Model #: SMART1500SLTXL

SmartPro Tower UPS - Intelligent, line-interactive network power management system

Highlights

1500VA / 1.5kVA line-interactive extended run tower UPS system for networks

Sine wave output in AC and battery mode

Simultaneous communications via SNMPWEBCARD slot, HID enabled USB

and DB9 serial port

Free PowerAlert UPS monitoring software manages an unlimited number of

network UPS systems

Input: NEMA 5-15P (120V 15A) / Output: 8 NEMA 5-15R (120V)

2 year product warranty / $250,000 Ultimate Lifetime Insurance (USA, Puerto

Rico & Canada only)

Description

1500VA line-interactive tower UPS system for server, networking and telecommunications equipment. Upright tower form factor. Offers sine wave

120V nominal output in both AC and battery modes. Runtime is expandable with the addition of BP36V15-2U (limit 1) or BP36V42-3U external

battery packs. Switches to battery-derived AC output during power failures and extreme voltage variations. Line-interactive automatic voltage

regulation (AVR) provides voltage boost/cut during brownouts/overvoltages to maintain regulated 120V nominal output over an input voltage range of

95-145V. Includes NEMA 5-15P input plug and 8 UPS-supported NEMA 5-15R output receptacles. Network-grade AC surge and noise suppression.

Network management interfaces support simultaneous communications via USB port, DB9 serial port and SNMPWEBCARD slot. HID-compliant

USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Supports simultaneous

detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3 network interfaces. Includes PowerAlert monitoring

software and complete cabling. Three-stage metered current monitoring and battery charge status LEDs. Data line surge suppression for dialup,

DSL or network Ethernet connections (POE compatible). Utility power and voltage regulation LEDs. Audible alarm. Self-test. Field-replaceable,

hot-swappable internal batteries. Attractive all-black color scheme. 2-year warranty and $250,000 connected equipment insurance; extended

warranty and service contracts available.

Package Includes

SMART1500SLTXL UPS System

PowerAlert Software CD

USB and serial cabling

Owner's manual with warranty information

Features

SmartPro line-interactive UPS system is ideal for voice, data, medical and industrial networking applications

Line-interactive voltage regulation maintains selectable 120V nominal output during brownouts as low as 95V and overvoltages to 145V

Enables continuous operation through blackouts, voltage fluctuations and surges

Line-interactive automatic voltage regulation (AVR) provides 14% voltage boost during brownouts and a 12% voltage cut during

overvoltages

Standard internal battery set offers 16 min. runtime at half load (490W) and 6.75 min. at full load (980W)

Runtime is expandable with the addition of BP36V15-2U (limit 1) or BP36V42-3U external battery packs

Space-saving upright tower format

Network interfaces support simultaneous communications via built-in USB port, DB9 serial port and SNMPWEBCARD slot HID-compliant

USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X.

Included PowerAlert UPS monitoring software supports safe unattended shutdown, monitoring and control via local connected servers, plus

any number of additional servers over IP

UPS interface supports on-battery, low-battery, power-restored, AC-voltage, DC-voltage, output current monitoring, battery charge current,

battery capacity, timed inverter shutoff, activate self-test and output power control

NEMA 5-15P input plug / 8 x NEMA 5-15R output receptacles

Front panel LEDs offer current monitoring, voltage regulation and battery charge level information

UPS ships fully assembled in full compliance with DOT regulations; no time-consuming connection of internal batteries by user required

Single-line tel/DSL or network Ethernet line surge suppression (POE compatible)

2-year product warranty; $250,000 Ultimate Lifetime Insurance (USA, Puerto Rico, Canada)

Specifications

OUTPUT

Output Volt Amp

Capacity (VA)

1500

Output kVA capacity

(kVA)

1.5

Output Watt Capacity

(watts)

980

Output power factor 0.7

Nominal Output

Voltage(s) Supported

120V

Frequency

compatibility

60 Hz

Output voltage

regulation (line mode)

-12% / +14%

Output voltage

regulation (Battery

mode)

+/- 5%

Built-in UPS output

receptacles

8 5-15R outlet(s)

Basic PDU options PDU1215 (1U / 13 5-15R outlets); PDUNV (1U / 2 C19, 12 C13 outlets); PDU1415 (0U / 14 5-15R outlets);

PDUV15 (0U / 12 5-15R outlets)

Metered PDU options PDUMH15 (1U / 13 5-15R outlets); PDUMH15AT (1U / 8 5-15R outlets)*; PDUMV15 (0U / 16 5-15R outlets)

Switched PDU options PDUMH15ATNET (1U / 8 5-15R outlets)*; PDUMV15NET (0U / 16 5-15R outlets)

External PDU

redundancy options

*Auto Transfer Switch features utilizing the secondary PDU input cord are compatible with Smart Online UPS

models only

Output AC waveform

(AC mode)

Sine wave

Output AC waveform

(battery mode)

Pure Sine wave

INPUT

Rated input current (at

maximum load)

9.8A

Nominal Input

Voltage(s) Supported

120V AC

UPS input connection

type

5-15P

UPS Input cord length

(ft.)

UPS Input cord length

(m)

1.8

Recommended

Electrical Service

15A 120V

BATTERY

Full load runtime

(minutes)

6.75 min. (980w)

Half load runtime

(minutes)

16 min. (490w)

Expandable battery

runtime

Extended runtime supported via optional external battery packs

External battery pack

compatibility

BP36V15-2U (limit 1); BP36V42-3U (multi-pack compatible)

DC system voltage

(VDC)

Battery recharge rate

(included batteries)

Less than 4.5 hours from 10% to 90%

Replacement battery

cartridge (internal UPS

battery replacement)

RBC53

Battery Access Battery access door

Battery replacement

description

Hot-swappable, user replaceable batteries

VOLTAGE REGULATION

Voltage regulation

description

Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 95V to 145V

Overvoltage correction Input voltages between 127 and 145V are reduced by 12%

Undervoltage

correction

Input voltages between 95 and 108V are boosted by 14%

LEDS ALARMS & SWITCHES

LED Indicators 9 LEDs indicate line power, battery power, AVR, overload and replace battery status - with a 3-LED level meter for

load and battery charge level

Site wiring fault

indication

Rear panel site wiring fault LED

Alarms Audible alarm indicates power failure and overload conditions

Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation

SURGE / NOISE SUPPRESSION

UPS AC suppression

joule rating

738

UPS AC suppression

response time

Instantaneous

UPS Dataline

suppression

1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet

EMI / RFI AC noise

suppression

Yes

PHYSICAL

Installation form

factors supported with

included accessories

Tower

Primary form factor Tower

UPS / Power Module

dimensions in primary

form factor (height x

width x depth / inches)

10.1 x 6.6 x 13.8

UPS / Power Module

dimensions in primary

form factor (height x

width x depth / cm)

25.7 x 16.9 x 34.9

UPS / Power Module

weight (lbs)

44.6

UPS / Power Module

weight (kg)

20.2

UPS Shipping

dimensions (height x

width x depth / inches)

14 x 9.8 x 13.3

UPS Shipping

dimensions (height x

width x depth / cm)

35.6 x 24.9 x 33.8

Shipping weight (lbs) 47.7

Shipping weight (kg) 21.7

UPS housing material Steel

Cooling method Fan

ENVIRONMENTAL

Operating

Temperature Range

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature

Range

+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC mode BTU / hr.

(full load)

175.4

Battery mode BTU / hr.

(full load)

542.4

Audible Noise Audible Noise < 50 dBA at Front Side 1 Meter

COMMUNICATIONS

Communications

interface

USB; DB9 Serial; Slot for SNMP/Web interface

Network monitoring

port description

Supports detailed monitoring of UPS and site power conditions

PowerAlert software Included

Communications cable USB and DB9 cabling included

WatchDog

compatibility

Supports Watchdog application, OS and hard-reboot restart options for remote applications

LINE / BATTERY TRANSFER

Transfer time 4-6 milliseconds

Low voltage transfer

to battery power

(setpoint)

High voltage transfer

to battery power

(setpoint)

145

SPECIAL FEATURES

Cold Start (startup in

battery mode during a

power failure)

Cold-start operation supported

High availability UPS

features

Hot swappable batteries

Green & high

efficiency features

Greater than 95% efficiency - GREEN UPS

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A

(EMI); Meets FCC Part 68 / Industrie Canada (telecommunications); ROHS (Restriction of Hazardous Substances)

WARRANTY

Product Warranty

Period (Worldwide)

2-year limited warranty

Connected Equipment

Insurance (U.S.,

Canada & Puerto Rico)

$250,000 Ultimate Lifetime Insurance

Related Items

Optional Products

Product Type Related Model Description Qty.

Extended Warranties WEXT3-500-1500 3-Year Extended Warranty - For Smart Line-Interactive and Online

Tower or Rack models, 1500VA or less

Extended Warranties WEXT5-500-1500 5-Year Extended Warranty - For Smart Line-Interactive and Online

Tower or Rack models, 1500VA or less

External Battery Packs BP36V15-2U BP36V15-2U - External Battery Pack for UPS System 1

External Battery Packs BP36V42-3U BP36V42-3U - External Battery Pack for UPS System 1

Power Distribution PDU1215 Basic PDU / Power Distribution Unit - Safe, reliable power distribution

for critical networking equipment

Power Distribution PDU1415 Basic PDU / Power Distribution Unit - Safe, reliable power distribution

for critical networking equipment

Power Distribution PDUMH15 Metered PDU / Power Distribution Unit - Safe, reliable power

distribution with digital current meter

Power Distribution PDUMH15ATNET Switched, Metered PDU with ATS - Power Distribution Unit with

dual-input Auto Transfer Switching, individual outlet control and remote

network interface

Power Distribution PDUV15 Safe, reliable power distribution for critical networking equipment 1

SNMP Accessories ENVIROSENSE Monitors temperature, humidity and contact-closure inputs. (Requires

SNMPWEBCARD or switched PDU.)

SNMP Accessories SNMPWEBCARD For remote monitoring and control via SNMP, Web, or Telnet. 1

Software WATCHDOGSW WatchDog Service Monitoring / Reboot Software 1

USB Hubs/Accessories U022-010 10-ft. USB2.0 A/B Gold Device Cable

(A Male to B Male)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3848.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.

Table des matières

Autres manuels Tripp Lite UPS

Tripp Lite

Tripp Lite SmartOnLine SU2200RT2U-L520 Instructions d'installation et d'utilisation

Tripp Lite

Tripp Lite AVRX Series Manuel utilisateur

Tripp Lite

Tripp Lite S3M100KX Manuel utilisateur

Tripp Lite

Tripp Lite INTERNET350U Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro SMART1050SLT Manuel utilisateur

Tripp Lite

Tripp Lite INTERNET OFFICE 350 Manuel utilisateur

Tripp Lite

Tripp Lite ECO-UPS ECO650LCD Manuel utilisateur

Tripp Lite

Tripp Lite SMART3000RM2UL Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU80K Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU3000RTXL3U Manuel utilisateur

Tripp Lite

Tripp Lite SMART750TSU Manuel utilisateur

Tripp Lite

Tripp Lite AVRX750UF Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro AG-03AD Series Manuel utilisateur

Tripp Lite

Tripp Lite SMART2500XLHG Manuel utilisateur

Tripp Lite

Tripp Lite OmniSmart OMNIVS800 Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro SMART700USB Guide de configuration

Tripp Lite

Tripp Lite INTERNET OFFICE 300 Guide de l'utilisateur

Tripp Lite

Tripp Lite ST750RMXL2U Manuel utilisateur

Tripp Lite

Tripp Lite ECO750UPS Manuel utilisateur

Tripp Lite

Tripp Lite RBC11A Manuel utilisateur

Tripp Lite

Tripp Lite OmniSmart OMNI300NAFTA Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU3000XLNAFTA Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU3000XL Manuel utilisateur

Tripp Lite

Tripp Lite 120V Input Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
