Owner’s Manual

USB Type-C™ to HDMI, VGA,

Gigabit Ethernet and USB-A

Hub Adapter

Models:

U444-06N-HV4GU (White),

U444-06N-HV4GUB (Black)

USB Type-C and USB-C are trademarks of USB Implementers Forum

PROTECT YOUR INVESTMENT!

peace of mind. You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

Este manual esta disponible en español en la página de

Tripp Lite: www.tripplite.com

Ce manuel est disponible en français sur le site Web de

Tripp Lite : www.tripplite.com

Русскоязычная версия настоящего руководства

представлена на веб-сайте компании Tripp Lite по

адресу: www.tripplite.com

18-08-021-9337A5-EN.indd 1 8/10/2018 1:31:34 PM

Package Includes

• U444-06N-HV4GU (White) or U444-06N-HV4GUB

(Black)

• Owner’s Manual

Optional Accessories

• N201-Series Cat6 Gigabit Snagless Patch Cables

• P502-Series High-Resolution VGA Cables with RGB

Coax

• P568-Series High-Speed HDMI Cables

• U322-Series USB 3.0 A/B Device Cables

• U326-Series USB 3.0 Micro-B Device Cables

18-08-021-9337A5-EN.indd 2 8/10/2018 1:31:34 PM

Product Features

• Supports USB DisplayPort Alternate Mode for

connecting a 4K HDMI monitor via a USB-C port

• Supports 4K x 2K Ultra High Deﬁnition (UHD)

resolutions up to 3840 x 2160 (30Hz)

• VGA port supports video resolutions up to

1920 x 1200 (60Hz) including 1080p

• Ethernet port supports true 10/100/1000 Mbps

network speeds

• USB-A hub port supports data transfer rates up to

5 Gbps; backward compatible with previous USB

generations

• HDCP 1.4 compatible

• Plug and play; no software or drivers required

18-08-021-9337A5-EN.indd 3 8/10/2018 1:31:34 PM

Installation

Note: When the unit is connected to the USB-C port on your

computer and to a network via Cat5e/6 cabling, a network

connection will be automatically established. If no connection

is made, you can manually establish one by going to your

computer’s network settings page. For example, on a Mac,

you would navigate to the Network section found in the

System Preferences, click the ‘Assist Me’ button to get to the

Network Setup Assistant, then follow the prompts to establish

a connection.

1. Connect the adapter’s USB Type-C connector to

the USB-C port on your laptop, tablet or other

compatible device.

2. Connect the adapter’s HDMI port to the monitor’s

HDMI port using an HDMI cable (such as Tripp Lite’s

P568-Series HDMI cables).

Connect the adapter’s VGA port to the monitor’s

VGA port using a VGA cable (such as Tripp Lite’s

P502-Series High-Resolution VGA cables with RGB

coax).

3. Connect a USB device to the adapter’s USB-A hub

port.

4. Connect the adapter’s RJ45 port to a network

using a UTP cable (such as Tripp Lite’s N201-

Series Cat6 cables).

18-08-021-9337A5-EN.indd 4 8/10/2018 1:31:34 PM

Models

U444-06N-

HV4GU

U444-06N-

HV4GUB

Input Connectors

USB USB-C (Male)

Output Connectors

4K HDMI HDMI (Female)

VGA VGA (Female)

USB USB-A (Female)

Ethernet RJ45 (Female)

Output Resolution

HDMI 3840 x 2160 @ 30Hz (4K x 2K)

VGA 1920 x 1200 @ 60Hz (1080p)

Environmental

Operating Temperature 32°F to 113°F (0°C to 45°C)

Operating Humidity 10% to 85% RH, Non-Condensing

Storage Temperature 14°F to 158°F (-10°C to 70°C)

Storage Humidity 5% to 90% RH, Non-Condensing

Power Requirements

USB 3.0 Port 5V 0.9A (4.5W)

Speciﬁcations

18-08-021-9337A5-EN.indd 5 8/10/2018 1:31:34 PM

Warranty and Product Registration

3-YEAR LIMITED WARRANTY

TRIPP LITE warrants its products to be free from defects in materials

and workmanship for a period of three (3) years from the date of

initial purchase. TRIPP LITE’s obligation under this warranty is limited

to repairing or replacing (at its sole option) any such defective

products. To obtain service under this warranty, you must obtain a

Returned Material Authorization (RMA) number from TRIPP LITE or

an authorized TRIPP LITE service center. Products must be returned

to TRIPP LITE or an authorized TRIPP LITE service center with

transportation charges prepaid and must be accompanied by a brief

description of the problem encountered and proof of date and place

of purchase. This warranty does not apply to equipment, which has

been damaged by accident, negligence or misapplication or has

been altered or modiﬁed in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied

warranties; therefore, the aforesaid limitation(s) or exclusion(s) may

not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE

BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR

CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS

PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH

DAMAGE. Speciﬁcally, TRIPP LITE is not liable for any costs, such as

lost proﬁts or revenue, loss of equipment, loss of use of equipment,

loss of software, loss of data, costs of substitutes, claims by third

parties, or otherwise.

PRODUCT REGISTRATION

Visit www.tripplite.com/warranty today to register your new Tripp Lite

product. You’ll be automatically entered into a drawing for a chance

to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions

apply. See website for details.

18-08-021-9337A5-EN.indd 6 8/10/2018 1:31:34 PM

Warranty and Product Registration

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause

undesired operation.

Note: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modiﬁcations to this equipment not expressly

approved by Tripp Lite could void the user’s authority to operate this

equipment.

18-08-021-9337A5-EN.indd 7 8/10/2018 1:31:34 PM

818-08-021 93-37A5_RevA

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

WEEE Compliance Information for Tripp Lite Customers and

Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment

(WEEE) Directive and implementing regulations, when

customers buy new electrical and electronic equipment

from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like

basis (this varies depending on the country)

• Send the new equipment back for recycling when this ultimately

becomes waste

Use of this equipment in life support applications where failure of

this equipment can reasonably be expected to cause the failure

of the life support equipment or to signiﬁcantly affect its safety or

effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Speciﬁcations are

subject to change without notice.

Warranty and Product Registration

18-08-021-9337A5-EN.indd 8 8/10/2018 1:31:34 PM
