Windsor 10080220 Manuel utilisateur

Read these instructions before operating the machine

MODEL: CDT7

10080220

Operating Instructions

86038220 09/27/07

PRV NO. 98626

CARPET EXTRACTOR

MACHINE DATA LOG/OVERVIEW

CADET 86038220 03/16/07

MODEL _______________________________________

DATE OF PURCHASE __________________________

SERIAL NUMBER ______________________________

SALES REPRESENTATIVE # _____________________

DEALER NAME ________________________________

OPERATIONS GUIDE NUMBER ___________________

PUBLISHED __________________________________________

For the name and address of your dealer contact: Windsor Industries

YOUR DEALER

Name: __________________________________________________________________________________________________

Address: _______________________________________________________________________________________________

Phone Number: _________________________________________________________________________________________

TABLE OF CONTENTS

CADET 86038220 03/16/07

Machine Data Log/Overview.........................1

Table of Contents..........................................2

HOW TO USE THIS MANUAL

How to use this Manual.................................1-1

SAFETY

Important Safety Instructions........................2-1

Hazard Intensity Level ..................................2-2

Grounding Instructions..................................2-3

OPERATIONS

Technical Specifications. ..............................3-1

Controls/Component Location ......................3-2

Filling Operation............................................3-5

Operations. ...................................................3-6

Cleaning Procedure......................................3-8

Accessory Tool Usage................................3-10

MAINTENANCE

Service Schedule..............................……… 4-1

Periodic Maintenance. ..................................4-2

Daily/ Regular Maintenance..........................4-2

Vacuum Motor Replacement ........................4-3

Belt Replacement..........................................4-4

Solution Pump Replacement ............……… 4-5

Wiring Diagram.............................................4-6

Troubleshooting Chart ..................................4-7

GROUP PARTS LIST

Frame Assembly.........................................5-1

Brush Assembly..........................................5-3

Pump Assembly(prior to SN). .....................5-5

Pump Assembly..........................................5-7

Vacuum Shoe Assembly.............................5-9

Control Panel Assembly..............................5-11

Solution Tank Assembly. ............................5-13

Recovery Tank Assembly...........................5-15

Suggested Spare Parts/Notes ....................5-17

HOW TO USE THIS MANUAL

CADET 86038220 03/16/07

This manual contains the following sections:

- HOW TO USE THIS MANUAL

- SAFETY

- OPERATIONS

- MAINTENANCE

- PARTS LIST

The HOW TO USE THIS MANUAL section will tell

you how to find important information for ordering

correct repair parts.

Parts may be ordered from authorized dealers.

When placing an order for parts, the machine model

and machine serial number are important. Refer to

the MACHINE DATA box which is filled out during

the installation of your machine. The MACHINE

DATA box is located on the inside of the front cover

of this manual.

1-1

The model and serial number of your machine is on

the bottom back-end of the machine.

The SAFETY section contains important information

regarding hazard or unsafe practices of the

machine. Levels of hazards is identified that could

result in product or personal injury, or severe injury

resulting in death.

The OPERATIONS section is to familiarize the

operator with the operation and function of the

machine.

The MAINTENANCE section contains preventive

maintenance to keep the machine and its

components in good working condition. They are

listed in this general order:

- Periodic

- Daily/Regular

- Troubleshooting

The PARTS LIST section contains assembled parts

illustrations and corresponding parts list. The parts

lists include a number of columns of information:

MODEL _____________________________________

DATE OF PURCHASE ________________________

SERIAL NUMBER ____________________________

SALES REPRESENTATIVE # ___________________

DEALER NAME ______________________________

OPERATIONS GUIDE NUMBER __________________

- REF – column refers to the reference

number on the parts illustration.

- PART NO. – column lists the part

number for the part.

- PRV NO. - reference number.

- QTY – column lists the quantity of the

part used in that area of the machine.

- DESCRIPTION – column is a brief

description of the part.

- SERIAL NO. FROM – column indicates

the first machine the part number is

applicable to. When the machine design

has changed, this column will indicate

serial number of applicable machine.

The main illustration shows the most

current design of the machine. The

boxed illustrations show older designs.

If column has an asterisk (*), call

manufacturer for serial number.

-NOTES – column for information not

noted by the other columns.

NOTE: If a service or option kit is installed on your

machine, be sure to keep the KIT INSTRUCTIONS

which came with the kit. It contains replacement

parts numbers needed for ordering future parts.

NOTE: The number on the lower left corner of the

front cover is the part number for this manual.

PUBLISHED __ _________________________

_____

SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precaution

must always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.

This machine is for commercial use.

To reduce the risk of fire, electric shock, or injury:

Connect to a properly grounded outlet. See Grounding Instructions.

WARNING:

Do not leave the machine unattended. Unplug machine from outlet when not in use and before maintenance or

service.

Use only indoors. Do not use outdoors or expose to rain.

Do not allow machine to be used as a toy. Close attention is necessary when used by or near children.

Use only as described in this manual. Use only manufacturer’s recommended components and attachments.

Do not use damaged electrical cord or plug. Follow all instructions in this manual concerning grounding the

machine. If the machine is not working properly, has been dropped, damaged, left outdoors, or dropped into

water, return it to an authorized service center.

Do not pull or carry machine by electrical cord, use as a handle, close a door on cord, or pull cord around sharp

edges or corners.

Do not run machine over cord. Keep cord away from heated surfaces.

Do not unplug machine by pulling on cord. To unplug, grasp the electrical plug, not the electrical cord.

Do not handle the electrical plug or machine with wet hands.

Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce airflow.

This machine is intended for cleaning carpet only.

Do not vacuum anything that is burning or smoking, such as cigarettes, matches, or hot ashes.

This machine is not suitable for picking up health endangering dust.

Turn off all controls before unplugging.

Machine can cause a fire when operating near flammable vapors or materials. Do not operate this machine near

flammable fluids, dust or vapors.

This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops

and offices for more than normal housekeeping purposes.

Maintenance and repairs must be done by qualified personnel.

If foam or liquid comes out of machine, switch off immediately.

SAVE THESE INSTRUCTIONS

CADET 86038220 03/16/07 2-1

HAZARD INTENSITY LEVEL

CADET 86038220 03/16/07

2-2

The following symbols are used throughout this guide as indicated in their descriptions:

HAZARD INTENSITY LEVEL

There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR

SAFETY. The level of hazard intensity is determined by the following definitions:

!WARNING

WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.

!CAUTION

CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or property

damage.

FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.

Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper

operating condition. Following is information that signals some potentially dangerous conditions to the

operator or the equipment. Read this information carefully. Know when these conditions can exist. Locate

all safety devices on the machine. Please take the necessary steps to train the machine operating

personnel.

FOR SAFETY:

DO NOT OPERATE MACHINE:

Unless Trained and Authorized.

Unless Operation Guide is Read and understood.

In Flammable or Explosive areas.

In areas with possible falling objects.

WHEN SERVICING MACHINE:

Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the

machine. Use manufacturer approved replacement parts.

GROUNDING INSTRUCTIONS

NOTE: In Canada, the use of a temporary adaptor is no

ermitted by the Canadian Electrical Code

PROPER GROUNDING

Metal Screw

dapto

Grounded Outlet Box

Fig. A Fig. B

Fig. C

Tab For Grounding Screw

Grounded

Outlet

Grounding Pin

dapto

THIS PRODUCT IS FOR COMMERCIAL USE ONLY.

ELECTRICAL:

In the USA this machine operates on a standard 15

amp 115V, 60 hz, A.C. power circuit . The amp,

hertz, and voltage are listed on the data label found

on each machine. Using voltages above or below

those indicated on the data label will cause serious

damage to the motors.

GROUNDING INSTRUCTIONS:

This appliance must be grounded. If it should

malfunction or break down, grounding provides a path

of least resistance for electric current to reduce the

risk of electric shock. This appliance is equipped with

a cord having an equipment-grounding conductor and

grounding plug. The plug must be inserted into an

appropriate outlet that is properly installed and

grounded in accordance with all local codes and

ordinances.

This appliance is for use on a nominal 115-volt circuit,

and has a grounded plug that looks like the plug in

“Fig. A”. A temporary adaptor that looks like the

adaptor in “Fig . C” may be used to connect this plug

to a 2-pole receptacle as shown in “Fig. B”, if a

properly grounded outlet is not available. The

temporary adaptor should be used only until a

properly grounded outlet (Fig. A) can be installed by a

qualified electrician. The green colored rigid ear, lug,

or the like extending from the adaptor must be

connected to a permanent ground such as a properly

grounded outlet box cover. Whenever the adaptor is

used, it must be held in place by a metal screw.

WARNING:

Improper connection of the equipment-grounding

conductor can result in a risk of electric shock. Check

with a qualified electrician or service person if you are

in doubt as to whether the outlet is properly

grounded. Do not modify the plug provided with the

appliance - if it will not fit the outlet, have a proper

outlet installed by a qualified electrician.

CADET 86038220 03/16/07 2-3

TECHNICAL SPECIFICATIONS

POWER TYPE

ELECTRICAL: 115 V, 15 A, 60 HZ

ELECTRIC VACUUM MOTOR: (1) –3 stage, 1 hp, 99

cfm (2.80 cubic meters/min.) Waterlift –117” (297cm)

BRUSH: (1) 15” (38.1 cm.)

SOLUTION PUMP: Diaphragm style, internal bypass

SOLUTION CAPACITY: 7 gallons (26.5ltr)

RECOVERY CAPACITY: 7 gallons (26.5ltr)

BRUSH SPEED: 1000 rpm

GENERAL DIMENSIONS/WEIGHT

Vacuum shoe: 17” (43.18 cm) cast

aluminum with spring loaded down

pressure

WHEELS: (2) 10” dia. (25 cm) wheels

by 2”

WEIGHT: 92lbs. (42kg)

LENGTH: 41” (104 cm)

HEIGHT: 34” (86.36 cm)

WIDTH: 17.5” (44.45 cm)

SOLUTION SPRAY: 2 quick change

jets.

POWER CABLE: 50’ (12.7 m) (14

gauge)

17.5”

(44.45cm)

41”

(104cm)

34”

(86.36cm)

CADET 86038220 03/16/07

3-1

CONTROLS/COMPONENT LOCATIONS

1. Main Handle. Used to pull and maneuver

machine.

2. Electrical Cord.

3. Pump Switch. Turns on pump and enables

spray.

3 5

4. Brush/Spray switch. Turns on brush motor

and activates electro-valve to dispense solution

to floor through jets. Intermittent, off, and

continuous settings.

5. Vacuum Motor Switch. Turns on vacuum

motor

6. Brush Motor Circuit Breaker. 6 amp. Breaker

protecting brush motor.

1 7. Vacuum Motor Circuit Breaker. 15 amp.

Breaker protecting vacuum motor.

8. Recovery Dump Hose. Facilitates draining

dirty cleaning solution.

9. Solution Dump Hose. Facilitates draining

excess cleaning solution from solution tank.

CADET 86038220 03/16/07

3-2

CONTROLS/COMPONENT LOCATIONS

1. Solution Accessory Tool Hookup. Used for

various auxiliary cleaning tools.

2. Vacuum Hose Door. Used to connect various

auxiliary 1 ½ inch cleaning tool vacuum hoses.

3. Brush Height Adjustment. Used to regulate

brush height from storage position to various

carpet heights.

4. Recovery Tank. Used to collect dirty cleaning

solution.

5. Solution Tank. Used to hold cleaning solution.

6. Recovery Tank Dome.

7. Vacuum Shoe.

8. Brush Housing.

9. Front Lifting Handle.

10. Cleaning Solution Filter.

CADET 86038220 03/16/07

3-3

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Windsor Machine de plancher

Windsor

Windsor Chariot iScrub Manuel utilisateur

Windsor

Windsor MD1500 Manuel utilisateur

Windsor

Windsor Saber Compact 16SP Manuel utilisateur

Windsor

Windsor passport Manuel utilisateur

Windsor

Windsor SPIRIT DUAL SPD-J Manuel utilisateur

Windsor

Windsor Dominator 17 NMWU2215N Manuel utilisateur

Windsor

Windsor SCENX326 10052340 Manuel utilisateur

Windsor

Windsor D250 (115V) Manuel utilisateur

Windsor

Windsor DOMINATOR D250 Manuel utilisateur

Windsor

Windsor COMDU Caractéristiques techniques

Windsor

Windsor Chariot iGloss 20 Manuel utilisateur

Windsor

Windsor D250(115V) 10070100 Manuel utilisateur

Windsor

Windsor ADMIRAL ADM8IA - 10080010 Manuel utilisateur

Windsor

Windsor 10080480 Manuel utilisateur

Windsor

Windsor EXPERT Manuel utilisateur

Windsor

Windsor Dri-Matic Manuel utilisateur

Windsor

Windsor Cadet CDT7IA Caractéristiques techniques

Windsor

Windsor FILTRONIC F22 Manuel utilisateur

Windsor

Windsor Armada BRC 40/22 120V Manuel utilisateur

Windsor

Windsor Clipper Duo Manuel utilisateur

Windsor

Windsor SUPREME ULTRA HIGH SPEED BURNISHER P1700120 Guide de dépannage

Windsor

Windsor Cadet 7 CDT7I Manuel utilisateur

Windsor

Windsor VOYDU1, VOYXDU 10086130 Manuel utilisateur

Windsor

Windsor U1500 Manuel utilisateur

Manuels Machine de plancher populaires d'autres marques

Nilfisk-Advance

Nilfisk-Advance Advance SC370 17B Manuel utilisateur

Numatic

Numatic ET 4045 Manuel utilisateur

HAWK ENTERPRISES

HAWK ENTERPRISES HP1513-180BRUTE Manuel utilisateur

Mytee

Mytee 8070 Mytee-Lite Manuel utilisateur

Kärcher

Kärcher B 140 R Manuel utilisateur

Triple S

Triple S Ace 26T1 Manuel utilisateur

Nilfisk-Advance

Nilfisk-Advance SW 750 Manuel utilisateur

Tornado

Tornado Marathon 2000 98190 Manuel

Numatic

Numatic TTB 1117/100 Manuel utilisateur

Tennant

Tennant 8210D Manuel utilisateur

Nobles

Nobles Frontier Manuel du produit

lavina

lavina 21-X Manuel utilisateur

KENT

KENT Edge 28B Manuel utilisateur

Tennant

Tennant 215 Manuel du produit

CleanFreak

CleanFreak DURA-18HD Manuel utilisateur

Nilfisk-Advance

Nilfisk-Advance Warrior 34RST Guide de l'administrateur

BETCO

BETCO PB24 Manuel utilisateur

IPC

IPC CT51-71 BT Manuel utilisateur
