Windsor 10080480 Manuel utilisateur

Operating Instructions (ENG)

Carpet Extractor

Model: 10080480

86302100-J

10/17/08

MACHINE DATA LOG/OVERVIEW

86302100 CLIPPER DUO 10/02/07

OVERVIEW

This carpet extractor is an electrical powered, portable carpet extractor intended for

commercial use. The appliance sprays a cleaning solution onto the carpet agitates the wet

carpet, and then extracts the soiled solution back into the unit’s recovery tank. The appliance

is fitted with and a hand tool for cleaning upholstery and stairs.

Model:

Date of Purchase:

Serial Number:

Sales Representative:

Address:

Phone Number:

TABLE OF CONTENTS

86302100 CLIPPER DUO 10/17/08 3

Machine Data Log/Overview................................2

Table Of Contents................................................3

HOW TO USE THIS MANUAL

How To Use This Manual.....................................1-1

SAFETY

Important Safety Instructions ............................ 2-1

Hazard Intensity Level....................................... 2-2

Grounding Instructions......................................2-3

Safety Label Location........................................ 2-4

OPERATIONS

Technical Specifications.................................... 3-1

How The Machine Works..................................3-3

Components......................................................3-4

Controls............................................................. 3-5

Filling Solution Tank..........................................3-6

Pre-run Setup.................................................... 3-7

Operating the Machine...................................... 3-9

Using the Hand Tool .........................................3-12

MAINTENANCE

Service Schedule..............................................4-1

Maintenance Components................................ 4-2

Periodic, Daily & Regular Maintenance ........... 4-3

Circuit Protection............................................... 4-4

Scrub Deck........................................................4-5

Scrub Brushes...................................................4-6

Vacuum............................................................. 4-7

Machine Troubleshooting.................................. 4-8

PARTS LIST & SERIAL NUMBERS

Brush Deck........................................................5-1

Brush Deck Motor..............................................5-3

Brush Deck Mounting........................................5-5

Control Panel.....................................................5-7

Decal .................................................................5-9

Hand Tool..........................................................5-11

Handle...............................................................5-13

Handle Bracket..................................................5-15

Handle Mounting...............................................5-17

Handle Release Lever.......................................5-19

Recovery Tank ..................................................5-21

Solution..............................................................5-23

Solution Tank ....................................................5-25

Vac Shoe...........................................................5-29

Vac Shoe Mounting...........................................5-31

Vacuum.............................................................5-33

Wheel & Axle.....................................................5-35

Wiring Diagram..................................................5-37

Suggested Spare Parts.....................................5-39

Serial Numbers..................................................5-40

Warranty

HOW TO USE THIS MANUAL

86302100 CLIPPER DUO 06/06/08

1-1

This manual contains the following sections:

- HOW TO USE THIS MANUAL

- SAFETY

- OPERATIONS

- MAINTENANCE

- PARTS LIST

The HOW TO USE THIS MANUAL section will tell

you how to find important information for ordering

correct repair parts.

Parts may be ordered from authorized dealers.

When placing an order for parts, the machine model

and machine serial number are important. Refer to

the MACHINE DATA box which is filled out during

the installation of your machine. The MACHINE

DATA box is located on the inside of the front cover

of this manual.

The model and serial number of your machine are

located where shown.

The SAFETY section contains important information

regarding hazardous or unsafe practices of the

machine. Levels of hazards are identified that could

result in product damage, personal injury, or severe

injury resulting in death.

The OPERATIONS section is to familiarize the

operator with the operation and function of the

machine.

The MAINTENANCE section contains preventive

maintenance to keep the machine and its

components in good working condition. They are

listed in this general order:

- Periodic

- Daily/Regular

- Troubleshooting

The PARTS LIST section contains assembled parts

illustrations and corresponding parts list. The parts

lists include a number of columns of information:

- REF – column refers to the reference

number on the parts illustration.

- PART NO. – column lists the part

number for the part.

- PRV NO. – Reference number.

- QTY – column lists the quantity of the

part used in that area of the machine.

- DESCRIPTION – column is a brief

description of the part.

- SERIAL NO. FROM – If this column has

an (*) and a Reference number, see the

SERIAL NUMBERS page in the back of

your manual. If column has two asterisk

(**), call manufacturer for serial number.

The serial number indicates the first

machine the part number is applicable

to. The main illustration shows the most

current design of the machine. When a

boxed illustration is shown, it displays

the older design.

- NOTES – column for information not

noted by the other columns.

NOTE: If a service or option kit is installed on your

machine, be sure to keep the KIT INSTRUCTIONS

which came with the kit. It contains replacement

parts numbers needed for ordering future parts.

NOTE: The manual part number is located on the

lower left corner of the front cover.

MODEL _____________________________________

DATE OF PURCHASE ________________________

SERIAL NUMBER ____________________________

SALES REPRESENTATIVE # ___________________

SAFETY

86302100 CLIPPER DUO 10/02/07 2-1

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precaution

must always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.

This machine is for commercial use.

To reduce the risk of fire, electric shock, or injury:

Connect to a properly grounded outlet. See Grounding Instructions.

Do not leave the machine unattended. Unplug machine from outlet when not in use and before maintenance or

service.

Use only indoors. Do not use outdoors or expose to rain.

Do not allow machine to be used as a toy. Close attention is necessary when used by or near children.

Use only as described in this manual. Use only manufacturer’s recommended components and attachments.

Do not use damaged electrical cord or plug. Follow all instructions in this manual concerning grounding the

machine. If the machine is not working properly, has been dropped, damaged, left outdoors, or dropped into

water, return it to an authorized service center.

Do not pull or carry machine by electrical cord, use as a handle, close a door on cord, or pull cord around sharp

edges or corners.

Do not run machine over cord. Keep cord away from heated surfaces.

Do not unplug machine by pulling on cord. To unplug, grasp the electrical plug, not the electrical cord.

Do not handle the electrical plug or machine with wet hands.

Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce airflow.

This machine is intended for cleaning carpet only.

Do not vacuum anything that is burning or smoking, such as cigarettes, matches, or hot ashes.

This machine is not suitable for picking up health endangering dust.

Turn off all controls before unplugging.

Machine can cause a fire when operating near flammable vapors or materials. Do not operate this machine near

flammable fluids, dust or vapors.

This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops

and offices for more than normal housekeeping purposes.

Maintenance and repairs must be done by qualified personnel.

If foam or liquid comes out of machine, switch off immediately.

SAVE THESE INSTRUCTIONS

SAFETY

86302100 CLIPPER DUO 10/02/07

2-2

The following symbols are used throughout this guide as indicated in their descriptions:

HAZARD INTENSITY LEVEL

There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR

SAFETY. The level of hazard intensity is determined by the following definitions:

WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.

CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or property

damage.

FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.

Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper operating

condition. Following is information that signals some potentially dangerous conditions to the operator or the

equipment. Read this information carefully. Know when these conditions can exist. Locate all safety devices on

the machine. Please take the necessary steps to train the machine operating personnel.

FOR SAFETY:

DO NOT OPERATE MACHINE:

Unless Trained and Authorized.

Unless Operation Guide is Read and understood.

In Flammable or Explosive areas.

In areas with possible falling objects.

WHEN SERVICING MACHINE:

Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use

Windsor approved replacement parts.

SAFETY

86302100 CLIPPER DUO 10/02/07 2-3

GROUNDING INSTRUCTIONS

THIS PRODUCT IS FOR COMMERCIAL

USE ONLY.

ELECTRICAL:

In the USA this machine operates on a standard 15

amp 120V, 60 hz, A.C. power circuit. The amp,

hertz, and voltage are listed on the data label found

on each machine. Using voltages above or below

those indicated on the data label will cause serious

damage to the motors.

EXTENSION CORDS:

If an extension cord is used, the wire size must be at

least one size larger than the power cord on the

machine, and must be limited to 50 feet (15.5m) in

length.

GROUNDING INSTRUCTIONS:

This appliance must be grounded. If it should

malfunction or break down, grounding provides a

path of least resistance for electric current to reduce

the risk of electric shock. This appliance is equipped

with a cord having an equipment-grounding

conductor and grounding plug. The plug must be

inserted into an appropriate outlet that is properly

installed and grounded in accordance with all local

codes and ordinances.

120 VOLT MODELS:

This appliance is for use on a nominal 120-volt

circuit, and has a grounded plug that looks like the

plug in “Fig. A”. A temporary adaptor that looks like

the adaptor in “Fig. C” may be used to connect this

plug to a 2-pole receptacle as shown in “Fig. B”, if a

properly grounded outlet is not available. The

temporary adaptor should be used only until a

properly grounded outlet (Fig. A) can be installed by

a qualified electrician. The green colored rigid ear,

lug, or wire extending from the adaptor must be

connected to a permanent ground such as a

properly grounded outlet box cover. Whenever the

adaptor is used, it must be held in place by a metal

screw.

Improper connection of the equipment-

grounding conductor can result in a risk of

electric shock. Check with a qualified electrician

or service person if you are in doubt as to

whether the outlet is properly grounded. Do not

modify the plug provided with the appliance - if it

will not fit the outlet, have a proper outlet

installed by a qualified electrician.

GROUNDING

GROUNDED

OUTLET ADAPTER

METAL SCREW TAB FOR

GROUNDING SCREW

GROUNDED

OUTLET BOX

(A) (B) (C)

SAFETY

86302100 CLIPPER DUO 06/06/08

2-4

SAFETY LABEL LOCATION

NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels become

illegible, promptly replace them.

PRV NO 500009

PART NUMBER 86242230

WARNING LABEL

PART NUMBER 86310500

EXPLOSION FRENCH

OPERATIONS

86302100CLIPPER DUO 10/02/07 3-1

TECHNICAL SPECIFICATIONS

ITEM DIMENSION/CAPACITY

Construction Steel chassis with rotationally molded polyethylene tanks

Vacuum Motor Three stage, bypass, 1.5 hp (1,119 watts), 100 cfm

(2.8m³/min), 120” (3050 mm) waterlift

Solution Pump 100 psi (7 bar) – Restorative

50 psi (3.5 bar) - Interim

Brush Motor 1/2 hp (604 watts) AC with circuit breaker protection

Brushes 2 x 16” (406 mm), ABS core, Perform Alert™ bristle spiral

pattern

Cleaning Path 16” (40.6 cm)

Cleaning Rate Interim – 10,560 ft²/hr (981 m²/hr)

Restorative – 3,520 ft²/hr (327 m²/hr)

Flow Rate Interim - 0.09 gpm ( 0.37 lpm)

Restorative – 1.0 gpm (37.8 lpm)

Solution Spray Interim – One quick-disconnect jet

Restorative - One quick-disconnect jet

Solution Tanks 10 gallons ( 37.8 l)

Recovery Tank 10 gallons (37.8 l)

Vacuum Shoe 18” (458 mm) wide, cast aluminum

Wheels 10” (254 mm) non-marking rubber

Power Cable 50’ (15 m) detachable

Weight 166 lbs (75.3 kg) with cord

OPERATIONS

8630210 CLIPPER DUO 05/08/08

3-2

WIDTH

HEIGHT

LENGTH

TECHNICAL SPECIFICATIONS

ITEM MEASURE

Height 43 inches (1092 mm)

Length 40.5 inches (1029 mm)

Width 22 inches (559 mm)

Width of scrub path 16 inches (406 mm)

The sound pressure level at the operator’s ear was

measured to be 73.7 dBA. This was a nearfield, broad-band

measurement taken in a typical industrial environment on a

tile floor. This appliance contains no possible source of

impact noise. The instantaneous sound pressure level is

below 63 Pa.

The weighted root mean square acceleration at the

operator’s arms was measured to be below 2.5m/s2 . This

was a tri-axial, third-octave-band measurement made during

normal operation on a composite tile floor. The

measurement and related calculations were made in

accordance with ISO 5349-1.

SPECIAL NOTES:

This appliance is not intended for use by persons

(including children) with reduced physical, sensory or

mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety. Children should

be supervised to ensure that they do not play with

appliance.

Autres manuels pour 10080480

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Windsor Machine de plancher

Windsor

Windsor CLP12 Manuel utilisateur

Windsor

Windsor COMMODORE CMD Manuel utilisateur

Windsor

Windsor Commodore 20 CMD20 Manuel utilisateur

Windsor

Windsor Saber Compact 16SP Manuel utilisateur

Windsor

Windsor Dominator NWWU2250H Caractéristiques techniques

Windsor

Windsor SABER S28 Manuel utilisateur

Windsor

Windsor COMDU Caractéristiques techniques

Windsor

Windsor Chariot 2 iGloss 20 Manuel utilisateur

Windsor

Windsor CE26 Manuel utilisateur

Windsor

Windsor BDP 51/2000C Manuel utilisateur

Windsor

Windsor Trident Compact TC17 Manuel utilisateur

Windsor

Windsor Ensign E50 Manuel utilisateur

Windsor

Windsor Escort ECS Manuel utilisateur

Windsor

Windsor COMPASS CMPS 10070050 Manuel utilisateur

Windsor

Windsor Chariot 2 CBPS20 Manuel utilisateur

Windsor

Windsor Dominator 10070090 Manuel utilisateur

Windsor

Windsor MB2000 Caractéristiques techniques

Windsor

Windsor NMWU225H Caractéristiques techniques

Windsor

Windsor CDT7IB/10080060 Manuel utilisateur

Windsor

Windsor 10020430 Manuel utilisateur

Windsor

Windsor Dominator NMWU2215N Caractéristiques techniques

Windsor

Windsor SCENX326 10052340 Manuel utilisateur

Windsor

Windsor Cadet 7 Manuel utilisateur

Windsor

Windsor EXPERT Manuel utilisateur

Manuels Machine de plancher populaires d'autres marques

Nilfisk-Advance

Nilfisk-Advance Advance SC370 17B Manuel utilisateur

Numatic

Numatic ET 4045 Manuel utilisateur

HAWK ENTERPRISES

HAWK ENTERPRISES HP1513-180BRUTE Manuel utilisateur

Mytee

Mytee 8070 Mytee-Lite Manuel utilisateur

Kärcher

Kärcher B 140 R Manuel utilisateur

Triple S

Triple S Ace 26T1 Manuel utilisateur

Nilfisk-Advance

Nilfisk-Advance SW 750 Manuel utilisateur

Tornado

Tornado Marathon 2000 98190 Manuel

Numatic

Numatic TTB 1117/100 Manuel utilisateur

Tennant

Tennant 8210D Manuel utilisateur

Nobles

Nobles Frontier Manuel du produit

lavina

lavina 21-X Manuel utilisateur

KENT

KENT Edge 28B Manuel utilisateur

Tennant

Tennant 215 Manuel du produit

CleanFreak

CleanFreak DURA-18HD Manuel utilisateur

Nilfisk-Advance

Nilfisk-Advance Warrior 34RST Guide de l'administrateur

BETCO

BETCO PB24 Manuel utilisateur

IPC

IPC CT51-71 BT Manuel utilisateur
