TRENDnet TEW-676APBO Manuel utilisateur

PRODUCT OVERVIEW

• High speed wireless n building-to-building connections

• Supports Access Point, Router Access Point, Wireless Distribution System (WDS), Customer Premises Equipment (CPE), and

Repeater modes

• IP-66/67 rated aluminum housing

• Powered by Power over Ethernet (PoE) technology

TEW-676APBO

rev: 03.29.2012

N300 Wireless 12dBi Outdoor 5GHz PoE Access Point

TEW-676APBO (v1.0R)

The N300 Wireless 12dBi Outdoor 5GHz PoE Access Point, model

TEW-676APBO, provides high speed point-to-point building connectivity. It supports a

variety of installation scenarios with Access Point, Router Access Point, Wireless

Distribution System (WDS), Customer Premises Equipment (CPE), and Repeater

modes.

An IP-66/67 weather rating and rugged aluminum housing ensures the

highest level of protection against extreme weather. An outdoor mounting kit is

included and weatherproof LED indicators expedite product installation and

troubleshooting.

No need to install this access point near a power source—PoE technology transmits

both power and data over an Ethernet cable. Support for the latest wireless security

protocols ensures the highest level of network protection. Install this access point with

TRENDnet’s Outdoor Lightning Arrestor Kit, model TEW-ASAL1, to protect your entire

network from catastrophic lightning strikes.

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,

N300 Wireless 12dBi Outdoor 5GHz PoE Access Point

TEW-676APBO (v1.0R)

TEW-676APBO

rev: 03.29.2012

FEATURES

• PoE compliant device

• 1 x 10/100Mbps PoE Auto-MDIX LAN port

• 1 x reset button

• LED indicators: Power, WLAN, LAN

• Internal high powered 12dBi patch antenna (polarization: V30°, H30°)

• Compliant with 802.11n/a technology (5 GHz spectrum) with data rates up to 300Mbps

• Rugged IP66/67 rated weather proof aluminum housing

• Supports Router Access Point (AP), Access Point (AP), Wireless Distribution System (WDS), Customer Premises Equipment

(CPE), Client Bridge + Repeater, and CPE + AP modes

• Multiple SSID or Virtual Access Points with Layer 2 VLAN client isolation

• Access restriction with Internet Access Control, MAC, and IP ﬁ ltering

• Universal Plug and Play (UPnP) for auto discovery and support for device conﬁ guration of Internet applications

• Complete wireless security with WPA/WPA2-RADIUS, WPA /WPA2-PSK, and WEP

• Multiple pass-through sessions for popular VPN applications (IPSec, L2TP, and PPTP)

• Quality of Service technology: IEEE 802.11p COS, IEEE 802.11q Tag VLAN priority control and Wi-Fi Multimedia (WMM)

• Supports IEEE 802.11f IAPP (Inter Access Point Protocol), IEEE 802.11h (Transmission Power Control) and IEEE 802.11d

(Multi-country roaming)

• Easy setup via Web browser using the latest versions of Internet Explorer, FireFox, and Safari

• Supports SNMP (v2c and v3), Telnet, SSH, and HTTP/HTTPS management

• Surface mounting hardware

• Electrical ground cable

• 3-year limited warranty

Speed and Distance References

Please note that the following information concerning potential connection distances and speeds are for reference only. They are

referenced from clear line of sight installations with no other potential sources of signal degradation. Every installation environment

is unique. TRENDnet is not responsible for performance metrics that may vary from those referenced below.

• When networked to the same unit, this unit is rated for connecting over clear line-of-sign distances of up to 7 km (4.3 miles).

N300 Wireless 12dBi Outdoor 5GHz PoE Access Point

TEW-676APBO (v1.0R)

SPECIFICATIONS

HARDWARE

Standards • Wired: IEEE 802.3u (100Base-TX)

• Wireless: IEEE 802.11a/n (5 GHz)

LED Indicator • Power, LAN, WLAN (wireless activity)

Antenna • 12dBi patch antenna (polarization: V30°, H30°)

PoE • 1 x 10/100Mbps RJ-45 PoE port, Passive only (non-802.3af compliant)

Dimension (L x W x H) • 215 x 122 x 66 mm ( 8.5 x 4.8 x 2.6 in)

Weight • 1kg (2.2lbs)

Power Consumption • 15 Watts (max.)

Management • Web browser (HTTP/HTTPS), SNMP (v2c and 3), Telnet, SSH

Wind Speed Support • 210 km/hr

Waterproof • IP66/67 compliant

Temperature • Operating: -20° ~ 60°C (-4°F ~ 140°F)

• Storage: 0° ~ 60°C (32°F ~ 140°F)

Humidity • Max. 95% (non-condensing)

Power • PoE power injector DC output: 48VDC, 0.4A

Certiﬁ cations • FCC

WIRELESS

Frequency • 5.725 ~ 5.845 GHz

Modes • Router, Access Point + WDS, WDS, CPE, Client Bridge + Repeater, CPE + Access Point

Virtual Access Points • 7

Associated Clients (max) • 224 (AP Mode), 32 (Repeater Mode)

*Coverage • 7km line-of-sight

Modulation Technique • 802.11a: OFDM with BPSK, QPSK, QAM and 64QAM

• 802.11n: BPSK, QPSK, 16-QAM, 64-QAM

Data Rate (auto-fallback) • 802.11a: up to 54Mbps

• 802.11a/n: up to 300Mbps

Security • 64/128/152-bit WEP, WPA /WPA2-PSK, WPA/WPA2-RADIUS for AP/CPE mode, WEP/WPA2-PSK for WDS mode

• MAC ﬁ lter (20 entries) and IP ﬁ lter (20 entries)

Output Power • Up to 27dBm (FCC)

Receiving Sensitivity • 802.11a: -91dBm (typical) @ 6Mpbs

• 802.11a/n: -68dBm (typical) @ 300Mbps

Channels • FCC: 149,153,157,161,165

* Effective wireless coverage may vary depending on the wireless device’s output power, antenna gain, antenna alignment, receiving sensitivity, and radio

interference. For optimal results, we recommended that you consult a professional installer for site survey, safety precautions, and proper installation.
