Uniden UH835S Manuel utilisateur
Handheld UHF-CB Transceiver
For more exciting new products please visit our website:
Australia: www.uniden.com.au
UH835S Series
UH850 Series
UH850S Series
Being defined as having no ingress of water when immersed at 1
metre for 30 minutes.
The radio will only meet this rating if fully assembled and all
rubber seals and covers are well maintained and correctly fitted.
This means that the accessory jack cover is sealed, and
the battery pack and antenna are attached and securely
fastened.
LITHIUM ION BATTERY PACK WARNING
• This equipment contains a Lithium Ion Battery Pack.
• The Lithium Ion Battery Pack contained in this equipment may
explode if disposed of in a fire.
• Do not short-circuit the Battery Pack.
• Do not charge the Lithium Ion Battery Pack used in this equipment in
any charger other than the one designed to charge this Battery Pack.
Using another charger may damage the Battery Pack or cause the
Battery Pack to explode.
• Lithium Ion batteries must be disposed off properly.
USER LICENSE INFORMATION
NOTE
The citizen band radio service is licensed in Australia by
ACMA Radio-communications (Citizen Band Radio
Stations) Class Licence and in New Zealand by MED
General User Licence for Citizen Band Radio and
operation is subject to conditions contained in those
licenses.
2
Warning
UNIDEN UH835S/UH850/UH850S Handheld UHF-CB Transceiver
WATERPROOF: IPX7/JIS7
Uniden’s UH835S/UH850/UH850S radio is designed to meet
the water proofing standard of IPX7/JIS7.
This Means:
3
Contents
Handheld UHF-CB Transceiver
UNIDEN UH835S/UH850/UH850S
Introduction 4
Included In your Package 5
Controls and Indicators 6
Getting Started
Connect Drop-in Charger with the AC Adaptor 7
Attaching the Antenna 7
Attaching the Battery Pack 8
Attaching the Beltclip 8
Charging the Battery Pack 9
Battery Level Display 10
LED Status 11
Accessory Jack Cover 11
Connecting the SPKR/MIC 11
Operation
12
12
12
13
13
14
15
15
15
17
18
19
22
22
22
23
23
24
24
25
25
26
26
26
27
27
Power On/Off
Volume
Setting the Squelch
Selecting Channel
To Transmit and Receive
To Operate in Duplex Mode
Transmit Power Select
Smart-key Function
Scanning
Open Scan (OS) Mode
Group Scan (GS) Mode
Master Scan (M.SCN) Mode
Priority Channel
Drop-Out Delay
Instant Priority Channel
Monitor
CTCSS
DCS
VOX
Busy Channel Lock-out (BCL)
Call Tone
Roger Beep
Key Beep
Scramble
Keypad Lock
Backlighting
Voice Enhancer (EOL) Setting 27
CTCSS Codes and Frequencies 28
DCS Codes Table 29
UHF-CB Channel Guidelines 30
UHF-CB Channels and Frequencies 31
Warranty 33
4
Introduction
Handheld UHF-CB Transceiver
The UH835S/UH850/UH850S/UH850S-2TP is a IPX7/JIS7 Waterproof,
portable two-way UHF-CB radio. It is compact, rugged and fits easily in
your hand. This hand held UHF-CB radio will give you consistent,
outstanding performance in virtually all conditions and situations. To
ensure that you get the most from the radio features, please read this
operating guide carefully before using the unit.
FEATURES
¹ Refer to p.30 - p.32 for channel information
2 The radio meets waterproof (IPX7/JIS7) specifications only
when the battery, the antenna and accessory MIC jack cap are
correctly installed. The radio won't retain its waterproof rating
when the accessory Speaker MIC/Earphone MIC are connected.
UNIDEN UH835S/UH850/UH850S
•
•
• Narrow Band (NB) Radio
• Communicate with up to 80 Channels in the UHF-CB Band1
• 5W (UH850/UH850S) / 3.5W (UH835S) Max TX Power
• LOW/HIGH Switchable TX Power
* UH835S is 1W/3.5W and UH850/UH850S is 1W/5.0W
• Waterproof (meets IPX7/JIS7 waterproof specifications)2
•38 Built-in CTCSS codes & additional 104 DCS codes
• Backlit LCD Display
• One-Touch Smart Key
Voice Enhancer (EQL)
• Instant Channel
• 10 Call Tone
• Duplex Mode1
• Master Scan
• Open and Group Scan
• Busy Channel Lockout Function
• VOX Function
• Accessory Jack
• Keypad Lock
• Battery Type: Lithium-lon Rechargeable
• Low Battery Alert
• Battery strength Indicator
• Auto Battery Save
• Roger Beep
• Scramble On/Off
ITEM UH835S UH850S UH850S-2TP
UH850S UHF Radio -- 1 2
UH835S UHF Radio 1 -- --
Li-Ion Battery Pack (2220mAh)
(BP850) -- 1 --
Li-Ion Battery Pack (2000mAh)
(BP835) 1 -- --
Antenna 1 1 2
Belt Clip 1 1 2
Drop-In Charger (DT850A/
DT850B/DT850D) 1 1
AC Adaptor (PS-S12C0BL1) 1 1 1
Cigarette Lighter Lead for
Charger
-- 1 --
External Speaker MIC. (SM-800) -- 1 2
VOX Earpiece MIC. (EM-800) 1 1 2
Owner’s Manual 1 1 1
Cigarette Cradle Charger
(CK-850) -- -- 1
Magnetic Antenna (AT-820) -- -- 1
Magnetic Antenna manual -- -- 1
Swivel-Type Belt Clip -- -- --
5
Included in your Package
Handheld UHF-CB Transceiver
If any of these items are missing from the box, contact your
NOTE place of purchase, immediately.
UNIDEN UH835S/UH850/UH850S
Li-Ion Battery Pack (2850mAh)
(BP-850L)
UH850S-DLX
Carry Case -- -- 1
1
--
--
--
1
1
1
1
--
1
1
1
1
1
1
1
--
-- -- 12
UH850
--
1
--
1
1
1
1
1
--
--
--
--
--
--
UH850 UHF Radio -- ----
-- 1
--
1
--
--
--
6
Controls and Indicators
Handheld UHF-CB Transceiver
UNIDEN UH835S/UH850/UH850S
1 Antenna
2 MON/Keylock
3 Rotary Vol/Power Knob
4 Speaker
5 Accy Speaker MIC Jack
6 Microphone
7 LCD Display
8 SCAN [OS/GS/MS] key
9 UP and DOWN Keys
10 LED
11 MENU [MEM] Key
12 PTT KEY
13 SMART KEY
A Transmit
B Channel Indicator
C Scan CH Memory
D Equalizer indicator
E Group Scan and
Master Scan
F Key Lock
G Master Scan
H Battery Indicator
I Scanning
J VOX
K Busy Channel
Lockout
L CTCSS/DCS
Code Indicator
M Digitally Coded
Squelch
N Continuous Tone
coded Squelch
System
O Scramble
P Priority Watch
Q High Power
1
2
3
4
5
6
7
8
9
10
11
12
13
A B C D E F HG
I
J
K
Q
P
O
N M L
7
Getting Started
Handheld UHF-CB
Connect
Transceiver
Drop-in Charger with AC Adaptor
Plug one end of the AC adaptor into the wall outlet and the other end
into the drop-in charger.
OR...
Connect DC Charging Adaptor to Cigarette Lighter Jack
Attaching the Antenna
Attach the antenna to the radio.
Be sure the antenna is firmly seated.
The drop-in charger and DC charging adaptor are not water
NOTE
proof. Ensure the radio is dry before connecting to the
charger. Don’t use the chargers when the ambient
temperature is below 5º C (37º F) or above 40º C (108º F)
Input Voltage (Cigarette Lead Charger): +12VDC to
+24VDC. If Charge LED didn’t light up, please confirm the
above temperature.
UNIDEN UH835S/UH850/UH850S
DT850DDT850A/B
8
Getting Started
Attaching the Battery Pack
1. Place the battery pack onto the back
Handheld UHF-CB Transceiver
of the radio. It will only t in one way.
2. Snap the battery release clip until it clicks.
Be sure the battery pack f its tightly against
the radio body.
Avoid exposing the Lithium Ion battery, attached or
CAUTION
unattached to the radio, in direct sunshine, heated cars, or
in areas with temperatures below –20°C (–4°F) or above
+60°C (+140°F).
Exposing the chemicals contained within the battery pack to
temperatures above +60 °C (+140°F) may cause the battery
to rupture, fail or reduce performance.
In case of exposure to cell contents, wash the affected area
thoroughly, and seek medical attention.
Additional battery cautions should be applied as described
on p.2.
To Attach the Belt Clip:
Slide the belt clip into the catch until it snaps into place.
UNIDEN UH835S/UH850/UH850S
To Remove the Belt Clip:
Pinch and hold the belt clip latch and then slide the belt clip up
and out of the catch.
9
Getting Started
Your radio is powered by a specially designed Lithium Ion battery pack.
Handheld UHF-CB Transceiver
The drop-in charger (DT850A/DT850B) can charge
the Lithium Ion battery pack attached to the radio, in
the front charging slot.
The drop-in charger (DT850D) can charge the Lithium
Ion battery pack attached to the radio, in the front and
the back charging slot.
1. Place the radio, in the drop-in charger.
2. The red LED illuminates and stays ON, until fully
charged.
• The charger won’t overcharge the battery packs.
3. The green LED illuminates and stays ON after
charging is completed.
• Do not transmit when the radio is in the drop-
in charger!
•You can monitor incoming calls while the radio is
in the drop-in charger.
Charging the Battery Pack
For the initial battery charge, make sure the radio is off for
NOTE optimum charging.
UNIDEN UH835S/UH850/UH850S
NOTE
UH850S-2TP comes with dual desktop charger, it allows
you to charge two radios at once. Do not charge the
standalone battery pack with the Drop-In Charger (DT850D).
• Before operating the radio, charge the Lithium Ion battery pack for
- up to 4 hours (1-slot type)
- up to 8 hours (2-slot type)
without interruption in the drop-in charger.
Getting Started
10 Handheld UHF-CB Transceiver
Battery Level Display
The BATTERY icon at the top of the screen indicates the battery level at
all times. The battery level is displayed in 4 levels.
LEVEL 4
Battery 100% full
LEVEL 2
Low Battery
At LEVEL 2, low battery alert will be sounded every 15 minutes.
When (PTT) is pressed at Level 1, an error tone sounds
NOTE
and transmission is disabled. Once at Level 1 the unit
will automatically shutdown after 30 seconds.
Battery Life
UH850S-DLX/UH850S-2TP (2850mA battery):
-up to 39 hours (Low Power*)/up to 23 hours (High Power)
UH850/UH850S (2220mA battery):
-up to 30 hours (Low Power*)/up to 18 hours (High Power)
UH835S (2000mA battery)
- up to 27 hours (Low Power*)/up to 18 hours (High Power)
*This is based on the following Duty Cycle:
Transmit (Low Power) 5%
Receive 5%
Stand-by 90%
Battery approx.
40% capacity
LEVEL 1
(flashing)
Empty Battery
UNIDEN UH835S/UH850/UH850S
LEVEL 3
Ce manuel convient aux modèles suivants
8
Table des matières
Autres manuels Uniden Émetteur-récepteur
Uniden
Uniden UH755 Series Manuel utilisateur
Uniden
Uniden SMU250KTS Manuel utilisateur
Uniden
Uniden UH810S Manuel utilisateur
Uniden
Uniden UH089NB Manuel utilisateur
Uniden
Uniden UH076SX-NB Manuel utilisateur
Uniden
Uniden SUNDOWNER UH-011 Manuel utilisateur
Uniden
Uniden UH785 Series Manuel utilisateur
Uniden
Uniden UH7750NB Manuel utilisateur
Uniden
Uniden UH9000S Manuel utilisateur
Uniden
Uniden UH35 Series Manuel utilisateur
Uniden
Uniden sundowner UH-088 Manuel utilisateur
Uniden
Uniden UH5040R Manuel utilisateur
Uniden
Uniden UH950S Manuel utilisateur
Uniden
Uniden UH305SX-2NB Manuel utilisateur
Uniden
Uniden UH5060VP Manuel utilisateur
Uniden
Uniden Sundowner UH-100 Manuel utilisateur
Uniden
Uniden Handheld UHF Transceiver UH076SX Manuel utilisateur
Uniden
Uniden UH8010S+ANT Manuel utilisateur
Uniden
Uniden UH7760NB Manuel utilisateur
Uniden
Uniden SEA-WASP MC-4300 Manuel utilisateur
