TRENDnet TEW-WLC100 Manuel utilisateur

TEW-WLC100

Quick Installation Guide

Table of Content

1 English

1. Before You Start

2. Hardware Installation and Configuration

3. Connect your wireless access points

1. Before You Start

Optional Equipment

ŸEIA standard 19” rack

You can download the access point firmware from http://www.trendnet.com/support which

include instructions on how to upgrade the firmware.

Access Point Compatibility

Access Point Model Description Firmware Version

TEW-755AP N300 PoE Access Point 1.02 or above

TEW-821DAP AC1200 Dual Band PoE Access Point 1.04 or above

Before you proceed, please ensure you are using one of the access point models in the list and

the firmware version of your access points has been upgraded accordingly to the versions

indicated in the list below. Please reset all access points to the factory default configuration.

Also, make sure your network is using a DHCP server to distribute IP addresses to the access

points. By default, TRENDnet access point models listed below will obtain an IP address

automatically through DHCP or otherwise default back to 192.168.10.100 / 255.255.255.0 if a

DHCP server is not available on your network. Each access point must be assigned a unique IP

address on the same network.

Package Contents

ŸTEW-WLC100

ŸQuick Installation Guide

ŸCD-ROM (User's Guide)

ŸPower adapter (12V DC, 1A)

ŸRack mount kit

Minimum Requirements

ŸComputer with an Ethernet port and web browser

ŸNetwork cable

ŸWireless Access point(s) (TEW-755AP, TEW-821DAP)

ENGLISHFRANÇAISDEUTSCH

ESPAÑOLРORTUGUÊS

2. Hardware Installation and Configuration

3. Assign a Static IP address to your computer's network adapter in the subnet of 192.168.10.x

(e.g. 192.168.10.25) and a subnet mask of 255.255.255.0.

4. Open your web browser, type the IP address of the switch in the address bar, and then press

Enter. The default IP address is 192.168.10.200.

Power

6. Click Advanced, click Setup, then click on LAN Settings.

7. Configure the wireless controller IP address settings to match the requirements of your

network and click Apply.

5. Enter the User name and Password, and then click Login. By default:

User Name: admin

Password: admin

Note: User Name and Password are case sensitive.

Note: The Default Gateway and DNS IP settings must be assigned to ensure the wireless

controller is able to check for available online firmware upgrades.

Advanced

LAN Settings

ENGLISHFRANÇAISDEUTSCH

ESPAÑOLРORTUGUÊS

8. Using an Ethernet cable, connect one of the five Gigabit Ethernet ports located on the back of

the wireless controller to your network (e.g. router, switch, etc.)

9. Access the wireless controller management page using the newly assigned IP address.

Note: You may need to revert to your computer's original IP address settings before you can

access the wireless controller with the new IP address settings.

TEW-WLC100

Network

3. Connect your wireless access points

Important Note: Please make sure your access points have met the requirements in Section 1

Access Point Compatibility.

1. Using an Ethernet cable, connect each wireless access point to the wireless controller or

your network.

Note: If powering the access points using their power adapters, you can connect the access

points directly to your network or the wireless controller. If powering the access point using

power over Ethernet (PoE), you can connect your access points to your network or to the

wireless controller using a separate PoE injector or PoE switch (not included).

Network Network Network

PoE Injector

OR OR

Acess Point PoE Switch

Acess Point Acess Point

Power

ENGLISHFRANÇAISDEUTSCH

ESPAÑOLРORTUGUÊS

3. After your access points have been found, they will automatically appear in the Device List.

2. After the access points are connected to your network and powered on, click on Basic, click

AP Management, and Device List in the wireless controller management page. Then click on

Discover to search for available wireless access points.

5. You can modify the access point basic settings such as SSID and encryption key on each band.

4. To configure access point settings, under the Select column, check one or multiple access

points you would like to configure and click on Device Settings to configure access points.

ENGLISHFRANÇAISDEUTSCH

ESPAÑOLРORTUGUÊS

6. After modifying the settings, scroll down to the Password field, enter the access points

management password (default access point password: admin) and click OK to apply the

settings to the access points.

Note: If you are using a combination of single band (2.4G) and dual band access points (2.4G &

5G), the 5G settings will only be applied to dual band access points.
