Owner’s Manual
4K x 2K UHD HDMI Switch
Models:
B119-002-UHD (2-Port),
B119-004-UHD (4-Port),
B119-005-UHD (5-Port)
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
Español 11 • Français 21 • Русский 31
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
tripplite.com/warranty
2
Product Features
• Switch between multiple HDMI source
devices connected to a single HDMI port on
a monitor
• Switch devices via pushbutton or the
included remote control
• Intelligent Auto Switching functionality will
automatically switch to the next powered-on
device when the power to the current device
is turned off*
• Supports 4K x 2K Ultra High Definition
(UHD) video resolutions up to 3840 x 2160
@ 60 Hz
• Supports up to 48-bit Deep Color
(16 bits per channel)
• Supports DTS-HD, Dolby®TrueHD and
7.1 channel surround sound audio
• 3D, HDCP v2.2 and EDID compatible
• The B119-005-UHD model includes an
international power supply with compatible
North American, U.K., European and
Australian plug adapters.
• Plug and play; no software or drivers
required
3
Package Contents
• B119-002-UHD, B119-004-UHD or
B119-005-UHD
• Remote Control
• External Power Supply
(Input: 100-240V, 50/60 Hz, 0.3A;
Output: 5V 1A)*
• Owner’s Manual
*Includes NEMA 1-15P (North America), CEE 7/16
Schuko (Europe), BS 1363 (U.K.) and AS/NZS 3112
(Australia) plugs.
Product Features
*Auto switching will not work properly if you have a
device that is in sleep mode. Devices must be powered
off completely for auto switch to work properly.
4
Installation
1. Make sure the power to all devices that you
will be connecting is turned off.
2. Connect an HDMI source device to an
Input port on the switch.
Note: The length of the HDMI cable connecting
the source to the switch must not exceed 16 ft.
(5 m).
3. Repeat step 2 to connect source devices to
the remaining Input ports on the switch.
4. Connect the Output port on the switch to
the HDMI input port of your display.
Note: The length of the HDMI cable connecting
the switch to the display must not exceed 16 ft.
(5 m).
Optional Accessories
• P569-XXX-CERT Premium High-Speed HDMI
with Ethernet Cables
5
Installation
5. Connect the external power supply to the
switch, and then plug it into a Tripp Lite
Surge Protector, Uninterruptible Power
Supply (UPS), or Power Distribution Unit
(PDU). The red Power LED and green
Input 1 LED will illuminate to indicate that
power is being received.
6. Turn on the power to the HDMI source
devices and display.
7. Switch between source devices via the
Select pushbutton on the unit or the
included remote control. You can also let
the Auto Switch functionality automatically
switch to ports that are powered on. When
multiple ports have powered on devices
connected to them, the lowest numbered
port will be switched to. Once the device
connected to the lowest numbered port is
powered off, the next powered on port in
line will be switched to.
6
Troubleshooting
If you are unable to get an acceptable image
after following the installation instructions, try
the troubleshooting tips below.
1. Is the external power supply that came
with the product connected and plugged
into a working power source? For the
product to function properly, the switch must
be connected to and receiving power from
an external power supply.
2. Was the power to the connected devices
turned off prior to installation? If not,
restart them.
3. What resolution are you trying to reach?
Tripp Lite’s B119-002-UHD, B119-004-UHD
and B119-005-UHD are tested to support
4K x 2K Ultra High Definition (UHD) video
resolutions up to 3840 x 2160 @ 60 Hz,
and 48-bit Deep Color (16 bits per channel).
4. What length HDMI cable are you using?
(See the Installation section in this manual
for details on the maximum cable distance).
The shorter the cable being used, the higher
the resolution you will be able to obtain.
(continued)
7
Troubleshooting
If you are not able to get an acceptable
image, try using a shorter cable, or lowering
your source’s video resolution or color depth
settings.
5. What type of cabling are you using?
Inferior cabling can result in poor
performance, so it is important that you use
cables that can support the video resolution
you are trying to obtain. It is recommended
that you use Tripp Lite’s P569-Series High
Speed HDMI cables, as they have been
tested to work with the B119-002-UHD,
B119-004-UHD and B119-005-UHD.
6. Test your cables to ensure they are
working properly. For example, connect
your HDMI cable between a source and
monitor that you know works to see if the
cable is functioning.
7. Is the unit located in an area that
exposes it to higher temperatures? If the
product is overheated, it will not function
properly.
8
Specifications
Model B119-002-UHD B119-004-UHD B119-005-UHD
Connectors
Input (x2) HDMI Female (x4) HDMI Female (x5) HDMI Female
Output HDMI Female HDMI Female HDMI Female
Video
Maximum
Resolution
3840 x 2160
(60 Hz)
3840 x 2160
(60 Hz)
3840 x 2160
(60 Hz)
Color Depth 48-bit Deep Color
(16 bits per channel)
48-bit Deep Color
(16 bits per channel)
48-bit Deep Color
(16 bits per channel)
Video Amplifier
Bandwidth
6Gbps / 600Mhz 6Gbps / 600Mhz 6Gbps / 600Mhz
Environmental
Operating
Temperature
32 to 104°F
(0 to 40°C)
32 to 104°F
(0 to 40°C)
32 to 104°F (0 to
40°C)
Operating
Humidity
10% to 85% RH,
Non-Condensing
10% to 85% RH,
Non-Condensing
10% to 85% RH,
Non-Condensing
Storage
Temperature
14 to 176°F
(-10 to 80°C)
14 to 176°F
(-10 to 80°C)
14 to 176°F (-10
to 80°C)
Storage Humidity 5% to 90% RH,
Non-Condensing
5% to 90% RH,
Non-Condensing
5% to 90% RH,
Non-Condensing
Physical
Unit Dimensions
(HxWxD, in.)
0.8 x 3.1 x 2.0 0.8 x 4.8 x 2.0 0.8 x 4.8 x 2.0
Unit Dimensions
(HxWxD, mm)
20 x 80 x 51 20 x 123 x 51 20 x 123 x 51
Unit Weight (lb.) 0.23 0.33 0.33
Unit Weight (kg) 0.1062 0.15 0.15
Power Requirements
External Power
Supply
5V/1A 5V/1A 5V/1A
Power
Consumption
(Max)
2W 2W 2.5W
9
Warranty and Product Registration
3-YEAR LIMITED WARRANTY
TRIPP LITE warrants its products to be free from defects in
materials and workmanship for a period of three (3) years
from the date of initial purchase. TRIPP LITE’s obligation
under this warranty is limited to repairing or replacing (at its
sole option) any such defective products. To obtain service
under this warranty, you must obtain a Returned Material
Authorization (RMA) number from TRIPP LITE or an authorized
TRIPP LITE service center. Products must be returned to
TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by
a brief description of the problem encountered and proof of
date and place of purchase. This warranty does not apply to
equipment, which has been damaged by accident, negligence
or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
Some states do not permit limitation or exclusion of implied
warranties; therefore, the aforesaid limitation(s) or exclusion(s)
may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF
THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any
costs, such as lost profits or revenue, loss of equipment, loss
of use of equipment, loss of software, loss of data, costs of
substitutes, claims by third parties, or otherwise.
10
Warranty and Product Registration
PRODUCT REGISTRATION
Visit tripplite.com/warranty today to register your new Tripp Lite
product. You’ll be automatically entered into a drawing for a
chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some
restrictions apply. See website for details.
WEEE Compliance Information for Tripp Lite Customers
and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment
(WEEE) Directive and implementing regulations,
when customers buy new electrical and electronic
equipment from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one,
like-for-like basis (this varies depending on the
country)
• Send the new equipment back for recycling when
this ultimately becomes waste
Use of this equipment in life support applications where failure
of this equipment can reasonably be expected to cause the
failure of the life support equipment or to significantly affect its
safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice.
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
19-08-201 93-37C3_RevD
