Wacker Neuson BS 60-4s Manuel utilisateur

0170873en 001 0410

0170873EN

Operator’s Manual

Rammer

BS 60-4s

notice

All rights, including copying and distribution rights, are reserved.

This publication may be photocopied by the original purchaser of the machine. Any

other type of reproduction is prohibited without express written permission from

Wacker Neuson Corporation.

Any type of reproduction or distribution not authorized by Wacker Neuson Corporation

represents an infringement of valid copyrights. Violators will be prosecuted.

Trademarks

All trademarks referenced in this manual are the property of their respective owners.

Manufacturer

Wacker Neuson Corporation

N92W15000 Anthony Avenue

Menomonee Falls, WI 53051 U.S.A.

Tel: (262) 255-0500 · Fax: (262) 255-0550 · Tel: (800) 770-0957

www.wackerneuson.com

Original

instructions

This Operator’s Manual presents the original instructions. The original language of this

Operator’s Manual is American English.

Foreword

wc_tx001489gb.fm 3

Foreword

Machines

covered by

this manual

Machine

documentation

Keep a copy of the Operator’s Manual with the machine at all times.

Use the separate Parts Book supplied with the machine to order replacement

parts.

Refer to the separate Repair Manual for detailed instructions on servicing and

repairing the machine.

If you are missing any of these documents, please contact Wacker Neuson

Corporation to order a replacement or visit www.wackerneuson.com.

When ordering parts or requesting service information, be prepared to provide

the machine model number, item number, revision number, and serial number.

Expectations

for

information in

this manual

This manual provides information and procedures to safely operate and

maintain the above Wacker Neuson model(s). For your own safety and to

reduce the risk of injury, carefully read, understand, and observe all instructions

described in this manual.

Wacker Neuson Corporation expressly reserves the right to make technical

modifications, even without notice, which improve the performance or safety

standards of its machines.

The information contained in this manual is based on machines manufactured

up until the time of publication. Wacker Neuson Corporation reserves the right

to change any portion of this information without notice.

CALIFORNIA

Proposition

65 Warning

Engine exhaust, some of its constituents, and certain vehicle components, contain

or emit chemicals known to the State of California to cause cancer and birth

defects or other reproductive harm.

Laws

pertaining to

spark

arresters

NOTICE: State Health Safety Codes and Public Resources Codes specify that in

certain locations spark arresters be used on internal combustion engines that use

hydrocarbon fuels. A spark arrester is a device designed to prevent accidental dis-

charge of sparks or flames from the engine exhaust. Spark arresters are qualified

and rated by the United States Forest Service for this purpose. In order to comply

with local laws regarding spark arresters, consult the engine distributor or the local

Health and Safety Administrator.

Manufacturer’s

approval

This manual contains references to approved parts, attachments, and

modifications. The following definitions apply:

Machine Item Number

BS 60-4s 0620073

0620813

0620323

0620387

0620388

0620816

0620819

0620820

Foreword

4 wc_tx001489gb.fm

Approved parts or attachments are those either manufactured or provided by

Wacker Neuson.

Approved modifications are those performed by an authorized Wacker

Neuson service center according to written instructions published by Wacker

Neuson.

Unapproved parts, attachments, and modifications are those that do not

meet the approved criteria.

Unapproved parts, attachments, or modifications may have the following

consequences:

Serious injury hazards to the operator and persons in the work area

Permanent damage to the machine which will not be covered under warranty

Contact your Wacker Neuson dealer immediately if you have questions about

approved or unapproved parts, attachments, or modifications.

BS 60-4s Table of Contents

wc_bo0170873en_001TOC.fm 5

Foreword 3

1 Emission Control System Information 7

2 Safety Information 14

2.1 Signal Words Found in this Manual .................................................... 14

2.2 Machine Description and Intended Use ............................................. 15

2.3 Operating Safety ................................................................................ 16

2.4 Operator Safety while using Internal Combustion Engines ................ 18

2.5 Service Safety .................................................................................... 19

3 Labels 22

3.1 Label Locations .................................................................................. 22

3.2 Label Meanings .................................................................................. 23

4 Lifting and Transporting 27

4.1 Lifting and Transporting the Machine ................................................. 27

5 Operation 28

5.1 Preparing the Machine for First Use ................................................... 28

5.2 Recommended Fuel ........................................................................... 28

5.3 Position of the Operator ..................................................................... 29

5.4 Before Starting ................................................................................... 30

5.5 To Start ............................................................................................... 30

5.6 To Stop ............................................................................................... 31

5.7 Low Oil Shutoff Switch ....................................................................... 32

5.8 Emergency Shutdown Procedure ....................................................... 32

Table of Contents BS 60-4, BS 60-4s

6 wc_bo0170873en_001TOC.fm

6 Maintenance 33

6.1 Periodic Maintenance Schedule ..........................................................33

6.2 Servicing Air Cleaner ...........................................................................34

6.3 Engine Oil ............................................................................................35

6.4 Checking and Changing the Ramming System Oil .............................36

6.5 Shoe Hardware ...................................................................................38

6.6 Long-Term Storage .............................................................................39

7 Basic Troubleshooting 41

8 Tech Data 43

8.1 Rammer ...............................................................................................43

8.2 Sound Measurements .........................................................................44

8.3 Vibration Measurements .....................................................................44

8.4 Dimensions ..........................................................................................45

Emission Control System Information

wc_tx000369gb.fm 7

1 Emission Control System Information

Source of Emissions

The combustion process produces carbon monoxide, oxides of

nitrogen, and hydrocarbons. Control of hydrocarbons and oxides of

nitrogen is very important because, under certain conditions, they

react to form photochemical smog when subjected to sunlight. Carbon

monoxide does not react in the same way, but it is toxic.

Wacker Neuson utilizes lean carburetor settings and other systems to

reduce the emissions of carbon monoxide, oxides of nitrogen, and

hydrocarbons.

The U.S. and California Clean Air Acts

EPA and California regulations require all manufacturers to furnish

written instructions describing the operation and maintenance of

emission control systems.

The following instructions and procedures must be followed in order to

keep the emissions from your Wacker Neuson engine within the

emissions standards.

Tampering and Altering

Tampering with or altering the emission control system may increase

emissions beyond the legal limit. Among those acts that constitute

tampering are:

•Removal or alteration of any part of the intake, fuel, or exhaust

systems.

•Altering or defeating the speed-adjusting mechanism to cause the

engine to operate outside its design parameters.

Problems That May Affect Emissions

If you are aware of any of the following symptoms, have your engine

inspected and repaired by your servicing dealer.

•Hard starting or stalling after starting.

•Rough idle.

•Misfiring or backfiring under load.

•Afterburning (backfiring).

•Black exhaust smoke or high fuel consumption.

Emission Control System Information

8 wc_tx000369gb.fm

Replacement Parts

The emission control systems on your Wacker Neuson engine were

designed, built, and certified to conform with EPA and California

emissions regulations. We recommend the use of genuine Wacker

Neuson parts whenever you have maintenance done. These original-

design replacement parts are manufactured to the same standards as

the original parts, so you can be confident of their performance. The

use of replacement parts that are not of the original design and quality

may impair the effectiveness of your emission control system.

A manufacturer of an aftermarket part assumes the responsibility that

the part will not adversely affect emission performance. The

manufacturer or rebuilder of the part must certify that use of the part

will not result in a failure of the engine to comply with emission

regulations.

Maintenance

Follow the maintenance schedule. Remember that this schedule is

based on the assumption that your machine will be used for its

designed purpose. Sustained high-load or high-temperatureoperation,

or use in unusually wet or dusty conditions, will require more frequent

service.

OXYGENATED FUELS

Some conventional gasolines are being blended with alcohol or an

ether compound. These gasolines are collectively referred to as

oxygenated fuels. To meet clean air standards, some areas of the

United States and Canada use oxygenated fuels to help reduce

emissions.

If you use an oxygenated fuel, be sure it is unleaded and meets the

minimum octane rating requirement.

Before using an oxygenated fuel, try to confirm the fuel’s contents.

Some States / Provinces require this information to be posted on the

pump.

The following are EPA-approved percentages of oxygenates:

ETHANOL - (ethyl or grain alcohol) 10% by volume. You may use

gasoline containing up to 10% ethanol by volume. Gasoline containing

ethanol may be marketed under the name “Gasohol”. E85 fuel should

never be used, as it is an alternative fuel containing 85% ethanol, 15%

gasoline.

MTBE - (methyl tertiary butyl ether) 15% by volume. You may use

gasoline containing up to 15% MTBE by volume.

Emission Control System Information

wc_tx000369gb.fm 9

METHANOL - (methyl or wood alcohol) 5% by volume. You may use

gasoline containing up to 5% methanol by volume, as long as it

contains cosolvents and corrosion inhibitors to protect the fuel system.

Gasoline containing more than 5% methanol by volume may cause

starting and/or performance problems. It may also damage metal,

rubber, and plastic parts of your fuel system.

If you notice any undesirable operating symptoms, try another service

station, or switch to another brand of gasoline.

Fuel system damage or performance problems resulting from the use

of an oxygenated fuel containing more than the percentages of

oxygenates mentioned above are not covered under warranty.

Emission Control System Information

10 wc_tx000369gb.fm

EMISSIONS COMPONENT DEFECT WARRANTY COVERAGE

This emission warranty is applicable in all States.

Wacker Neuson Corporation, N92 W15000 Anthony Avenue,

Menomonee Falls, WI 53051-1504, (herein "Wacker Neuson")

warrant(“s”) to the initial retail purchaser and each subsequent owner,

that this non-road engine (herein "engine") has been designed, built,

and equipped to conform at the time of initial sale to all applicable

regulations of the U.S. Environmental Protection Agency (EPA), and

that the engine is free of defects in materials and workmanship which

would cause this engine to fail to conform with EPA regulations during

its warranty period.

For the components listed under PARTS COVERED, the service

dealer authorized by Wacker Neuson will, at no cost to you, make the

necessary diagnosis, repair, or replacement necessary to ensure that

the engine complies with applicable U.S. EPA regulations.

EMISSISON COMPONENT DEFECT WARRANTY PERIOD

The warranty period for this engine begins on the date of sale to the

initial purchaser and continues for a period of 2 years.

Autres manuels pour BS 60-4s

Table des matières

Autres manuels Wacker Neuson Outils électriques

Wacker Neuson

Wacker Neuson bs65y Manuel utilisateur

Wacker Neuson

Wacker Neuson BS 50 Mode d'emploi

Wacker Neuson

Wacker Neuson BH23 Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 2950 Manuel utilisateur

Wacker Neuson

Wacker Neuson BPU 2950A Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 2440F WGB Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 25 Series Manuel utilisateur

Wacker Neuson

Wacker Neuson BS 50-4s Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 4545 Manuel utilisateur

Wacker Neuson

Wacker Neuson BPS1030A Manuel utilisateur

Wacker Neuson

Wacker Neuson WP 1030A Manuel utilisateur

Wacker Neuson

Wacker Neuson AR 36 Series Manuel utilisateur

Wacker Neuson

Wacker Neuson BH24 Manuel utilisateur

Wacker Neuson

Wacker Neuson P 35A Manuel utilisateur

Wacker Neuson

Wacker Neuson BS 50-4 Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 3050H Manuel utilisateur

Wacker Neuson

Wacker Neuson BPU 3050A Manuel utilisateur

Wacker Neuson

Wacker Neuson DS720 Manuel utilisateur

Wacker Neuson

Wacker Neuson EH 27/115 Manuel utilisateur

Wacker Neuson

Wacker Neuson APS1030 Manuel utilisateur

Wacker Neuson

Wacker Neuson AR 75/3/200/400 Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 6055 Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 130Le Manuel utilisateur

Wacker Neuson

Wacker Neuson DPU 4545 Manuel utilisateur

Manuels Outils électriques populaires d'autres marques

AEG

AEG OMNI-JS Manuel utilisateur

SIP

SIP 01533 Manuel utilisateur

Ribimex

Ribimex PRS499 Manuel utilisateur

3M Fiber Optic Connector Crimp Tool Manuel utilisateur

Ryobi

Ryobi P524 Manuel utilisateur

ROJEK

ROJEK FSN 300A Manuel utilisateur

Kemper

Kemper 1740PRO Manuel utilisateur

WABCO

WABCO OptiTire Manuel utilisateur

EINHELL

EINHELL TE-MS 18/210 Li Manuel utilisateur

Orgapack

Orgapack OR-T 85 Guide rapide

TOUGHCUT

TOUGHCUT Diamond 400 Manuel utilisateur

Yaros

Yaros PB-3603 Manuel utilisateur

Fein

Fein BSS 2.0 E Guide de configuration

Baileigh Industrial

Baileigh Industrial SS-2725 Manuel utilisateur

Milwaukee

Milwaukee 2674-20 Manuel utilisateur

Fein

Fein BLs 1.6 Manuel utilisateur

Princess

Princess Electric Multi Sharpener Manuel utilisateur

FOREDOM

FOREDOM K.1050 Manuel
