutdown/start-up and monitor UPS status through PC.

1kVA, 2kVA, 3kVA, 5kVA models are equipped with intelligent slot perfect for SNMP, RS-232, USB or

Relay/AS400 card. When installing with these communicaon card in the UPS, it will provide advanced communi-

caon and monitoring opons.

Step 1:

Step 2:

Step 3:

Remove cover of intelligent slot.

Insert communicaon card into the slot

Screw card ghtly and complete installaon.

Step 4: Network connecon

Connect a single modem/phone/fax line into surge-protected “IN” outlet on the back panel of the UPS unit. Con-

nect from “OUT” outlet to the equipment with another modem/fax/phone line cable.

Xtreme Power Conversion Corporaon

TX90 User’s Manual

Page 8

Uninterrupble Power Supply

Step 5: Turn on the UPS

Press the ON/Mute buon on the front panel for two seconds to power on the UPS.

Note: The baery charges fully during the rst ve hours of normal operaon. Do not expect full baery run capa-

bility during this inial charge period.

Step 6: Install soware

For opmal computer system protecon, install UPS monitoring soware to fully congure UPS shutdown. You

may insert provided CD into CD-ROM to install the monitoring soware. If not, please follow steps below to down-

load and install monitoring soware from the internet:

1. Go to the website hp://www.power-soware-download.com

2. Click ViewPower soware icon and then choose your required OS to download the soware.

3. Follow the on-screen instrucons to install the soware.

4. When your computer restarts, the monitoring soware will appear as an orange plug icon located in the

system tray, near the clock.

Step 7: External baery connecon

Follow the below chart to make external baery connecon.

To external baery To external baery

Step 8: External baery capacity conguraon in soware

To calculate accurate backup me of external baeries, it’s necessary to congure baery numbers in soware.

The standard calculated capacity for one baery is 9Ah. If connecng to 100Ah baeries, then it’s equal to 11 in

parallel (100Ah / 9Ah ≈ 11 sets).

Xtreme Power Conversion Corporaon

TX90 User’s Manual

Page 9

Uninterrupble Power Supply

Operaons

Buon Operaon

Buon Funcon

ON/Mute Buon

• Turn on the UPS: Press and hold ON/Mute buon for at least 2 seconds

to turn on the UPS.

• Mute the alarm: Aer the UPS is turned on in baery mode, press and

hold this buon for at least 5 seconds to disable or enable the alarm sys-

tem. But it’s not applied to the situaons when warnings or errors occur.

• Up key: Press this buon to display previous selecon in UPS seng

mode.

• Switch to UPS self-test mode: Press ON/Mute buons simultaneously for

5 seconds to enter UPS self-tesng while in AC mode or converter mode.

OFF/Enter Buon

• Turn o the UPS: Press and hold this buon at least 2 seconds to turn

o the UPS in baery mode. UPS will be in standby mode under power

normal or transfer to Bypass mode if the Bypass enable seng by press-

ing this buon.

• Conrm selecon key: Press this buon to conrm selecon in UPS set-

ng mode.

Select Buon

• Switch LCD message: Press this buon to change the LCD message for

input voltage, input frequency, baery voltage, output voltage and out-

put frequency. It will return back to default display when pausing for 10

seconds.

• Seng mode: Press and hold this buon for 5 seconds to enter UPS set-

ng mode when UPS is in standby mode or bypass mode.

• Down key: Press this buon to display next selecon in UPS seng

mode.

ON/Mute + Select Buon

• Switch to bypass mode: When the main power is normal, press ON/Mute

and Select buons simultaneously for 5 seconds. Then UPS will enter to

bypass mode. This acon will be ineecve when the input voltage is out

of acceptable range.

ON/Mute + Select Buon

• Switch to UPS self-test mode: Press ON/Mute and OFF/Enter buons

Simultaneously for 5 seconds to enter UPS self-tesng while in AC mode

or converter mode

Xtreme Power Conversion Corporaon

TX90 User’s Manual

Page 10

Uninterrupble Power Supply

LCD Panel

Display Funcon

Backup me informaon

Indicates the backup me in pie chart.

Indicates the backup me in numbers.

H: hours, M: minute, S: second

Fault informaon

Indicates that the warning and fault occurs.

Indicates the warning and fault codes, and the codes are listed in details in 3-5

secon.

Mute operaon

Indicates that the UPS alarm is disabled.

Output & Baery voltage informaon

Indicates the output voltage, frequency or baery voltage.

Vac: output voltage, Vdc: baery voltage, Hz: frequency

Load informaon

Indicates the load level by 0-25%, 26-50%, 51-75%, and 76-100%.

Indicates overload.

Indicates the load or the UPS output is short circuit.

Mode operaon informaon

Indicates the UPS connects to the mains.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Xtreme Power Conversion UPS

Xtreme Power Conversion

Xtreme Power Conversion Pure Sine Wave Series Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion P91c-1000 Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion P90 1000VA Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion M90 Manuel utilisateur

Xtreme Power Conversion

Xtreme Power Conversion P80 Manuel utilisateur

Xtreme Power Conversion

Xtreme Power Conversion P91g Series Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion XPRT?1000 Manuel d'utilisation

Xtreme Power Conversion

Xtreme Power Conversion E90 Series Manuel utilisateur

Xtreme Power Conversion

Xtreme Power Conversion M90S Series Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion 20kVA Model Manuel d'utilisation

Xtreme Power Conversion

Xtreme Power Conversion XVT 600VA Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion XVT 600VA Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion XST?400 Manuel utilisateur

Xtreme Power Conversion

Xtreme Power Conversion XVT?600 Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion M90S Series Manuel utilisateur

Xtreme Power Conversion

Xtreme Power Conversion 800VA P80 Series Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion P90g Series Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion P91 Manuel utilisateur

Xtreme Power Conversion

Xtreme Power Conversion 700VA Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion Network Xtreme Rack/Tower Series Manuel d'utilisation

Xtreme Power Conversion

Xtreme Power Conversion S70 Line?Interactive Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion P80g Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion XPRT 6/10KVA Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion P90-BP36 Mode d’emploi

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
