Tripp Lite U344-001-DP Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: U344-001-DP

USB 3.0 to Displayport Video Adapter

Highlights

Add an additional monitor for Extended Desktop Display

Up to six adapters can be added to one computer

Backward compatible to USB 2.0

Requires no external power supply

Description

Tripp Lite U344-001-DP, USB 3.0 to DisplayPort® Multi Monitor Adapter, creates as an external DisplayPort video card, via an available USB 3.0

port on your PC or Laptop. Connect up to six Displayport enable monitors, with resolution support of 2560x1600 video, and 5.1 surround sound

audio.

Taking advantage of the SuperSpeed USB 3.0 interface ( 5Gbps), the adapter delivers smooth, high-definition content to your DisplayPort-capable

display, and can be used to clone the image across multiple displays, or use in Extended Desktop Display mode.

Applications

Office workstation

View large spreadsheets across multiple screens

Multitask more effectively without overlapping windows

Edit on one screen while surfing the Internet for information on the other

On the road

Do multiple screen presentations without bringing another computer

Easily provide multiple screen exhibitions in a trade show

Graphics workstation

Use second display for palettes/tools

Get a panoramic view of large documents

Editing workstation

Type documents on one screen while viewing reference material on the other

Compare two documents simultaneously across two screens

Financial analysis

Have one monitor per data stream

View charts and live data at the same time

Entertainment

View videos/TV on one screen and reviews on the other

Get additional perspectives when playing games

System Requirements

Windows PC with: WIN8 32/64, WIN7 32/64, Vista 32/64, XP 32/64, WIN2000 ( Aero 3D interface supported)

Supports Surface Pro tablets running Windows 8 Pro and Surface Pro 2 tablets running Windows 8.1 Pro

Apple OSX Mountain Lion (10.8), Lion (10.7), Snow Leopard ( 10.6 )

Audio Support not available for Apple systems

If using OS X 10.8, Apple update 10.8.3 must be installed before installing DisplayLink Software

Refer to User Manual ( under Support tab ) for multi-monitor CPU and RAM requirements

Package Includes

U344-001-DP Adapter

Driver CD

USB 3.0 Cable

Owners Manual

Features

Adds an additional monitor, LCD or projector through a single USB 3.0 port

USB 3.0 is 10 times faster than USB 2.0, with transfer rates up to 5 Gbps

Backward compatible with USB 2.0

Simultaneously connect up to 6 display adapters

Automatically resumes from hibernation and suspend modes

Features 512MB DDR2 SDRAM of memory

U344-001-R and U344-001-HDMI-R support video resolutions up to 2048 x 1152 @ 60Hz

U344-001-DP supports video resolutions up to 2560 x 1600 @ 60Hz

Video streaming is supported up to 1080p

Set additional monitors to extend the primary display, duplicate the primary display, or set an additional monitor as the primary display

DisplaLink DL3500 Chipset

Refer to User Manual ( under Support Tab ) for additional CPU and RAM requirements for multiple adapters

Supports Surface Pro tablets running Windows 8 Pro and Surface Pro 2 tablets running Windows 8.1 Pro

Specifications

OVERVIEW

Amp Capacity Bus Powered ( 340mA operating power )

Display Style Adapter

PHYSICAL

Unit Dimensions (HWD/in) 0.4 x 1.0 x 3.2

Unit weight (lbs) 0.7

Color Black

ENVIRONMENTAL

Storage Temperature Range -10 to 80 C ( 14 - 176 F )

Relative Humidity Less than 85%, Non-Condensing

Operating Temperature 10 - 40 C ( 50 - 104 F )

CONNECTIONS

Connector A

USB 3.0 MICRO-B (FEMALE)

Connector B

DISPLAYPORT (FEMALE)

WARRANTY

Product Warranty Period

(Worldwide)

1-year limited warranty

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=5527.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
