Maxelerate User’s Manual - 1 -

Maxelerate™

USER’S MANUAL

Revised October 6, 2006

Features

•Three USB 2.0 ports and three FireWire 400 ports; daisy-

chainable

•Supports Hi-Speed USB data transfer speed of up to 480Mbps,

and IEEE 1394a data transfer speed of up to 400Mbps

•Supports 3.5" IDE drives

•Aluminum case with fan provides maximum cooling

•Allows daisy-chaining of FireWire 400 devices

•Delivers bus power (passed through from Mac mini host) for downstream USB 1.1 and 2.0 devices

•Delivers bus power (also passed through from Mac mini host) for downstream FireWire devices

•Built-in power switch

Installation Instructions

1. Check the accessories with your Maxelerate. Please contact WiebeTech if any items are missing or damaged.

The box should contain:

Maxelerate unit 1

AC adapter & power cord 1

1394a (FireWire 400) cable 1

USB cable 1

Screws (for MAX-0) 8

Manual and Warranty information (on CD)

2. Take a moment to familiarize yourself with the parts of your new Maxelerate. This will aid you in the

remaining steps. If you purchased your Maxelerate with a drive pre-installed, you may skip ahead to the section on

connecting the unit to your computer.

Power switch IEEE 1394a

orts

DC Jack USB t

e A

USB T

e B

(

stream

)

WiebeTech LLC

3. Configure the jumpers on your 3.5” IDE hard drive. The drive must be set to the Master setting. Consult the

instructions for your drive (some drives display configuration information on the drive’s label). A few drives have both

“Master with Slave present” and “Master without Slave” options. Choose the latter in this case. In rare cases, if the

Master setting does not work then try Cable Select.

(Example)

4. Remove the bottom panel. Turn the Maxelerate over so the bottom side is facing up and remove the unit from

the bag. Please note that the bottom panel is not attached to the Maxelerate unit and is loose inside the bag. The

package contains a total of 8 screws, 4 for fixing the bottom panel to the enclosure, and 4 for securing the drive.

Remove the enclosure and bottom panel from the bag.

5. Connect the cables to the hard drive. Locate the IDE cable inside the Maxelerate and insert the free end into

the hard drive. The drive’s IDE pins can be easily bent, so be careful when connecting the cable.

Maxelerate User’s Manual - 2 -

WiebeTech LLC

Locate the power cable and insert the plug into the hard drive. It will only fit one way.

6. Rest the drive inside the Maxelerate case on top of the folded IDE and power cables. Ensure that the control

board side of the hard drive is facing up. When properly positioned, the screw holes in the hard drive will be facing

up, ready for alignment with the corresponding openings in the bottom panel.

7. Secure the bottom panel. Carefully align the openings in the bottom panel with the screw holes in the hard

drive, and the screw holes in the body of the enclosure. Fasten the drive to the bottom panel first, and then fasten the

bottom panel to the body with the included screws.

The Maxelerate is now assembled and ready for connection to a computer.

Maxelerate User’s Manual - 3 -

WiebeTech LLC

Connecting the Maxelerate to a Computer

The Maxelerate can be connected to a computer via USB 2.0 and/or FireWire 400.

Connection via USB 2.0

1. Connect the AC/DC power adapter.

12V

OFF

HOST

2. Insert the USB type B connector into the type B port on the Maxelerate, and the USB type A connector into a type

A port on the computer.

12V

OFF

HOST

Computer

3. Turn the power switch to the “ON” position; the blue LED indicator on the front of the Maxelerate will be active.

12V

OFF

HOST

Compute

ON !

The Maxelerate is now ready for use via USB 2.0 connection.

Note: When the Maxelerate is connected via USB 2.0 only, the 1394a ports are not available to the host.

LED Indicator

The Maxelerate can be self-powered, or bus-powered via the USB upstream cable. If the Maxelerate is connected as

a USB hard drive, sufficient power will be provided for hard drive and hub functions, and the LED indicator will be

“on”. The amount of bus power supplied by the host, however, may not be sufficient for devices connected to the hub

portion of the Maxelerate. Many devices draw more power and require the use of an AC adapter. Additionally, when

Maxelerate User’s Manual - 4 -

WiebeTech LLC

connected to some hosts, the LED indicator may be on when both host and Maxelerate are powered off, but still

connected to the host via the USB cable, if the host is designed to supply power initiatively.

The following table details the status of the LED indicator under various operating scenarios.

Host PC Maxelerate LED USB Hub

On On On Functional

On Off On Functional

Off On On Off

Off Off Depends on Motherboard Off

Connection via FireWire

1. Connect the AC/DC power adapter

12V

OFF

HOST

2. Insert one end of the FireWire connector into the FireWire port on the Maxelerate and the other end into the

FireWire port on the computer. Compute

12V

OFF

HOST

3. Turn the power switch to the “ON” position; the blue LED indicator on the front of the Maxelerate will be active.

12V

OFF

HOST

Compute

ON !

The Maxelerate is now ready for use via FireWire connection.

Note: When the Maxelerate is connected via FireWire only, the 2 USB ports are not available to the host.

Maxelerate User’s Manual - 5 -

WiebeTech LLC

LED Indicator

The Maxelerate can be self-powered, or bus-powered via FireWire cable. If the Maxelerate is connected as a

FireWire hard drive, sufficient power will be provided for hard drive and repeater functions, and the LED indicator will

be “on”. The amount of bus power supplied by the host, however, may not be sufficient for devices connected to the

repeater portion of the Maxelerate. Many devices draw more power and require the use of an AC adapter.

Additionally, when connected to some hosts, the LED indicator may be on when both host and Maxelerate are

powered off, but still connected to the host via FireWire, if the host is designed to supply power initiatively.

The following table details the status of the LED indicator under various operating scenarios.

Host PC Maxelerate LED FireWire Repeater

On On On Functional

On Off On Functional

Off On On Functional

Off Off Depends on Motherboard Depends

Connection via both FireWire and USB 2.0

1. Connect the AC/DC power adapter

12V

OFF

HOST

2. Insert the one end of the FireWire and USB 2.0 connectors into the FireWire and USB ports on the Maxelerate and

the other ends into the FireWire and USB ports on the computer.

12V

OFF

HOST

Compute

3. Turn the power switch to the “ON” position; the blue LED indicator on the front of the Maxelerate will be active.

Note: When the Maxelerate is connected via both FireWire and USB 2.0, the FireWire repeater and USB 2.0 hub

functionalities are supported and the Maxelerate acts as a FireWire hard drive.

LED Indicator

The Maxelerate can be self-powered, or bus-powered via the FireWire cable. If both USB and FireWire cables

connect the Maxelerate to the host, sufficient power will be provided for the hard drive, FireWire repeater and USB

hub, and the LED indicator will be “on”. The amount of bus power supplied by the host, however, may not be

sufficient for devices connected to the hub and/or repeater portion of the Maxelerate. Many devices draw more

power and require the use of an AC adapter. Additionally, when connected to some hosts, the LED indicator may be

on when the host and Maxelerate are powered off, but still connected to the host via the USB and FireWire cables.

The following table details the status of the LED indicator under various operating scenarios.

Maxelerate User’s Manual - 6 -

WiebeTech LLC

Maxelerate User’s Manual - 7 -

Host PC Maxelerate LED FireWire Repeater USB Hub

On On On Functional Functional

On Off On Functional Functional

Off On On Functional Off

Off Off Depends on

Motherboard Depends Off

Technical Specifications

Bridge Chipset Initio 1530, Cypress CY7C65640A

Bus Interface USB 2.0 and IEEE 1394a (FireWire 400)

Data Speeds USB 2.0 port maximum: 480Mbps

IEEE 1394a port maximum: 400Mbps

Connectors Two USB type-A receptacles

One USB type-B receptacle

Three 6-pin 1394a connectors

One DC-Jack Input (+12V / 3A)

HDD Support 3.5” IDE HDD, standard ATA-6, ATA-7

Power Supply 12V / 3A AC/DC Adapter

Power Supply to HDD 12V / 2A, 5V / 1A

Operating Temperature 50 – 85° Fahrenheit (10 – 30° Celsius)

Operating Humidity 5% to 95%, noncondensing

Compatibility Mac OS X

Windows XP

Linux distributions which support FireWire

Weight (without HDD) 1.2 pounds (551 g)

Dimensions 6.5” x 6.5” x 1.5” (165mm x 165mm x 38mm)

Certification CE, FCC

Warranty 1-year limited warranty. See warranty statement for details and limitations.

WiebeTech offers free phone support for 90 days after purchase (1-866-744-

8722). Email support is available at [email protected].

Maxelerate is a trademark of WiebeTech LLC. Other marks are the property of their respective owners.

FCC Compliance Statement: “This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired

operation.”

Maxelerate

Tested to comply

with FCC standards

FOR HOME OR OFFICE USE

In the event that you experience Radio Frequency Interference, you should take the following steps to resolve the problem:

1) Ensure that the bottom plate and case of your attached drive is grounded, either to the Maxelerate case or to an Earth ground.

2) Use a FireWire cable with RFI reducing ferrites on each end.

3) Use a power supply with an RFI reducing ferrite approximately 5 inches from the DC plug.

If you have any questions or problems, please contact [email protected] for technical support. If you are

interested in purchasing more WiebeTech products, check our website or contact [email protected]. We

appreciate being able to serve you!
