Operator’s Manual
Vibroplate
WP 1030A
0402342en 001 0110
0402342EN
Copyright
notice
© Copyright 2010 by Wacker Neuson Corporation.
All rights, including copying and distribution rights, are reserved.
This publication may be photocopied by the original purchaser of the machine. Any
other type of reproduction is prohibited without express written permission from
Wacker Neuson Corporation.
Any type of reproduction or distribution not authorized by Wacker Neuson Corporation
represents an infringement of valid copyrights. Violators will be prosecuted.
Trademarks
All trademarks referenced in this manual are the property of their respective owners.
Manufacturer
Wacker Neuson Manila Incorporated
Lot 2,Blk 1 Phase 3, PEZA Drive, First Cavite Industrial Estate, Brgy. Langkaan
Dasmariñas, Cavite, Philippines
Tel: +63-(0)2-580-7136 Fax: +63-(0)2-580-7122
www.wackerneuson.com
Translated
instructions
This Operator’s Manual presents a translation of the original instructions. The original
language of this Operator’s Manual is American English.
WP 1030A Table of Contents
wpm_bo0402342001enTOC.fm 1
Foreword 3
1. Safety Information 4
1.1 Laws Pertaining to Spark Arresters ...................................................... 5
1.2 Operating Safety .................................................................................. 6
1.3 Operator Safety while using Internal Combustion Engines .................. 7
1.4 Service Safety ...................................................................................... 8
1.5 Label Locations .................................................................................... 9
1.6 Warning and Informational Labels ...................................................... 10
2. Technical Data 13
2.1 Engine Data ........................................................................................ 13
2.2 Machine Data ..................................................................................... 14
2.3 Sound and Vibration Measurements .................................................. 14
2.4 Dimensions ......................................................................................... 15
3. Operation 16
3.1 Recommended Fuel ........................................................................... 16
3.2 Application .......................................................................................... 16
3.3 Before Starting ................................................................................... 16
3.4 To Start ............................................................................................... 17
3.5 To Stop ............................................................................................... 17
3.6 Operation ............................................................................................ 18
Table of Contents WP 1030A
wpm_bo0402342001enTOC.fm 2
4. Maintenance 19
4.1 Periodic Maintenance Schedule ..........................................................19
4.2 Spark Plug ...........................................................................................21
4.3 Air Cleaner ..........................................................................................22
4.4 Engine Oil ............................................................................................23
4.5 Adjusting Engine Speed ......................................................................23
4.6 Carburetor Adjustment ........................................................................24
4.7 Cleaning Sediment Cup ......................................................................24
4.8 Protection frame ..................................................................................25
4.9 Exciter Lubrication ...............................................................................26
4.10 Cleaning the Plate ...............................................................................26
4.11 Lifting Machine ....................................................................................27
4.12 Transporting Machine ..........................................................................28
4.13 Storage ................................................................................................28
4.14 Troubleshooting ...................................................................................29
wc_tx000001gb.fm 3
CALIFORNIA
Proposition 65 Warning:
Engine exhaust, some of its constituents, and certain vehicle
components, contain or emit chemicals known to the State of
California to cause cancer and birth defects or other reproductive
harm.
Foreword
This manual provides information and procedures to safely operate
and maintain this Wacker Neuson model. For your own safety and
protection from injury, carefully read, understand and observe the
safety instructions described in this manual.
Keep this manual or a copy of it with the machine. If you lose this
manual or need an additional copy, please contact Wacker Neuson
Corporation. This machine is built with user safety in mind; however,
it can present hazards if improperly operated and serviced. Follow
operating instructions carefully! If you have questions about operating
or servicing this equipment, please contact Wacker Neuson
Corporation.
The information contained in this manual was based on machines in
production at the time of publication. Wacker Neuson Corporation
reserves the right to change any portion of this information without
notice.
All rights, especially copying and distribution rights, are reserved.
Copyright 2010 by Wacker Neuson Corporation.
No part of this publication may be reproduced in any form or by any
means, electronic or mechanical, including photocopying, without
express written permission from Wacker Neuson Corporation.
Any type of reproduction or distribution not authorized by Wacker
Neuson Corporation represents an infringement of valid copyrights
and will be prosecuted. We expressly reserve the right to make
technical modifications, even without due notice, which aim at
improving our machines or their safety standards.
WARNING
Safety Information WP 1030A
wpm_si000443gb.fm 4
1. Safety Information
This manual contains DANGER, WARNING, CAUTION, NOTICE,
and NOTE signal words which must be followed to reduce the
possibility of personal injury, damage to the equipment, or improper
service.
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER indicates a hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
NOTICE: Used without the safety alert symbol, NOTICE indicates a
situation which, if not avoided, could result in property damage.
Note: Contains additional information important to a procedure.
DANGER
WARNING
CAUTION
WP 1030A Safety Information
wpm_si000443gb.fm 5
1.1 Laws Pertaining to Spark Arresters
Notice: State Health Safety Codes and Public Resources Codes
specify that in certain locations spark arresters be used on internal
combustion engines that use hydrocarbon fuels. A spark arrester is a
device designed to prevent accidental discharge of sparks or flames
from the engine exhaust. Spark arresters are qualified and rated by
the United States Forest Service for this purpose.
In order to comply with local laws regarding spark arresters, consult
the engine distributor or the local Health and Safety Administrator.
Safety Information WP 1030A
wpm_si000443gb.fm 6
1.2 Operating Safety
Familiarity and proper training are required for the safe operation of the
machine. Machines operated improperly or by untrained personnel
can be hazardous. Read the operating instructions contained in this
manual and the engine manual, and familiarize yourself with the
location and proper use of all controls. Inexperienced operators should
receive instruction from someone familiar with the machine before
being allowed to operate it.
1.2.1 Do not allow anyone to operate this equipment without proper training.
People operating this equipment must be familiar with the risks and
hazards associated with it.
1.2.2 Do not touch the engine or muffler while the engine is on or
immediately after it has been turned off. These areas get hot and may
cause burns.
1.2.3 Do not use accessories or attachments that are not recommended by
Wacker Neuson. Damage to equipment and injury to the user may
result.
1.2.4 NEVER operate the machine with the beltguard missing. Exposed
drive belt and pulleys create potentially dangerous hazards that can
cause serious injuries.
1.2.5 Never leave the machine running unattended.
1.2.6 Be sure operator is familiar with proper safety precautions and
operation techniques before using machine.
1.2.7 Always wear protective clothing appropriate to the job site when
operating the machine.
1.2.8 Wear hearing protection when operating equipment.
1.2.9 Close fuel valve on engines equipped with one when machine is not
being operated.
1.2.10 Store the machine properly when it is not being used. The machine
should be stored in a clean, dry location out of the reach of children.
1.2.11 Always operate machine with all safety devices and guards in place
and in working order. Do not modify or defeat safety devices. Do not
operate machine if any safety devices or guards are missing or
inoperative.
1.2.12 Read, understand, and follow procedures in the Operator’s Manual
before attempting to operate the machine.
WARNING
WP 1030A Safety Information
wpm_si000443gb.fm 7
1.3 Operator Safety while using Internal Combustion Engines
Internal combustion engines present special hazards during operation
and fueling. Read and follow the warning instructions in the engine
owner’s manual and the safety guidelines below. Failure to follow the
warnings and safety standards could result in severe injury or death.
1.3.1 DO NOT run the machine indoors or in an enclosed area such as a
deep trench unless adequate ventilation, through such items as
exhaust fans or hoses, is provided. Exhaust gas from the engine
contains poisonous carbon monoxide gas; exposure to carbon
monoxide can cause loss of consciousness and may lead to death.
1.3.2 Do not smoke while operating the machine.
1.3.3 Do not smoke when refueling the engine.
1.3.4 Do not refuel a hot or running engine.
1.3.5 Do not refuel the engine near an open flame.
1.3.6 Do not spill fuel when refueling the engine.
1.3.7 Do not run the engine near open flames.
1.3.8 Refill the fuel tank in a well-ventilated area.
1.3.9 Replace the fuel tank cap after refueling.
1.3.10 ALWAYS check the fuel lines and the fuel tank for leaks and cracks
before starting the engine. Do not run the machine if fuel leaks are
present or the fuel lines are loose.
WARNING
Safety Information WP 1030A
wpm_si000443gb.fm 8
1.4 Service Safety
A poorly maintained machine can become a safety hazard! In order
for the machine to operate safely and properly over a long period of
time, periodic maintenance and occasional repairs are necessary.
1.4.1 Do not attempt to clean or service the machine while it is running.
Rotating parts can cause severe injury.
1.4.2 Do not crank a flooded engine with the spark plug removed on
gasoline-powered engines. Fuel trapped in the cylinder will squirt out
the spark plug opening.
1.4.3 Do not test for spark on gasoline-powered engines if the engine is
flooded or the smell of gasoline is present. A stray spark could ignite
the fumes.
1.4.4 Do not use gasoline or other types of fuels or flammable solvents to
clean parts, especially in enclosed areas. Fumes from fuels and
solvents can become explosive.
1.4.5 Keep the area around the muffler free of debris such as leaves, paper,
cartons, etc. A hot muffler could ignite the debris and start a fire.
1.4.6 Replace worn or damaged components with spare parts designed and
recommended by Wacker Neuson Corporation.
1.4.7 Disconnect the spark plug on machines equipped with gasoline
engines, before servicing, to avoid accidental start-up.
1.4.8 Keep the machine clean and labels legible. Replace all missing and
hard-to-read labels. Labels provide important operating instructions
and warn of dangers and hazards.
WARNING
Table des matières
Autres manuels Wacker Neuson Outils électriques
Wacker Neuson
Wacker Neuson WP Series Manuel utilisateur
Wacker Neuson
Wacker Neuson BPU 4045 Manuel utilisateur
Wacker Neuson
Wacker Neuson ARFU 36/6/120 Manuel utilisateur
Wacker Neuson
Wacker Neuson DPU 5545He Manuel utilisateur
Wacker Neuson
Wacker Neuson DPU 7060SC Manuel utilisateur
Wacker Neuson
Wacker Neuson DPU 4545 Manuel utilisateur
Wacker Neuson
Wacker Neuson VP1340A US Manuel utilisateur
Wacker Neuson
Wacker Neuson DPU Series Manuel utilisateur
Wacker Neuson
Wacker Neuson BH24 Manuel utilisateur
Wacker Neuson
Wacker Neuson BS 50-4 Manuel utilisateur
Wacker Neuson
Wacker Neuson BS 60-4s Manuel utilisateur
Wacker Neuson
Wacker Neuson IREN 38 Manuel utilisateur
Wacker Neuson
Wacker Neuson DPU 25 Series Manuel utilisateur
Wacker Neuson
Wacker Neuson BPU 2440 series Mode d'emploi
Wacker Neuson
Wacker Neuson VP2050A US Manuel utilisateur
Wacker Neuson
Wacker Neuson BPS1030 Manuel utilisateur
Wacker Neuson
Wacker Neuson EH 9 BL/230 Manuel utilisateur
Wacker Neuson
Wacker Neuson BPU 3545A Manuel utilisateur
Wacker Neuson
Wacker Neuson DPU 2440F WGB Manuel utilisateur
Wacker Neuson
Wacker Neuson VPY70 Manuel utilisateur
