Tripp Lite B004-002 Series Manuel utilisateur

Tripp Lite World Headquarters

1111 W. 35th Street, Chicago, IL 60609 USA

(773) 869-1234, www.tripplite.com

User’s Manual

KVM Switches

(PS/2 Type)

Model #’s: B004-002 Series

B004-004 Series

NOTE: Follow these installation and operating procedures to ensure correct

performance and to prevent damage to this unit or to its connected devices.

their respective owners. Technical specifications are subject to change without notice.

Español 11

Français 21

Deutsch 31

Portuguese 41

Features

• Control multiple computers from a single Keyboard,

Monitor and Mouse

• Supports PC (PS/2) Computers

• Select PC either manually or from keyboard using

Hot Keys

• No external power required

• No software required. Works with all Operating

Systems

• Supports Microsoft Intellimouse, Logitech NetMouse

and the Scrolling Wheel on most mice

• Supports Ultra High 180MHz Video Resolution

up to 1920 x 1440 Resolution

• Automatically recalls each keyboard’s settings

(Caps Lock, Num Lock, and Scroll Lock)

• LED display identifies which system is connected

• Hot Pluggable: Add/remove any PC without

powering down the switch or other PCs

Hardware Requirements

Console

• One VGA, SVGA, or Multisync monitor capable of

the highest resolution being used on any of the PCs.

• One PS/2 mouse.

• One PS/2 style keyboard.

Each connected PC must have:

• A VGA, SVGA or Multisync card.

• A mini-DIN 6 (PS/2 style) mouse port.

• Either a mini-DIN 6 (PS/2 style) keyboard port or a

DIN5 (AT style) keyboard port (see below).

Cables

One cable kit per PC to connect it to the KVM Switch

(Tripp Lite Model #P754-006 or P754-010).

Note: 1) The keyboard and mouse cables in the above

kit have PS/2 style connectors at each end.

If your PC has an AT style keyboard port,

use AT-to-PS/2 keyboard adapter (Tripp Lite

Model #P106-000) to plug the cable into the

PC’s keyboard port.

2) KVM Switch does not support serial mice.

Installation

Before you begin, make sure that power to all the

devices you will be connecting up have been turned off.

1. Plug the keyboard and mouse into the appropriate

ports on the front of the KVM switch. Connect the

monitor to the Console port located on the back of

the switch.

2. Use the cables in the cable kit (see Hardware

Requirements section) to connect the monitor, key

board and mouse ports of each of the PCs to the

appropriate ports on the back of the switch.

3. Turn on the power to the connected PCs.

Note: The switch’s Power On default links the switch

to the first computer you turn on.

Warning: Do not switch between PCs during boot-

up procedure.

Operation

Manual Port Selection

Press the Port Selection button on the KVM Switch to

switch between computers. The LED lights to indicate

which port is active.

Hot Key Port Selection

Hot Key navigation lets you select the active PC or initi-

ate an Auto Scan procedure directly from the keyboard.

1. Selecting the Active Port:

Toggle between PCs by pressing and releasing the

[Scroll Lock] key twice, then pressing the " " or

" " key.

2. Auto Scan Mode:

Auto Scan automatically switches between PCs at

regular 4 second intervals. To invoke the Auto Scan

Mode, press and release the [Scroll Lock] key twice,

then press and release the [s] key. Scanning continues

until the [spacebar] is pressed to exit the Auto Scan

Mode. The port that was active when the [spacebar]

was pressed remains active.

Note: While Auto Scan Mode is in effect, none of the

other keyboard keys will function. The Auto

Scan Mode must be exited in order to use the

console for anything else.

LED Display

A lit LED identifies which PC is currently selected. A

continually lit LED indicates that the switch is in the

Manual Mode. A flashing LED indicates that the switch

is in the Auto Scan Mode.

Appendix

Troubleshooting

If you are experiencing problems, first make sure

that there are no cable problems. Check all cable

connections.

Problem Cause Solution

Keyboard Not Keyboard needs to Unplug the keyboard

Responding* be reset from the Switch, then

plug it back in.

Switch needs to be Turn off the PCs. Wait 5

reset seconds; then turn the

PCs on.

Switch is in

Auto

Press the [spacebar] to

Scan

Mode exit

Auto Scan

Mode.

Switched between Shut down the PC and

PCs during boot-up reboot without switching

procedure between PCs.

Problem Cause Solution

Mouse Not

Responding**

Mouse needs to be

reset

Unplug the mouse from

the Switch, then plug it

back in.

Switch needs to be

reset

Turn off the PCs. Wait 5

seconds; then turn the

PCs on.

Wrong type of

mouse or adapter

The switch will only

work with a PS/2

mouse. A serial mouse

cannot be converted to

a PS/2 mouse by using

a serial to PS/2 adapter.

One exception is a

combo-mouse which is

specifically designed for

both applications. In

this case, ensure that

the mouse is set up for

PS/2 mode and is being

used with the adapter

originally provided.

Unsupported or

incorrect mouse

driver

Each PC needs to be

using the mouse driver

correlating to the mouse

connected to the

console port.

Some newer mice (with

extra buttons and

wheels) have unique

drivers that may not be

supported. Try a regular

mouse with a generic

mouse driver (like the

one that comes with the

operating system).

Problem Cause Solution

* This Switch is designed to work with AT and PS/2

keyboards. Older XT (84 key) and some older AT

keyboards (those with the function keys on the side)

will not work.

** Some Notebook computers, notably the IBM

Thinkpad and Toshiba Tecra, have trouble

working with a switch when their mouse and

keyboard ports are used simultaneously. To avoid

this problem, only connect the mouse port or the

keyboard port to the Switch. If you connect the

mouse port, you will need to use the notebook’s

keyboard when the notebook is the active

computer.

Video

Problems Resolution and/or

Bandwidth set too

high

The Switch supports

VGA, SVGA, Multisync,

and XGA (interlaced)

monitors with resolutions

of up to 1920x1440 Hz.

The maximum bandwidth

is 180 MHz.

A power source

such as a power

panel or poorly

insulated device is

too close to the

KVM switch or its

cables

Move the device that is

creating the electromag-

netic interference, or

move the KVM switch

and/or its cables.

Specifications

FCC Radio / TV Interference Notice

Note: This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interfer-

ence in which case the user will be required to correct the interference at his own

expense. The user must use shielded cables and connectors with this product. Any

changes or modifications to this product not expressly approved by the party respon-

sible for compliance could void the user’s authority to operate the equipment.

PC Connections

Port Selection

LEDs

Connectors

Scan Interval

Power Adapter

(User Supplied)

Keyboard

Mouse

Video

2 (B004-002 Series) or

4 (B004-004-R)

Push Button Switch; Hot Keys

1 per port

1 x 6 pin mini-DIN female (PS/2

style) – Console

1 x 6 pin mini-DIN female (PS/2

style) per CPU Port

1 x 6 pin mini-DIN female (PS/2

style) – Console

1 x 6 pin mini-DIN female (PS/2

style) per CPU Port

1 x HDB-15 female (std.

VGA/SVGA) – Console

1 x HDB-15 male (std. VGA/SVGA)

per CPU Port

4 Seconds

9V, 500 milliamp

5-YEAR LIMITED WARRANTY

TRIPP LITE warrants its products to be free from defects in materials and workman-

ship for a period of five (5) years from the date of initial purchase. TRIPP LITE’s

obligation under this warranty is limited to repairing or replacing (at its sole option)

any such defective products. To obtain service under this warranty, you must obtain

a Returned Material Authorization (RMA) number from TRIPP LITE or an author-

ized TRIPP LITE service center. Products must be returned to TRIPP LITE or an

authorized TRIPP LITE service center with transportation charges prepaid and must

be accompanied by a brief description of the problem encountered and proof of date

and place of purchase. This warranty does not apply to equipment which has been

damaged by accident, negligence or misapplication or has been altered or modified in

any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limi-

tation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or

exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE

FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL

DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF

ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP

LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss

of use of equipment, loss of software, loss of data, costs of substitutes, claims by third

parties, or otherwise.

TRIPP LITE has a policy of continuous improvement. Specifications are subject to

change without notice.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Tripp Lite Changer

Tripp Lite

Tripp Lite NSU-G16 Manuel utilisateur

Tripp Lite

Tripp Lite B170-004-R Manuel utilisateur

Tripp Lite

Tripp Lite NetCommander B072-008-1 Manuel utilisateur

Tripp Lite

Tripp Lite B004-VPA2-K-R Guide de l'utilisateur

Tripp Lite

Tripp Lite U223-007-IND Manuel utilisateur

Tripp Lite

Tripp Lite PDUMH30AT Manuel utilisateur

Tripp Lite

Tripp Lite NetDirectorB030-DP16-17DIP Manuel utilisateur

Tripp Lite

Tripp Lite B022-002-KT-R Manuel utilisateur

Tripp Lite

Tripp Lite NetCommander B070-016-19-IP2 Manuel utilisateur

Tripp Lite

Tripp Lite B119-003-UHD-MN Manuel utilisateur

Tripp Lite

Tripp Lite B119-302-R Manuel utilisateur

Tripp Lite

Tripp Lite NetDirector B030-DP08-17DIP Manuel utilisateur

Tripp Lite

Tripp Lite U215-004-R Manuel utilisateur

Tripp Lite

Tripp Lite B119-003-UHD Manuel utilisateur

Tripp Lite

Tripp Lite 0SU22082 Guide de configuration

Tripp Lite

Tripp Lite B022-U16-IP Manuel utilisateur

Tripp Lite

Tripp Lite 4-Port USB 2.0 Self- or Bus-Powered Ultra-Mini Hub... Manuel utilisateur

Tripp Lite

Tripp Lite U460-004-2A2C Manuel utilisateur

Tripp Lite

Tripp Lite 4 Port USB 1.1 Self- or Bus-Powered Hub... Manuel utilisateur

Tripp Lite

Tripp Lite 0DT60001 Manuel utilisateur

Tripp Lite

Tripp Lite B310-701-4K Manuel utilisateur

Tripp Lite

Tripp Lite B004-VPA2-K-R Guide de configuration

Tripp Lite

Tripp Lite NetCommander B070-008-19-IP Manuel utilisateur

Tripp Lite

Tripp Lite NetCommander B070-008-19 Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
