Tripp Lite U444-06N-HD4K6B Manuel utilisateur

Owner’s Manual

USB Type-C™

Display Adapters

Models: U444-06N-HD4K6B (USB Type-C to HDMI),

U444-06N-DP4K6B, U444-06N-DP4K6W

(USB Type-C to DisplayPort)

USB Type-C and USB-C are trademarks of USB Implementers Forum

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

All trademarks are the property of their owners.

Este manual esta disponible en español en la página

de Tripp Lite: www.tripplite.com.

Ce manuel est disponible en français sur le site Web

de Tripp Lite : www.tripplite.com.

Русскоязычная версия настоящего руководства

представлена на веб-сайте компании Tripp Lite по

адресу: www.tripplite.com.

17-12-253-9336D3-EN.indd 1 1/8/2018 10:21:47 AM

Product Features

• Add an additional 4K HDMI or DisplayPort™

monitor via the USB-C or Thunderbolt™

3 port on your laptop, tablet or other device

• Supports USB DisplayPort Alternate Mode,

allowing you to transmit an audio/video

signal via the USB Type-C port on your

smartphone, tablet, Ultrabook or computer

•

U444-06N-HD4K6B

supports HDMI 2.0a

video resolutions up to 4096 x 2160

(4K x 2K) @ 60 Hz as well as HDCP 2.2

compatibility

•

U444-06N-DP4K6B and U444-06N-DP4K6W

supports video resolutions up to

3840 x 2160, UHD 4K (4K x 2K) @ 60 Hz

• Supports 24-bit Deep Color (8 bits per

channel) max

• Supports max per lane data transfer rates

of 5.4 Gbps (HBR2), 2.7 Gbps (HBR) and

1.62 Gbps (RBR)

• Supports 7.1 surround sound audio

• Thunderbolt 3 port compatible

• Speciﬁcally designed for use with the

MacBook®, Google Chromebook Pixel™ and

USB Type-C supported computers

17-12-253-9336D3-EN.indd 2 1/8/2018 10:21:47 AM

Product Features

Package Contents

System Requirements

Optional Accessories

• Slim design is perfect for travel and stores

easily in your laptop bag when not in use

• Plug-and-Play; no software or drivers

required

• U444-06N-HD4K6B, U444-06N-DP4K6B or

U444-06N-DP4K6W

• Owner’s Manual

• USB Type-C or Thunderbolt 3 device that

supports USB DisplayPort Alternate Mode

• DisplayPort or HDMI monitor

• P568-Series High-Speed HDMI Cables

• P569-XXX-CERT Premium High-Speed

Cables with Gripping Connectors

• P580-Series DisplayPort Cables

17-12-253-9336D3-EN.indd 3 1/8/2018 10:21:47 AM

Installation

1. Connect the USB Type-C connector on the

adapter to the USB Type-C port on your

smartphone, tablet, Ultrabook or computer.

2. Connect the DisplayPort or HDMI port on

the adapter to a monitor using a DisplayPort

or HDMI cable (such as Tripp Lite’s

P580-Series DisplayPort cables or

P568-Series HDMI cables).

3. The video image will appear on the add-on

monitor. Customize how video is displayed

on the add-on monitor using your device’s

display settings.

17-12-253-9336D3-EN.indd 4 1/8/2018 10:21:47 AM

Speciﬁcations

U444-06N-HD4K6B U444-06N-DP4K6B /

U444-06N-DP4K6W

Connectors-Input

USB USB-C (Male)

Connectors-Output

Ethernet HDMI (Female) DisplayPort (Female)

Video

Maximum Resolutions 4096 x 2160, UHD 4K,

@ 60 Hz

3840 x 2160, UHD 4K,

@ 60 Hz

Color Depth 24-bit Deep Color (8 bits per channel)

Environmental

Operating Temperature -4° to 158°F (-20° to 70°C)

Storage Temperature -4° to 185°F (-20° to 85°C)

Relative Humidity 5% to 90% RH, Non-Condensing

17-12-253-9336D3-EN.indd 5 1/8/2018 10:21:47 AM

Warranty and

Product Registration

3-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in

materials and workmanship for a period of three (3) years

from the date of initial purchase. TRIPP LITE’s obligation

under this warranty is limited to repairing or replacing (at its

sole option) any such defective products. To obtain service

under this warranty, you must obtain a Returned Material

Authorization (RMA) number from TRIPP LITE or an authorized

TRIPP LITE service center. Products must be returned to

TRIPP LITE or an authorized TRIPP LITE service center with

transportation charges prepaid and must be accompanied by

a brief description of the problem encountered and proof of

date and place of purchase. This warranty does not apply to

equipment, which has been damaged by accident, negligence

or misapplication or has been altered or modiﬁed in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE.

Some states do not permit limitation or exclusion of implied

warranties; therefore, the aforesaid limitation(s) or exclusion(s)

may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE

BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR

CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF

THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGE. Speciﬁcally, TRIPP LITE is not liable for any

costs, such as lost proﬁts or revenue, loss of equipment, loss

of use of equipment, loss of software, loss of data, costs of

substitutes, claims by third parties, or otherwise.

17-12-253-9336D3-EN.indd 6 1/8/2018 10:21:47 AM

Warranty and

Product Registration

Visit www.tripplite.com/warranty today to register your new

Tripp Lite product. You’ll be automatically entered into a

drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply.

See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may

not cause harmful interference, and (2) this device must

accept any interference received, including interference that

may cause undesired operation.

Note: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference

by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for

help.

17-12-253-9336D3-EN.indd 7 1/8/2018 10:21:47 AM

Warranty and

Product Registration

Any changes or modiﬁcations to this equipment not expressly

approved by Tripp Lite could void the user’s authority to operate

this equipment.

WEEE Compliance Information for Tripp Lite Customers

and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment

(WEEE) Directive and implementing regulations,

when customers buy new electrical and electronic

equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one,

like-for-like basis (this varies depending on the

country)

• Send the new equipment back for recycling when

this ultimately becomes waste

Use of this equipment in life support applications where failure

of this equipment can reasonably be expected to cause the

failure of the life support equipment or to signiﬁcantly affect its

safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement.

Speciﬁcations are subject to change without notice.

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

17-12-253 93-36D3_RevD

17-12-253-9336D3-EN.indd 8 1/8/2018 10:21:47 AM
