Verifone VX805 Integration Guide

Note: Before this integration can begin, you will need your VAR sheet or Setup letter from

Verifone. If you do not have this information, you can contact Verifone on 1-800-VERIFONE.

This integration is only compatible with Windows till systems.

Installing the app

1. Log in to your Epos Now Back Office

2. Head to Apps along the left-hand side

3. Use your touchscreen keyboard to bring up the URL bar by pressing CTRL + F12

4. Select any app showing on the home screen of the app page - you will see an address in

the URL bar with some numbers at the end

5. Remove the numbers from the end of this URL and replace them with 253

6. Press enter on your keyboard

7. Install the Mercury EMV app (this app is free to install)

This completes the installation of the payment app on your till software.

Activating the app

1. Log in to your Epos Now Back Office

2. Head to the Setup tab (top left corner)

3. Select Locations

4. Select Locations and Devices

5. Scroll to the right on your location, select Show Devices

6. Locate the device you wish to connect the card reader to, select Edit

7. Scroll to the right, tick the Mercury tick box

8. Scroll to the left, select Update

Mercury will now show as enabled on the device.

Configuring the card reader

Downloading the card reader software

Click here to download the software. Follow the steps below to continue with the installation:

1. You will see the folder downloading in the bottom left hand corner, select the download

2. Select open and run

3. Locate NETePay on the desktop, right click (you can right click using a touchscreen by

holding down for a few seconds, release and the right click menu will appear) and select

open

4. On the popup, select Obtain Serial Number

5. Select OK on the next popup

6. Select Setup (top right corner)

7. Select Setup Information

8. Select Load New Parameters (bottom right corner)

9. Select YES on the popup

10. Select I have my Deployment ID

11. Enter the Deployment ID from your VAR sheet or Setup letter

12. Select OK

13. Confirm that your Merchant Information is correct. If the information is correct, select

Yes, This is the Correct Merchant. If the information is incorrect, select cancel and

contact Verifone for a new Deployment ID (you will be unable to continue with the

integration until you have the correct Deployment ID)

14. NETePay will now refresh and load the parameters, exit the Setup Parameters popup

and minimize the NETePay page

Editing the config files

1. Select the Windows Icon in the bottom left corner

2. Locate and select File Explorer

3. Select C/: Drive Epos Now (on the left)

4. Double click the Program Files (x86) folder

5. Double click the Epos Now folder

6. Double click the POSSystem folder

7. Locate the MercuryRetail folder

8. Right click on the folder, select Properties

9. Select the Security tab

10. Select Edit

11. On each group or username, select the checkbox that says allow for full control for all

users

12. Select Apply and OK

13. Open the MercuryRetail folder (in notepad)

14. Open MercuryRetail.exe

15. Delete all text inside the MercuryRetail.exe

16. Paste the information from the NETePay Config (Flavour) Template into the

MercuryRetail.exe file (mentioned in your VAR Sheet or Setup Letter)

17. Replace the Merchant ID Number with the Merchant ID Number from your VAR sheet

or setup Letter

18. Select File (top left corner)

19. Select Save and close the file

20. Right click on the Windows Icon in the bottom left corner

21. Select Run

22. Type in shell:startup and enter

23. In a separate File Explorer window, navigate to C://Drive

24. Select the Program Files (x86) folder

25. Select the Datacap Systems folder

26. Select the NETePay folder

27. Right click on the NETePay icon

28. Select Create Shortcut

29. Click and drag the NETePay shortcut to the shell:startup window

30. You can now close both windows

Running the software

1. Locate and open EMVUSClient on your desktop

2. Fill in the Merchant ID and Terminal ID fields (this will be different depending on who

your Merchant Provider is - WorldPay / TSYS Host / First Data)

3. Ensure the Com Port field is set to 9

4. Select the Pad/Processor (this will be different depending on who your Merchant

Provider is - WorldPay / TSYS Host / First Data)

5. Select Pin Pad reset

6. Select OK to pop up

7. Wait until the popup reloads - You should see a Success message

8. Select EMVParamDownload

9. Select OK to the popup

10. Wait until the popup reloads - You should see a Success message

Epos Now till app

Enabling Verifone

You will now need to enable Verifone in the Front Till settings.

1. Log into your Front Till

2. Select the 3 lines (top left corner)

3. Select Cloud Sync (performing a cloud sync will sync all saved data/changes from the

Back Office to the Front Till)

4. Once synced, go back to the 3 lines (top left corner)

5. Select Settings

6. Select Peripherals along the top of the screen

7. You will see Mercury Payments, toggle this on (the toggle will appear blue when on)

8. Press the Download button next to Perform Payment Terminal Parameter

Download

9. Select the back arrow (top left corner) to save your changes

Testing a transaction

You can now test a transaction on your Front Till to make sure your new Verifone card reader is

communicating with your till system.

1. Log in to your Front Till

2. Select the Misc. Product action button found at the bottom right and click the + sign on

the top left of the screen. Enter any product name and enter a small amount (1p/cent)

and press Add. The product will appear in the transaction panel on the right.

3. Select PAY

4. Select the tender as Mercury

You will then see a pop up on the screen confirming that Epos Now software is connecting to the

Verifone card reader, be sure to check the card reader screen to see if it’s showing the amount.

If the transaction amount is showing on the card reader, you can now take payment. The till

system will receive a signal from the Verifone card reader and will cash off the payment on the

Epos Now software.payment. The Epos Now Terminal will receive a signal from the Verifone Card

Reader and will cash off the payment on the Epos Now screen.
