FAQ

MotionMount NEXT 7355

Q. What is the minimum screen size of the TV in combination with the

MotionMount?

A. The minimum screen size is 40 inch (102 cm).

Q. What is the maximum screen size of the TV in combination with the

MotionMount?

A. The maximum screen size is 65 inch (165 cm), with a maximum weight

of 30 kg. The Screen Protection System (SPS

) with anti-bump is active

up to a screen size of 65 inch.

Q. Does the MotionMount have a tilt function?

A. There is no tilt in the MotionMount.

Q. Can the DesignMount NEXT 7345 be upgraded to MotionMount?

A. No, that’s not possible.

Q. What is the guarantee of the MotionMount?

A. The guarantee is 2 years for the motor units and electronics.

Q. Is the drilling template of the SoundMount the same as of the

DesignMount (NEXT 7345)?

A. Yes, the drilling template is the same for all NEXT Series products.

Q. Do I need to adjust settings to my TV after installing the MotionMount?

A. No special settings are required.

Q. Is the MotionMount provided with a remote control?

A. No, there is no dedicated remote control needed. The TV automatically

turns to the viewer (last position) when TV is switched on and

automatically returns to the wall position when TV is switched to standby.

For additional functionality, MotionMount App can be downloaded from

App Store / Google Play free of charge.

Q. How many wall sockets for powering the TV and the MotionMount do I

need?

A. You only need one wall socket. Integrated ‘power distribution’ is part of

the MotionMount proposition.

January 2017

Q. Can I use the Vogel’s cable cover NEXT 7840 together with the

MotionMount?

A. Yes, the NEXT 7840 cable cover can also be used in combination with

the MotionMount. Please mount the MotionMount at a height of 116 cm

from the floor.

Q. Are all cables and mounting materials included in the MotionMount

packaging?

A. Yes, all cables and mounting materials are included.

Q. What is the standby power consumption of the MotionMount electronics?

A. The standby power consumption of the MotionMount electronics is less

than 0.5 Watt.

Q. What mains voltage range and frequency are suitable for the

MotionMount?

A. The mains (AC) voltage range of the MotionMount is 220 – 240 Volt, 50 /

60 Hz.

Q. Does the App control make use of Bluetooth connection with the

MotionMount?

A. Indeed, the App control makes use of Bluetooth 4.0 connection. The

Bluetooth of your smartphone / tablet needs to be switched on while

using the App.

Q. Do I need to connect my TV power socket to the power cable from the

MotionMount?

A. Yes, you need to connect the power socket of the TV with the power

cable from the MotionMount. This makes that TV is automatically moving

to last position when switching on the TV and is automatically moving

back to the wall when TV is switched off.

Q. How many preset positions can be stored with the App?

A. Up to ten preset positions can be stored.

Q. Which devices support the MotionMount App?

A. Apple devices with iOS 8 and higher, with Bluetooth (iPhone: 4S and

newer, iPad: 2 and newer, iPad Air: 1 and newer, iPad Mini: 1 and

newer, iPod Touch) and devices with Android 4.3 (Jelly Bean / v18) and

higher, with Bluetooth (smart phones and tablets from HTC, Huawei, LG,

Samsung, Sony).

Q. Is it possible to turn the TV manually (‘manual override’)?

A. Yes, due to the integrated slip-hinge, it is possible to turn the TV

manually.

Q. What is the maximum distance the TV can move from the wall?

A. The maximum distance from the wall is 72 cm.

January 2017

Q. What is the maximum turn angle?

A. The maximum turn angle is 120˚ (2x 60˚).

Q. Is there any risk for trapping, squeezing or injury to people while mount is

moving automatically?

A. The integrated slip-hinge and electronic protection circuit (which switches

off the motors in case of too much friction), pinching will be prevented.
