Totally Wicked TORNADO NC Manuel utilisateur

USER MANUAL

TOTALLY WICKED

TORNADO NC

ELECTRONIC

CIGARETTE KIT

CONGRATULATIONS

ON PURCHASING YOUR

THE TOTALLY WICKED TORNADO NC

4 5

For those familiar with e-cigarettes, the steps below can be followed to allow the

device to be used in the shortest possible time:

• Prime the atomizer head

• Fill the tank

• Switch the Tornado NC on

• Press the power button and inhale

• Charge the battery (it will may not have been shipped with a full charge)

It is important to “prime” a new atomizer head before ﬁrst use. Failure to do so

can damage the atomizer head.

Grip the airﬂow adjuster and unscrew the tank from the battery. Holding the

tank by the airﬂow adjuster, unscrew the top cap and tank glass. Prime the ﬁtted

atomizer by dripping a few drops of e-liquid onto the heating element and the

cotton inside it. Screw the top cap and tank glass back onto the tank base, then

screw the tank back onto the battery.

Note: Leave a new atomizer head to sit in a tank full of e-liquid for ﬁve

minutes before vaping. This ensures the atomizer head is fully saturated with

e-liquid before use.

QUICK START GUIDE PRIMING THE ATOMIZER HEAD

6 7

PRIMING THE ATOMIZER HEAD FILLING THE TANK

Slide the top cap open by

pushing ﬁrmly in the indicated

direction to expose the ﬁll

hole. Insert the ﬁlling nozzle

into the ﬁll hole and ﬁll the

tank being careful not to

overﬁll. Slide the top cap shut

after ﬁlling.

Note: To avoid leaking,

ensure an air gap of around

2mm remains above the

e-liquid after ﬁlling.

8 9

USING YOUR TORNADO NC KIT USING YOUR TORNADO NC KIT

Vaping

Press and hold the power button as

you gently inhale the vapour, release

the power button when you have

ﬁnished inhaling. The indicator light will

illuminate while the power button is held

down, and will illuminate again after

vaping to show battery condition. See

Battery Life Indication for a description

of each light condition.

Adjusting Airﬂow

If you ﬁnd the airﬂow too airy or

too tight, rotate the airﬂow adjuster

to expose less or more of the slot.

Experiment to ﬁnd your preference.

Atomizer Head Lifespan

Atomizer heads do not last forever

and need to be replaced periodically.

Lifespan is generally from a few days

to several weeks, depending on

power used, vaping style, ﬂavour and

type of e-liquid. A slight burnt taste,

general loss of vapour production, or

a reduction in ﬂavour intensity can all

be indicators that the atomizer head

requires replacement.

Switching On and Off

To switch the Tornado NC on or off,

quickly press the power button ﬁve

times. The indicator light will ﬂash three

times when switched on or off.

10 11

USING YOUR TORNADO NC KIT USING YOUR TORNADO NC KIT

E-liquid Level

To prevent the atomizer head from

becoming dry and burning prematurely,

ensure the tank remains at least ¼ full

at all times.

Battery Life Indication

The indicator light will relight 2 seconds

after vaping, and for the following

4 seconds will show the battery life

remaining. Illumination will remain

constant if the battery has full charge,

and as the level of charge decreases

the indicator light will ﬂash faster. The

table below can be used as a reference

Changing Output Modes

The Tornado NC has 2 modes, constant

voltage or direct output. Constant

voltage produces less heat, power

and vapour, but delivers a consistent

vape experience whether the battery is

fully charged or nearly depleted. Direct

output produces more heat, power

and vapour for a more intense vaping

experience, but you may notice power

and vapour production decrease as

the battery charge depletes. To switch

between constant voltage and direct

output modes, switch the battery off

by pressing the power button 5 times,

then press and hold the power button;

the indicator light will illuminate white

for direct output mode or orange for

constant voltage mode. Switching the

battery back on activates the selected

mode.

Battery Percentage Light Condition

100-60% Stays Lit

59-30% Flashes slowly

29-10% Flashes moderately

9-0% Flashes quickly

12 13

USING YOUR TORNADO NC KIT USING YOUR TORNADO NC KIT

part of the atomizer head slightly,

and gently push the other end into

place. Before using a new atomizer

head it must be primed, please

see Priming the Atomizer Head and

Filling the tank for more information.

Ensure the wicking material is

evenly disposed along the length

of the metal part of the atomizer

head, and protrudes evenly from

both ends of the slot in the tank

base. Reﬁt the tank base to the top

cap and tank glass, and reﬁt the

assembled tank to the battery.

Reminder: Leave a new atomizer

head to sit in a tank full of

e-liquid for ﬁve minutes before

vaping. This ensures the atomizer

head is fully saturated with

e-liquid before use.

Charging the Battery

Insert the supplied USB cable into

the Tornado NC charging port, and

connect the other end to a USB

port or suitable wall adaptor. The

indicator light will illuminate red

while charging. When fully charged,

the indicator light will switch off.

The Tornado NC can be used

normally while charging.

Replacing the Atomizer Head

Unscrew the tank from the battery,

invert the tank, and unscrew the

tank base from the top cap and

tank glass. Remove the ﬁtted

atomizer head by gently pulling

on one end of the atomizer head.

The atomizer head should pull

away easily from the base. Place

one end of the new atomizer head

into the base, compress the metal

14 15

USING YOUR TORNADO NC KIT PROTECTIONS

Atomizer Head Protection

If the power button is held down for

longer than 15 seconds while vaping,

the indicator light will ﬂash 10 times and

the Tornado NC will refuse to power

or produce any vapour. Releasing the

power button allows normal operation

to resume.

Low Voltage Protection

If battery voltage drops to 3.3 volts, the

indicator light will ﬂash 40 times and

the Tornado NC will switch off. Charge

the Tornado NC using the procedure

outlined in Charging the Battery to allow

normal operation to resume.

Incompatible Atomizer Head

Resistance

If the atomizer head resistance is below

0.3ohm, the indicator light will quickly

ﬂash 5 times when pressing the power

button. If the atomizer head resistance

exceeds 3.0ohm, the indicator light will

Replacing the Atomizer Head

16 17

PROTECTIONS

cap, tank glass and tank base can be

cleaned under hot running water. Allow

the tank to fully dry before reﬁtting

the atomizer head into the tank base.

Reassemble the tank.

Note: Do not attempt to clean the

battery or atomizer head with water.

1 x Tornado NC battery

1 x Tornado NC tank

5 x NC 0.45ohm atomizer heads

(1 ﬁtted)

1 x Spare glass

4 x Silicone rings

1 x USB cable

1 x User manual

ﬂash slowly when pressing the power

button. Replacing the atomizer head

with one of a compatible resistance

above 0.3ohm and below 3.0ohm will

allow normal operation to resume.

Short Circuit Protection

If an atomizer short circuit occurs, the

indicator light will ﬂash 5 times and the

Tornado NC will switch off. Replace the

atomizer head by following the steps

outlined in Replacing the Atomizer

Head, then follow the procedure

outlined in Charging the Battery to

restore power and allow normal

operation to resume.

Cleaning and Maintenance

The Tornado NC battery and tank

connection can be cleaned by wiping

down with tissue or a dry cloth. The tank

can be cleaned after removing it from

the battery and removing the atomizer

head from the tank base; then the top

PROTECTIONS KIT CONTENTS

18 19

SPECIFICATIONS ADDITIONAL PRODUCT INFORMATION

Dimensions: 22mm (diameter) x 127.5mm (length)

Battery: 2300mAh Integrated Battery

Max Charging Current: 1.0A

Tank Capacity: 2ml

Atomizer Head Type: NC

Maximum power: 45 watts

Voltage Output: 4.2V - 3.3V (Direct output)

Voltage output: 3.5V (Constant voltage).

Resistance Range: 0.3 – 3.0ohm.

Maximum Filling Nozzle Diameter: 3.2mm

There are no reported medical side effects with this product. If you believe you

experience a side effect, please contact the manufacturer.
