Tripp Lite SmartPro SMART750RMXL2U Manuel utilisateur
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: SMART750RMXL2U
SmartPro .75kVA Line Interactive Sine Wave UPS, Extended-run & SNMPWEBCARD options, 2U Rack/Tower,
USB, Serial, EPO, 120V
Highlights
750VA line interactive 2U rack/tower UPS; Sine wave output
120V nominal output during brownouts to 83V and overvoltages to 147V
USB, RS232, EPO and optional SNMP/Web card are available for
simultaneous use
Expandable runtime, Status LEDs; 2 switched output load banks
NEMA 5-15P input; 6 NEMA 5-15R outlets
Description
Tripp Lite's SMART750RMXL2U intelligent, line interactive rack/tower uninterruptible power supply prevents data loss, downtime and equipment
damage due to power outages, voltage fluctuations and transient surges. Requires only two rack spaces (2U) in a standard rack enclosure. Large
internal batteries offer 30 minutes half load runtime and 12.5 minutes at full load. Extended runtime available with optional BP24V15RT2U,
BP24V28-2U (limit of one per UPS) or BP24V70-3U (multi-pack compatible) external battery packs. Maintains regulated 120V nominal output
without using battery power during brownouts and overvoltages from 83 to 147V. 750VA/450 watt power handling capability supports a variety of
networking, telecom and other sensitive electronic applications. Includes a total of 6 outlets arranged in 2 load banks that are individually controllable
via software interface to reboot select equipment on demand or shed less significant loads to extend battery runtime for more critical equipment.
Supports remote monitoring of UPS and site power conditions via built-in USB and DB9 monitoring ports. Includes PowerAlert UPS monitoring and
unattended shutdown software with complete cabling. Built-in accessory slot supports SNMP with optional SNMPWEBCARD adapter. Emergency
Power Off (EPO) interface offers option for instantaneous power-off of UPS and connected equipment in the case of fire or emergency.
Multi-function audible alarms and set of 5 front panel LEDs offer at-a-glance notification of UPS and line power status. Network-grade AC surge
suppression protects equipment from damage and performance problems resulting from transient surges and line noise. Attractive all-black color
scheme.
Package Includes
SMART750RMXL2U UPS System
PowerAlert software with USB and DB9 cables
Mounting hardware for 4 post rackmount installation
Cable for Emergency Power Off interface
Instruction manual
Features
SMART750RMXL2U line interactive UPS offers voltage regulation and battery support, plus complete AC surge suppression
Supports 2U rackmount and upright tower applications (2-9USTAND accessory sold separately)
Full time sine wave output offers guaranteed compatibility with all equipment types
Supports a max load of 750VA for 12.5 minutes and a half load of 375VA for 30 minutes
Extended runtime available with optional BP24V15RT2U, BP24V28-2U (limit of one per UPS) or BP24V70-3U (multi-pack compatible)
external battery packs
Maintains regulated 120V nominal output 83 to 147V
750VA/450 watt power handling capability supports a variety of sensitive electronic loads
Includes 6 UPS supported outlets arranged in 2 individually controllable load banks
Built in USB and DB9 serial ports support remote monitoring of UPS and site power conditions
Built in accessory slot supports SNMP with optional SNMPWEBCARD adapter
Emergency Power Off (EPO) interface with cable
Multi-function audible alarms and set of 5 front panel LEDs
Network-grade AC surge suppression
Attractive all-black color scheme
UPS battery set ships fully assembled and ready for installation, no time consuming connection of internal batteries by user is necessary
Mounting hardware included for 4 post rackmount enclosures, 2 post telecom rack compatible with separate purchase 2POSTRMKITWM,
compatible with upright tower installation with included hardware
Specifications
OUTPUT
Output Volt Amp Capacity
(VA)
750
Output Watt Capacity
(watts)
450
Output power factor 0.6
Nominal Output Voltage(s)
Supported
120V
Frequency compatibility 60 Hz
Output voltage regulation
(line mode)
-21%, +8%
Output voltage regulation
(Battery mode)
+/- 5%
Built-in UPS output
receptacles
6 5-15R outlet(s)
Built-in controllable
switched load banks
Two switchable two-outlet 5-15R load banks
Output AC waveform (AC
mode)
Sine wave
Output AC waveform
(battery mode)
Pure Sine wave
INPUT
Rated input current (at
maximum load)
6.8A
Nominal Input Voltage(s)
Supported
120V AC
UPS input connection type 5-15P
Input circuit breaker 15A
UPS Input cord length (ft.) 10 ft / 3m
UPS Input cord length (m) 3.05
Recommended Electrical
Service
15A 120V
Input cord length (ft.) 10
Input cord length (m) 3
BATTERY
Full load runtime (minutes) 12.5 min. (450w)
Half load runtime (minutes) 30 min. (225w)
Expandable battery runtime Extended runtime supported via optional external battery packs
External battery pack
compatibility
BP24V15RT2U (limit 1); BP24V28-2U (limit 1); BP24V70-3U (multi-pack compatible)
DC system voltage (VDC) 24
Battery recharge rate
(included batteries)
Less than 4 hours from 10% to 90%
Replacement battery
cartridge (internal UPS
battery replacement)
RBC92-2U
Battery Access Front panel battery access door
Battery replacement
description
Hot-swappable, user replaceable batteries
VOLTAGE REGULATION
Voltage regulation
description
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 147
Overvoltage correction Input voltages between 128 and 147 are reduced by 12%
Undervoltage correction Input voltages between 83 and 107 are boosted by 14%
LEDS ALARMS & SWITCHES
LED Indicators 5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status
Alarms Audible alarm indicates power-failure, overload and low-battery conditions
Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate
low-battery status
Switches 2 Switches control off/on power status and alarm-cancel/self-test operation
SURGE / NOISE SUPPRESSION
UPS AC suppression joule
rating
480 joules
EMI / RFI AC noise
suppression
Yes
AC suppression joule rating 480
AC suppression response
time
Instantaneous
PHYSICAL
Installation form factors
supported with included
accessories
4 post 19 inch rackmount (mounting rail kit included)
Installation form factors
supported with optional
accessories
2 post rackmount (2POSTRMKITWM); Wallmount (2POSTRMKITWM); Tower (2-9USTAND)
Primary form factor Rackmount
UPS / Power Module
dimensions in primary form
factor (height x width x
depth / inches)
3.5 x 17.5 x 14.2
UPS / Power Module
dimensions in primary form
factor (height x width x
depth / cm)
8.9 x 44.4 x 36.2
Installed whole system
total rack space height
(rack spaces)
2U
Secondary form factor Tower (requires 2-9USTAND)
Installed whole system
dimensions in secondary
form factor (height x width
x depth / inches)
17.5 x 3.5 x 14.2
UPS dimensions in
secondary form factor
(height x width x depth / cm)
44.4 x 8.9 x 36.2
UPS / Power Module weight
(lbs)
35
UPS / Power Module weight
(kg)
15.9
UPS Shipping dimensions
(height x width x depth /
inches)
9.2 x 20 x 24
UPS Shipping dimensions
(height x width x depth / cm)
23.5 x 50.8 x 61
Shipping weight (lbs) 46
Shipping weight (kg) 20.9
UPS housing material Steel
Cooling method Fan
Installed whole system
dimensions in secondary
form factor (height x width
x depth / cm)
44.45 x 8.89 x 36.07
ENVIRONMENTAL
Operating Temperature
Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr. (full
load)
47.3
Battery mode BTU / hr. (full
load)
170
COMMUNICATIONS
Communications interface USB; DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface
Network monitoring port
description
Supports detailed monitoring of UPS and site power conditions
PowerAlert software Included
Communications cable USB and DB9 cabling included
WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time 2-4 milliseconds
Low voltage transfer to
battery power (setpoint)
83
High voltage transfer to
battery power (setpoint)
147
SPECIAL FEATURES
Grounding lug Back panel grounding lug
Cold Start (startup in
battery mode during a
power failure)
Cold-start operation supported
High availability UPS
features
Hot swappable batteries
Green & high efficiency
features
Individually controllable load banks
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B
(EMI)
WARRANTY
Product Warranty Period
(Worldwide)
2-year warranty, 3 year with registration. Note: registration is required for 3-year warranty.
Connected Equipment
Insurance (U.S., Canada &
Puerto Rico)
$250,000 Ultimate Lifetime Insurance
Related Items
Optional Products
Product Type Related Model Description Qty.
Audio Cables CT120 Instant-Read- AC Outlet Circuit Tester 1
Extended Warranties WEXT5-500-1500 5-Year Extended Warranty - For Smart Line-Interactive and Online
Tower or Rack models, 1500VA or less
1
External Battery Packs BP24V15RT2U BP24V15RT2U - External Battery Pack for UPS System 1
External Battery Packs BP24V28-2U BP24V28-2U - External Battery Pack for UPS System 1
External Battery Packs BP24V70-3U BP24V70-3U - External Battery Pack for UPS System 1
Power Distribution PDU1215 Basic PDU / Power Distribution Unit - Safe, reliable power distribution
for critical networking equipment
1
Power Distribution PS7224 Tripp Lite Power Strip - Multiple outlets wherever you need them 1
Rackmount/Wallmount Kits 2POSTRMKITWM Enables 2-Post Rackmount or Wallmount Installation of Select
Rackmount UPS Systems
1
SNMP Accessories ENVIROSENSE Monitors temperature, humidity and contact-closure inputs. (Requires
SNMPWEBCARD or switched PDU.)
1
SNMP Accessories SNMPWEBCARD For remote monitoring and control via SNMP, Web, or Telnet. 1
Surge Protectors DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial
lines
1
Surge Protectors DNET1 Network Surge Suppressor - Essential protection for data and
communication lines
1
Surge Protectors DTEL2 Network Surge Suppressor - Essential protection for data and
communication lines
1
Tower Stands 2-9USTAND Enables Tower Placement of Rackmount UPS Systems 1
USB Hubs/Accessories U022-010 10-ft. USB2.0 A/B Gold Device Cable
(A Male to B Male)
1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3020.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
Autres manuels pour SmartPro SMART750RMXL2U
1
Table des matières
Autres manuels Tripp Lite UPS
Tripp Lite
Tripp Lite SmartOnline SU8000RT3UHW Manuel utilisateur
Tripp Lite
Tripp Lite INTERNET550U Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnline Single-Phase 10kVA Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnline SU16KRT-1TF Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnLine SU2200RT2U-L520 Instructions d'installation et d'utilisation
Tripp Lite
Tripp Lite SmartOnline SU1000RTXL2U Guide de configuration
Tripp Lite
Tripp Lite SmartOnline SU10KRT3U Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnline 3-Phase UPS System SU30K3/3XR5 Manuel utilisateur
Tripp Lite
Tripp Lite AVR Series Manuel utilisateur
Tripp Lite
Tripp Lite 450-1400VA Manuel utilisateur
Tripp Lite
Tripp Lite OMNISMART1400HG Instructions d'installation et d'utilisation
Tripp Lite
Tripp Lite SMART1200LCD Manuel utilisateur
Tripp Lite
Tripp Lite SmartOnline 5KVA Manuel utilisateur
Tripp Lite
Tripp Lite OmniSmart OMNI900LCD Manuel utilisateur
Tripp Lite
Tripp Lite SmartPro SMART700RT1U Manuel utilisateur
Tripp Lite
Tripp Lite OMNIPOWER PRO550 Manuel utilisateur
Tripp Lite
Tripp Lite Smart Pro SM3000NAFTA Manuel utilisateur
Tripp Lite
Tripp Lite SmartPro VS SMART2200VSXL Manuel utilisateur
Tripp Lite
Tripp Lite SmartPro RMX RMX 1000-2000 VA Manuel utilisateur
Tripp Lite
Tripp Lite TMU Series Manuel utilisateur
Manuels UPS populaires d'autres marques
Pylontech
Pylontech Victron & Pylontech US5000 Manuel utilisateur
Tecnoware
Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur
Mecer
Mecer ME-1000-WTU Manuel utilisateur
Mustek
Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation
Emerson
Emerson Liebert NXL series Manuel utilisateur
MAKELSAN
MAKELSAN BOXER SERIES Manuel utilisateur
