CC1110-CC1111DK Quick Start Instructions

RF/Packet Error Rate Test

1. Kit Contents

•2 SmartRF04EB

•2 CC1110EM 433 MHz

•2 CC1110EM 868-915 MHz

•1 CC1111 USB dongle 868-915 MHz

•1 SOC_DEM

•2 antennas (433 MHz)

•2 antennas (868/915 MHz)

•2 USB cables

•1 USB extension cable

•1 10-pin cable

2. EB overview

3. Plug EM into EB

Insert a CC1110EM into both SmartRF04EBs.

The connectors will only fit in one position, so

that the EM cannot be inserted the wrong way.

Do not force the EM. Remember to mount the

antenna as well. The frequency range of the

selected EM decides which antenna to use.

NB! Different antennas for different frequencies:

433MHz

868/915MHz

4a. Battery power

There are three different ways of applying power

to the EB:

The first method involves using a battery, either a

9V or a 4xAA battery pack connected to the

battery connector on the bottom side of the board

4b. DC power

The second method applies DC power using the

DC input jack (right in picture, centre is +, sleeve is

ground), or by connecting a 4-10V voltage source

between the 4-10V and 0V terminals of the power

connector (left in picture). It is also possible to

connect a 3.3V voltage source between the 3.3V

and 0V terminals. The on-board voltage regulators

will be bypassed in this case.

4c. USB power

The EB can also be powered from the USB bus.

Make sure that the SmartRF®Studio software is

installed before connecting the EB to the PC,

otherwise you may experience problems in

installing it later due to driver issues.

Note that if multiple power sources are

connected, the source with the highest voltage

will power the EB. This means that you should

disconnect any attached battery when using a

lab supply or USB power, otherwise the battery

will be drained.

5. Set power switch

If a 3.3V source is used as described in 4b

above, the switch should be set to the leftmost

position. For all other cases, the switch should be

set to the rightmost position. This switch can be

used to turn off the EB by switching it to the

opposite position of that used to turn it on.

6. Packet error rate test

When power is applied to the board, the test

program will start. You should see the Chipcon

logo with chip name and revision number as shown

above on the LCD display on both EBs. Pushing

button S1 in the lower right corner of the board will

show the first menu item.

7. Select Frequency

Select a frequency according to the type of EM

module in use (433 MHz, 868 MHz, 903 MHz or

915 MHz). Move the joystick up or down to

display the choices and push button S1 in the

lower right corner of the board to select the

displayed frequency.

LCD screen

connectors

Button S1

Joystick

SWRU135A

October 2008

Address information

Low Power RF web site: http://www.ti.com/lprf

Low Power RF community: http://www.ti.com/lprf-forum

TI Worldwide Support: http://support.ti.com

Technical Support Email: [email protected]

Make sure to subscribe to the Low-Power

RF Newsletter to receive information about

updates to documentation, new product

releases and more. Sign up on our web site!

5. Select Data Rate

Select which data rate to use (1.2 kbps, 38.4

kbps or 250 kbps) by moving the joystick.

Confirm your choice by pushing button S1.

6. EB 1: Select Receiver

Select Receiver on the first EB by moving the

joystick. Confirm by pressing button S1. The

Receiving node will display “Ready to receive”.

7. EB 2: Select Transmitter

Select Transmitter on the other EB by moving the

joystick upward. Confirm by pressing button S1.

8. EB 2: Number of packets

On the transmitter EB, select the number of

packets to send. More packets take longer, but

give a better statistical result. Confirm by

pressing button S1.

9. PER Test (Transmitter)

Press S1 button again to start transmitting the

packet burst. The transmitter will show a running

counter that shows the number of packets sent.

10. PER Test (Receiver)

The receiver will show the total accumulated

packet error rate (PER) together with the average

signal strength (RSSI) of the previous 32 received

packets. A symbol in the upper right corner will

blink for every 32nd incoming packet to indicate

whether the link is maintained.

11. PER Test results

When the PER test is completed, the result will

be displayed on the receiver until a new test is

started. A new test can be started from the

transmitter.

12. Documentation

Please visit www.ti.com to download the

CC1110-CC1111DK User Manual, the

SmartRF® Studio software, examples, as well

as relevant datasheets and application notes.

If you for some reason cannot access the TI

web site and download the files, please contact

your local TI representative for assistance.

1. Troubleshooting/Notice

It you are experiencing problems with this test,

please check the following:

•Please visit www.ti.com and enter

CC1110-CC1111DK in the part number

search box. Check for updated SW and

documentation. Updated SW can be

downloaded to the device using IAR or the

Flash Programmer application.

•If you get poor PER results at short

distances, try to move the transmitter and

receiver further apart. The CC1110 may

experience saturation when transmitting at

full output power if the units are too close.

•The source code for the packet error rate

application is available on the web. You

may modify the source code to test at

other frequencies or data rates.

•See “DN300 -- SmartRF04EB

Troubleshooting” for general

troubleshooting of your EB board.

SmartRF®Studio

1. Download

Before connecting the EB to your PC, download

SmartRF®Studio from www.ti.com/smartrfstudio.

The installer is located in the “Support Software”

section. Download and run the installer.

2. Plug in EB

After the install program finishes, connect the EB

to the PC using the USB cable. Run SmartRF®

Studio. Select the SmartRF®04 tab. Select the

CC1110 board at the top of the list, and click the

Start button.

3. Configure

You can now configure the radio chip, run tests

or communicate with another EB.
