WIKA 5 Manuel utilisateur

Example: Model 532.53.100 per ATEX

Operating instructions

Betriebsanleitung

Mode d'emploi

Manual de instrucciones

Pressure gauge model 5, NS 100 and NS 160 per ATEX

Manometer Typ 5, NG 100 und NG 160 nach ATEX

Manomètre type 5, diam. 100 et diam. 160 selon ATEX

Manómetro modelo 5, DN 100 y DN 160 según ATEX

avrora-arm.ru

+7 (495) 956-62-18

2WIKA operating instructions pressure gauge model 5 per ATEX

11554810.03 04/2017 EN/DE/FR/ES

Operating instructions model 5 per ATEX Page 3-16

Betriebsanleitung Typ 5 nach ATEX Seite 17-30

Mode d’emploi type 5 selon ATEX Page 31-44

Manual de instrucciones modelo 5 según ATEX Página 45-57

WIKA®is a registered trademark in various countries.

WIKA®ist eine geschützte Marke in verschiedenen Ländern.

Prior to starting any work, read the operating instructions!

Keep for later use!

Vor Beginn aller Arbeiten Betriebsanleitung lesen!

Zum späteren Gebrauch aufbewahren!

Lire le mode d'emploi avant de commencer toute opération !

A conserver pour une utilisation ultérieure !

¡Leer el manual de instrucciones antes de comenzar cualquier trabajo!

¡Guardar el manual para una eventual consulta posterior!

3WIKA operating instructions pressure gauge model 5 per ATEX

11554810.03 04/2017 EN/DE/FR/ES

1. General information 4

2. Safety 5

3. Specications 9

4. Design and function 10

5. Transport, packaging and storage 10

6. Commissioning, operation 11

7. Maintenance and cleaning 13

8. Dismounting and disposal 14

Appendix: EU declaration of conformity 15

Contents

Declarations of conformity can be found online at www.wika.com.

WIKA operating instructions pressure gauge model 5 per ATEX4

11554810.03 04/2017 EN/DE/FR/ES

1. General information

The instrument described in the operating instructions has been designed and

manufactured using state-of-the-art technology. All components are subject to

stringent quality and environmental criteria during production. Our management

systems are certied to ISO 9001 and ISO 14001.

These operating instructions contain important information on handling the

instrument. Working safely requires that all safety instructions and work instruc-

tions are observed.

Observe the relevant local accident prevention regulations and general safety

regulations for the instrument's range of use.

The operating instructions are part of the product and must be kept in the

immediate vicinity of the instrument and readily accessible to skilled personnel

at any time.

Skilled personnel must have carefully read and understood the operating

instructions prior to beginning any work.

The manufacturer‘s liability is void in the case of any damage caused by using

the product contrary to its intended use, non-compliance with these operating

instructions, assignment of insuciently qualied skilled personnel or unauthor-

ised modications to the instrument.

The general terms and conditions contained in the sales documentation shall

apply.

Subject to technical modications.

Further information:

- Internet address: www.wika.de / www.wika.com

- Relevant data sheet: PM 05.02

Explanation of symbols

WARNING!

... indicates a potentially dangerous situation that can result in

serious injury or death, if not avoided.

Information

... points out useful tips, recommendations and information for

ecient and trouble-free operation.

WARNING!

... indicates a potentially dangerous situation in the hazardous area

that results in serious injury or death, if not avoided.

5WIKA operating instructions pressure gauge model 5 per ATEX

11554810.03 04/2017 EN/DE/FR/ES

2. Safety

WARNING!

Before installation, commissioning and operation, ensure that the

appropriate instrument has been selected in terms of measuring

range, design and specic measuring conditions.

Check the compatibility with the medium of the materials subjected

to pressure!

In order to guarantee the measurement accuracy and long-term

stability specied, the corresponding load limits must be observed.

Non-observance can result in serious injury and/or damage to the

equipment.

Further important safety instructions can be found in the individual

chapters of these operating instructions.

2.1 Intended use

These instruments are used for measuring absolute pressure in hazardous areas

of industrial applications.

They are particularly used for the monitoring of vacuum pumps, the control of

vacuum packing machines, the monitoring of condensation pressures and the

determination of vapour pressure in liquids.

The instrument has been designed and built solely for the intended use described

here, and may only be used accordingly.

The manufacturer shall not be liable for claims of any type based on operation

contrary to the intended use.

2.2 Personnel qualication

WARNING!

Risk of injury should qualication be insucient!

Improper handling can result in considerable injury and damage to

equipment.

The activities described in these operating instructions may only

be carried out by skilled personnel who have the qualications

described below.

WIKA operating instructions pressure gauge model 5 per ATEX6

11554810.03 04/2017 EN/DE/FR/ES

2. Safety

Skilled personnel

Skilled personnel are understood to be personnel who, based on their techni-

cal training, knowledge of measurement and control technology and on their

experience and knowledge of country-specic regulations, current standards

and directives, are capable of carrying out the work described and independently

recognising potential hazards.

2.3 Safety instructions for pressure gauges per ATEX

WARNING!

Non-observance of these instructions and their contents may result

in the loss of explosion protection.

WARNING!

It is imperative that the application conditions and safety require-

ments of the EC-type examination certicate are followed.

▶

Instruments must be grounded via the process connection.

Permissible ambient temperature

-20 ... +60 °C

-40 ... +60 °C (optional, only for silicone oil lling)

Attention! With gaseous media, the temperature may increase as a result of

compression warming. In these cases it may be necessary to throttle the rate of

change of pressure or reduce the permissible medium temperature.

Permissible medium temperature

-20 ... +100 °C

-40 ... +200 °C (optional, only for unlled gauges)

The permissible medium temperature does not only depend on the instrument

design, but also on the ignition temperature of the surrounding gases, vapours or

dusts. Both aspects have to be taken into account.

Maximum surface temperature

The surface temperature of the instruments mainly depends on the medium

temperature of the application. For determining the maximum surface tempera-

ture, besides the medium temperature also other inuences such as the ambient

temperature and, if applicable, the solar irradiation must be taken into account.

Potentially explosive gas atmosphere

7WIKA operating instructions pressure gauge model 5 per ATEX

11554810.03 04/2017 EN/DE/FR/ES

Required temperature

class

(ignition temperature of

gas or vapour)

Maximum permissible medium temperature

(in the measuring system)

dry gauges liquid-lled gauges

T6 (T > 85 °C) +65 °C +65 °C

T5 (T > 100 °C) +80 °C +80 °C

T4 (T > 135 °C) +105 °C +100 °C

T3 (T > 200 °C) +160 °C +100 °C

T2 (T > 300 °C) +200 °C +100 °C

T1 (T > 450 °C) +200 °C +100 °C

Hazardous dust atmosphere

For dusts, the procedure specied in ISO/IEC 80079-20-2 for determining the

ignition temperature has to be applied.The ignition temperature is determined

separately for dust clouds and dust layers, respectively. For dust layers, the

ignition temperature depends on the dust layer thickness per IEC/EN 60079-14.

Ignition temperature

of dust

Maximum permissible medium temperature

(in the measuring system)

Dust cloud: Tcloud < 2/3 Tcloud

Dust layer: Tlayer < Tlayer − 75 K − (reduction depending on the layer thickness)

The permissible maximum medium temperature must not exceed the lowest

determined value, even in case of a malfunction.

Explosive atmosphere consisting of hybrid mixtures

The instruments must not be used in areas in which an atmosphere consisting of

explosive hybrid mixtures (dusts mixed with gases) can occur.

2.4 Special hazards

WARNING!

For hazardous media such as oxygen, acetylene, ammable or

toxic gases or liquids, and refrigeration plants, compressors, etc., in

addition to all standard regulations, the appropriate existing codes or

regulations must also be followed.

For additional important safety instructions see chapter 2.3 “Safety instructions

for pressure gauges per ATEX”.

2. Safety

WIKA operating instructions pressure gauge model 5 per ATEX8

11554810.03 04/2017 EN/DE/FR/ES

WARNING!

Residual media in dismounted instruments can result in a risk to

persons, the environment and equipment.

Take sucient precautionary measures.

2.5 Labelling / safety marks

Dial

ATEX marking:

II 2 G c IIC TX X

II 2 D c TX X

Serial number

Product label

Model

Article number

Permissible ambient temperature

Date of manufacture (month/year)

Before mounting and commissioning the instrument, ensure

you read the operating instructions!

The instrument bearing this mark is a safety pressure gauge with a

solid bae wall in accordance with EN 837.







2. Safety

9WIKA operating instructions pressure gauge model 5 per ATEX

11554810.03 04/2017 EN/DE/FR/ES

2.6. Special conditions for safe use (X conditions)

Pressure surges must be avoided at all costs. Open the shut-o valves slowly.

Temperature increases due to compression warming absolutely must be taken

into account. In these cases it may be necessary to throttle the rate of change

of pressure or reduce the permissible medium temperature.

The end user must ensure that the instrument is connected to the equipotential

bonding of the end-use application via the process connection.

Avoid handling substances that might react dangerously with the materials of

the instrument.

Avoid handling substances that are liable to spontaneous combustion.

3. Specications

Pressure limitation

Steady: Full scale value

Fluctuating: 0.9 x full scale value

Overpressure safety

Minimum 1 bar absolute pressure (atmospheric pressure),

in addition 10 x full scale value, max. 25 bar absolute pressure

Temperature eect

When the temperature of the measuring system deviates from the reference

temperature (+20 °C):

max. ±0.8 %/10 K of full scale value

Case ingress protection 1) (per IEC/EN 60529)

IP54 (with liquid lling IP65)

For further specications see WIKA data sheet PM 05.02 and the order

documentation.

1) For general use, no ATEX requirement

2. Safety / 3. Specications

WIKA operating instructions pressure gauge model 5 per ATEX10

11554810.03 04/2017 EN/DE/FR/ES

4. Design ... / 5. Transport, packaging and storage

4. Design and function

Description

Nominal size 100 and 160 mm

The instruments measure the pressure by means of resilient diaphragm

measuring elements.The reference point is absolute pressure “zero”.

In addition, the enclosing components of

models 53X.30.1X0 and 53X.36.1X0 also

meet the requirements of EN 837-1, relating to

safety pressure gauges with a solid bae wall

(code S3).

The diaphragm (1) separates the media

chamber (3) and the reference pressure

chamber (2) with absolute pressure zero

Pressure dierential between media chamber

(3) and reference pressure chamber (2) will

deect the diaphragm (1)

In case of an overpressure overload the

pressure element will be protected by a

contoured metal bolster

The deection is transferred from the pressure

chambers through bellows or corrugated

tubes (4), transmitted to the movement via the link (5) and indicated.

Scope of delivery

Cross-check scope of delivery with delivery note.

5. Transport, packaging and storage

5.1 Transport

Check the instrument for any damage that may have been caused by transport.

Obvious damage must be reported immediately.

5.2 Packaging

Do not remove packaging until just before mounting.

Keep the packaging as it will provide optimum protection during transport (e.g.

change in installation site, sending for repair).

289752.01

(evacuated)

Illustration of the principle

Autres manuels pour 5

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels WIKA Instrument de mesure

WIKA

WIKA CPH6200-S1 Manuel utilisateur

WIKA

WIKA CPG1500 Manuel utilisateur

WIKA

WIKA PGS23 Manuel utilisateur

WIKA

WIKA CPG1000 Manuel utilisateur

WIKA

WIKA 712.15.100 Manuel utilisateur

WIKA

WIKA GA11 Manuel utilisateur

WIKA

WIKA 7000 Series Manuel utilisateur

WIKA

WIKA 212.20.100 Manuel utilisateur

WIKA

WIKA A-10 Manuel utilisateur

WIKA

WIKA NETRIS 3 Manuel utilisateur

WIKA

WIKA 1500 Series Manuel utilisateur

WIKA

WIKA CPH6400 Manuel utilisateur

WIKA

WIKA 712.15.160 Manuel utilisateur

WIKA

WIKA 73 02.100 Series Manuel utilisateur

WIKA

WIKA PGS10 Manuel utilisateur

WIKA

WIKA DG-10 Manuel utilisateur

WIKA

WIKA 7 Series Manuel utilisateur

WIKA

WIKA PG23HP Series Manuel utilisateur

WIKA

WIKA DPG40 Manuel utilisateur

WIKA

WIKA mensor 9250 Manuel utilisateur

WIKA

WIKA CPG1500 Manuel utilisateur

WIKA

WIKA TFT35 Manuel utilisateur

WIKA

WIKA TC82 Mode d'emploi

WIKA

WIKA 700.01 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
