Texas Instruments Bq2022A Manuel utilisateur

SLUU258B–November 2007–Revised July 2017

bq2022A Evaluation Software

User's Guide

SLUU258B–November 2007–Revised July 2017

bq2022A Evaluation Software

The bq2022A is a 1 K-bit serial EPROM containing a factory-programmed, unique 48-bit identification

number, 8-bit CRC generation, and an 8-bit family code. A 64-bit status register controls write protection

and page redirection.

The purpose of the evaluation software is to demonstrate the functionality of the bq2022A. The bq2022A

evaluation board can be used for one or two ICs.

The bq2022A is ideal for applications such as battery pack configuration parameters, record maintenance,

asset tracking, product revision status, and access-code security.

Contents

1 Kit Contents................................................................................................................... 2

2 bq2022A-Based Circuit Module............................................................................................ 2

3 bq2022A Circuit Module Schematic....................................................................................... 3

4 Circuit Module Physical Layouts........................................................................................... 4

5 bq2022A Circuit Module List of Materials................................................................................. 8

6 bq2022AEVM Circuit Module Performance Specification Summary.................................................. 8

7 EVM Hardware and Software Setup ...................................................................................... 8

8 Software Operation ........................................................................................................ 10

List of Figures

1 EVM Schematic.............................................................................................................. 3

2 Silk Screen ................................................................................................................... 4

3 EVM Top Assembly ......................................................................................................... 5

4 EVM Layer One.............................................................................................................. 6

5 EVM Layer Two.............................................................................................................. 7

6 ROM CMD Page ........................................................................................................... 11

7 DATA Page ................................................................................................................. 12

List of Tables

1 Test Points.................................................................................................................... 2

2 List of Materials .............................................................................................................. 8

3 Performance Specification Summary ..................................................................................... 8

4 Wire Connection ............................................................................................................. 9

Trademarks

Microsoft, Windows are registered trademarks of Microsoft Corporation.

All other trademarks are the property of their respective owners.

Kit Contents

www.ti.com

2SLUU258B–November 2007–Revised July 2017

Submit Documentation Feedback

bq2022A Evaluation Software

1 Kit Contents

1. bq2022A, HPA125 revision-B board

2. CD-ROM including Microsoft®Windows®based PC software and support documentation

NOTE: An EV2300 board is required to interface this EVM with the PC and can be purchased

separately.

The EV2400 up through at least version 0.18 does not support this EVM.

2 bq2022A-Based Circuit Module

The bq2022A-based circuit module is ideal for programming the 1 K-bit EPROM and the STATUS bytes of

the bq2022A IC. The circuit module includes a 3-pin SOT23 dual socket, a bq2022A IC, a Zener diode for

host protection during EPROM programming, and a programming circuit that generates a 12-V pulse when

used with a power supply and a control signal. In a typical application, only the bq2022A IC and a pullup

resistor is required.

2.1 Test Points

Table 1. Test Points

Test Point SIGNAL NAME DESCRIPTION

J1-1 VSS Device ground

J1-2 PROG Input for timing of EPROM programming pulse

J1-3 SDQ SDQ single-wire communication bus

J2-1 12V High voltage for EPROM programming

J2-2 VSS Programming ground

J3 Connect for EPROM programming

www.ti.com

bq2022A Circuit Module Schematic

SLUU258B–November 2007–Revised July 2017

bq2022A Evaluation Software

3 bq2022A Circuit Module Schematic

The schematic shows the circuit for the bq2022AEVM implementation.

Figure 1. EVM Schematic

Circuit Module Physical Layouts

www.ti.com

4SLUU258B–November 2007–Revised July 2017

Submit Documentation Feedback

bq2022A Evaluation Software

4 Circuit Module Physical Layouts

This section contains the board layout and assembly drawings for the bq2022AEVM circuit module.

Figure 2. Silk Screen

www.ti.com

Circuit Module Physical Layouts

SLUU258B–November 2007–Revised July 2017

bq2022A Evaluation Software

Figure 3. EVM Top Assembly

Circuit Module Physical Layouts

www.ti.com

6SLUU258B–November 2007–Revised July 2017

Submit Documentation Feedback

bq2022A Evaluation Software

Figure 4. EVM Layer One

www.ti.com

Circuit Module Physical Layouts

SLUU258B–November 2007–Revised July 2017

bq2022A Evaluation Software

Figure 5. EVM Layer Two

bq2022A Circuit Module List of Materials

www.ti.com

8SLUU258B–November 2007–Revised July 2017

Submit Documentation Feedback

bq2022A Evaluation Software

5 bq2022A Circuit Module List of Materials

List of materials required for the bq2022AEVM circuit module.

Table 2. List of Materials

REF DES QTY DESCRIPTION MFR PART NUMBER

D1, D2 1 Diode, Zener, 5.6-V, 350-mW Diodes, Inc. BZX84C5V6

J3 1 Header, 2-pin, 100-mil spacing, (36-pin strip) Sullins PTC36SAAN

R1, R2, R6 3 Resistor, Chip, 100-Ω, 1/16-W Std Std

R3 1 Resistor, Chip, 100-kΩ, 1/16-W Std Std

R4 1 Resistor, Chip, 10-kΩ, 1/16-W Std Std

XU1 1 Socket, Double 3P SOT-23 Loranger 13293 121 X218A

J1 1 Header, Friction Lock Ass'y, 4-pin Right Angle Molex 22-05-3041

J2 1 Terminal Block, 2-pin, 6-A, 3.5-mm OST ED1514

VSS1, VSS2 2 Test Point, Black, 1-mm Keystone 5001

SDQ1, SDQ2 2 Test Point, Red, 1-mm Keystone 5000

Q1 1 MOSFET, N-ch, 60-V, 115-mA, 1.2-ΩVishay-Liteon 2N7002DICT

Q2 1 MOSFET, Pch, -20V, 3.7A, 65 mΩIR IRLML6402

U1 1 IC, 1 K Serial EPROM With SDQ Interface TI bq2022ADBZR

– 1 PCB, 2 In x 1.25 In x .125 In Any HPA125 Rev. B Board

N/A 1 Shunt, 100-mil, Black 3M 929950-00

6 bq2022AEVM Circuit Module Performance Specification Summary

Table 3. Performance Specification Summary

SPECIFICATION MIN TYP MAX UNITS

Voltage Pullup (VUP) 2.65 5.5 V

Programming Voltage(VPP) 11.5 12 V

7 EVM Hardware and Software Setup

7.1 Drivers and Software Installation

This section describes how to install the bq2022AEVM PC software, and how to connect the different

components of the EVM.

Use the following steps to install the bq2022A evaluation software:

1. Insert the CD ROM into a CD ROM drive.

2. Select the CD ROM drive using My Computer or File Manager.

3. Select the ReadMeFirst.txt file.

4. Select the Software/EV2300 Drivers directory of CD and run SETUP.EXE.

5. Plug the EV2300 into a USB port.

6. Wait until system prompt new hardware found appears. Choose select location manually, and use the

browse button to point to subdirectory TIUSBWin2K-XP-1.

7. Answer continue to the warning that drivers are not certified with Microsoft.

8. After installation finishes, another system prompt new hardware found appears. Repeat procedure

above, but point to subdirectory TIUSBWin2K-XP-2.

9. Answer continue to the warning that drivers are not certified with Microsoft. Installation of drivers is

now finished.

10. For Windows 98, point to directory TIUSBWin98.

www.ti.com

EVM Hardware and Software Setup

SLUU258B–November 2007–Revised July 2017

bq2022A Evaluation Software

11. After installing the USB drivers for EV2300, double-click on the Setup.exe icon that is under the

Software/bq2022A Evaluation Software folder.

12. Follow the instructions on screen during the installation of evaluation software.

13. The setup program installs a Windows application group.

7.2 Hardware Connection

The bq2022AEVM has three hardware components. :

1. The bq2022AEVM circuit module

2. The PC interface board, (EV2300 – purchased separately)

3. The PC

Use the following steps to configure the hardware for interface to the PC:

1. Connect the HPA125 board with the EV2300 PC interface board using Table 4 as a pin connection

guide.

2. Connect the USB cable to the EV2300 and the PC USB port.

The bq2022AEVM is now set up for normal operation.

Table 4. Wire Connection

bq2022AEVM (HPA125 Rev. B) EV2300

SDQ HDQ

VSS GND

PROG VOUT

To program the EPROM of bq2022AEVM, a 12-V pulse must be generated on the SDQ line. The HPA125

board has an additional circuit included that permits generating this pulse when using a power supply set

to 12 V and the VOUT output of the EV2300. The evaluation software controls this pulse for EPROM

programming.

When programming the EPROM, it is expected that a 12-V supply must be connected to the HPA125

board at the 12-V input terminal of the HPA125 board. Ensure that the ground of the power supply is

connected to VSS of the board.

A jumper (J3) must be connected when using the EPROM programming circuit.

7.2.1 Normal Operation

Normal operation includes performing any of the ROM commands, reading the 1 K-bit EPROM and

reading the EPROM Status Memory.

7.2.2 EPROM Programming

To program EPROM registers, a 12-V pulse must be sent across the SDQ line after sending the code

0x5A during a write command. See the bq2022A data sheet (SLUS724) for a specific description of

EPROM programming requirements. When programming EPROM registers, the following must be

ensured:

• J3 jumper is connected.

• VOUT output of EV2300 is connected to PROG input of HPA125 board.

• Power supply set to 12 V is connected across the 12 V and VSS inputs of HPA125 board.

Software Operation

www.ti.com

10 SLUU258B–November 2007–Revised July 2017

Submit Documentation Feedback

bq2022A Evaluation Software

8 Software Operation

Run the program from the Start|Programs|Texas Instruments|bq2022A Evaluation Software menu

sequence.

8.1 Evaluation Software Pages

This section describes the function of each page of the EVSW.

8.2 ROM CMD

This page provides all the ROM commands for bq2022A (see Figure 6).

8.2.1 Sections Within the ROM CMD Page

Application — This section determines the number of bq2022A devices that are on the SDQ bus. If only

one device is used, then select Single Device. This option sends the SKIP ROM command before

any communication attempt is made with the device. If more than one device is used, then select

Multiple Devices. This option sends the MATCH ROM command before any communication attempt

is made with the desired device

Search ROM — This section demonstrates the SEARCH ROM command. When multiple devices are on

the SDQ bus, the ROM ID of the devices that share the bus is listed.

Match ROM — This section is only available when the Multiple Devices option is selected in the

Application section. To use the MATCH ROM, enter the ROM ID of the device of interest in the text

box, and then click on the Select Device button. This causes the MATCH ROM commands with the

desired ROM ID to be sent whenever communication is attempted with the desired device. If

SEARCH ROM is used, the desired ID can be copied from the SEARCH ROM list, and then pasted

into the MATCH ROM text box. Ensure that only the ID numbers are pasted into the text box and

not the whole line referring to the device.

Read ROM — This section is only available when the Single Device option is selected in the Application

section. The ID ROM of the device on the SDQ communication line is displayed.

Table des matières

Autres manuels Texas Instruments Unité de contrôle

Texas Instruments

Texas Instruments TUSB320-LA-EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPS272C45 Manuel utilisateur

Texas Instruments

Texas Instruments bq26220EVM-001 Manuel utilisateur

Texas Instruments

Texas Instruments TPS40190EVM-001 Manuel utilisateur

Texas Instruments

Texas Instruments TMS320C3 Series Manuel utilisateur

Texas Instruments

Texas Instruments UCC27288EVM Manuel utilisateur

Texas Instruments

Texas Instruments DAC1220EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPA0152 Manuel utilisateur

Texas Instruments

Texas Instruments TPS650380EVM-054 Manuel utilisateur

Texas Instruments

Texas Instruments LM5123EVM-BST Manuel utilisateur

Texas Instruments

Texas Instruments TDP158RSBEVM Manuel utilisateur

Texas Instruments

Texas Instruments WL1835MODCOM8B Manuel utilisateur

Texas Instruments

Texas Instruments TRF2443 Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink Wi-Fi CC3 20 Series Manuel utilisateur

Texas Instruments

Texas Instruments ADS1 7 EVM-PDK Series Manuel utilisateur

Texas Instruments

Texas Instruments TAS2770YFF Manuel utilisateur

Texas Instruments

Texas Instruments bq20z65EVM-001 Manuel utilisateur

Texas Instruments

Texas Instruments LP8864 Manuel utilisateur

Texas Instruments

Texas Instruments TLV320DAC26EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPS6101xEVM-157 Manuel utilisateur

Texas Instruments

Texas Instruments TPSM846C24 Manuel utilisateur

Texas Instruments

Texas Instruments ADS8353-Q1 Manuel utilisateur

Texas Instruments

Texas Instruments TPS23523EVM-863 Manuel utilisateur

Texas Instruments

Texas Instruments UCC28056EVM-296 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur

Texas Instruments bq2022A Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques
