Wolf 24 E Series Manuel utilisateur

24" E Series Oven

Installation Guide

SPECIFICATIONS, INSTALLATION,

AND MORE

2 | Wolf Customer Care 800.222.7820

Contents

324" E Series Oven

4Speciﬁcations

7Installation

9Troubleshooting

Features and speciﬁcations are subject to change at any

time without notice. Visit wolfappliance.com/specs for the

most up-to-date information.

24" E Series Oven

Important Note

To ensure this product is installed and operated as safely

and eciently as possible, take note of the following types

of highlighted information throughout this guide:

IMPORTANT NOTE highlights information that is especially

important.

CAUTION

Indicates a situation where minor injury or product

damage may occur if instructions are not followed.

WARNING

States a hazard that may cause serious injury or

death if precautions are not followed.

IMPORTANT NOTE: Throughout this guide, dimensions in

parentheses are millimeters unless otherwise speciﬁed.

IMPORTANT NOTE: Save these instructions for the local

electrical inspector.

wolfappliance.com | 3

Product Information

Important product information, including the model and

serial number, are listed on the product rating plate. The

rating plate is located on the left side of the front face

frame. The oven door must be open to view the rating

plate. Refer to the illustration below.

If service is necessary, contact Wolf Factory Certiﬁed

Service with the model and serial number. For the name of

the nearest Wolf Factory Certiﬁed Service or for questions

regarding the installation, visit the Product Support section

of our website, wolfappliance.com, or call Wolf Customer

Care at 800-222-7820.

24" E Series Oven

Rating plate location

RATING PLATE

4 | Wolf Customer Care 800.222.7820

Electrical Requirements

Installation must comply with all applicable electrical codes.

For ease of installation, the electrical supply for the oven

should be placed in an adjacent cabinet within reach of the

conduit.

Performance may be compromised if the electrical supply

is less than 240 volts.

The oven is supplied with a conduit consisting of two hot

lead conductors and a ground conductor. The wiring dia-

gram covering the control circuit is provided with the oven.

ELECTRICAL REQUIREMENTS

Electrical Supply grounded, 240/208 VAC, 60 Hz

Service 20 amp dedicated circuit

Conduit 4' (1.2 m)

Total Amps 16

Max Connected Load 3.6 kW

Specifications

Installation Requirements

The oven can be installed in a standard or ﬂush inset

application.

Finish the edges of the opening. They may be visible when

the door is open.

For standard installations, the face trim overlaps stiles and

rails. Refer to the chart.

For ﬂush inset installations, a minimum ⁄" (3) reveal is

required on all sides. To ensure consistent reveals, each

corner of the opening must be exactly 90°.

INSTALLATION REQUIREMENTS

Minimum Base Support 150 lb (68 kg)

TRIM OVERLAP

Top ⁄" (3)

Bottom 0" (0)

Sides ⁄" (22)

Rating plate location

RATING PLATE

wolfappliance.com | 5

Specifications

24" E Series Oven

STANDARD INSTALLATION

FRONT VIEW

SIDE VIE

233/8"

(594)

OPENING

HEIGHT

23" (584)

OPENING

DEPTH

TOP VIEW

221/8" (562)

OPENING WIDTH

NOTE: Location of electrical supply within opening may require additional cabinet depth.

6 | Wolf Customer Care 800.222.7820

233/4" (603)

FLUSH INSET WIDTH**

FRONT VIEW

SIDE VIE

24" (610)

FLUSH

INSET

DEPTH

7/8" (22)

233/4" (603)

FLUSH INSET

HEIGHT**

1/4" (6)

1/8" (3)

TOP VIEW

13/16" (21)

FINISHED

CLEATS*

ill be visible and should be finished to match cabinetry.

Dimension provides minimum reveals.

NOTE: Location of electrical supply within opening may require additional cabinet depth.

24" E Series Oven

FLUSH INSET INSTALLATION

Specifications

wolfappliance.com | 7

OVEN DOOR REMOVAL

To remove, open the oven door completely. Rotate both

hinge latches forward to the open position. Close the door

to approximately 30° open, then lift up and out. Refer to

the illustrations below.

To reinstall, insert door hinges into the frame openings.

Open the oven door completely and rotate both hinge

latches back to the closed position.

Installation

Preparation

Before moving the oven, protect any ﬁnished ﬂooring and

secure the oven door(s) closed to prevent damage.

Use an appliance dolly to move the unit near the opening.

Remove and recycle packing materials. Do not lift or carry

the oven by the door handle.

CAUTION

Do not lift the oven by the door handle. This will

damage the oven door and hinges.

CLOSED

POSITION

Oven door hinge latch

Door open 30°

8 | Wolf Customer Care 800.222.7820

Installation

Place the oven in the opening and slide back.

Locate the mounting holes on the oven side trim, two on

each side. Drill ⁄" pilot holes. Use the provided mounting

screws to secure the oven to the cabinetry. Refer to the

illustration below.

To avoid interference, a 90° door stop may be required for

any appliance or cabinet door installed next to the oven.

CAUTION

Failure to install the mounting screws may cause the

oven to tip forward during use.

MOUNTING

HOLES

Oven installation

Installation

Electrical Connection

WARNING

Verify power is disconnected from the electrical box

before proceeding.

If the electrical supply is located in the opening, the elec-

trical connection must be made prior to placing the oven

in the opening. If the electrical supply is in an adjacent

cabinet, the electrical connection can be made after plac-

ing the oven in the opening.

1 Connect the black appliance wire to the black (L1)

power supply.

2 Connect the red appliance wire to the red (L2) power

supply.

3 Connect the green appliance wire to the green/ground

wire.

wolfappliance.com | 9

Troubleshooting

IMPORTANT NOTE: If the oven does not operate properly,

follow these troubleshooting steps:

• Verify electrical power is supplied to the oven.

• Verify proper electrical connections.

• If the oven does not operate properly, contact Wolf

Factory Certiﬁed Service. Do not attempt to repair the

oven. Wolf is not responsible for service required to

correct a faulty installation.

Sub-Zero, Sub-Zero & Design, Sub-Zero & Snowﬂake Design, Dual Refrigeration, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, Wolf, Wolf &

Design, Wolf Gourmet, W & Design, red colored knobs, Cove, and Cove & Design are registered trademarks and service marks of Sub-Zero Group, Inc. and its subsidiaries.

All other trademarks are property of their respective owners in the United States and other countries.

Troubleshooting

2 | Atención al cliente de Wolf 800.222.7820

Contenido

3Horno de la serie E de 24"

4Especiﬁcaciones

7Instalación

9Solución de problemas

Las características y especiﬁcaciones están sujetas a

cambios sin previo aviso. Visite wolfappliance.com/specs

para obtener la información más actualizada.

Horno de la serie E de 24"

Aviso importante

Para garantizar que este producto se instale y opere de

la forma más segura y eﬁciente posible, tome nota de los

siguientes tipos de información resaltada en este manual:

AVISO IMPORTANTE señala la información que es

especialmente importante.

PRECAUCIÓN

Indica una situación en la que se pueden sufrir

heridas leves o provocar daños al producto si no se

siguen las instrucciones.

ADVERTENCIA

Indica peligro de que se produzcan heridas graves o

incluso la muerte si no se siguen las precauciones.

AVISO IMPORTANTE: En toda esta guía, las dimensiones

entre paréntesis son milímetros, a menos que se

especiﬁque lo contrario.

AVISO IMPORTANTE: Guarde estas instrucciones para el

inspector eléctrico local.
