Tripp Lite B203-101-POC Manuel utilisateur

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

win an ISOBAR surge protector in our monthly drawing!

tripplite.com/warranty

Owner’s Manual

1-Port USB 2.0 over Cat5

Plug-and-Play Extender Kit

with Power over Cable

Model: B203-101-POC

4-Port USB 2.0 over Cat5

Plug-and-Play Extender Kit

with Power over Cable

Model: B203-104-POC

Español 9 • Français 16 • Русский 23

Product Features

Package Includes

• B203-101-POC extends a USB 2.0 signal up to 164 ft. (50 m)

from the source

• The B203-104-POC allows you to connect four USB 2.0

devices up to 164 ft. (50 m) from the source

• Supports USB 2.0 data transfer rates up to 480 Mbps

• Power over Cable (PoC) technology provides power to the

receivers via Cat5 cable

• Backward compatible with USB 1.1

• Plug-and-Play; no software or drivers required

• Compatible with all major operating systems

• B203-101-POC or B203-104-POC Transmitter

• B203-101-POC or B203-104-POC Receiver

• Owner’s Manual

Installation

Optional Accessories

Note: Test to make sure that the entire installation works properly before

pulling cables through ceilings or walls.

1. Connect the built-in USB cable on the transmitter unit to an

available USB port on your computer.

2. Connect the RJ45 ports on the transmitter and receiver units

with Cat5e/6 cable.

Note: The distance between the transmitter and receiver units must be

no longer than 164 ft. (50 m).

3. Connect a USB 2.0 device to each available port on the

receiver unit.

4. (Optional) If connecting power-hungry device(s), use the USB

Micro-B port on the receiver to add external power.

• N202-Series Cat6 Snagless Patch Cables

• U022-Series USB 2.0 Cables

• UR022-Series Reversible USB 2.0 Cables

• U030-Series USB 2.0 5-Pin Mini-B Cables

• UR030-Series Reversible USB 2.0 5-Pin Mini-B Cables

• U050-Series USB 2.0 Micro-B Cables

• UR050-Series Reversible USB 2.0 Micro-B Cables

Installation Diagrams

B203-101-POC

Workstation Web Cam

Transmitter Receiver USB Cable

24 AWG Solid CAT 6 Cable

Up to 164 ft. / 50 m

AC Outlet

B203-104-POC

Workstation

Web Cam

Printer

Hard Drive

Mouse

Transmitter Receiver

USB Cable

24 AWG Solid CAT 6 Cable

Up to 164 ft. / 50 m

* When connecting the receiver to high-power device(s), add external

power via its USB Micro-B port.

Speciﬁcations

Speciﬁcation B203-101-POC B203-104-POC

Supported USB Versions USB 2.0 (480 Mbps),

USB 1.1 (12 Mbps)

Transmitter Ports (x1) RJ45

Receiver Ports (x1) RJ45 ;

(x1) USB-A ;

(x1) USB Micro-B

(x1) RJ45 ;

(x4) USB-A ;

(x1) USB Micro-B

Transmitter Plug USB-A

Maximum Extension

Distance

164 ft. (50 m)

Operating Temperature 32°F to 122°F (0° to 50°C)

Storage Temperature -4°F to 158°F (-20° to 70°C)

Transmitter Dimensions

[H x W x D]

0.59 x 14.36 x 1.02 in.

(15 x 365 x 26 mm)

Receiver Dimensions

[H x W x D]

0.59 x 2.36 x

1.02 in.

(15 x 60 x 26 mm)

1.95 x 1.00 x

2.42 in.

(50 x 26 x 62 mm)

Warranty and

Product Registration

1-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials

and workmanship for a period of one (1) year from the date of initial

purchase. TRIPP LITE’s obligation under this warranty is limited to

repairing or replacing (at its sole option) any such defective products. To

obtain service under this warranty, you must obtain a Returned Material

Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE

service center. Products must be returned to TRIPP LITE or an authorized

TRIPP LITE service center with transportation charges prepaid and must

be accompanied by a brief description of the problem encountered

and proof of date and place of purchase. This warranty does not apply

to equipment which has been damaged by accident, negligence or

misapplication or has been altered or modiﬁed in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties;

therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the

purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE

FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL

DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF

ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Speciﬁcally,

TRIPP LITE is not liable for any costs, such as lost proﬁts or revenue,

loss of equipment, loss of use of equipment, loss of software, loss of

data, costs of substitutes, claims by third parties, or otherwise.

Warranty and

Product Registration

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product.

You’ll be automatically entered into a drawing for a chance to win a FREE

Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. Open to

U.S. residents only. See tripplite.com for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of

the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

19-12-207 93-3BC4_RevA

Warranty and

Product Registration

Any changes or modiﬁcations to this equipment not expressly approved by

Tripp Lite could void the user’s authority to operate this equipment.

WEEE Compliance Information for Tripp Lite Customers and

Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE)

Directive and implementing regulations, when customers buy

new electrical and electronic equipment from Tripp Lite they are

entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like

basis (this varies depending on the country)

• Send the new equipment back for recycling when this

ultimately becomes waste

Tripp Lite has a policy of continuous improvement. Product speciﬁcations

are subject to change without notice. Photos and illustrations may differ

slightly from actual products.

1111 W. 35th Street, Chicago, IL 60609, EE UU • tripplite.com/support

Manual del Propietario

USB 2.0 de 1 Puerto sobre

Cat5 Juego Extensor para

Conectar y Usar con PoC

Modelo: B203-101-POC

USB 2.0 de 4 Puertos sobre

Cat5 Juego Extensor para

Conectar y Usar con PoC

Modelo: B203-104-POC

English 1 • Français 16 • Русский 23

Características del Producto

El Paquete Incluye

• El B203-101-POC extiende una señal USB 2.0 hasta a 50 m

[164 pies] de la fuente

• El B203-104-POC le permite conectar cuatro dispositivos

USB 2.0 hasta a 50 m [164 pies] de la fuente

• Soporta velocidades de transferencia de datos USB 2.0 de

hasta 480 Mbps

• La tecnología PoC proporciona energía a los receptores

mediante cable Cat6

• Es compatible con el USB 1.1

• Conectar y usar; no requiere software ni controladores

• Compatible con todos los principales sistemas operativos

• Transmisor B203-101-POC o B203-104-POC

• Receptor B203-101-POC o B203-104-POC

• Manual del Propietario
