Operator’s Manual

Vibroplate

VP 2050A

VP 2050AW

0154570en 010 0110

0154570EN

notice

All rights, including copying and distribution rights, are reserved.

This publication may be photocopied by the original purchaser of the machine. Any

other type of reproduction is prohibited without express written permission from

Wacker Neuson Corporation.

Any type of reproduction or distribution not authorized by Wacker Neuson Corporation

represents an infringement of valid copyrights. Violators will be prosecuted.

Trademarks

All trademarks referenced in this manual are the property of their respective owners.

Manufacturer

Wacker Neuson Manila Incorporated

Lot 2,Blk 1 Phase 3, PEZA Drive, First Cavite Industrial Estate, Brgy. Langkaan

Dasmariñas, Cavite, Philippines

Tel: +63-(0)2-580-7136 Fax: +63-(0)2-580-712

www.wackerneuson.com

Translated

instructions

This Operator’s Manual presents a translation of the original instructions. The original

language of this Operator’s Manual is American English.

VP 2050A/AW Table of Contents

wpm_bo0154570010enTOC.fm 1

Foreword 3

1. Safety Information 4

1.1 Laws Pertaining to Spark Arresters ...................................................... 5

1.2 Operating Safety .................................................................................. 6

1.3 Operator Safety while using Internal Combustion Engines .................. 7

1.4 Service Safety ...................................................................................... 8

1.5 Label Locations .................................................................................... 9

1.6 Warning and Informational Labels ...................................................... 10

2. Technical Data 13

2.1 Engine Data ........................................................................................ 13

2.2 Machine Data ..................................................................................... 14

2.3 Sound and Vibration Measurements .................................................. 14

2.4 Dimensions ......................................................................................... 15

3. Operation 16

3.1 Recommended Fuel ........................................................................... 16

3.2 Application .......................................................................................... 16

3.3 Before Starting ................................................................................... 16

3.4 To Start ............................................................................................... 17

3.5 To Stop ............................................................................................... 17

3.6 Operation ............................................................................................ 18

Table of Contents VP 2050A/AW

wpm_bo0154570010enTOC.fm 2

4. Maintenance 19

4.1 Periodic Maintenance Schedule ..........................................................19

4.2 Spark Plug ...........................................................................................21

4.3 Air Cleaner ..........................................................................................22

4.4 Engine Oil ............................................................................................23

4.5 Adjusting Engine Speed ......................................................................23

4.6 Carburetor Adjustment ........................................................................24

4.7 Cleaning Sediment Cup ......................................................................24

4.8 Drive Belt .............................................................................................25

4.9 Exciter Lubrication ...............................................................................26

4.10 Cleaning the Plate ...............................................................................26

4.11 Lifting Machine ....................................................................................27

4.12 Transporting Machine ..........................................................................28

4.13 Storage ................................................................................................28

4.14 Troubleshooting ...................................................................................29

wc_tx000001gb.fm 3

CALIFORNIA

Proposition 65 Warning:

Engine exhaust, some of its constituents, and certain vehicle

components, contain or emit chemicals known to the State of

California to cause cancer and birth defects or other reproductive

harm.

Foreword

This manual provides information and procedures to safely operate

and maintain this Wacker Neuson model. For your own safety and

protection from injury, carefully read, understand and observe the

safety instructions described in this manual.

Keep this manual or a copy of it with the machine. If you lose this

manual or need an additional copy, please contact Wacker Neuson

Corporation. This machine is built with user safety in mind; however,

it can present hazards if improperly operated and serviced. Follow

operating instructions carefully! If you have questions about operating

or servicing this equipment, please contact Wacker Neuson

Corporation.

The information contained in this manual was based on machines in

production at the time of publication. Wacker Neuson Corporation

reserves the right to change any portion of this information without

notice.

All rights, especially copying and distribution rights, are reserved.

No part of this publication may be reproduced in any form or by any

means, electronic or mechanical, including photocopying, without

express written permission from Wacker Neuson Corporation.

Any type of reproduction or distribution not authorized by Wacker

Neuson Corporation represents an infringement of valid copyrights

and will be prosecuted. We expressly reserve the right to make

technical modifications, even without due notice, which aim at

improving our machines or their safety standards.

WARNING

Safety Information VP 2050A/AW

wpm_si000310gb.fm 4

1. Safety Information

This manual contains DANGER, WARNING, CAUTION, NOTICE, and

NOTE callouts which must be followed to reduce the possibility of

personal injury, damage to the equipment, or improper service.

This is the safety alert symbol. It is used to alert you to potential

personal injury hazards. Obey all safety messages that follow this

symbol to avoid possible injury or death.

DANGER indicates a hazardous situation which, if not avoided, will

result in death or serious injury.

WARNING indicates a hazardous situation which, if not avoided, could

result in death or serious injury.

CAUTION indicates a hazardous situation which, if not avoided, could

result in minor or moderate injury.

NOTICE:Used without the safety alert symbol, NOTICE indicates a

situation which, if not avoided, could result in property damage.

Note: Contains additional information important to a procedure.

DANGER

WARNING

CAUTION

VP 2050A/AW Safety Information

wpm_si000310gb.fm 5

1.1 Laws Pertaining to Spark Arresters

Notice: State Health Safety Codes and Public Resources Codes

specify that in certain locations spark arresters be used on internal

combustion engines that use hydrocarbon fuels. A spark arrester is a

device designed to prevent accidental discharge of sparks or flames

from the engine exhaust. Spark arresters are qualified and rated by

the United States Forest Service for this purpose.

In order to comply with local laws regarding spark arresters, consult

the engine distributor or the local Health and Safety Administrator.

Safety Information VP 2050A/AW

wpm_si000310gb.fm 6

1.2 Operating Safety

Familiarity and proper training are required for the safe operation of the

machine. Machines operated improperly or by untrained personnel

can be hazardous. Read the operating instructions contained in this

manual and the engine manual, and familiarize yourself with the

location and proper use of all controls. Inexperienced operators should

receive instruction from someone familiar with the machine before

being allowed to operate it.

1.2.1 Do not allow anyone to operate this equipment without proper training.

People operating this equipment must be familiar with the risks and

hazards associated with it.

1.2.2 Do not touch the engine or muffler while the engine is on or

immediately after it has been turned off. These areas get hot and may

cause burns.

1.2.3 Do not use accessories or attachments that are not recommended by

Wacker Neuson. Damage to equipment and injury to the user may

result.

1.2.4 NEVER operate the machine with the beltguard missing. Exposed

drive belt and pulleys create potentially dangerous hazards that can

cause serious injuries.

1.2.5 Never leave the machine running unattended.

1.2.6 Be sure operator is familiar with proper safety precautions and

operation techniques before using machine.

1.2.7 Always wear protective clothing appropriate to the job site when

operating the machine.

1.2.8 Wear hearing protection when operating equipment.

1.2.9 Close fuel valve on engines equipped with one when machine is not

being operated.

1.2.10 Store the machine properly when it is not being used. The machine

should be stored in a clean, dry location out of the reach of children.

1.2.11 Always operate machine with all safety devices and guards in place

and in working order. Do not modify or defeat safety devices. Do not

operate machine if any safety devices or guards are missing or

inoperative.

1.2.12 Read, understand, and follow procedures in the Operator’s Manual

before attempting to operate the machine.

WARNING

VP 2050A/AW Safety Information

wpm_si000310gb.fm 7

1.3 Operator Safety while using Internal Combustion Engines

Internal combustion engines present special hazards during operation

and fueling. Read and follow the warning instructions in the engine

owner’s manual and the safety guidelines below. Failure to follow the

warnings and safety standards could result in severe injury or death.

1.3.1 DO NOT run the machine indoors or in an enclosed area such as a

deep trench unless adequate ventilation, through such items as

exhaust fans or hoses, is provided. Exhaust gas from the engine

contains poisonous carbon monoxide gas; exposure to carbon

monoxide can cause loss of consciousness and may lead to death.

1.3.2 Do not smoke while operating the machine.

1.3.3 Do not smoke when refueling the engine.

1.3.4 Do not refuel a hot or running engine.

1.3.5 Do not refuel the engine near an open flame.

1.3.6 Do not spill fuel when refueling the engine.

1.3.7 Do not run the engine near open flames.

1.3.8 Refill the fuel tank in a well-ventilated area.

1.3.9 Replace the fuel tank cap after refueling.

1.3.10 ALWAYS check the fuel lines and the fuel tank for leaks and cracks

before starting the engine. Do not run the machine if fuel leaks are

present or the fuel lines are loose.

WARNING

Safety Information VP 2050A/AW

wpm_si000310gb.fm 8

1.4 Service Safety

A poorly maintained machine can become a safety hazard! In order

for the machine to operate safely and properly over a long period of

time, periodic maintenance and occasional repairs are necessary.

1.4.1 Do not attempt to clean or service the machine while it is running.

Rotating parts can cause severe injury.

1.4.2 Do not crank a flooded engine with the spark plug removed on

gasoline-powered engines. Fuel trapped in the cylinder will squirt out

the spark plug opening.

1.4.3 Do not test for spark on gasoline-powered engines if the engine is

flooded or the smell of gasoline is present. A stray spark could ignite

the fumes.

1.4.4 Do not use gasoline or other types of fuels or flammable solvents to

clean parts, especially in enclosed areas. Fumes from fuels and

solvents can become explosive.

1.4.5 Keep the area around the muffler free of debris such as leaves, paper,

cartons, etc. A hot muffler could ignite the debris and start a fire.

1.4.6 Replace worn or damaged components with spare parts designed and

recommended by Wacker Neuson Corporation.

1.4.7 Disconnect the spark plug on machines equipped with gasoline

engines, before servicing, to avoid accidental start-up.

1.4.8 Keep the machine clean and labels legible. Replace all missing and

hard-to-read labels. Labels provide important operating instructions

and warn of dangers and hazards.

WARNING

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Wacker Neuson Outils électriques

Wacker Neuson

Wacker Neuson BPU 4045 Manuel utilisateur

Wacker Neuson

Wacker Neuson BS 60-2i Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 2440F WGB Manuel utilisateur

Wacker Neuson

Wacker Neuson BH 65 Manuel utilisateur

Wacker Neuson

Wacker Neuson ARFU 36/6/120 Manuel utilisateur

Wacker Neuson

Wacker Neuson AR 75/3/200/400 Manuel utilisateur

Wacker Neuson

Wacker Neuson BS 60-2i Manuel utilisateur

Wacker Neuson

Wacker Neuson P 35A Manuel utilisateur

Wacker Neuson

Wacker Neuson WP Series Manuel utilisateur

Wacker Neuson

Wacker Neuson BS 60-4s Manuel utilisateur

Wacker Neuson

Wacker Neuson BS 50-2 Manuel utilisateur

Wacker Neuson

Wacker Neuson VP1030A-CE Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 130Le Manuel utilisateur

Wacker Neuson

Wacker Neuson BS 65-V Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU80 Series Manuel utilisateur

Wacker Neuson

Wacker Neuson BPU 2540A Manuel utilisateur

Wacker Neuson

Wacker Neuson APS1030 Manuel utilisateur

Wacker Neuson

Wacker Neuson BS 50-2 Manuel utilisateur

Wacker Neuson

Wacker Neuson PV 35A Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 4045H Manuel utilisateur

Wacker Neuson

Wacker Neuson EH 27/115 Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 2950 Manuel utilisateur

Wacker Neuson

Wacker Neuson BH 22 Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 6555He Manuel utilisateur

Manuels Outils électriques populaires d'autres marques

AEG

AEG OMNI-JS Manuel utilisateur

SIP

SIP 01533 Manuel utilisateur

Ribimex

Ribimex PRS499 Manuel utilisateur

3M Fiber Optic Connector Crimp Tool Manuel utilisateur

Ryobi

Ryobi P524 Manuel utilisateur

ROJEK

ROJEK FSN 300A Manuel utilisateur

Kemper

Kemper 1740PRO Manuel utilisateur

WABCO

WABCO OptiTire Manuel utilisateur

EINHELL

EINHELL TE-MS 18/210 Li Manuel utilisateur

Orgapack

Orgapack OR-T 85 Guide rapide

TOUGHCUT

TOUGHCUT Diamond 400 Manuel utilisateur

Yaros

Yaros PB-3603 Manuel utilisateur

Fein

Fein BSS 2.0 E Guide de configuration

Baileigh Industrial

Baileigh Industrial SS-2725 Manuel utilisateur

Milwaukee

Milwaukee 2674-20 Manuel utilisateur

Fein

Fein BLs 1.6 Manuel utilisateur

Princess

Princess Electric Multi Sharpener Manuel utilisateur

FOREDOM

FOREDOM K.1050 Manuel
