Owner’s Manual

Smart and OmniSmart®

Medical-Grade UPS Systems

Models:

OMNISMART350HG

(Series Number: AGOM350KSR57HG)

Important Safety Instructions 2

Package Contents 5

Quick Installation 6

Basic Operation 8

Guidance and Manufacturer’s Declaration 14

Storage & Service 15

Regulatory Compliance & 16

Product Registration

Español 17

Français 33

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

SMART700HG

(Series Number: AGSM700PSR3HG) SMART1200XLHG

(Series Number: AGSM1200PSR3HG)

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

15-11-178-9332C2.indb 1 12/4/2015 9:20:10 AM

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the installation,

operation and storage of all Tripp Lite UPS Systems. Failure to heed these warnings may affect

your warranty.

Statement of Intended Use

Tripp Lite Medical-Grade UPS Systems are intended to support and protect non-medical and

medical computer equipment and medical devices that require leakage current reduction, surge

protection, voltage regulation, line noise ﬁltering and battery backup during power outages and

generator testing, both inside and outside patient care areas. Tripp Lite’s Medical-Grade UPS

Systems come with hospital-grade plugs and receptacles that reduce leakage to below 100μA.

Product Information

AGOM350KSR57HG AGSM700PSR3HG AGSM1200PSR3HG

AC Input Voltage 120 120 120

AC Input Voltage Range 83–147 81–143 81–143

Input Amp(s) 2.3 5.5 9.2

Output Amps(s) 1.9 5.8 6.25

Rated Power (VA/Watts) 330VA/225W 700VA/450W 1000VA/750W

Frequency 50/60 Hz 50/60 Hz 50/60 Hz

No. of Phases Single Single Single

Class Type Class I Class I Class I

Plug/Connector Type NEMA 5-15P NEMA 5-15P NEMA 5-15P

Operation Continuous Continuous Continuous

AC Input Protection (Qty./type/rating) Input breaker

(2 x 3.5A), thermal Input breaker

(2 x 10A), thermal Input breaker

(2 x 15A), thermal

Max Leakage Current (uA) Less than 100uA Less than 100uA Less than 100uA

Weight 25.0 lbs 44.2 lbs 46.4 lbs

Known Contraindication None None None

UPS Location Warnings

Relevant Symbols

Denotes that information in the manual should be reviewed before use.

Used to signal a warning that a statement is particularly important and could pose a safety

risk.

Warning-Dangerous Voltage No sitting

Denotes general warning sign No stepping on surface

Refer to Instruction Manual/Booklet No pushing

15-11-178-9332C2.indb 2 12/4/2015 9:20:10 AM

Important Safety Instructions continued

• Do not use this equipment within oxygen-enriched atmospheres, or within 0.3 m (1 ft.) of a point

at which an oxygen-enriched atmosphere is intentionally vented.

• Use caution when lifting UPS. Because of the considerable weight of all UPS systems, at least

two people should assist in lifting and installing them.

• Install your UPS indoors, away from excess moisture or heat, dust or direct sunlight.

• For best performance, the UPS should be used in a location that meets the following conditions:

Temperature: 0 to 40° C (32 to 104° F); Humidity: 0 to 95% (non-condensing);

Elevation: <6,562 ft. (2,000 m) above sea level; Pressure: >95kPa

• Leave adequate space around all sides of the UPS for proper ventilation. Do not obstruct its vents

or fan openings.

• Do not mount unit with its front or rear panel facing down (at any angle). Mounting in this manner

will seriously inhibit the unit’s internal cooling, eventually causing product damage not covered

under warranty.

• UPS is not intended for patient contact. Avoid installation that will cause accidental contact of

patients.

UPS Connection Warnings

• The UPS contains its own energy source (battery). The output terminals may be live even when

the UPS is not connected to an AC supply.

• Connect your UPS to a properly grounded AC power outlet. Do not modify the UPS’s plug in a

way that would eliminate the UPS’s connection to ground. Do not use adapters that eliminate the

UPS’s connection to ground.

• Do not plug your UPS into itself; this will damage the UPS and void your warranty.

• If you are connecting your UPS to a motor-powered AC generator, the generator must provide

ﬁltered, frequency-regulated output.

• To remove the UPS from the supply mains, the plug serves as a disconnect device.

• Once connected, do not limit access to the input plug. The plug must be accessible to be used as

a means of disconnection.

• When connecting your UPS to the power outlet, ensure that the power outlet is provided with

suitable overcurrent protection in accordance with your national and local electrical codes. Ensure

that the overcurrent protection has a minimum of 1500A breaking capacity.

CAUTION: Do not remove cover for 5 minutes after disconnecting all sources of

supply. Risk of electric shock—hazardous live parts inside. Do not remove cover.

No user serviceable parts inside. Refer servicing to qualiﬁed service personnel.

This UPS receives power from more DC sources; disconnection of the AC and DC

source is required to de-energize the unit before servicing.

CAUTION: To ensure proper grounding with supply mains power, the input cord must

be connected with an approved country-speciﬁc plug with a protective earth ground

connection.

CAUTION: If this product is operated on battery (not connected to mains power),

adequate safeguards should be employed to protect against accidental contact

with AC power conductors.

CAUTION: Do not exceed total rated output.

WARNING: No modiﬁcation of this equipment is allowed.

15-11-178-9332C2.indb 3 12/4/2015 9:20:10 AM

Important Safety Instructions continued

Equipment Connection Warnings

• Do not use Tripp Lite UPS Systems for life support applications in which a malfunction or failure of

a Tripp Lite UPS System could cause failure or signiﬁcantly alter the performance of a life-support

device.

• Do not connect surge protectors or extension cords to the output of your UPS. This might damage

the UPS and may affect the surge suppressor and UPS warranties.

CAUTION: The unit is for exclusive interconnection with IEC60601-1 certiﬁed

equipment in the patient environment and IEC60950-1 certiﬁed equipment outside

of the patient environment. Do not contact SIP/SOP (such as the USB port, RS232

port, etc.) and the patient at the same time.

Battery Warnings

• Batteries can present a risk of electrical shock and burn from high short-circuit current. Observe

proper precautions. Do not dispose of the batteries in a ﬁre. Do not open the UPS or batteries.

Do not short or bridge the battery terminals with any object. Unplug and turn off the UPS before

performing battery replacement. Use tools with insulated handles. There are no user-serviceable

parts inside the UPS. Battery replacement should be performed only by authorized service

personnel using the same number and type of batteries (Sealed Lead-Acid). The batteries

are recyclable. Refer to your local codes for disposal requirements or visit

www.tripplite.com/UPSbatteryrecycling for recycling information. Tripp Lite offers a complete

line of UPS System Replacement Battery Cartridges (R.B.C.). Visit Tripp Lite on the Web at

www.tripplite.com/products/battery-ﬁnder/ to locate the speciﬁc replacement battery

for your UPS.

• Do not operate UPS without batteries.

• If your UPS is equipped with an external battery connector, only connect Tripp Lite external battery

packs of the appropriate voltage.

• If your UPS is not equipped with an external battery connector, do not attempt to add external

batteries.

UPS and Battery Recycling

Please recycle Tripp Lite Products. The batteries used in Tripp Lite products are sealed

Lead-Acid batteries. These batteries are highly recyclable. Please refer to your local codes

for disposal requirements.

You can call Tripp Lite for recycling info at 1.773.869.1234.

You can go the Tripp Lite Website for up-to-date information on recycling the

batteries or any Tripp Lite product. Please follow this link:

http://www.tripplite.com/support/recycling-program/

Replacement Battery

MODEL BATTERY

AND QUANTITY NOMINAL VOLTAGE

OF BATTERY STRING BATTERY

PACK NO.

OMNISMART350HG (AGOM350KSR57HG) LEAD-ACID 6V, 2 PCS 12V, 12AH RBC52

SMART700HG (AGSM700PSR3HG) LEAD-ACID 12V, 3 PCS 36V, 9AH RBC53

SMART1200XLHG (AGSM1200PSR3HG) LEAD-ACID 12V, 3 PCS 36V, 9AH RBC53

15-11-178-9332C2.indb 4 12/4/2015 9:20:10 AM

Important Safety Instructions continued

Package Contents

Maintenance:

• Other than battery replacement, the UPS does not require maintenance. There are no user

serviceable parts inside. Battery replacement should only be performed by qualiﬁed service

personnel.

Cleaning/Disinfecting:

• Before cleaning or disinfecting, the UPS should be turned off and unplugged.

• For cleaning the UPS, only a damp cloth should be used.

• For disinfecting the UPS, a damp cloth wetted with isopropyl alcohol may be used. No other

cleaning agent should be used.

UPS and Battery Disposal

• Always comply with local ordinances for proper methods of recycling and disposal of electronic

equipment.

• When purchasing a new UPS from Tripp Lite, you may send an old UPS back for recycling on a

one-for-one, like-for-like basis. The new equipment should also be sent back to Tripp Lite when it

ultimately becomes waste.

• Batteries can present risk of electric shock, burn and ﬁre if not disposed of properly.

OMNISMART350HG

• 6-ft. RJ11 Cable

• 6-ft. DB9 Cable

• Owner’s Manual

SMART700HG

• 6-ft. USB Cable

• 6-ft. DB9 Cable

• Owner’s Manual

SMART1200XLHG

• 6-ft. USB Cable

• 6-ft. DB9 Cable

• Owner’s Manual

15-11-178-9332C2.indb 5 12/4/2015 9:20:10 AM

Quick Installation

1For All Models—Plug your UPS into a

3-wire grounded, 120V AC, 60 Hz utility

outlet.

Note: UL 60601-1 listed UPS systems only meet UL standard UL

60601-1 for medical equipment when plugged into a hospital-grade

outlet.

Note: UPS system will function properly upon initial startup; however,

maximum runtime for the unit’s battery will only be accessible after it

has been charged for 24 hours.

Note: Although some installation procedures are common to all models, some procedures

vary depending on whether you are installing a Smart model or an OmniSmart model.

2For All Models—Plug your equipment into

the UPS.

You will overload the UPS if the total VA ratings for all of the

equipment you connect exceeds the UPS’s Output Capacity. To

ﬁnd your equipment’s VA ratings, look on their nameplates. If the

equipment is listed in amps, multiply the number of amps by 120 to

determine VA (Example: 1 amp x 120 = 120VA). If you are unsure

if you have overloaded the UPS’s outlets, see “OUTPUT LOAD LEVEL”

LED description.

3For Smart Models Only—

Turn the UPS ON.

Press and hold the “POWER” button for one second. The

alarm will beep once brieﬂy after one second has passed.

Release the button.

For OmniSmart Models Only—

Select UPS Operating Mode.*

For Smart Models Only:

After you plug the UPS into a live AC outlet, the UPS will automatically charge its batteries

but will not supply power to its outlets until it is turned ON (see Step 3 below). The BATTERY

CHARGE LED will be the only LED illuminated.

For OmniSmart Models Only:

Your UPS will run a self-test after it is plugged in. See Basic Operation section to understand

the results of its self-test.

Press the UPS/STANDBY button to toggle your UPS between the UPS (“POWER” LED lit) and

the STANDBY (“POWER” LED ﬂashing) modes. Choose the operating mode based on your

location:

USA, Canada & Western Europe:

• Leave the UPS in the UPS mode at all times.

All Other Countries:

• Put the UPS in STANDBY mode when you are not using connected equipment.

(WARNING! When set to “CHARGE ONLY,” the UPS will not provide battery backup

during a blackout or brownout.)

• Put the UPS in UPS mode when you are using connected equipment.

*See Basic Operation section for a complete explanation of each mode.

15-11-178-9332C2.indb 6 12/4/2015 9:20:11 AM

Quick Installation Optional

IN OUT SEE MANUAL FOR

PROPER CONNECTION

NORM

These connections are optional. Your UPS will function properly without these connections.

1Serial Communications

(Select models only)

If your UPS has a DB9 port, you can connect it to the DB9

port of a computer with the included cable. Use with

Tripp Lite’s PowerAlert®Software for automatic ﬁle saves

and safe shutdown in case of power failure. (See Basic

Operation section.)

2USB Communications

Connect the USB port of your UPS to the USB port of a

computer with the included cable. Use with Tripp Lite’s

PowerAlert Software for automatic ﬁle saves and safe

shutdown in case of power failure. (See Basic Operation

section.)

3Tel/DSL Protection

(Select Models Only)

Using telephone cords, connect your wall jack to the UPS

jack marked “LINE” (or “IN”) and your equipment to the

UPS jack marked “EQUIP” (or “OUT”). This will protect your

equipment from surges over the phone line, but you should

make sure that your equipment is also protected against

surges on the AC line.

UPS models with tel/DSL protection can protect two lines

on one cable simultaneously. If you want to protect two

lines that travel through separate cables, you must use “Y”

splitters appropriate to your application to adapt them to

your UPS’s phone jacks.

Not compatible with PoE (Power over Ethernet) applications.

4External Batteries

(Select Models Only)

External batteries are only needed to extend runtime. Adding

external batteries will increase recharge time as well as

runtime.

The illustration shows the location of your UPS’s External

Battery Connector, where you will insert the battery pack

cable. Complete installation and mounting instructions

for your battery pack appear in the battery pack’s owner’s

manual. Make sure that cables are fully inserted into

their connectors. Small sparks may result during battery

connection; this is normal.

15-11-178-9332C2.indb 7 12/4/2015 9:20:13 AM

Basic Operation

Buttons

For Smart Models Only—“POWER” Button:

• To turn the UPS ON: With the UPS plugged into a live AC wall outlet,* press

and hold the POWER button for about two seconds.** Release the button. If

utility power is absent, you can “cold-start” the UPS (i.e.: turn it ON and supply

power for a limited time from its batteries***) by pressing and holding the

POWER button for about two seconds.**

• To turn the UPS OFF: With the UPS ON and receiving utility power, press and

hold the POWER button for one second.** Then unplug the UPS from the wall

outlet. The UPS will be completely OFF.

*After you plug the UPS into a live AC outlet, the UPS will automatically charge its batteries,

but will not supply power to its outlets until it is turned ON. ** The alarm will beep once

brieﬂy after the indicated interval has passed. *** If fully charged.

For OmniSmart Models Only—“UPS/STANDBY” Button:

Use the UPS/STANDBY button to do three things:

Switch your UPS’s Operating Mode: While your UPS is plugged into a live AC

outlet, press the UPS/STANDBY button and hold it until you hear a beep (about

2 seconds) to toggle between the following operating modes. Choose your

UPS’s operating mode based on the regional guidelines in Step 3 of the Quick

Installation section.

• UPS Mode: ENABLES battery backup. UPS Conditions: While receiving

adequate utility line power, the UPS supplies power to its AC receptacles and

charges its batteries; its “POWER” indicator light will be lit. If the utility line

power fails or becomes inadequate, the UPS will supply inverted AC power

to its receptacles if its batteries are sufﬁciently charged. Setting Advantages:

Provides battery backup during blackouts or brownouts.

• STANDBY Mode: DISABLES battery backup. UPS Conditions: While receiving

adequate utility line power, the UPS supplies power to its AC receptacles and

charges its batteries; the “POWER” indicator light will be ﬂashing. Setting

Advantages: Continues to charge the battery when power is present while

turning OFF the inverter to prevent battery depletion during power outages

when equipment is not in use.

Cold-Start Your UPS: You may “cold start” your UPS and use it as a stand-alone

power source when utility power is not present, providing that the UPS battery

is charged. To “cold start” your UPS, press and hold the UPS/STANDBY button

until you hear a beep (about 2 seconds), then release it. The “BATTERY CHARGE/

BATTERY POWER” indicator light will illuminate and AC power inverted from stored

battery power will be provided at the UPS receptacles.

Shut Down Your UPS: Press and hold the UPS/STANDBY button when AC

line power is absent (i.e. during a blackout, or when the UPS is unplugged) to

deactivate your UPS.

Note: Although some operational features and functions are common to all models, some

operational features vary depending on whether you are operating a Smart model or an

OmniSmart model.

15-11-178-9332C2.indb 8 12/4/2015 9:20:13 AM

Basic Operation continued

For All Models—“MUTE/TEST” Button:

To Re-enable Audible Alarms: The UPS is shipped with the audible alarms

muted by default. To re-enable the audible alarms, press and hold the MUTE/TEST

button until you hear a short beep followed by a continuous beep; then release the

button. To disable the audible alarms, press and hold the MUTE/TEST button until

you hear a short beep followed by another short beep; then release the button.

To Silence (or “Mute”) UPS Alarms: brieﬂy press and release the MUTE/TEST

button.*

To Run a Self-Test: With your UPS plugged in and turned ON, press and hold

the MUTE/TEST button for two seconds.* The alarm will beep several times and

the UPS will perform a self-test. See “Results of a Self-Test” below. Note: you

can leave connected equipment on during a self-test. Your UPS, however, will not

perform a self-test if it is not turned ON (see “POWER” Button description).

CAUTION! Do not unplug your UPS to test its batteries. This will remove

safe electrical grounding and may introduce a damaging surge into your

network connections.

Results of a Self-Test: The test will last approximately 10 seconds as the

UPS switches to battery to test its load capacity and battery charge.** If the

“OUTPUT LOAD LEVEL” LED remains lit red and the alarm continues to sound

after the test, the UPS’s outlets are overloaded. To clear the overload, unplug

some of your equipment and run the self-test repeatedly until the “OUTPUT

LOAD LEVEL” LED is no longer lit red and the alarm is no longer sounding.

CAUTION! Any overload that is not corrected by the user immediately

following a self-test may cause the UPS to shut down and cease

supplying output power in the event of a blackout or severe brownout.

If the “BATTERY WARNING” LED remains lit and the alarm continues to sound

after the test, the UPS batteries need to be recharged or replaced. Allow the

UPS to recharge continuously for 12 hours, and repeat the self-test. If the

LED remains lit, contact Tripp Lite for service. If your UPS requires battery

replacement, visit www.tripplite.com/products/battery-ﬁnder/ to locate the

speciﬁc Tripp Lite replacement battery for your UPS.

*The alarm will beep once brieﬂy after the indicated interval has passed. **Smart models’

operation during the self-test: the “POWER” LED will be ﬂashing and the “OUTPUT LOAD

LEVEL” and “BATTERY CHARGE” LEDs will be lit and the UPS alarm will sound. OmniSmart

models’ operation during the self-test: all LEDs will be lit and the UPS alarm will sound.

15-11-178-9332C2.indb 9 12/4/2015 9:20:13 AM

Basic Operation continued

Indicator Lights

All Indicator Light descriptions apply when the UPS is plugged into an AC outlet and turned on.

“POWER” LED

For Smart Models Only: This green LED lights continuously when the UPS is ON

and supplying connected equipment with AC power from a utility source. The LED

ﬂashes and an alarm sounds (4 short beeps followed by a pause) to indicate the

UPS is operating from its internal batteries during a blackout or severe brownout.

If the blackout or severe brownout is prolonged, you should save ﬁles and shut

down your equipment since internal battery power will eventually be depleted.

See “BATTERY CHARGE” LED description below.

For OmniSmart Models Only: This green light will turn ON whenever your UPS

is receiving normal AC line power. It will ﬂash while the UPS is in CHARGE ONLY

mode to indicate that the UPS will not provide battery backup during a blackout

or brownout.

“VOLTAGE CORRECTION” LED (For Select Smart and OmniSmart Models):

This green LED lights continuously whenever the UPS is automatically correcting

high or low AC voltage on the utility line without the assistance of battery power.

The UPS will also emit a slight clicking noise. These are normal, automatic

operations of the UPS. No action is required on your part.

“OUTPUT LOAD LEVEL” LED (For Select Smart and OmniSmart Models):

For Smart Models Only: This multicolored LED indicates the approximate

electrical load of equipment connected to the UPS’s AC outlets. It will turn from

green (light load) to yellow (medium load) to red (overload). If the LED is red

(either illuminated continuously or ﬂashing), clear the overload immediately by

unplugging some of your equipment from the outlets until the LED changes from

red to yellow (or green) and the alarm is no longer sounding. CAUTION! Any

overload that is not corrected by the user immediately may cause the UPS

to shut down and cease supplying output power in the event of a blackout

or severe brownout.

For OmniSmart Models Only: This red light will turn ON continuously when the

UPS is providing power from battery or after the UPS runs a self-test to indicate

that the UPS’s inverter is overloaded. If it lights up, immediately remove some

of the equipment connected to the UPS and run a self-test. CAUTION! Any

overload that is not corrected by the user immediately may cause the UPS

to shut down and cease supplying output power in the event of a blackout

or severe brownout.

15-11-178-9332C2.indb 10 12/4/2015 9:20:13 AM

Autres manuels pour SMART700HG

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Tripp Lite UPS

Tripp Lite

Tripp Lite DCOW 2 Manuel utilisateur

Tripp Lite

Tripp Lite Line-Interactive UPS System SMART750USB Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU8000RT4U Manuel utilisateur

Tripp Lite

Tripp Lite SM1500NAFTA Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline 2-9USTAND Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro VS SMART2200VS Manuel utilisateur

Tripp Lite

Tripp Lite OmniPro 300VA Manuel utilisateur

Tripp Lite

Tripp Lite SMART1200LCD Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU30K3/3 Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro SMART2600RM2U Instructions d'installation et d'utilisation

Tripp Lite

Tripp Lite SmartOnline SU1000RTXLCD2U Guide de configuration

Tripp Lite

Tripp Lite UPS System AVRX550U Manuel utilisateur

Tripp Lite

Tripp Lite ECO-UPS ECO650LCD Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro 3U Rackmount Manuel utilisateur

Tripp Lite

Tripp Lite AVRX Series Manuel utilisateur

Tripp Lite

Tripp Lite SUPDMB6KIEC Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU20K3/3XR5 Manuel utilisateur

Tripp Lite

Tripp Lite SMX1500LCD Manuel utilisateur

Tripp Lite

Tripp Lite OMNIVS1500XLTAA Manuel utilisateur

Tripp Lite

Tripp Lite ECO550UPS Manuel utilisateur

Tripp Lite

Tripp Lite OMNIVSINT800 Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU3000RTXL2U Manuel utilisateur

Tripp Lite

Tripp Lite OmniSmart OMNISMART500 Manuel utilisateur

Tripp Lite

Tripp Lite BC Pro BCPRO600 Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
