TRENDnet P600 Manuel utilisateur

P600 Wireless 11g Outdoor AP Bridge

User Manual

Version 1.0

User’s Guide 1

No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical,

photocopying, recording, or otherwise without the prior writing of the publisher.

DEC. 2004

User’s Guide 2

Contents

1. Introduction............................................................................................................... 4

2. Safety Notification .................................................................................................... 5

3. AP Default Settings................................................................................................... 6

4. Web Management Settings ...................................................................................... 7

4.1. Primary Setup…………………………………………………………………………….8

4.2. System…………………………………………………………………………………...12

4.3. Operating Mode…………………………………………………………………………13

4.4. Status…………………………………………………………………………………….15

4.5 Traffic Log………………………………………………………………………………..16

4.6 Access Control…………………………………………………………………………..17

4.7 Advanced Wireless……………………………………………………………………...18

4.8. SNMP INFO……………………………………………………………………………..20

4.9. Upgrade Firmware……………………………………………………………………...21

5. Troubleshooting ..................................................................................................... 23

User’s Guide 3

1. Introduction

Thank you for purchasing your P600 Wireless 802.11g Outdoor AP Bridge.

This user guide will assist you with the installation procedure.

The package you have received should contain the following items:

 P600 Wireless 802.11g Outdoor AP Bridge

 CD - User Guide

 PoE Host / Cord

 Waterproof RJ-45 connector

 Mount Kit package

Note: if anything is missing, please contact your vendor

User’s Guide 4

2. Safety Notification

Your Wireless AP should be placed in a safe and secure location. To ensure proper operation, please

keep the unit away from water and other damaging elements. Please read the user manual thoroughly

before you install the device. The device should only be repaired by authorized and qualified

personnel.

 Please do not try to open or repair the device yourself.

 Do not place the device in a damp or humid location, i.e. a bathroom.

 The device should be placed in a sheltered and non-slip location within a temperature range of

+5 to +40 Celsius degree.

 Please do not expose the device to direct sunlight or other heat sources. The housing and

electronic components may be damaged by direct sunlight or heat sources.

User’s Guide 5

3. AP Default Settings

The default settings are shown following.

User admin

Password admin

AP IP Address 192.168.1.250

AP Subnet Mask 255.255.255.0

RF ESSID ap11g

11g RF Channel 6

Mode 11b+g

Encryption Disabled

User’s Guide 6

4. Web Management Settings

TURN ON POWER SUPPLY

Quick power cycle can caused system corruption. When power on, be careful not to shut down in

about 5 seconds, because data is writing to the flash.

START UP & LOGIN

In order to configure the outdoor Wireless 11g AP, you must use your web browser and manually input

http://192.168.1.250 into the Address box and press Enter. The Main Page will appear.

To start configure the outdoor Wireless 11g AP, you must login as “admin” in the User Name box.

And input password “admin” on the password section.

Once you have logged-in as administrator, it is a good idea to change the administrator password to

ensure a secure protection to the outdoor Wireless 11g AP. The Security Settings section described

later in this manual describes how to change the password.

Once you have input the correct password and logged-in, the screen will change to the Setup page

screen.

User’s Guide 7

4.1. Primary Setup

MAKE CORRECT NETWORK SETTINGS OF YOUR COMPUTER

To change the configuration, use Internet Explorer (IE) or Netscape Communicator to connect the

WEB management 192.168.1.250.

Primary Setup

This screen contains all of the AP's basic setup functions.

Most users will be able to configure the AP and get it working properly using the settings on this

screen.

LAN IP Address and Subnet Mask: This is the AP's IP Address and Subnet Mask as seen on the

internal LAN. The default value is 192.168.1.250 for IP Address and 255.255.255.0 for Subnet Mask.

Wireless: This section provide the Wireless Network settings for your WLAN

User’s Guide 8

Wireless Settings

SSID: The service set identifier ( SSID ) or network name. It is case sensitive and must not exceed 32

characters, which may be any keyboard character. You shall have selected the same SSID for all the

APs that will be communicating with mobile wireless stations.

Channel: Select the appropriate channel from the list provided to correspond with your network

settings. You shall assign a different channel for each AP to avoid signal interference.

Security: There are 3 types of security to be selected. To secure your Wireless Networks, it’s strongly

recommended to enable this feature.

-WEP Make sure that all wireless devices on your network are using the same encryption level and

key. WEP keys must consist of the letters "A" through "F" and the numbers "0" through "9."

User’s Guide 9

Important Notice

In order to make right use of WPA, please ensure that your current Wireless Adapter’s driver, and

Wireless Utility can support it, WPA needs 802.1x authentication (when RADIUS mode is chosen),

though the Operating System must also support 802.1x protocol. For Microsoft’s OS family, only

Windows XP has incorporated this by default. The rest of the OS must installed 3er party’s client

software such as Funk ODySSey.

-WPA-Preshared key

There are two encryption options for WPA Pre-Shared Key, TKIP and AES. TKIP stands for

Temporal Key Integrity Protocol. TKIP utilizes a stronger encryption method and incorporates

Message Integrity Code (MIC) to provide protection against hackers. AES stands for Advanced

Encryption System, which utilizes a symmetric 128-Bit block data encryption.

To use WPA Pre-Shared Key, enter a password in the WPA Shared Key field between 8 and 63

characters long. You may also enter a Group Key Renewal Interval time between 0 and 99,999

seconds.

WPA

Algorithms Please choose your algorithms method. You can select

between TKIP or AES.

WPA Shared

Key Please input the Pre-Shared Key. The key should be 8

characters or 63 characters in alphanumeric.

Group Key

Renewal Please input the period of renewal time. The default selection

is 300 seconds.

User’s Guide 10
