WIKA TG58SA Manuel utilisateur
DE
EN
Operating instructions
Betriebsanleitung
Mode d'emploi
Manual de instrucciones
ES
FR
Back mount (axial) Lower mount
Bimetal thermometer for sanitary applications
Model TG58SA
Bimetallthermometer für die sterile Verfahrenstechnik
Typ TG58SA
Thermomètre bimétallique pour applications sanitaires
Type TG58SA
Termómetro bimetálico para aplicaciones sanitarias
Modelo TG58SA
2
14399932.01 06/2022 EN/DE/FR/ES
WIKA operating instructions model TG58SA
DE
EN
ES
FR
Operating instructions model TG58SA
Page 3 - 22
Betriebsanleitung Typ TG58SA
Seite 23 - 42
Mode d'emploi type TG58SA
Page 43 - 62
Manual de instrucciones modelo TG58SA
Página 63 - 82
© 06/2022 WIKA Alexander Wiegand SE & Co. KG
All rights reserved. / Alle Rechte vorbehalten.
WIKA®is a registered trademark in various countries.
WIKA®ist eine geschützte Marke in verschiedenen Ländern.
Prior to starting any work, read the operating instructions!
Keep for later use!
Vor Beginn aller Arbeiten Betriebsanleitung lesen!
Zum späteren Gebrauch aufbewahren!
Lire le mode d'emploi avant de commencer toute opération !
A conserver pour une utilisation ultérieure !
¡Leer el manual de instrucciones antes de comenzar cualquier trabajo!
¡Guardar el manual para una eventual consulta!
EN
WIKA operating instructions model TG58SA
14399932.01 06/2022 EN/DE/FR/ES
3
Contents
Contents
1. General information 4
2. Design and function 5
3. Safety 6
4. Transport, packaging and storage 11
5. Commissioning, operation 13
6. Faults 15
7. Maintenance and cleaning 16
8. Dismounting, return and disposal 18
9. Specications 20
EN
14399932.01 06/2022 EN/DE/FR/ES
4WIKA operating instructions model TG58SA
1. General information
■
The bimetal thermometers described in these operating instructions
have been designed and manufactured using state-of-the-art techno-
logy. All components are subject to stringent quality and environmen-
tal criteria during production. Our management systems are certied
to ISO 9001 and ISO 14001.
■
These operating instructions contain important information on
handling the instrument.Working safely requires that all safety instruc-
tions and work instructions are observed.
■
Observe the relevant local accident prevention regulations and
general safety regulations for the instrument's range of use.
■
The operating instructions are part of the product and must be kept
in the immediate vicinity of the instrument and readily accessible to
skilled personnel at any time. Pass the operating instructions on to the
next operator or owner of the instrument.
■
Skilled personnel must have carefully read and understood the opera-
ting instructions prior to beginning any work.
■
The general terms and conditions contained in the sales
documentation shall apply.
■
Subject to technical modications.
1. General information
Supplementary documentation:
▶
Please follow all the documentation included within the scope of
delivery.
With versions for hazardous areas, also follow the
additional operating instructions!
EN
WIKA operating instructions model TG58SA
14399932.01 06/2022 EN/DE/FR/ES
5
■
Further information:
- Internet address: www.wika.de / www.wika.com
- Relevant data sheet: TM 58.01
- Application consultant: Tel.: +49 9372 132-0
2. Design and function
2.1 Overview
Case
Dial
Pointer
Process connection
2.2 Description
The bimetal thermometer has been specically designed for the require-
ments of sanitary applications.
1. General information / 2. Design and function
EN
14399932.01 06/2022 EN/DE/FR/ES
6WIKA operating instructions model TG58SA
The purely mechanical temperature transmission via a bimetal coil in the
stem and the high overtemperature resistance ensure a safe tempera-
ture measurement.
The TG58SA in hygienic design can be used for CIP (cleaning in place)
and SIP (sterilisation in place) and in wash-down areas.The measuring
instrument can thus be cleaned reliably and time-eciently. Based on
a third party verication, the model TG58SA corresponds to the 3-A
Sanitary Standard.
2.3 Scope of delivery
Cross-check scope of delivery with delivery note.
3. Safety
3.1 Explanation of symbols
WARNING!
... indicates a potentially dangerous situation that can result in
serious injury or death, if not avoided.
CAUTION!
... indicates a potentially dangerous situation that can result in
light injuries or damage to property or the environment, if not
avoided.
DANGER!
... identies hazards caused by electrical power. Should the
safety instructions not be observed, there is a risk of serious
or fatal injury.
WARNING!
... indicates a potentially dangerous situation that can result in
burns, caused by hot surfaces or liquids, if not avoided.
2. Design and function / 3. Safety
EN
WIKA operating instructions model TG58SA
14399932.01 06/2022 EN/DE/FR/ES
7
3. Safety
Information
... points out useful tips, recommendations and information for
ecient and trouble-free operation.
3.2 Intended use
The model TG58SA bimetal thermometer is used for temperature
measurement, especially in sanitary applications.
The stem with its hemispherical base, in conjunction with the aseptic
process connections (e.g. clamp, threaded, VARINLINE®), enables a
dead-space free connection to the process.
The instruments are not approved for use in hazardous areas!
The instruments have been designed and built solely for the intended
use described here, and may only be used accordingly.
→ For performance limits, see chapter 9 “Specications”.
The manufacturer shall not be liable for claims of any type based on
operation contrary to the intended use.
3.3 Improper use
WARNING!
Injuries through improper use
Improper use of the instrument can lead to hazardous situa-
tions and injuries.
▶
Refrain from unauthorised modications to the instrument.
▶
Do not use the instrument within hazardous areas.
▶
Do not use the instrument with abrasive or viscous media.
EN
14399932.01 06/2022 EN/DE/FR/ES
8WIKA operating instructions model TG58SA
Any use beyond or dierent to the intended use is considered as
improper use.
Do not use this instrument in safety or emergency shutdown devices.
3.4 Compliance with EHEDG conformity
For an EHEDG-compliant connection, sealings in accordance with the
current EHEDG policy document must be used.
Sealings for connections per ISO 2852, DIN 32676 and BS 4825 part 3
are, e.g., manufactured by Combit International B.V.
A manufacturer of VARINLINE®sealings is, e.g., GEA Tuchenhagen
GmbH.
3.5 Responsibility of the operator
The instrument is used in the industrial sector.The operator is therefore
responsible for legal obligations regarding safety at work.
The safety instructions within these operating instructions, as well as the
safety, accident prevention and environmental protection regulations for
the application area must be maintained.
The operator is obliged to maintain the product label in a legible
condition.
To ensure safe working on the instrument, the operating company must
ensure
■
that suitable rst-aid equipment is available and aid is provided
whenever required.
■
that the operating personnel are regularly instructed in all topics
regarding work safety, rst aid and environmental protection and know
the operating instructions and in particular, the safety instructions
contained therein.
■
that the instrument is suitable for the particular application in
accordance with its intended use.
3. Safety
EN
WIKA operating instructions model TG58SA
14399932.01 06/2022 EN/DE/FR/ES
9
3.6 Personnelqualication
WARNING!
Riskofinjuryshouldqualicationbeinsucient
Improper handling can result in considerable injury and
damage to property.
▶
The activities described in these operating instructions
may only be carried out by skilled personnel who have the
qualications described below.
Skilled personnel
Skilled personnel, authorised by the operator, are understood to be
personnel who, based on their technical training, knowledge of measu-
rement and control technology and on their experience and knowledge
of country-specic regulations, current standards and directives, are
capable of carrying out the work described and independently recognis-
ing potential hazards.
Operating personnel
The personnel trained by the operator are understood to be personnel
who, based on their education, knowledge and experience, are capab-
le of carrying out the work described and independently recognising
potential hazards.
Special operating conditions require further appropriate knowledge, e.g.
of aggressive media.
3. Safety
EN
14399932.01 06/2022 EN/DE/FR/ES
10 WIKA operating instructions model TG58SA
3. Safety
3.7 Labelling, safety marks
Marking at the process connection
Dial (example)
3.8 Personal protective equipment
The personal protective equipment is designed to protect the skilled
personnel from hazards that could impair their safety or health during
work.When carrying out the various tasks on and with the instrument,
the skilled personnel must wear personal protective equipment.
Legend:Legend:
Material markingMaterial marking
Smart codeSmart code
WIKA material code (WMC) / BatchWIKA material code (WMC) / Batch
numbernumber
Flange standardFlange standard
Flange sizeFlange size
Maximum allowable pressureMaximum allowable pressure
1.4404
XXXXXX
SS316L
VARINLINE
Form X
Max. 25 bar
Legend:Legend:
StandardStandard
Active lengthActive length
Start of measuring rangeStart of measuring range
Logos of the certicationsLogos of the certications
Accuracy
End of measuring range
