User’s Guide

TPS65941212-Q1 and TPS65941111-Q1 PMIC User Guide

for Jacinto™ 7 J721E, PDN-0B

ABSTRACT

This user’s guide can be used as a guide for integrating the TPS65941212-Q1 and TPS65941111-Q1 power

management integrated circuits (PMICs) into a system powering the Automotive Jacinto™ 7 DRA829 or

TDA4VM processor.

Table of Contents

1 Introduction.............................................................................................................................................................................2

2 Device Versions...................................................................................................................................................................... 2

3 Processor Connections..........................................................................................................................................................4

3.1 Power Mapping.................................................................................................................................................................. 4

3.2 Control Mapping.................................................................................................................................................................7

4 Supporting Functional Safety Systems..............................................................................................................................10

4.1 Achieving ASIL-B System Requirements......................................................................................................................... 11

4.2 Achieving up to ASIL-D System Requirements................................................................................................................11

5 Static NVM Settings..............................................................................................................................................................13

5.1 Application-Based Configuration Settings........................................................................................................................13

5.2 Device Identification Settings........................................................................................................................................... 14

5.3 BUCK Settings................................................................................................................................................................. 14

5.4 LDO Settings....................................................................................................................................................................16

5.5 VCCA Settings................................................................................................................................................................. 17

5.6 GPIO Settings.................................................................................................................................................................. 17

5.7 Finite State Machine (FSM) Settings............................................................................................................................... 20

5.8 Interrupt Settings..............................................................................................................................................................20

5.9 POWERGOOD Settings...................................................................................................................................................23

5.10 Miscellaneous Settings.................................................................................................................................................. 24

5.11 Interface Settings............................................................................................................................................................25

5.12 Multi-Device Settings..................................................................................................................................................... 26

5.13 Watchdog Settings......................................................................................................................................................... 26

6 Pre-Configurable Finite State Machine (PFSM) Settings.................................................................................................. 26

6.1 Configured States............................................................................................................................................................ 27

6.2 PFSM Triggers................................................................................................................................................................. 28

6.3 Power Sequences............................................................................................................................................................ 29

7 Impact of NVM Changes.......................................................................................................................................................49

8 References............................................................................................................................................................................ 50

9 Revision History................................................................................................................................................................... 50

Trademarks

Jacinto™ is a trademark of Texas Instruments.

All trademarks are the property of their respective owners.

www.ti.com Table of Contents

SLVUC32B – JUNE 2021 – REVISED FEBRUARY 2022

Submit Document Feedback

TPS65941212-Q1 and TPS65941111-Q1 PMIC User Guide for Jacinto™ 7

J721E, PDN-0B

1 Introduction

This user’s guide describes a power distribution network (PDN), PDN-0B, between two TPS6594-Q1 devices

and either DRA829V or TDA4VM processor with independent MCU and Main power rails. This PDN enables

board level isolation of the processor MCU and Main voltage resources as required to leverage the processor

architecture in implementing two desirable end product features:

1. MCU processor acts as independent safety monitor (MCU Safety Island) over the Main processing

resources to ensure safe system operations.

2. MCU processor maintains minimum system operations (MCU Only) to significantly reduce processor power

dissipation thereby extending battery life during stand-by use cases and reducing component temperature.

This description includes the following to clarify platform system operation:

1. PDN power resource connections

2. PDN digital control connections

3. Primary and secondary PMIC default NVM contents

4. PMIC sequencing settings to support different PDN power state transitions for an advanced processor

system

PMIC and processor data manuals describe recommended operation, electrical characteristics, external

components, package details, register maps, and overall component functionality. In the event of any

inconsistency between any user's guide, application report, or other referenced material, the data sheet

specification is the definitive source.

2 Device Versions

There are different orderable part numbers (PNs) of the TPS6594-Q1 device available with unique NVM settings

to support different end product use cases and processor types. The unique NVM settings for each PMIC

device is optimized per PDN design to support different processors, processing loads, SDRAM types, system

functional safety levels, and end product features (such as low power modes, processor voltages, and memory

subsystems). The NVM settings can be identified by both NVM_ID and NVM_REV registers. Each PMIC device

is distinguished by the part number, NVM_ID, and NVM_REV values listed in Table 2-1.

Introduction www.ti.com

2TPS65941212-Q1 and TPS65941111-Q1 PMIC User Guide for Jacinto™ 7

J721E, PDN-0B

SLVUC32B – JUNE 2021 – REVISED FEBRUARY 2022

Submit Document Feedback

Table 2-1. Dual TPS6594-Q1 Orderable Part Numbers for Independent MCU and Main PDN System

PDN USE CASE PDN Orderable Part Number TI_NVM_ID

(TI_NVM_REV

)

Orderable Part

Number

TI_NVM_I

(TI_NVM

_REV)

Error

Signal

Monitor

ing

• Up to 9 A(1) on the Primary PMIC 3-phase

CPU rail

• Up to 12 A1 on the Secondary PMIC 4-

phase CORE rail

• Up to 3.4 A(1) on the SDRAM, with support

for LPDDR4

• Supports Processor 2 GHz maximum

clock with high-speed SERDES operations

• Supports 32 Gb of LPDDR4 SDRAM with

4266MTs data rate

• Supports Functional Safety up to ASIL-D

level with MCU Safety Island

• Supports MCU-only and DDR_Retention

low power modes

• Supports I/O level of 3.3 V or 1.8 V

• Supports optional end product features:

– Compliant high-speed SD Card

memory

– Compliant USB 2.0 Interface

– On-board Efuse programming of high

security processors

0B TPS65941212RWERQ1 0x12 (0x03) TPS65941111R

WERQ1

0x11

(0x03)

Combin

ed MCU

and

SOC

0C TPS65941213RWERQ1 0x13 (0x04) TPS65941111R

WERQ1

0x11

(0x03)

Dedicat

ed MCU

and

SOC

(1) TI recommends having 15% margin between the maximum expected load current and the maximum current allowed per each PMIC

output rail.

Note

PDN-0C is recommended for all new designs and designs needing the additional functional safety

coverage provided afforded by the GPIO optimizations found in PDN-0C. This document describes

PDN-0B.

www.ti.com Device Versions

SLVUC32B – JUNE 2021 – REVISED FEBRUARY 2022

Submit Document Feedback

TPS65941212-Q1 and TPS65941111-Q1 PMIC User Guide for Jacinto™ 7

J721E, PDN-0B

3 Processor Connections

This section details how the dual TPS6594-Q1 power resources and GPIO signals are connected to the

processor and other peripheral components in order to support the PDN use case.

3.1 Power Mapping

Figure 3-1 shows the power mapping between the dual TPS6594-Q1 PMIC power resources and processor

voltage domains required to support independent MCU and Main power rails. In this configuration, both PMICs

use a 3.3 V input voltage. For Functional Safety applications, there is a protection FET before VCCA that

connects to the OVPGDRV pin of the primary PMIC, allowing voltage monitoring of the input supply to the

PMICs.

The VCCA voltage must be the first voltage applied to the PMIC devices. VIO_IN of the PMICs must not

be supplied before VCCA. A load switch supplies VIO_IN in this PDN. This load switch also supplies the

VDDSHVx_MCU voltage domain of the processor. This allows PMIC GPIO control signals referenced to VIO_IN

to remain active during MCU Only low power mode and to be disabled during DDR Retention (aka Suspend-to-

RAM) to reduce PMIC power.

For SD card dual-voltage I/O support (3.3 V and 1.8 V), LDO1 of the TPS659411-Q1 device can be used. A

processor GPIO control signal with a logic high default value is used to set SD VIO to 3.3 V initially. During

processor power up, the boot loader SW can set GPIO signal low to select 1.8 V level as needed for high-speed

card operation per SD specification. This allows control of the LDO1 voltage without the need for the MCU

processor to establish I2C communication with the PMICs during boot from SD card operations.

This PDN uses four discrete power components with three being required and one is optional depending

upon end product features. The two TPS22965-Q1 Load Switches connect VCCA_3V3 power rail to supply

OV protected 3.3 V to processor I/O domains. Two load switches are required in order to enable isolation

between MCU and Main processor sub-sections for MCU Safety Island or MCU Only low power operations. The

TPS62813-Q1 Buck Converter supplies LPDDR4 SDRAM component with required 1.1V supply. The unused

primary PMIC FB pin, FB_B3, has been configured per NVM settings, Table 5-3, to provide voltage monitoring

for VDD_DDR_1V1 power rail if an end product OV/UV monitoring requirements include this supply. The one

optional discrete power component is TLV73318-Q1 LDO that can be used if an end product uses a high security

processor type and desires the capability to program Efuse values on-board. If this feature is not desired, then

this LDO can be omitted and processor VPP pins treated per data manual recommendations.

Note

The PMIC voltage monitor on FB_B3 must be connected to 1.1 V. The VMON_ABIST_EN=1 for both

the primary and secondary PMICs. If 1.1 V is not connected to FB_B3 when the monitor is enabled

then the self-test fails and the BIST_FAIL_INT interrupt is set and the device goes to the safe state

and main processor voltages are disabled.

Processor Connections www.ti.com

4TPS65941212-Q1 and TPS65941111-Q1 PMIC User Guide for Jacinto™ 7

J721E, PDN-0B

SLVUC32B – JUNE 2021 – REVISED FEBRUARY 2022

Submit Document Feedback

TPS65941212-Q1

BUCK4

(4A max)

BUCK5

(2A max)

LDO1

(500mA max)

LDO2

(500mA max)

LDO3

(500mA max)

LDO4

(300mA max)

PRIMARY PMIC

Processor

MAIN PROCESSOR

VDD_CORE

VDDAR_CPU/CORE

VDDS_DDR_BIAS

VDD_PHY_1V8

VDD_CPU_AVS*

MAIN ANALOG

VDDA_1P8_PHYs

VDDA_0P8_PHYs

VDDA_0P8_PLLs/DLLs

VDDA_1P8_PLLs

VDDA_3P3_USB

MAIN DIGITAL

VDDSHV0-4

VDDSHV6

VDDS_MMC0

VDD1_DDR_1V8

MCU SAFETY ISLAND

VDD_MCU

VDDAR_MCU

VDDSHVx_MCU (1.8V)

System

VPP_x (EFUSE)

VDD_MCU_0 V85

VDA_MCU_1V8

VDDSHVx_MCU (3.3V)

VDA_DLL_0V8

TPS22965-Q1

(load switch, 4A max)

VDD_MCUIO_3V3

VDD_MCUIO_1V8

LPDDR4

VDD1

VDD2

3.3V

VDD_CPU (AVS)

VCCA

OVPGDRV

VIO_IN

BUCK1 + BUCK2

+ BUCK3

(10.5A max)

VDDSHV5

TLV73318P-Q1

(LDO, 300mA max)

TPS62813-Q1

(BUCK, 3A max)

VDD_IO_3V3

VPP_EFUSE_1V 8

VDD_DDR_1V1

VDDA_x

VDDS_DDR_IO

VDDQ

Octal SPI FLASH

Hyper FLASH

EMMC

VCCQ

VCC

TPS65941111-Q1

BUCK5

(2A max)

LDO1

(500mA max)

LDO2

(500mA max)

LDO3

(500mA max)

LDO4

(300mA max)

SECONDARY PMIC

VCCA

OVPGDRV

VIO_IN

BUCK1 + BUCK2

+ BUCK3 + BUCK4

(14A max)

VDD_CORE_0V8

TPS22965-Q1

(load switch, 4A max)

VDD_RAM_0V85

UFS

VCCQ

VCC

FB_B3 (pin 49)

LDO

PDN Features

Base PDN

MCU-only

Suspend-to-RAM

BUCK

Processor

Processor Sub-group

Processor Voltage

Domains

Power Components

System Group

System Sub-group

System Rail

VDD_SD_DV**

VDD_USB_3V 3

VDD_IO_1V8

VDA_PLL_1V8

Figure 3-1. Power Connections

• * VDD_CPU_AVS, boot voltage of 0.8 V then software sets device specific AVS; 0.68 V – 0.72 V.

• ** VDD_SD_DV, 3.3 V then software changes to 1.8 V per HS-SD.

www.ti.com Processor Connections

SLVUC32B – JUNE 2021 – REVISED FEBRUARY 2022

Submit Document Feedback

TPS65941212-Q1 and TPS65941111-Q1 PMIC User Guide for Jacinto™ 7

J721E, PDN-0B

Table 3-1 identifies which power resources are required to support different system features. If the system

feature listed is not required, the power resource connection can be removed and the processor voltage domains

need to be grouped into alternative power rails.

Table 3-1. PDN Power Mapping and System Features

Power Mapping System Features

Device Power

Resource Power Rails Processor and Memory

Domains Active SoC MCU - only Suspend-

to-RAM SD Card USB

Interface

TPS659412

12-Q1

BUCK123 VDD_CPU_

AVS VDD_CPU Required

FB_B3 VDDS_DDR_BIAS,

VDDS_DDR_IO, LPDDR4 Required Required

BUCK4 VDD_MCU_

0V85 VDDAR_MCU, VDD_MCU Required Required

BUCK5 VDD_PHY_

1V8 VDDA_1P8_PHYs Required

LDO1 VDD1_DDR

_1V8 Mem: VDD1 Required Optional Required

LDO2 VDD_MCUI

O_1V8

VDDSHVx_MCU (1.8 V) Required Required

Mem: VCC

LDO3 VDA_DLL_0

V8 VDDA_0P8_PLLs/DLLs Required

LDO4 VDA_MCU_

1V8 VDDA_x Required Required

TPS659411

11-Q1

BUCK1234 VDD_CORE

_0V8

VDD_CORE,

VDDA_0P8_PHYs Required

BUCK5 VDD_RAM_

0V85

VDDAR_CPU/CORE Required

LDO1 VDD_SD_D

VVDDSHV5 Required

LDO2 VDD_USB_

3V3 VDDA_3P3_USB Required

LDO3 VDD_IO_1V

VDDS_MMC0 Required

Mem: VCCQ

LDO4 VDA_PLL_1

VDDA_1P8_PLLs Required

TPS22965-

Q1 Load Switch VDD_MCUI

O_3V3 VDDSHVx_MCU (3.3 V) Required Required

TPS22965-

Q1 Load Switch VDD_IO_3V

VDDSHV0-4,VDDSHV6

(3.3 V) Required Required

TLV73318P-

LDO VPP_EFUS

E_1V8

VPP_x(EFUSE) Optional

TPS62813-

BUCK VDD_DDR_

1V1

VDDS_DDR_BIAS,

VDDS_DDR_IO

Required Optional Required

Mem: VDD2

Processor Connections www.ti.com

6TPS65941212-Q1 and TPS65941111-Q1 PMIC User Guide for Jacinto™ 7

J721E, PDN-0B

SLVUC32B – JUNE 2021 – REVISED FEBRUARY 2022

Submit Document Feedback

3.2 Control Mapping

Figure 3-2 shows the digital control signal mapping between processor and PMIC devices. For the two PMIC

devices to work together, the primary PMIC and secondary PMIC must establish an SPMI communication

channel. This allows the two TPS6594-Q1 to synchronize their internal Pre-Configurable State Machines (PFSM)

so that they operate as one PFSM across all power and digital resources. The GPIO_5 and GPIO_6 pins on the

TPS6594-Q1 are assigned for this functionality. In addition, the primary PMIC LDOVINT pin is connected to the

secondary PMIC ENABLE input to correctly initiate the PFSM.

Other digital connections from the TPS6594-Q1 devices to the processor provide error monitoring, processor

reset, processor wake up, and system low-power modes. Specific GPIO pins have been assigned to key signals

in order to ensure proper operation during low power modes when only a few GPIO pins remain operational.

The digital connections shown in Figure 3-2 allow system features including MCU-only MCU Safety Island and

suspend-to-RAM low power modes, functional safety up to ASIL-D, compliant dual voltage SD card operation,

and LPDDR4x integration.

www.ti.com Processor Connections

SLVUC32B – JUNE 2021 – REVISED FEBRUARY 2022

Submit Document Feedback

TPS65941212-Q1 and TPS65941111-Q1 PMIC User Guide for Jacinto™ 7

J721E, PDN-0B

TPS65941212-Q1

ENABLE

INTn

nRSTOUT

GPIO_1 (SCL_I2C2)

TPS65941111-Q1

PRIMARY PMIC

Processor

SoC MAIN CONTROLS

MMC1_IO

DDR_RET

RESETSTATz

SAFETY MCU CONTROLS

Safety MCU GPIO

WKUP_I2C0_SCL/SDA

MCU_PORz

Board

MCU_SAFETY_ERRORn

TPS22965-Q1

Warm Reset

ON REQUEST

SCL_I2C1

SDA_I2C1

GPIO_2 (SDA_I2C2)

GPIO_3 (GPO)

GPIO_4 (LP_WKUP1)

GPIO_5 (SCLK_SPMI)

GPIO_6 (SDATA_SPMI)

GPIO_7 (nERR_MCU)

GPIO_8 (DISABLE_WDOG)

GPIO_9 (GPI)

GPIO_10 (WKUP1)

GPIO_11 (nRSTOUT_SoC)

INTn

GPIO_1 (GPI)

SECONDARY PMIC

SCL_I2C1

SDA_I2C1

GPIO_2 (GPI)

GPIO_8 (GPI)

GPIO_9 (GPO)

GPIO_5 (SCLK_SPMI)

GPIO_6 (SDATA_SPMI)

GPIO_10 (WKUP2)

LDOVINT LDOVINT

MCU_I2C0_SCL/SDA

PMIC_POWER_EN1

PORz

PMIC Voltage Domains

VRTC ±1.8V

VINT ±1.8V

VIO ±1.8V or 3.3V

PORz_OUT

Disable Watchdog

Wakeup

PDN FEATURES

Base PDN

MCU-only

Suspend-to-RAM

Reset to Board

GPIO_11 (GPO)

TPS22965-Q1

GPIO_3 (GPO)

GPIO_4 (GPO)

GPIO_7 (GPI)

ENABLE

nRSTOUT

TPS62813-Q1

VCCA

Domain Descriptions

Processor Group

Processor Sub-group

Processor I/O

Power

System Group

System Sub-group

System I/O

SYS_SAFETY_ERRn

HW_WKUP_I2C0

HW_MCU_I2C0_SCL

HW_MCU_I2C0_SDA

EN_MCU3V3IO_LDSW

H_WAKE_PMIC

H_MCU_INTn

H_MCU_PORz_1V8

LEOA_SCLK

LEOA_SDATA

PMICA_SAFETY_ERRn

PMICA_GPIO8

PMICA_GPIO10

H_SOC_PORz_1V8

SEL_SDIO_3V3_1V8n

EN_DDR_BUCK

H_DDR_RET_1V1

EN_EFUSE_LDO

EN_3V3IO_LDSW

Figure 3-2. TPS6594-Q1 Digital Connections

Processor Connections www.ti.com

8TPS65941212-Q1 and TPS65941111-Q1 PMIC User Guide for Jacinto™ 7

J721E, PDN-0B

SLVUC32B – JUNE 2021 – REVISED FEBRUARY 2022

Submit Document Feedback

Note

The PMIC voltage domain of an IO can be different depending upon configuration. When configured

as an input GPIO3 and GPIO4 are in the VRTC domain. When configured as an output, GPIO3 and

GPIO4 are in the VINT domain.

Note

In addition to the I2C signals, four additional signals are open-drain outputs and require a pullup to a

specific power rail. Please refer to Table 3-2 for a list of the signals and the specific power rail.

Table 3-2. Open-drain signals and Power Rail

PDN Signal Pullup Power Rail

H_MCU_INTn VDD_MCUIO_3V3

H_MCU_PORz_1V8 VDA_MCU_1V8

H_SOC_PORz_1V8 VDA_MCU_1V8

H_DDR_RET_1V1 VDD_DDR_1V1_REG

H_WKUP_I2C0 VDD_MCUIO_3V3

H_MCU_I2C0_SCL/SDA VDD_MCUIO_3V3

Please use Table 3-3 as a guide to understand GPIO assignments required for each PDN system feature.

If the feature listed is not required, the digital connection can be removed; however, the GPIO pin is still

configured per NVM defined default function shown. After the processor has booted up, system software can

potentially reconfigure an unused GPIO to support a new function. This is possible as long as that function is

only needed after boot and default function does not cause any conflicts with normal operations (for example,

two outputs driving same net). For details on how functional safety related connections help achieve functional

safety system-level goals, see Section 4.

Table 3-3. Digital Connections by System Feature

Device

GPIO Mapping System Features

PMIC Pin NVM

Function PDN Signals Active SoC Functional

Safety

MCU - only

and MCU-

Safety

Island

Suspend-

to-RAM SD Card

TPS659412

12-Q1

nPWRON/

ENABLE Enable SOC_PWR_ON Required

INT INT H_MCU_INTn Required

nRSTOUT nRSTOUT H_MCU_PORz_1V8 Required Required

SCL_I2C1 SCL_I2C1 H_WKUP_I2C0 Required

SDA_I2C1 SDA_I2C1 H_WKUP_I2C0 Required

GPIO_1 SCL_I2C2 H_MCU_I2C0_SCL Required

GPIO_2 SDA_I2C2 H_MCU_I2C0_SDA Required

GPIO_3 GPO EN_MCU3V3IO_LDSW Required

GPIO_4 LP_WKUP1 H_WAKE_PMIC Required

GPIO_5 SCLK_SPM

ILEOA_SCLK Required

GPIO_6 SDATA_SP

MI LEOA_SDATA Required

GPIO_7 nERR_MC

UPMICA_SAFETY_ERRn Required

GPIO_8 DISABLE_

WDOG PMICA_GPIO8 (2) (2)

GPIO_9 GPI PMICA_GPIO9(3)

GPIO_10 WKUP1 PMIC_POWER_EN1 Required

GPIO_11 nRSTOUT_

SOC H_SOC_PORz_1V8 Required

www.ti.com Processor Connections

SLVUC32B – JUNE 2021 – REVISED FEBRUARY 2022

Submit Document Feedback

TPS65941212-Q1 and TPS65941111-Q1 PMIC User Guide for Jacinto™ 7

J721E, PDN-0B

Table 3-3. Digital Connections by System Feature (continued)

Device

GPIO Mapping System Features

PMIC Pin NVM

Function PDN Signals Active SoC Functional

Safety

MCU - only

and MCU-

Safety

Island

Suspend-

to-RAM SD Card

TPS659411

11-Q1

nPWRON/

ENABLE ENABLE VINT_LEOA_1V8 Required

nINT nINT H_MCU_INTn

nRSTOUT nRSTOUT Unused

SCL_I2C1 SCL_I2C1 H_WKUP_I2C0 Required

SDA_I2C1 SCL_I2C1 H_WKUP_I2C0 Required

GPIO_1 GPI Unused(3)

GPIO_2 GPI SEL_SDIO_3V3_1V8n(1) Required

GPIO_3 GPO EN_DDR_BUCK

GPIO_4 GPO H_DDR_RET_1V1 Required

GPIO_5 SCLK_SPM

ILEOA_SCLK Required

GPIO_6 SDATA_SP

MI LEOA_SDATA Required

GPIO_7 GPI Unused(3)

GPIO_8 GPI Unused(3)

GPIO_9 GPO EN_EFUSE_LDO(3)

GPIO_10 WKUP2 Unused(3)

GPIO_11 GPO EN_3V3IO_LDSW Required

(1) This pin is an input with an internal pulldown enabled. A rising edge on this GPI initiates the FSM trigger and associated sequence.

The sequence configures LDO1 to bypass mode, supplying 3.3 V. A falling edge triggers an alternate sequence which configures

LDO1 to LDO mode, supplying 1.8 V. See also Table 6-1

(2) If it is desired to disable the watchdog through hardware, GPIO_8 is required and must be set high by the time nRSTOUT goes high.

After nRSTOUT is high, the watchdog state is latched and the pin can be configured for other functions through software.

(3) This GPIO is not required for power sequencing or PMIC functionality and can be configured by software for a different purpose if

desired.

4 Supporting Functional Safety Systems

By using the dual TPS6594-Q1 solution to power the DRA829V or TDA4VM processor, the system can leverage

the following PMIC functional safety features:

• Independent Power Control of MCU and Main Rails

• Independent Monitoring and Reset for MCU and Main Rails

• Input Supply Monitoring

• Output Voltage and Current Monitoring

• Question and Answer Watchdog

• Fault Reporting Interrupts

• Enable Drive Pin that provides an independent path to disable system actuators

• Error Pin Monitoring

• Internal Diagnostics including voltage monitoring, temperature monitoring, and Built-In Self-Test

Refer to the Safety Manual of the TPS6594-Q1 device for full descriptions and analysis of the PMIC functional

safety features. These functional safety features can assist in achieving up to ASIL-D rating for a system.

Additionally, these features help in achieving the functional safety assumptions utilized by the processor to

achieve up to ASIL-D rating. See the DRA829/TDA4VM Safety Manual for Jacinto™ 7 Processors for a complete

list of functional safety system assumptions.

Supporting Functional Safety Systems www.ti.com

10 TPS65941212-Q1 and TPS65941111-Q1 PMIC User Guide for Jacinto™ 7

J721E, PDN-0B

SLVUC32B – JUNE 2021 – REVISED FEBRUARY 2022

Submit Document Feedback

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Texas Instruments Microcontrôleur

Texas Instruments

Texas Instruments MSP430FG6626 Manuel utilisateur

Texas Instruments

Texas Instruments CC1120 Manuel utilisateur

Texas Instruments

Texas Instruments AM243x Manuel utilisateur

Texas Instruments

Texas Instruments LaunchPad C2000 F280015 Series Manuel utilisateur

Texas Instruments

Texas Instruments BoosterPack BOOSTXL-RS232 Manuel utilisateur

Texas Instruments

Texas Instruments MSP430F67481 Manuel utilisateur

Texas Instruments

Texas Instruments CC2530 ZigBee Development Kit Manuel utilisateur

Texas Instruments

Texas Instruments OMAP35 Series Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuel utilisateur

Texas Instruments

Texas Instruments AFE79 Series Manuel utilisateur

Texas Instruments

Texas Instruments REF70EVM Manuel utilisateur

Texas Instruments

Texas Instruments MSP430G2533 Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink MSP432P4111 Manuel utilisateur

Texas Instruments

Texas Instruments TMS370 Series Manuel d'utilisation et d'entretien

Texas Instruments

Texas Instruments MSP430FR6989 LaunchPad Manuel utilisateur

Texas Instruments

Texas Instruments TMS570LS Manuel utilisateur

Texas Instruments

Texas Instruments Stellaris LM3S9B96 Manuel utilisateur

Texas Instruments

Texas Instruments LaunchPad MSP430FR2476 Manuel utilisateur

Texas Instruments

Texas Instruments LaunchPad LP-EM-CC2340R5 Manuel utilisateur

Texas Instruments

Texas Instruments TMS570LS31 HDK Manuel utilisateur

Texas Instruments

Texas Instruments MSP430F67661 Manuel utilisateur

Texas Instruments

Texas Instruments LaunchPad LAUNCXL-CC2650 Manuel utilisateur

Texas Instruments

Texas Instruments Serial Programming Adapter MSP430 Manuel utilisateur

Texas Instruments

Texas Instruments LaunchPad MSP-EXP430FR5994 Manuel utilisateur

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Novatek

Novatek NT6861 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur

Silicon Laboratories

Silicon Laboratories C8051F800 Manuel utilisateur

Energy micro

Energy micro EFM32 Giant Gecko Starter Kit Manuel utilisateur

Mikroe

Mikroe click Proximity 2 Manuel utilisateur
