Tripp Lite Smart Pro SM3000NAFTA Manuel utilisateur
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: SM3000NAFTA
Smart Pro line interactive UPS System - NAFTA assembled version of SMART3000NET
Highlights
3000VA / 3kVA line interactive, extended-run tower UPS
Maintains 120V nominal output over an input range of 87 to 140V
Network communications supported via 3 DB9 ports (1 serial / 2 contact
closure)
Current monitoring and switched PDU control via 2 single-outlet load banks
Input: L5-30P (120V 30A) / Output: 4 NEMA 5-15/20R, 4 NEMA 5-15R (120V)
$250,000 Ultimate Lifetime Insurance (USA, Puerto Rico and Canada only)
Description
Tripp Lite's SM3000NAFTA intelligent, line interactive large tower UPS system protects servers, networking accessories and telecommunications
equipment from blackouts, voltage fluctuations and transient surges. Large internal batteries offer 23 minutes half load runtime and 7 minutes fully
loaded. Runtime is expandable with optional BP24V28-2U (limit 1) and BP24V70-3U external battery packs. 3000VA/2400 watt power handling
capability supports a variety of networking, telecom and other sensitive electronic applications. Includes 8 protected outlets. Supports remote
monitoring of UPS and site power conditions via built-in RS-232 enabled monitoring port, plus standard UPS monitoring via 2 built in contact closure
ports. Includes PowerAlert UPS monitoring and unattended shutdown software with complete cabling. Built-in audible alarm and front panel LEDs
indicate line power, battery power, battery charge level, load level and voltage regulation status. Network grade AC surge suppression protects
equipment from damage and performance problems resulting from transient surges. Attractive large gray tower housing. $250,000 connected
equipment insurance.
Package Includes
SMART3000NET UPS System
PowerAlert Software and three 6 foot network cables
Warranty information
Instruction manual
Features
SM3000NAFTA line interactive UPS offers battery derived AC output during power outages, voltage regulation during brownouts and
overvoltages, plus network-grade AC surge suppression
3000VA/2400 watt power handling capability supports a variety of networking, telecom and other sensitive electronic devices
Large internal batteries offer runtimes of 23 minutes at half load (1500VA/1200 watts) and 7 minutes at full load (3000VA/2400 watts)
Runtime is further expandable with optional external BP24V28-2U (limit 1) and BP24V70-3U battery packs
Automatic Voltage Regulation (AVR) circuits maintain 120V nominal output over an input voltage range of 87-140V
Includes 8 fully protected outlets (4 NEMA 5-15R & 4 NEMA 5-15/20R) with 2 single outlet load banks that can be individually powered off
and back on again via software interface
PowerAlert UPS monitoring and unattended shutdown software enables configurable network broadcast messaging, email notification,
event logging and running user defined script commands
Offers simultaneous monitoring of up to 3 directly connected devices through included DB9 contact closure and RS-232 enabled interfaces,
or the monitoring of any number of additional servers over IP with included PowerAlert monitoring software
In addition to the contact closure monitoring of on battery, low battery and power restored messaging, built-in RS-232 interface supports
messaging of UPS and line power status, including AC line voltage, DC battery voltage and remaining battery capacity
Supports activate self-test and UPS output power control for delayed or immediate reboot of connected equipment
Diagnostic LEDs (indicate 17 performance conditions)
UL (USA), cUL (Canada), NOM (Mexico), FCC Class A (Emissions)
$250,000 Ultimate Lifetime Insurance (USA & Canada Only)
Specifications
OUTPUT
Output Volt Amp
Capacity (VA)
3000
Output kVA capacity
(kVA)
3
Output Watt Capacity
(watts)
2400
Output kW capacity 2.4
Output power factor 0.8
Nominal Output
Voltage(s) Supported
120V
Frequency compatibility 60 Hz
Output voltage
regulation (line mode)
-13% / +5%
Output voltage
regulation (Battery
mode)
+/- 5%
Built-in UPS output
receptacles
4 5-15R outlet(s); 4 5-15/20R outlet(s)
Built-in controllable
switched load banks
Three switchable single-outlet 5-15R load banks
Output circuit breaker 15A branch rated (x2) - each breaker protects 4 outlets
Basic PDU options PDU1220 (1U / 13 5-15/20R outlets); PDUNV (1U / 2 C19, 12 C13 outlets); PDUV20 (0U / 12 5-15/20R outlets);
PDU40TDUAL (0U / 40 5-15/20R outlets)
Metered PDU options PDUMH20 (1U / 13 5-15/20R outlets); PDUMH20AT (1U / 16 5-15/20R outlets)*; PDUMV20 (0U / 16 5-15/20R
outlets); PDUMV40 (0U / 32 5-15/20R outlets)
Switched PDU options PDUMH20ATNET (1U / 16 5-15/20R outlets)*; PDUMV20NET (0U / 24 5-15/20R outlets)
External PDU
redundancy options
*Auto Transfer Switch features utilizing the secondary PDU input cord are compatible with Smart Online UPS
models only
Output AC waveform
(AC mode)
Sine wave
Output AC waveform
(battery mode)
PWM sine wave
INPUT
Rated input current (at
maximum load)
22A
Nominal Input
Voltage(s) Supported
120V AC
UPS input connection
type
L5-30P
UPS Input cord length
(ft.)
8
UPS Input cord length
(m)
2.4
Recommended
Electrical Service
30A 120V
Input cord length (m) 2.4
BATTERY
Full load runtime
(minutes)
7 min. (2400w)
Half load runtime
(minutes)
23 min. (1200w)
External battery pack
compatibility
BP24V28-2U (limit 1); BP24V70-3U (multi-pack compatible)
DC system voltage
(VDC)
24
Battery recharge rate
(included batteries)
Less than 9 hours from 10% to 90%
VOLTAGE REGULATION
Voltage regulation
description
Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 87 to 140
Overvoltage correction Input voltages between 127 and 140 are reduced by 12%
Undervoltage correction Input voltages between 95 and 105 are boosted by 10%
Severe undervoltage
correction
Input voltages between 87 and 94 are boosted by 22%
LEDS ALARMS & SWITCHES
LED Indicators 5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status
Alarms Audible alarm indicates power-failure, overload and low-battery conditions
Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate
low-battery status
Switches 2 Switches control off/on power status and alarm-cancel/self-test operation; set of 4 rear-panel switches control
system enable and contact closure port inverter shutoff commands
SURGE / NOISE SUPPRESSION
UPS AC suppression
joule rating
480
UPS AC suppression
response time
Instantaneous
EMI / RFI AC noise
suppression
Yes
PHYSICAL
Installation form factors
supported with included
accessories
Tower
Primary form factor Tower
UPS / Power Module
dimensions in primary
form factor (height x
width x depth / inches)
17 x 9 x 12.5
UPS / Power Module
dimensions in primary
form factor (height x
width x depth / cm)
43.2 x 22.9 x 31.8
UPS / Power Module
weight (lbs)
89
UPS / Power Module
weight (kg)
40.4
UPS Shipping
dimensions (height x
width x depth / inches)
22.2 x 12.8 x 16.5
UPS Shipping
dimensions (height x
width x depth / cm)
56.5 x 32.4 x 41.9
Shipping weight (lbs) 96
Shipping weight (kg) 43.6
UPS housing material PVC
Cooling method Fan
ENVIRONMENTAL
Operating Temperature
Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature
Range
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr. (full
load)
82.4
Battery mode BTU / hr.
(full load)
1219.3
COMMUNICATIONS
Communications
interface
DB9 Serial; Contact closure
Network monitoring
port description
Supports detailed monitoring of UPS and site power conditions; contact closure communications via two
additional DB9 ports (3 total)
PowerAlert software Included
Communications cable 3 DB9 cables included
LINE / BATTERY TRANSFER
Transfer time 2-4 milliseconds
Low voltage transfer to
battery power (setpoint)
87
High voltage transfer to
battery power (setpoint)
140
SPECIAL FEATURES
Cold Start (startup in
battery mode during a
power failure)
Cold-start operation supported
Green & high efficiency
features
Greater than 95% efficiency - GREEN UPS; Individually controllable load banks
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A
(EMI); ROHS (Restriction of Hazardous Substances)
WARRANTY
Product Warranty
Period (Worldwide)
2-year limited warranty
Connected Equipment
Insurance (U.S., Canada
& Puerto Rico)
$250,000 Ultimate Lifetime Insurance
Related Items
Optional Products
Product Type Related Model Description Qty.
Audio Cables CT120 Instant-Read- AC Outlet Circuit Tester 1
Extended Warranties WEXT3-2200-3000 3-Year Extended Warranty - For Smart Line-Interactive and Online
Tower or Rack models, 2200-3000VA
1
Extended Warranties WEXT5-2200-3000 5-Year Extended Warranty - For Smart Line-Interactive and Online
Tower or Rack models, 2200-3000VA or less
1
External Battery Packs BP24V28-2U BP24V28-2U - External Battery Pack for UPS System 1
External Battery Packs BP24V70-3U BP24V70-3U - External Battery Pack for UPS System 1
Power Distribution PDU1215 Basic PDU / Power Distribution Unit - Safe, reliable power distribution
for critical networking equipment
1
Power Distribution PDU1220 Basic PDU / Power Distribution Unit - Safe, reliable power distribution
for critical networking equipment
1
Power Distribution RS-1215 Tripp Lite Power Strip - Multiple outlets wherever you need them 1
Power Distribution RS-1215-20 Tripp Lite Power Strip - Multiple outlets wherever you need them 1
Surge Protectors DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial
lines
1
Surge Protectors DNET1 Network Surge Suppressor - Essential protection for data and
communication lines
1
Surge Protectors DTEL2 Network Surge Suppressor - Essential protection for data and
communication lines
1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3550.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
