Ubiquiti USW--Pro--48 Manuel utilisateur

UniFiSwitch RackMountBrackets(Qty.2) BracketScrews(Qty.8)

MountingScrews(Qty.4) CageNuts(Qty.4) PowerCord

RubberFeet(Qty.4)

PackageContents

SystemRequirements

Linux,MacOSX,orMicrosoftWindows7/8/10

JavaRuntimeEnvironment1.6(1.8ornewerrecommended)

WebBrowser:GoogleChrome(Otherbrowsersmayhavelimitedfunctionality.)

UniFiControllersoftwarev5.12.x(ornewer),availableat:ui.com/download/unifi

IMPORTANT:WestronglyrecommendusingUPSbackupandpower

regulationtopreventequipmentdamageduetostabilityissueswithlocal

USWPro48QuickStartGuide

TouchscreenDisplay

RJ45Speed/Link/ActivityLED(Ports148)

SFP+Speed/Link/ActivityLED(Ports4952)

ACpower.

HardwareOverview

BootupAnimation Initializing.

SteadyWhite Factorydefaults,waitingforadoption.

SteadyBlue Successfullyadoptedbyanetworkandworking

properly.

LocationAnimation

ThisindicatesthatyouclickedLocateintheUniFi

Controllersoftware.Thesoftwarewillalsodisplay

thelocationofthedeviceonthemap.

Off NoLink

Amber

LinkEstablishedat10/100Mbps

FlashingIndicatesActivity

Green

LinkEstablishedat1000Mbps

FlashingIndicatesActivity

RJ45(Ports148)

SFP+(Ports4952)

ResetButton

USPLED

USPConnectDCInput

PowerPort

Off NoLink

Green

LinkEstablishedat1Gbps

FlashingIndicatesActivity

White

LinkEstablishedat10Gbps

FlashingIndicatesActivity

RJ45portssupport10/100/1000Ethernetconnections.

HotswappableSFP+portssupport1/10Gbpsconnections.

ThisbuttonservestwofunctionsfortheUniFiSwitch:

RestartPressandreleasetheResetbuttonquickly.

RestoretoFactoryDefaultSettingsPressandholdtheResetbuttonfor

morethanfiveseconds.

TheLEDlightsupbluewhenthereisanactivepowerconnectionontheUSP

DCinput.

ThisDCinputprovidesredundantpowerwhentheUniFiSwitchisconnectedto

theUniFiSmartPowerRedundantPowerSystem,modelUSPRPS,viathe

USPCable(notincluded).IfthereisanACpowerlossorinternalpowersupply

failure,theUniFiSwitchwilldrawpowerfromtheUSPRPSinstead.

ConnecttheincludedPowerCordtothePowerport.

InstallationRequirements

Phillipsscrewdriver

Standardsized,19"widerackwithaminimumof1Uheightavailable

Forindoorapplications,useCategory5(orabove)UTPcablingapprovedfor

indooruse.

Foroutdoorapplications,shieldedCategory5(orabove)cablingshouldbe

usedforallwiredEthernetconnectionsandshouldbegroundedthroughthe

ACgroundofthepowersupply.

Werecommendthatyouprotectyournetworksfromharmfuloutdoor

environmentsanddestructiveESDeventswithindustrialgrade,shielded

EthernetcablefromUbiquiti.Formoredetails,visit:ui.com/toughcable

HardwareInstallation

1.

2.

Note:Althoughthecablingcanbelocatedoutdoors,theUniFiSwitch

itselfshouldbehousedinsideaprotectiveenclosure.

ConnectingPower

1.

2.

ConnectingEthernet

ConnectingSFP

1.

2.

3.

ForinformationaboutcompatiblefiberSFPmodules,visit:

ubnt.link/UniFi_SFP_DAC_Compatibility

SoftwareInstallation

DownloadandinstallthelatestversionoftheUniFiControllersoftwareat

ui.com/download/unifiandfollowtheonscreeninstructions.

Note:IfyoualreadyhaveUniFiControllerv5.12.xorhigherinstalled,goto

thesection,AdoptingtheUniFiSwitch.

AfteryouhaveinstalledthesoftwareandruntheUniFiInstallationWizard,alogin

screenwillappearfortheUniFiControllermanagementinterface.Enterthe

usernameandpasswordthatyoucreatedandclickSignIn.

YoucanmanageyournetworkandviewnetworkstatisticsusingtheUniFi

Controllermanagementinterface.

ToadopttheUniFiSwitch,proceedtothesection,AdoptingtheUniFiSwitch.

ForinformationonconfiguringandusingtheUniFiControllersoftware,refertothe

UserGuideonthewebsite:ui.com/download/unifi

AdoptingtheUniFiSwitch

1.FromtheUniFiControllerdashboard,clickDevicesintheleftmenubar.

2.OntheDevicesscreen,locatetheUniFiSwitchinthelistofdevicesunderthe

Modelcolumn.ToadopttheUniFiSwitch,clickAdopt.

3.ThedisplaywillturnbluetoconfirmthattheUniFiSwitchhasbeensuccessfully

adopted.

Specifications

USWPro48

Dimensions 442.4x285.4x43.7mm

(17.42x11.24x1.72")

Weight 4.00kg(8.82lb)

WithRackmountBrackets 4.09kg(9.02lb)

Interfaces

Networking (48)10/100/1000RJ45Ports

(4)10GSFP+EthernetPorts

Management EthernetInBand

PowerMethod

UniversalInput 100240VAC,50/60Hz

USPRPSDCInput 11.5VDC,5.22A

PowerSupply AC/DC,Internal,60W

SupportedVoltageRange 100to240VAC

Max.PowerConsumption 60W

LEDs

RJ45DataPorts Speed/Link/Activity

SFP+DataPorts Link/Activity

ESD/EMPProtection Air:±16kV,Contact:±12kV

ShockandVibration ETSI3000191.4Standard

OperatingTemperature 5to45°C(23to113°F)

OperatingHumidity 10to90%Noncondensing

Certifications CE,FCC,IC

SafetyNotices

1.Read,follow,andkeeptheseinstructions.

2.Heedallwarnings.

3.Onlyuseattachments/accessoriesspecifiedbythemanufacturer.

WARNING:Failuretoprovideproperventilationmaycausefirehazard.Keepatleast

20mmofclearancenexttotheventilationholesforadequateairflow.

WARNING:Toreducetheriskoffireorelectricshock,donotexposethisproductto

rainormoisture.
