Xtreme Power Conversion XVT 600VA Mode d’emploi

XVT Line Interacve Tower UPS

600VA, 800VA, 1200VA, 1500VA Models

User & Installaon Manual

Xtreme Power Conversion Corporaon

XVT User’s Manual

Page 2

Uninterrupble Power Supply

Table of Contents

Safety Instrucons........................................................................................3

Product Descripon......................................................................................4

UPS Funconality.............................................................................................................................4

Determining The Power Requirements Of Your Equipment...........................6

Hardware Installaon Guide.........................................................................6

Quickstart Soware Installaon Guide For Windows....................................7

Funcons.........................................................................................................................................8

Replacing The Baery...................................................................................9

Denions For Led Indicators.......................................................................9

Alarms........................................................................................................10

Troubleshoong.........................................................................................11

Specicaons.............................................................................................12

Shipping List...............................................................................................13

Obtaining Service.......................................................................................14

Xtreme Power Conversion Limited Warranty...............................................15

Xtreme Power Conversion Load Protecon Policy.......................................16

Xtreme Power Conversion Corporaon

XVT User’s Manual

Page 3

Uninterrupble Power Supply

Safety Instrucons

ATTENTION: To safely interact with and enjoy all the features and benets of these Xtreme Power Conversion Un-

interrupble Power Supplies (UPS), please read and follow all installaon and operaon instrucons completely.

These UPS are designed to provide power protecon for connected electronic equipment.

Please read this manual before installing the XVT-Series UPS models XVT-600, XVT-800, XVT-1200, and XVT-1500

as it provides important informaon that should be followed during installaon and maintenance of the UPS and

baeries, allowing you to correctly set up your system for the maximum safety and performance. Included is infor-

maon on customer support and factory service, if it is required. If you experience a problem with the UPS, please

refer to the Troubleshoong secon in this manual to correct the problem. If the problem is not corrected, please

collect informaon so that the Technical Support personnel can more eecvely assist you.

CAUTION: Any changes or modicaons not expressly approved by the manufacturer of this device could void the

user’s authority to operate the equipment.

FCC Noce: This equipment has been tested and found to comply with the limits for a Class B Digital Device pur-

suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful in-

terference in residenal installaon. This equipment generates uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instrucons, may cause harmful interference to radio communi-

caons. There is no guarantee that interference will not occur in a parcular installaon. If this equipment does

cause harmful interference to radio or television recepon, which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separaon between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

4. Consult the dealer or an experienced technician for help. Any special accessories needed for compliance

must be specied in the instrucon.

CAUTION: A shielded-type power cord is required in order to meet FCC emission limits and to prevent interference

to the nearby radio or TV recepon. It is essenal that only the supplied power cord be used. Use only shielded

cables to connect I/O devices to this equipment.

CAUTION: Any changes or modicaons not expressly approved by the manufacturer of this device could void the

user’s authority to operate the equipment.

IMPORTANT SAFETY INSTRUCTIONS: (SAVE THESE INSTRUCTIONS)

This manual contains important safety instrucons. Please read and follow ALL instrucons carefully during the in-

stallaon and operaon of the UPS. Read this manual thoroughly before aempng to unpack, install, or operate.

CAUTION! To prevent the risk of re or electric shock, install in a temperature and humidity controlled indoor area,

free of conducve contaminants. (Please see specicaons for acceptable temperature and humidity range).

CAUTION! To reduce the risk of electric shock, do not remove the UPS cover. Qualied Service Personnel must

perform ALL repairs and maintenance. No user serviceable parts inside.

CAUTION! Hazardous live parts inside can be energized by the baery even when the AC input power is discon-

nected.

CAUTION! UPS must be connected to an AC power outlet with fuse or circuit breaker protecon. Do not plug into

Xtreme Power Conversion Corporaon

XVT User’s Manual

Page 4

Uninterrupble Power Supply

an AC wall outlet that is not grounded. If you need to de-energize this equipment, turn o and unplug the UPS.

DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT! Xtreme Power does not sell products for life support

or medical applicaons. DO NOT use these UPS in any circumstances that would aect operaon or safety of any

life support equipment or with any medical applicaons or paent care.

NOTICE! Not for use in a computer room as dened in the Standard for Protecon of Electronics Computer/Data

Processing Equipment.

NOTICE! An acceptable outlet (based upon UPS Specicaons) shall be installed near the equipment and shall be

easily accessible.

Product Descripon

UPS Funconality

The XVT UPS products use Line-Interacve Automac Voltage Regulaon (AVR) UPS technology. Under normal AC

power operaon, the input power ows through the AVR circuit, regulang the incoming AC power to the output

of the UPS and the load connected. If the input power disappears, the Inverter circuit is switched on to provide

output from the baeries contained within the UPS.

Xtreme Power Conversion Corporaon

XVT User’s Manual

Page 5

Uninterrupble Power Supply

Baery/Surge Outlets

Provides baery-powered/surge outlets for the connected equipment, and insures uninterrupble operaon of

your equipment during a power failure.

Power Switch

Can be used as a master on/o switch for equipment connected to the baery-powered outlets.

Power On Indicator

This LED is illuminated when the ulity condion is normal and the UPS outlets are providing power, free of surges

and spikes.

Circuit Breaker

The circuit breaker that provides overload and fault protecon.

USB

Port/protocol that provides communicaon between the UPS and PC Network.

Xtreme Power Conversion Corporaon

XVT User’s Manual

Page 6

Uninterrupble Power Supply

Determining The Power Requirements Of Your Equipment

1. Make sure the total Volt-Amp (VA) requirements of your connected equipment does not exceed the maxi-

mum VA rang for the UPS. The maximum VA rangs are shown in the Specicaons secon of this docu-

ment.

2. Ensure that the equipment plugged into the baery-powered outlets does not exceed the UPS rated ca-

pacity. If UPS rated capacies are exceeded, an overload condion may occur and cause the UPS to shut

down and trip the circuit breaker.

3. If the power requirements of your equipment are listed in values other than Volt-Amps (VA), convert Was

(W) or Amps (A) into VA by doing the calculaons below. Note: The equaon below only calculates the

maximum amount of VA that the equipment can use, not what is typically used by the equipment at any

given me. Users should expect usage requirements to be approximately 60% of the value to esmate

power requirements:

_____ Was (W) x 1.67 = _____ VA or _____ Amps (A) x 120 = _____ VA

Add the totals for all of the equipment and mulply this total by 0.65 to calculate actual power require-

ments.

Note: Many factors can aect the amount of power that your computer system will require. The total load

that you will be placing on the baery-powered outlets should not exceed 85% of the UPS capacity.

Hardware Installaon Guide

1. Your new UPS may be used immediately upon receipt, however, charging the baery for at least 4 hours is

recommended to ensure that the baeries maximum charge capacity is achieved. Charge loss may occur

during shipment and storage. To recharge the baery, plug the power cord into the correct type AC wall

outlet and turn the power switch on. Note: Xtreme Power units will charges the baery with the power

switch in either the on or o posion.

2. With the UPS o and unplugged, connect your computer, monitor, and/or any other externally powered

equipment into the baery power supplied outlets. DO NOT plug a laser printer, copier, space heater,

vacuum, or other large electrical device into the UPS. The power demands of these devices will overload

and possibly damage the UPS.

3. Plug the UPS into a 2 pole, 3 wire grounded receptacle (AC wall outlet) as rated in the Specicaons sec-

on of this document. Make sure the wall outlet is protected by a fuse or circuit breaker and does not

service equipment with large inrush electrical demands (e.g. refrigerator, copier, etc). Note: DO NOT use

extension cords or power or surge strips on the input or the output of the UPS.

4. Depress the power switch to turn the UPS on. The power on LED indicator, and charging LED will illuminate

aer the UPS inial test to indicate the UPS is switched “ON”.

5. If an overload is detected, an audible alarm will sound and the UPS will emit one long beep every 2-4

seconds. To correct this, turn the UPS o and unplug at least one piece of equipment from the baery-

powered outlets. Wait 10 seconds. Make sure the circuit breaker is depressed and then turn the UPS on.

6. Your UPS is equipped with an auto-charge feature. When the UPS is plugged into an AC wall outlet and

there is acceptable AC voltage present, the baery will automacally recharge. Charging is controlled by

rmware to rapidly charge units to 15VDC (600/800VA units) and 29VDC (1200/1500VA units). Aer this

threshold is met, the XVT places a oat charge to maintain baery energy, and the charging light will con-

nue to stay on during this me.

7. To maintain opmal baery charge, leave the UPS plugged into an AC wall outlet with the power switch

turned on at all mes.

8. To store your UPS for an extended period of me, cover and store it with the baery fully charged. Re-

charge the baery every two months to maintain baery life.

Xtreme Power Conversion Corporaon

XVT User’s Manual

Page 7

Uninterrupble Power Supply

Quickstart Soware Installaon Guide For Windows

1. Locate the USB Cable inside the box.

2. Insert one end of the USB Cable into the UPS and the other into a USB port on your computer.

3. Insert the CD into your computers CD drive.

4. UPSilon 2000 will display the installaon menu or you can select ‘run’ from windows start menu and ex-

ecute ‘setup.exe’. UPSilon les will be copied into the directory you appoint.

5. Follow the soware setup prompts.

6. When UPSilon has been launched, the operang system will select the local language for displaying UPSi-

lon.

7. Select ‘UPSilon 2000 for Windows’ for parameter sengs.

8. Click ‘Select UPS’ to monitor local or remote UPS.

9. Select ‘Sengs’ to set ‘Communicaon Type’ and ‘Select Comm Port’. If ‘Communicaon with UPS’ is on

the main screen then you have connected to the UPS.

UPSilon 2000 is a smart UPS monitoring and control soware. UPSilon displays the status of the UPS in digital and

graphic modes, which will enable the user to monitor the UPS.

Xtreme Power Conversion Corporaon

XVT User’s Manual

Page 8

Uninterrupble Power Supply

Funcons

Aer entering UPSilon, a funconal chart displays as below.

Secon 1 is the UPS Dynamic Display Area where relevant informaon regarding the UPS is displayed. Selecon of

dierent display modes is possible, with informaon including input voltage, output voltage, line frequency, bat-

tery capacity, load, temperature, etc.

Secon 2 is the UPS Status Area shows whether the UPS is connected to the computer, if AC power is in normal

range, status of the UPS, and relevant informaon regarding the UPS.

Secon 3 is the Funcon Selecon Area allows conguraon of the parameter values. Aer selecng to monitor

Local UPS, computer shutdown sequence and automac shutdown me parameters can then be programmed.

Xtreme Power Conversion Corporaon

XVT User’s Manual

Page 9

Uninterrupble Power Supply

Replacing The Baery

(QUALIFIED SERVICE PERSONNEL ONLY)

CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the baery. Service the bat-

tery under the supervision of Qualied Service Personnel knowledgeable of baeries and their precauons.

CAUTION! Use only the specied type of baery. See your dealer for replacement baeries.

CAUTION! The baery may present risk of electrical shock. Do not dispose of baeries in a re as it may explode.

Follow all local ordinances regarding proper disposal of baeries.

CAUTION! Do not open or mulate the baeries. Released electrolyte is harmful to skin and eyes and may be toxic.

CAUTION! Although the baery system voltage is only 12VDC and 24VDC, the baery can present a high risk of

short circuit current and electrical shock. The short circuit current capability of the baery is sucient to burn wire

or tools very rapidly, producing molten metal. Observe these precauons when replacing the baery:

1. Remove all watches, rings or other metal objects.

2. Only use tools with insulated handles.

3. Do not lay tools or metal parts on top of baery or any terminals.

4. Wear protecve eye wear (goggles), rubber gloves and boots.

5. Disconnect the charging source before connecng or disconnecng the baery terminals.

6. Determine if the baery is inadvertently grounded. If inadvertently grounded, remove the source of the

ground. Contact with a grounded baery can result in electrical shock! The likelihood of such shock will

be reduced if such grounds are removed during installaon and maintenance (applicable to a UPS and a

remote baery supply not having a grounded circuit).

Denions For Led Indicators

LED 1 (green) LED 2 (yellow) LED 3 (red) Unit Status

ON *OFF On AC Power

OFF OFF FLASH On Baery

*ON *Charge

* * ON

Overheat

Low Baery

Overload Protecon

Short Circuit

Note: * means any situaon

Xtreme Power Conversion Corporaon

XVT User’s Manual

Page 10

Uninterrupble Power Supply

Alarms

Alarm Indicaon Unit Status

Buzzer every 5 sec DC start

Buzzer every 1 sec Self test

2 buzzer every 1 sec Low baery

4 beep every 2.4 sec Overload

3 buzzer every 1 sec Overheat

Input is o, long beep, power o aer 5 sec Short circuit

Autres manuels pour XVT 600VA

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Xtreme Power Conversion UPS

Xtreme Power Conversion

Xtreme Power Conversion P91c-1000 Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion M90U Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion XVT Series Manuel d'utilisation

Xtreme Power Conversion

Xtreme Power Conversion Pure Sine Wave Series Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion TX90-1000 Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion E90 Series Manuel utilisateur

Xtreme Power Conversion

Xtreme Power Conversion P90 1000VA Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion NXRi-6KL Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion P80 Manuel utilisateur

Xtreme Power Conversion

Xtreme Power Conversion M90S Series Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion XVT?600 Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion 700VA Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion S70 Line?Interactive Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion P90-BP36 Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion M90 Manuel utilisateur

Xtreme Power Conversion

Xtreme Power Conversion P91g Series Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion P90g Series Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion Network Xtreme Rack/Tower Series Manuel d'utilisation

Xtreme Power Conversion

Xtreme Power Conversion A60 Standby Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion XST?400 Manuel utilisateur

Xtreme Power Conversion

Xtreme Power Conversion XPRT-6kVA Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion XVT 600VA Manuel utilisateur

Xtreme Power Conversion

Xtreme Power Conversion 800VA P80 Series Mode d’emploi

Xtreme Power Conversion

Xtreme Power Conversion 20kVA Model Manuel d'utilisation

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
