This User’s Guide describes the operation of the evaluation module (TPA3255EVM, rev A) for the

TPA3255 315-W Stereo/600-W mono PurePath™ Ultra-HD Analog Input Power Stage. The user’s guide

also provides design information, which includes schematics, BOM, and PCB layout. For questions and

support go to the E2E forums (e2e.ti.com).

The main contents of this document are:

• Hardware descriptions and implementation

• Design information

Related documents:

• TPA3255 Data Sheet (SLASEA8)

Topic ........................................................................................................................... Page

2 Hardware Overview .............................................................................................. 3

3 TPA3255EVM Setup.............................................................................................. 6

4 Using TPA3255EVM in Different Output Configurations............................................ 9

5 Board Layouts, Bill of Materials, and Schematic .................................................... 12

www.ti.com

2SLOU441–July 2016

Submit Documentation Feedback

TPA3255EVM

1 Trademarks

PurePath is a trademark of Texas Instruments.

www.ti.com

Hardware Overview

SLOU441–July 2016

TPA3255EVM

2 Hardware Overview

The TPA3255EVM PurePath™ Ultra-HD evaluation module demonstrates the TPA3255DDV integrated

circuit from Texas Instruments. The TPA3255DDV is a high-performance high-power class-D amplifier that

enables true premium sound quality with high-efficiency class-D technology. It features an advance

integrated feedback design and high-speed gate driver error correction (PurePath Ultra-HD), which

enables ultra-low distortion across the audio band and superior audio quality. This EVM supports two BTL

(stereo 2.0) output channels, one PBTL (mono 0.1) output channel, one BTL plus two SE (2.1) output

channels, and four SE (4.0) output channels configurations. The NE5532 is a High Performance Audio Op

Amp designed to allow TPA3255DDV operation with differential or single ended input signals to the EVM

with differential inputs yielding the optimal performance. TPA3255EVM is a complete 2-Vrms analog input

2 × 315-W stereo/1 × 600-W mono high-power amplifier ready for evaluation and excellent listening

experience.

Figure 1. TPA3255EVM

2.1 TPA3255EVM Features

The TPA3255EVM has the following features:

• Stereo PurePath Ultra-HD evaluation module

• Self-contained protection system (short circuit, clip, and thermal)

• Standard 4-VRMS differential input or single-ended line input

• BTL, PBTL, and SE output configuration support

• Frequency adjust and oscillator sync interface

• Single supply voltage range 14–53.5 V

• Double-sided, plated-through, 2-oz. Cu 2-layer PCB layout

Hardware Overview

www.ti.com

4SLOU441–July 2016

Submit Documentation Feedback

TPA3255EVM

2.2 TPA3255EVM Frequency Adjust

The TPA3255EVM offers hardware trimmed oscillator frequency by external control of the FREQ_ADJ pin.

The Frequency adjust can be used to reduce interference problems while using a radio receiver tuned

within the AM band, the switching frequency can be changed from nominal to lower values. These values

should be chosen such that the nominal and the lower value switching frequencies together results in the

fewest cases of interference throughout the AM band. The oscillator frequency can be selected by the

value of the FREQ_ADJ resistor connected to GND in master mode according to Table 1.

Table 1. Frequency Adjust Master Mode Selection

Master Mode Resistor to GND

Nominal 30 kΩ

AM1 20 kΩ

AM2 10 kΩ

For slave-mode operation, turn off the oscillator by pulling the FREQ_ADJ pin to DVDD. This configures

the OSC_I/O pins as inputs to be slaved from an external differential clock. In a master/slave system inter-

channel delay is automatically set up between the switching phases of the audio channels, which can be

illustrated by no idle channels switching at the same time. This will not influence the audio output, but only

the switch timing to minimize noise coupling between audio channels through the power supply. This will

optimize audio performance and result in better operating conditions for the power supply. The inter-

channel delay will be set up for a slave device depending on the polarity of the OSC_I/O connection such

that slave mode 1 is selected by connecting the OSC_I/O of the master device with the OSC_I/O of the

slave device with the same polarity (+ to + and – to –), while slave mode 2 is selected by connecting the

OSC_I/O's with the inverse polarity (+ to – and – to +).

2.3 TPA3255EVM Single-Ended and Differential Input

The TPA3255EVM supports both differential and single-ended inputs. For single-ended inputs, J4 and/or

J19 jumpers are set to the SE position, so that the TPA3255EVM uses the NE5532 to convert the single-

ended input signal to differential to properly drive the differential inputs of the TPA3255. The input RCA

jack, J3, is used to provide INA inputs and RCA jack J14 is used to provide INB inputs. RCA jack J18 is

used to provide INC inputs and RCA jack J15 is used to provide IND inputs with differential inputs.

For differential input operation, J4 and/or J19 jumpers are set to the DIFF position, and the TPA3255EVM

uses the NE5532 to buffer the differential input signal to the differential inputs of the TPA3255. The input

RCA jack, J3, is used to provide INA, RCA jack J14 provides INB, RCA jack J18 provides INC, and RCA

jack J15 provides IND with differential inputs.

NOTE: Single-ended input settings on the TPA3255EVM should only be used for channels with

output configuration BTL or PBTL, not SE. For SE output configuration J4 and/or J19

jumpers for that channel must be set to the DIFF position, so the input signal INx is mapped

directly to OUTx.

www.ti.com

Hardware Overview

SLOU441–July 2016

TPA3255EVM

2.4 TPA3255EVM Clip Overtemperature and Fault Indicators

The TPA3255EVM is equipped with LED indicators that illuminate when the FAULT and/or CLIP_OTW pin

goes low. See Table 2 and (SLASEA8) for more details.

Table 2. Fault and Clip Overtemperature Status

FAULT CLIP_OTW Description

0 0 Overtemperature (OTE) or overload (OLP) or undervoltage (UVP). Junction temperature higher

than 125°C (overtemperature warning).

0 0 Overload (OLP) or undervoltage (UVP). Junction temperature higher than 125°C (overtemperature

warning).

0 1 Overload (OLP) or undervoltage (UVP). Junction temperature lower than 125°C.

1 0 Junction temperature higher than 125°C (overtemperature warning)

1 1 Junction temperature lower than 125°C and no OLP or UVP faults (normal operation)

Power Supply

SE A/B Input

DIFF A Input

DIFF B Input

TPA3255

under

Heat Sink

SE C/D Input

DIFF C Input

DIFF D Input

3.3-V and 12-V

LEDs

Warning LEDs

RESET Switch

OUTD

OUTC

GND

OUTB

OUTA

TPA3255EVM Setup

www.ti.com

6SLOU441–July 2016

Submit Documentation Feedback

TPA3255EVM

3 TPA3255EVM Setup

This section describes the TPA3255EVM hardware setup and connection.

3.1 TPA3255EVM Setup

Figure 2 illustrates the TPA3255EVM connection.

Figure 2. TPA3255EVM Connections

3.2 Hardware Requirements

The following hardware is required for this EVM:

• TPA3255EVM (AAP053-001)

• Power supply 5–14 A/18–53.5 VDC

• Two 2–8 Ω(≈300 W) speakers/resistor loads

• Four speaker/banana cables

• RCA input cables

• Analog output audio source

www.ti.com

TPA3255EVM Setup

SLOU441–July 2016

TPA3255EVM

3.3 Hardware Default Setup BTL (2.0)

BTL (2.0) default hardware setup is as follows:

• Remove the EVM from the ESD bag.

• Check that jumpers are in their default state as shown in Figure 1 and Table 3 for stereo BTL

operation:

Table 3. Stereo BTL Default Jumper States

Jumper Setting Comment

J29 IN PVDD to 15-V BUCK

J31 IN 12-V LDO to 12-V TERM

J32 IN 3.3-V LDO to 3.3-V TERM

J33 IN 3.3-V LDO to 3.3-V TERM

J21 IN CSTART SE

J16 3 to 4 MASTER MODE

J5 2 to 3 M1 – BTL

J6 2 to 3 M2 – BTL

J22 IN OUTA CAP SHUNT

J23 IN OUTB CAP SHUNT

J24 IN OUTC CAP SHUNT

J25 IN OUTD CAP SHUNT

J26 2 to 3 INC SELECT

J27 2 to 3 IND SELECT

J7 OUT PBTL SELECT INC

J8 OUT PBTL SELECT IND

J10 OUT INC/D DIFF INPUT

J12 OUT INC/D DIFF INPUT

J4 1 to 2 INA/B SE INPUT

J19 1 to 2 INC/D SE INPUT

• Set S1 to the RESET position.

• Set power supply to 51 V (14–53.5-V range) and current to 10 A (5–14-A range). Do not power up until

all connections are completed.

• Connect power supply to TPA3255 EVM positive terminal to PVDD (RED) and negative terminal to

GND (BLACK).

• Connect left channel speaker/power resistor load (4–8 Ω) to TPA3255 EVM positive output terminal to

OUTA (RED) and AP analog input channel A positive terminal.

• Connect left channel speaker/power resistor load (4–8 Ω) to TPA3255 EVM negative output terminal to

OUTB (BLACK) and AP analog input channel A negative terminal.

• Connect right channel speaker/power resistor load (4–8 Ω) to TPA3255 EVM positive output terminal

to OUTC (RED) and AP analog input channel B positive terminal.

• Connect right channel speaker/power resistor load (4–8 Ω) to TPA3255 EVM negative output terminal

to OUTD (BLACK) and AP analog input channel B negative terminal.

• Be careful not to mix up PVDD, OUTA, and OUTB terminals, since the colors are the same (RED).

• For single-ended stereo inputs, connect AP channel A XLR to RCA male jacks to female RCA jacks

input A/AB (RED) and AP channel B XLR to RCA male jacks to female RCA jacks input C/CD (WHITE)

and set J4 and J19 jumper positions to SE.

• For differential stereo inputs, connect positive RCA male jacks to female RCA jacks input A/AB

(RED) and input C/CD (WHITE) and connect negative RCA male jacks to female RCA jacks input B

(BLUE) and input D (BLACK) and set J4 and J19 jumper positions to DIFF.

• Power up power supply once all the connections are made correctly and the 3.3-V and12-V LEDs

(GREEN) will illuminate.

TPA3255EVM Setup

www.ti.com

8SLOU441–July 2016

Submit Documentation Feedback

TPA3255EVM

• Set S1 to the NORMAL position.

• CLIP_OTWz (ORANGE) and FAULTz (RED) LEDs should be off, if the audio source is off.

NOTE: J3/J10 and J18/J15 can be used for differential inputs to INA/INB and INC/IND, respectively.

Using a smart phone, tablet, or PC with headphone to RCA cable, audio streaming via headphone jack

can begin once the EVM is powered up correctly with jumpers in their default state. Start the media player

of your choice and enjoy the enhanced audio performance TPA3255 provides as a quick check of the

setup.

www.ti.com

Using TPA3255EVM in Different Output Configurations

SLOU441–July 2016

TPA3255EVM

4 Using TPA3255EVM in Different Output Configurations

The TPA3255EVM can be configured for four different output operations. The 2.0 BTL configuration is the

default set up of the TPA3255EVM described in Section 3.3. The remaining three configurations are 2.1

BTL plus two single-ended (SE) outputs, 0.1 PBTL output, and 4.0 single-ended (SE) outputs.

Table 4. Mode Selection Pins

Mode Pins Input Mode Output Configuration Description

M2 M1

0 0 2N + 1 2 × BTL Stereo BTL output configuration

0 1 2N/1N + 1 1 × BTL + 2 × SE 2.1 BTL + SE mode

1 0 2N + 1 1 × PBTL Paralleled BTL configuration. Connect INPUT_C and INPUT_D to

GND.

1 1 1N + 1 4 × SE Single-ended output configuration

4.1 BTL Plus Two SE (2.1) Operation

Configure the EVM as follows for 2 SE + 1 BTL operation:

Table 5. 2 SE + 1 BTL Default Jumper States

Jumper Setting Comment

J29 IN PVDD to 15-V BUCK

J31 IN 12-V LDO to 12-V TERM

J32 IN 3.3-V LDO to 3.3-V TERM

J33 IN 3.3-V LDO to 3.3-V TERM

J21 IN CSTART SE

J16 3 to 4 MASTER MODE

J5 1 to 2 M1 – 2XSE + BTL

J6 2 to 3 M2 - 2XSE + BTL

J22 IN OUTA CAP SHUNT

J23 IN OUTB CAP SHUNT

J24 OUT OUTC CAP SHUNT

J25 OUT OUTD CAP SHUNT

J26 2 to 3 INC SELECT

J27 2 to 3 IND SELECT

J7 OUT PBTL SELECT INC

J8 OUT PBTL SELECT IND

J10 OUT INC/D DIFF INPUT

J12 OUT INC/D DIFF INPUT

J4 1 to 2 INA/B SE INPUT

J19 1 to 2 INC/D SE INPUT

• Set J6 to L and J5 to H.

• Connect left (stereo) speaker/power resistor load (2–4 Ω) positive terminal to OUTC and remove

jumper J24.

• Connect right (stereo) speaker/power resistor load (2–4 Ω) positive terminal to OUTD and remove

jumper J25.

• Connect subwoofer (mono) speaker/power resistor load (4–8 Ω) positive terminal to OUTA and

negative terminal to OUTB.

• Set J19 jumper position to DIFF.

• Connect left (stereo) channel input to female RCA jack input C/CD (WHITE) for OUTC speaker.

Using TPA3255EVM in Different Output Configurations

www.ti.com

10 SLOU441–July 2016

Submit Documentation Feedback

TPA3255EVM

• Connect right (stereo) channel input to female RCA jack input D (BLACK) for OUTD speaker.

• For single-ended subwoofer (mono) input, connect RCA male jack to female RCA jack input A/AB

(RED) and set J4 jumper positions to SE.

• For differential subwoofer (mono) inputs, connect positive RCA male jack to female RCA jack input

A/AB (RED) and connect negative RCA male jack to female RCA jack input B (YELLOW) and set J4

jumper positions to DIFF.

NOTE: OUTC and OUTD are the single-ended output channels and OUTA and OUTB are the BTL

channel for 2.1 operations.

4.2 PBTL (0.1) Output Operation

Configure the EVM as follows for PBTL operations:

Table 6. PBTL Default Jumper States

Jumper Setting Comment

J29 IN PVDD to 15-V BUCK

J31 IN 12-V LDO to 12-V TERM

J32 IN 3.3-V LDO to 3.3-V TERM

J33 IN 3.3-V LDO to 3.3-V TERM

J21 IN CSTART SE

J16 3 to 4 MASTER MODE

J5 2 to 3 M1 – PBTL

J6 1 to 2 M2 – PBTL

J22 IN OUTA CAP SHUNT

J23 IN OUTB CAP SHUNT

J24 IN OUTC CAP SHUNT

J25 IN OUTD CAP SHUNT

J26 2 to 3 INC SELECT

J27 2 to 3 IND SELECT

J7 2 to 3 PBTL SELECT INC – GND

J8 2 to 3 PBTL SELECT IND – GND

J10 OUT INC/D DIFF INPUT

J12 OUT INC/D DIFF INPUT

J4 1 to 2 INA/B SE INPUT

J19 1 to 2 INC/D SE INPUT

• Set J6 to H and J5 to L.

• Connect speaker/power resistor (2–4 Ω) positive terminal to OUTA and OUTC (OUT A and C shorted).

• Connect speaker/power resistor (2–4 Ω) negative terminal to OUTB and OUTD (OUT B and D

shorted).

• Install PBTL jumpers J7 and J8 (pulls input C and input D to GND).

• For single-ended mono input, connect RCA male jack to female RCA jack input A/AB (RED) and set

J4 jumper positions to SE.

• For differential mono inputs, connect positive RCA male jack to female RCA jack input A/AB (RED)

and connect negative RCA male jack to female RCA jack input B (YELLOW) and set J4 jumper

position to DIFF.

NOTE: INA and INB are the inputs for PBTL and INC and IND are grounded for PBTL operation.

Table des matières

Autres manuels Texas Instruments Unité de contrôle

Texas Instruments

Texas Instruments bq2022A Manuel utilisateur

Texas Instruments

Texas Instruments TRF7960A Manuel utilisateur

Texas Instruments

Texas Instruments UCC2 5 EVM-286 Series Manuel utilisateur

Texas Instruments

Texas Instruments TPS6101xEVM-157 Manuel utilisateur

Texas Instruments

Texas Instruments PurePath Digital TAS5342DDV6EVM Manuel utilisateur

Texas Instruments

Texas Instruments CC1101EMK Manuel utilisateur

Texas Instruments

Texas Instruments AN-2166 LMZ10500 Manuel utilisateur

Texas Instruments

Texas Instruments TPS25200EVM-618 Manuel utilisateur

Texas Instruments

Texas Instruments TAS5086-5186V6EVM Manuel utilisateur

Texas Instruments

Texas Instruments BQ25181 Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink CC3100MOD Manuel utilisateur

Texas Instruments

Texas Instruments ADS7042EVM-PDK Manuel utilisateur

Texas Instruments

Texas Instruments DAC90 EVM Series Manuel utilisateur

Texas Instruments

Texas Instruments DP83869EVM Manuel utilisateur

Texas Instruments

Texas Instruments EVMK2E Manuel utilisateur

Texas Instruments

Texas Instruments DRV8833C Manuel utilisateur

Texas Instruments

Texas Instruments TPS65320C-Q1-EVM Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink CC3235MODS Manuel utilisateur

Texas Instruments

Texas Instruments S6350 Manuel utilisateur

Texas Instruments

Texas Instruments TPA4411 Manuel utilisateur

Texas Instruments

Texas Instruments BoosterPack BOOSTXL-ADS7142-Q1 Manuel utilisateur

Texas Instruments

Texas Instruments BQ24260EVM-611 Manuel utilisateur

Texas Instruments

Texas Instruments TPS55165Q1-EVM Manuel utilisateur

Texas Instruments

Texas Instruments TMS320C6748 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
