Windsor CB20 Caractéristiques techniques

MODELS: CB20

10020080

CBE20

10020100

iGLOSS

Operating Instructions (ENG)

Read these instructions before using the machine.

86037750 12/06/10

PRV 980259

PRIOR TO SERIAL #10020080000118

MACHINE DATA LOG/OVERVIEW

86037750 CHARIOT BURNISHER 01/17/07

OVERVIEW

The Chariot burnisher is a battery powered, ride-on, hard floor burnisher intended for commercial

use. The appliance applies a high luster to hard floor surfaces.

MODEL _______________________________________

DATE OF PURCHASE __________________________

SERIAL NUMBER ______________________________

SALES REPRESENTATIVE # _____________________

YOUR DEALER

Name: __________________________________________________________________________________________________

Address: _______________________________________________________________________________________________

Phone Number: _________________________________________________________________________________________

TABLE OF CONTENTS

86037750 CHARIOT BURNISHER 01/17/07 3

Machine Data Log/Overview................................2

Table Of Contents................................................3

HOW TO USE THIS MANUAL

How To Use This Manual.....................................1-1

SAFETY

Important Safety Instructions ............................ 2-1

Hazard Intensity Level.......................................2-2

Safety Label Location........................................ 2-3

OPERATIONS

Technical Specifications.................................... 3-1

How The Machine Works..................................3-3

Components......................................................3-4

Drive Controls ...................................................3-5

Burnsiher Controls ............................................3-9

Machine Operation............................................3-11

Pre-Run Machine Inspection........................3-11

Starting Machine .......................................... 3-11

Operating The Machine................................ 3-11

Emergency Stop Procedures.......................3-11

To Begin Burnishing.....................................3-12

MAINTENANCE

Service Schedule ......................................... 4-1

Batteries....................................................... 4-2

Dust Bag Replacement ................................4-7

Pad Installation............................................. 4-7

Pad Driver Replacement.............................. 4-8

Shunt Adjustment......................................... 4-10

Drive Motor & Brake..................................... 4-11

Circuit Protection.......................................... 4-14

Troubleshooting............................................ 4-15

GROUP PARTS LIST

Bumper..............................................................5-1

Control Panel.....................................................5-3

Controls & Housing ...........................................5-5

Decal .................................................................5-7

Filter...................................................................5-9

Frame-Lower.....................................................5-11

Frame-Upper.....................................................5-13

Hood..................................................................5-15

Pedal Platform...................................................5-17

Rear Cover........................................................5-21

Deck Lift Mechanism.........................................5-23

Deck Lift Linkage...............................................5-25

Steering.............................................................5-27

Wheel-Front Drive.............................................5-29

Wheel-Front Brake............................................5-31

Wheel-Rear.......................................................5-33

Wiring-Batteries.................................................5-35

Wiring-Components...........................................5-37

Wiring-Control Panel.........................................5-39

Wiring-Drive Motor ............................................5-41

Wiring-Main Harness.........................................5-43

Wiring-Pedal Platform .......................................5-45

Wiring Diagram..................................................5-47

Suggested Spare Parts.....................................5-48

Back-Up Alarm – Option....................................5-49

Battery Cart – Option.........................................5-51

Seat – Option ....................................................5-55

Warning Light – Option......................................5-57

EC Declaration..................................................5-59

Warranty............................................................5-60

86037750 CHARIOT BURNISHER 01/17/07

BURNISHER

PARTS

BUMPER

86037750 CHARIOT BURNISHER 01/17/07

5-1

10 11

BUMPER

86037750 CHARIOT BURNISHER 01/17/07 5-2

REF PART NO. PRV NO. QTY DESCRIPTION SERIAL NO.

FROM NOTES:

1 86276890 70752 6 SCR, 5/16-18X3/4 PTHMS SS

2 86007070 70849 2 SCR, #12 X 1.25 PPHMS SS

3 86063230 140813 1 BUMPER, LEFT

4 86063240 140814 1 BUMPER, RIGHT

5 86071020 140783 1 BRKT, FRONT BUMPER

6 86270830 57023 4 NUT, 5/16-18 HEX NYLOCK SS

7 86010670 87029 4 WASHER, 5/16 FLAT SS

8 86070730 140729 2 BRKT, BUMPER MOUNT, SIDE

9 86197040 57264 4 NUT, 5/16-18 HEX ACORN PLTD

10 86279130 87083 4 WASHER, 5/16 SPLIT LOCK

11 86251750 67602 2 RISER, BUMPER

CONTROL PANEL

86037750 CHARIOT BURNISHER 08/14/07

5-3

28 24

29 21

41 46

43 44

CONTROL PANEL

86037750 CHARIOT BURNISHER 09/06/07 5-4

REF PART NO. PRV NO. QTY DESCRIPTION SERIAL NO.

FROM NOTES:

1 86273820 70019 2 SCR, 1/4-20 X 1.25 HHCS

2 86273830 70020 2 SCR, 1/4-20 X 1/2 HHCS SS

3 86010780 87162 2 WASHER, 1/4 SPLIT LOCK

4 86274380 70192 2 SCR, M5 X 15 PPHMS PLTD

5 86277480 70850 3 SCR, 5/16-18 X 1/2 PTHMS SS

6 86070670 140722 1 BRKT, BATTERY CONNECTOR

7 86008760 80682 1 CONN, 175 DCA GRY W/O TERMS

8 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS

9 86255910 73659 2 STANDOFF, 1/4-20 X 1.0 HEX INS

10 86006850 70393 2 SET SCR, 1/4-20 X 1.25L

11 86237000 80688 1 FUSE, 80 AMP

12 86010630 87013 6 WASHER, 1/4 ID X 5/8 OD SS

13 86008920 80889 2 BOOT, RUBBER TERM. ISOLATOR

14 86007180 72160 1 SWITCH, EMERGENCY STOP

15 86270830 57023 3 NUT, 5/16-18 HEX NYLOCK SS

16 86005710 57105 4 NUT, 1/4-20 HEX W/STAR WASHER

17 86255900 73538 8 STANOFF, 6-32 X 5/8 HEX NYL

18 86223740 70872 2 SCR, 1/4-20 X .59 PPHMS SS C

19 86257140 72196 1 SWITCH ASM, SEALED PB RND GRN

20 86007190 72161 1 SWITCH KEY DPST

21 86007140 72130 1 SWITCH, SPST 2-POSITION ROCKER

22 86257110 72189 1 SWITCH, 4P3T FIXED POS ROCKER

23 86257280 81371 1 SWITCH, PUSH BUTTON

24 86005560 54199 1 METER, 36V LED BATTERY

25 86008900 80845 1 BOOT, SEAL-PUSH BUTTON 7/16-28

26 86002010 14942 1 BOOT, 3/8 CIRCUIT BREAKER

27 86273980 70066 2 SCR, 10-32 X 3/4 PPHMS

28 86246980 54201 1 METER, 0-50 AMP DC

29 86007130 72128 1 SWITCH, DPDT 2-POSITION ROCKER

30 86251410 67506 1 RELAY, 15A 36V MINI

31 86226560 36082 1 GROMMET, 1/2 ID X 3/32 GROOVE

32 86249290 62283 1 PLATE, METER RETAINING

33 86237830 35264 1 GASKET, AMP METER

34 86002760 270092 1 CONTROLLER, CHAIN DRIVE BASIC

35 86005700 57104 3 NUT, 10-32 W/STAR WASHER PLTD

36 86006370 67315 1 RELAY, 36VDC 100AMP HVY DUTY

37 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS

38 86279130 87083 2 WASHER, 5/16 SPLIT LOCK PLTD

39 86010670 87029 2 WASHER, 5/16 FLAT SS

40 86271120 57125 2 NUT, 5/16-18 BRASS

41 86002000 14717 1 BREAKER, 3 AMP

42 86229770 140805 1 BLOCK, SHUNT MOUNT

43 86279300 87134 4 WASHER, #6 LOCK

44 86273990 70067 4 SCR, 6-32 X 3/8 PPHMS

45 86005530 54154 1 METER, 12-48 VDC LED HOUR

46 86001910 14606 1 BREAKER, 30A 50VDC CIRCUIT

47 86078170 61479 1 PANEL, BURNISHER

48 86246920 54131 1 METER, 0-70 AMP DC 1000149060

49 86246930 54144 1 METER, 36V BATTERY CHARGE LEVEL 1000155520

CONTROLS & HOUSING

86037750 CHARIOT BURNISHER 12/06/10

5-5

DETAIL 'A'

SEE DETAIL 'A'

13*

425

CONTROLS & HOUSING

86037750 CHARIOT BURNISHER 12/06/10 5-6

REF PART NO. PRV NO. QTY DESCRIPTION SERIAL NO.

FROM NOTES:

1 86290540 - 6 SCR, 10-32 X 1/2 TORX SS BLK NP

2 86277480 70850 2 SCR, 5/16-18 X 1/2 PTHMS SS

3 86237900 35278 3 GASKET, .125 T X .25 W X 23.L

4 86010670 87029 4 WASHER, 5/16 FLAT SS

5 86070710 140726 1 BRKT, LEFT CONSOLE MOUNT

6 86274710 70261 2 SCR, 6.32 X 1.00 PPHMS

7 86223740 70872 2 SCR, 1/4-20 X .59 PPHMS SS C

8 86006530 70057 4 SCR, 1/4-20 X 1 PPHMS SS

9 86006370 67315 1 RELAY, 36VDC 100AMP HVY DUTY

10 86005810 57245 10 NUT, 1/4-20 HEX NYLOCK SS

11 86273300 00-000277 5 SCR, MACH 6MM X 14MM

12 86010780 87162 5 WASHER, 1/4 SPLIT LOCK PLTD

13 86286430 270106 1 CONTROLLER, PAD MOTOR *

14 86270990 57090 4 NUT, 10-32 HEX NYLOCK SS

15 86229770 140805 1 BLOCK, SHUNT MOUNT

16 86255900 73538 2 STANDOFF, 6-32 X 5/8 HEX NYL

17 86251410 67506 1 RELAY, 15A 36V MINI

18 86279750 87252 4 WASHER, RET, PUSHNUT, 5/16 BOLT

19 86089650 78524 4 TUBE, 5/8 OD X .357 ID X 1.57

20 86273980 70066 2 SCR, 10-32 X 3/4 PPHMS

21 86070700 140725 1 BRKT, RIGHT CONSOLE MOUNT

22 86005710 57105 2 NUT, 1/4-20 HEX W/STAR WASHER

23 86253600 73445 1 SHUNT, 50MV 70AMP

24 86277420 70841 4 SCR, 5/16-18 X 2.5 PTHMS SS

25 86062220 270117 1 CONSOLE

* P/N 98409370, KIT, IGLOSS 20 MOTOR RETRO FIT (CONTACT WINDSOR TECHNICAL SUPPORT FOR

DETAILS.)
