Operating instructions
Betriebsanleitung
Mode d'emploi
Manual de instrucciones
Fig. left: Mounted on a pipe
Fig. right: With quick-mounting bracket
Strap-on thermometer with connection lead
Model TF44
Anlegethermometer mit Anschlussleitung
Typ TF44
Thermomètre de surface avec câble de raccordement
Type TF44
Termómetro de contacto con cable de conexión
Modelo TF44
© 12/2012 WIKA Alexander Wiegand SE & Co. KG
All rights reserved. / Alle Rechte vorbehalten.
WIKA®is a registered trademark in various countries.
WIKA®ist eine geschützte Marke in verschiedenen Ländern.
Prior to starting any work, read the operating instructions!
Keep for later use!
Vor Beginn aller Arbeiten Betriebsanleitung lesen!
Zum späteren Gebrauch aufbewahren!
Lire le mode d‘emploi avant de commencer toute opération !
A conserver pour une utilisation ultérieure !
¡Leer el manual de instrucciones antes de comenzar cualquier trabajo!
¡Guardar el manual para una eventual consulta!
ES
FR
DE
EN
2
WIKA operating instructions model TF44
14057036.03 06/2018 EN/DE/FR/ES
Operating instructions model TF44
Page 3 - 18
Betriebsanleitung Typ TF44
Seite 19 - 34
Mode d'emploi type TF44
Page 35 - 50
Manual de instrucciones modelo TF44
Página 51 - 65
WIKA operating instructions model TF44
14057036.03 06/2018 EN/DE/FR/ES
3
EN
Contents
Contents
1. General information 4
2. Design and function 5
3. Safety 6
4. Transport, packaging and storage 9
5. Commissioning, operation 10
6. Faults 12
7. Maintenance and cleaning 13
8. Dismounting, return and disposal 14
9. Specifications 16
10. Accessories 17
14057036.03 06/2018 EN/DE/FR/ES
4
WIKA operating instructions model TF44
EN
1. General information
■
The strap-on thermometer described in the operating instructions has been
manufactured using state-of-the-art technology. All components are subject to
stringent quality and environmental criteria during production. Our management
systems are certified to ISO 9001 and ISO 14001.
■
These operating instructions contain important information on handling the
instrument. Working safely requires that all safety instructions and work instructions
are observed.
■
Observe the relevant local accident prevention regulations and general safety
regulations for the instrument’s range of use.
■
The operating instructions are part of the product and must be kept in the immediate
vicinity of the instrument and readily accessible to skilled personnel at any time. Pass
the operating instructions on to the next operator or owner of the instrument.
■
Skilled personnel must have carefully read and understood the operating instructions
prior to beginning any work.
■
The general terms and conditions contained in the sales documentation shall apply.
■
Subject to technical modifications.
■
Further information:
- Internet address: www.wika.de / www.wika.com
- Relevant data sheet: TE 67.14
- Application consultant: Tel.: +49 9372 132-0
Fax: +49 9372 132-406
info@wika.de
1. General information
WIKA operating instructions model TF44
14057036.03 06/2018 EN/DE/FR/ES
5
EN
2. Design and function
2.1 Overview
Probe sleeve
Connection lead
Quick-mounting bracket
2.2 Description
The model TF44 strap-on thermometer consists of an aluminium probe sleeve with built-
in measuring element and a fixed mounted connection lead.
It is used for temperature measurement on pipe surfaces and can be secured by means
of a pipe clamp. Due to the materials, the geometry and the construction of the TF44, it
is not necessary to apply thermal compound between the probe sleeve and the pipeline.
If desired anyway, a small quantity of thermal compound is sufficient.
For quick and particularly easy mounting, the TF44 features WIKA quick-mounting
brackets.With these, the strap-on thermometer can be mounted easily without tools.
Quick-mounting brackets for different pipe diameters and thermal compound can be
purchased from WIKA not only as parts of the TF44 but also separately as accessories.
For the article numbers of these see data sheet TE 67.14
All electrical components are protected against splash water. The electrical connection
is made via the connection lead.
2.3 Scope of delivery
Cross-check scope of delivery with delivery note.
2. Design and function
14057036.03 06/2018 EN/DE/FR/ES
6
WIKA operating instructions model TF44
EN
3. Safety
3.1 Explanation of symbols
WARNING!
... indicates a potentially dangerous situation that can result in serious
injury or death, if not avoided.
CAUTION!
... indicates a potentially dangerous situation that can result in light injuries
or damage to equipment or the environment, if not avoided.
Information
... points out useful tips, recommendations and information for efficient
and trouble-free operation.
DANGER!
... identifies hazards caused by electric power. Should the safety
instructions not be observed, there is a risk of serious or fatal injury.
WARNING!
... indicates a potentially dangerous situation that can result in burns,
caused by hot surfaces or liquids, if not avoided.
3.2 Intended use
TF44 strap-on thermometer is used for measuring temperature on pipe surfaces.
The instrument has been designed and built solely for the intended use described here,
and may only be used accordingly.
The technical specifications contained in these operating instructions must be
observed. Improper handling or operation of the instrument outside of its technical
specifications requires the instrument to be taken out of service immediately and
inspected by an authorised WIKA service engineer.
The manufacturer shall not be liable for claims of any type based on operation contrary
to the intended use.
3. Safety
WIKA operating instructions model TF44
14057036.03 06/2018 EN/DE/FR/ES
7
EN
3.3 Improper use
WARNING!
Injuries through improper use
Improper use of the instrument can lead to hazardous situations and
injuries.
▶
Refrain from unauthorised modifications to the instrument.
▶
Do not use the instrument within hazardous areas.
▶
Do not use the instrument with abrasive or viscous media.
Any use beyond or different to the intended use is considered as improper use.
Do not use this instrument in safety or emergency stop devices.
3.4 Responsibility of the operator
The instrument is used in the industrial sector. The operator is therefore responsible for
legal obligations regarding safety at work.
The safety instructions within these operating instructions, as well as the safety,
accident prevention and environmental protection regulations for the application area
must be maintained.
The operator is obliged to maintain the product label in a legible condition.
To ensure safe working on the instrument, the operating company must ensure
■
that suitable first-aid equipment is available and aid is provided whenever required.
■
that the operating personnel are regularly instructed in all topics regarding work
safety, first aid and environmental protection and know the operating instructions and
in particular, the safety instructions contained therein.
■
that the instrument is suitable for the particular application in accordance with its
intended use.
■
that personal protective equipment is available.
3. Safety
14057036.03 06/2018 EN/DE/FR/ES
8
WIKA operating instructions model TF44
EN
3.5 Personnel qualification
WARNING!
Risk of injury should qualification be insufficient
Improper handling can result in considerable injury and damage to
equipment.
▶
The activities described in these operating instructions may only be
carried out by skilled personnel who have the qualifications described
below.
▶
Keep unqualified personnel away from hazardous areas.
Skilled personnel
Skilled personnel, authorised by the operator, are understood to be personnel
who, based on their technical training, knowledge of measurement and control
technology and on their experience and knowledge of country-specific regulations,
current standards and directives, are capable of carrying out the work described and
independently recognising potential hazards.
Special operating conditions require further appropriate knowledge, e.g. of aggressive
media.
3.6 Labelling, safety marks
Product label (example)
Model
Number of the production order
Permissible measuring range
Probe version
■
Measuring element
■
Connection method
■
Tolerance of the measuring element
Before mounting and commissioning the instrument, ensure you read the
operating instructions!
3. Safety
WIKA operating instructions model TF44
14057036.03 06/2018 EN/DE/FR/ES
9
EN
4. Transport, packaging and storage
4.1 Transport
Check the instrument for any damage that may have been caused by transport.
Obvious damage must be reported immediately.
CAUTION!
Damage through improper transport
With improper transport, a high level of damage to property can occur.
▶
When unloading packed goods upon delivery as well as during
internal transport, proceed carefully and observe the symbols on the
packaging.
▶
With internal transport, observe the instructions in chapter 4.2
“Packaging and storage”.
If the instrument is transported from a cold into a warm environment, the formation of
condensation may result in instrument malfunction. Before putting it back into operation,
wait for the instrument temperature and the room temperature to equalise.
4.2 Packaging and storage
Do not remove packaging until just before mounting.
Keep the packaging as it will provide optimum protection during transport (e.g. change
in installation site, sending for repair).
Permissible conditions at the place of storage:
■
Storage temperature: -20 ... +70 °C
■
Humidity: 35 ... 85 % relative humidity (no condensation)
Avoid exposure to the following factors:
■
Direct sunlight or proximity to hot objects
■
Mechanical vibration, mechanical shock (putting it down hard)
■
Soot, vapour, dust and corrosive gases
■
Hazardous environments, flammable atmospheres
Store the instrument in its original packaging in a location that fulfils the conditions
listed above. If the original packaging is not available, pack and store the instrument as
described below:
1. Wrap the instrument in an antistatic plastic film.
2. Place the instrument, along with shock-absorbent material, in the packaging.
3. If stored for a prolonged period of time (more than 30 days), place a bag containing a
desiccant inside the packaging.
4. Transport, packaging and storage
14057036.03 06/2018 EN/DE/FR/ES
10
WIKA operating instructions model TF44
EN
5. Commissioning, operation
Personnel: Skilled personnel
Tools: Screwdriver, diagonal pliers
Only use original parts (see chapter 10 “Accessories”).
WARNING!
Physical injuries and damage to property and the environment
caused by hazardous media
Upon contact with hazardous media (e.g. oxygen, acetylene, flammable
or toxic substances), harmful media (e.g. corrosive, toxic, carcinogenic,
radioactive), and also with refrigeration plants and compressors, there is a
danger of physical injuries and damage to property and the environment.
Should a failure occur, aggressive media with extremely high temperature
and under high pressure or vacuum may be present at the instrument.
▶
For these media, in addition to all standard regulations, the appropriate
existing codes or regulations must also be followed.
CAUTION!
Damage to the instrument
When working on open electrical circuits (printed circuit boards) there is
a risk of damaging sensitive electronic components through electrostatic
discharge.
▶
The correct use of grounded working surfaces and personal armbands
is required.
DANGER!
Danger to life caused by electric current
Upon contact with live parts, there is a direct danger to life.
▶
The instrument may only be installed and mounted by skilled
personnel.
▶
Operation using a defective power supply unit (e.g. short circuit from
the mains voltage to the output voltage) can result in life-threatening
voltages at the instrument!
5. Commissioning, operation
Table des matières
Langues :
Autres manuels WIKA Thermomètre
WIKA
WIKA 32 Manuel utilisateur
WIKA
WIKA TF45 Manuel utilisateur
WIKA
WIKA TRW Manuel utilisateur
WIKA
WIKA CTH7000 Manuel utilisateur
WIKA
WIKA TG58SA Mode d'emploi
WIKA
WIKA TR33 Manuel utilisateur
WIKA
WIKA F73.100 Manuel utilisateur
WIKA
WIKA TR Series Manuel utilisateur
WIKA
WIKA CTH6300 Manuel utilisateur
WIKA
WIKA TG53 Manuel utilisateur
WIKA
WIKA TGU73.100 Manuel utilisateur
WIKA
WIKA CTH 6200 Manuel utilisateur
WIKA
WIKA R52.100 Manuel utilisateur
WIKA
WIKA TR33 Manuel utilisateur
WIKA
WIKA TR12 Series Manuel utilisateur
WIKA
WIKA CTH63I0 Manuel utilisateur
WIKA
WIKA TR10-W Manuel utilisateur
WIKA
WIKA TG58SA Manuel utilisateur
WIKA
WIKA CTH 6200 Manuel utilisateur
WIKA
WIKA 53 Series Manuel utilisateur
