VooPoo DRAG 2 Manuel utilisateur

Manual Instruction

DRAG 2

Parameters :

Size : 88.3 x 51 x 26.5mm

Power Output : 5-177W

Battery : Dual battery 18650 x 2

Program upgradable : Yes

Resistance Range :

Non-TC wire : 0.05-5.0Ω（±5%）

TC wire : 0.05-1.5Ω（±5%）

Product description :

1. Appearance & Main Parameters:

510 Thread

Power Button

Screen

“+” Up Button

“-” Down Button

Micro-USB Port

3.Eight Security Protection :

- Overtime protection

- Over temperature protection

- Output over-current protection

- Overcharge protection

- Low battery protection

- Atomizer short-circuit protection

- Support balance charge with batteries

from different manufacturers

- Battery anti-reverse protection

2.Electric Parameter :

NO.

Working voltage 6.4～8.5 ±0.1 V

Output voltage range 0～7.5 ±2% V

Overheat protection 80 ±5% ℃

Input charging voltage 5 ±0.25 V

Output charging voltage 1800 ±5%

Quiescent currency ≤10 uA

Temperature Range 200-600℉

100-315℃

℉

℃

Power conversion efficiency 95% -5%～0 %

Item Range Accuracy Unit

Instructions :

1. Basic Operation

①. Press the fire button for 5 times: Power on/off

Press the fire button for 3 times: Sequently switch

from Power mode → FIT mode → TC mode

②. Press “+” and “-” buttons simultaneously:

Enter function menu

③. Press the fire and “+” buttons simultaneously:

Lock/Unlock

④. Press the fire and “-” buttons simultaneously：

Switch screen orientation.

①

②

④

③

2. Four Mode Settings :

Power Mode FIT Mode

TC Mode Custom Mode

3. Four Mode Operations :

A. Power Mode:

a). Adjust the wattage from 5W to 177W, The

product automatically recommends the

output wattage according to the resistance

of the atomizer when it detects that a new

atomizer has been attached.

b). Press up and down buttons at the same

time，enter function menu：

Power Mode Custom Mode

Series Number Software Version

B. FIT Mode:

a). Boot default , Press “+” or “-” button to

select the three options .

C. TC Mode:

a). Support SS, Ni, Ti, NC, TC, 5 kinds of

heating wire, factory default SS, Ni, Ti,

Connect computer APP to open NC, TC；

b). Temperature control adjustable range ：

200-600℉/ 100-315℃

- When the temperature setting is at 100℃,

keep pressing “-”, it will turn to be 600℉;

- When the temperature setting is at 200℉,

keep pressing “-”, it will turn to be 315°C.

c). To adjust wattage while in TC Mode, press

fire button 4 times rapidly to activate wattage

adjustment. You will see the “W” wattage icon

flashing. The wattage can be adjusted from

5W to 80W.

d). Press “+” and “-”Simultaneously，Enter

function menu ：

TC Mode Custom Mode

Coil Cooling Value Coil Coefficien

D. Custom Mode:

a). Custom mode under Power mode or TC

mode:

- Press “+” and “-”Simultaneously，Enter

function menu , select and Switch

M1 to M5；

- Press fire button 4 times，Switch ：Power

customization (W) → FIT mode →TC

customization (SS, Ni, Ti)；

b). Under Custom Mode, there are 2 ways to

adjust the value：

- Manually switch custom curve per second

(Shortly press fire button 4 times to enter

the curve interface, press UP/DOWN to

adjust, then long press fire button to exit.),

see the chart below:

- Connect to a computer app for custom

settings

e). Coil cooling value range : 0.05～1.50Ω

Power curve—current

watt shown on top right

TC curve—current

temperature shown on top right

More instructions :

A. Sleep Mode:

Screen will auto turn off in 30s without

operations, and will enter standby mode in

30min without operations/usage after screen

is turned off. To activate, press power button.

B. Charging Mode :

The device will enter charging state with the

battery icon running when it’s connected to

5V power supply with USB cable; when the

device is fully charged, the battery icon will

stop running.

Note：It takes 3 hours to fully charge the

device (5V/2A charger required).

C. Computer customization ：

You can do the following customization

operations via the VOOPOO Firmware:

Prompt page, Temperature coefficient,

Temperature curve, Wattage Curve, Increase

/Decrease Coil type and Device Upgrade etc.

Download address：http://www.voopoo.com.

D. Function tips :

TIME OUT CHECK COIL

LOW WATTAGE ATOMIZER SHORT

NO ATOMIZER ATOMIZER RESISTANCE

HIGH

HIGH TEMPERATURE

E. Accommodation coefficient of the

TC wire ：

Note：

1. The higher coil coefficient you set, the higher

coil temperature you get；

2. Because of the different material for the wire,

you may feel the power is not strong enough

when vaping, you can properly adjust the coil

coefficient at a higher rate to get a better

vaping experience；

3. Please adjust the coil coefficient at a low

rate, if too high there is a risk of firing cotton.

Coefficient Range

Ni：6000-7000

Ti：3500-4500

SS：1000-1600

NC：20-600

TC：100-700

6500

4000

1300

400

1000

Standard Default Value
