Texas Instruments Bq24650EVM Manuel utilisateur

User's Guide

SLUU444A–August 2010–Revised October 2010

bq24650EVM Synchronous, Switch-Mode, Battery Charge

Controller for Solar Power

This user's guide describes the features and operation of the bq24650EVM Evaluation Module (EVM). The

EVM assists users in evaluating the bq24650 synchronous battery charger. The EVM is also called the

HPA639 A. The manual includes the bq24650EVM bill of materials, board layout, and schematic.

Contents

1 Introduction .................................................................................................................. 1

1.1 Features ............................................................................................................. 1

1.2 General Description ................................................................................................ 2

1.3 I/O Description ...................................................................................................... 2

1.4 Control and Key Parameters Settings ........................................................................... 3

1.5 Recommended Operating Conditions ........................................................................... 3

2 Test Summary ............................................................................................................... 5

2.1 Definitions ........................................................................................................... 5

2.2 Safety ................................................................................................................ 5

2.3 Quality ............................................................................................................... 5

2.4 Apparel .............................................................................................................. 5

2.5 Equipment ........................................................................................................... 5

2.6 Equipment Setup ................................................................................................... 6

2.7 Procedure ........................................................................................................... 7

3 PCB Layout Guideline ...................................................................................................... 9

4 Bill of Materials, Board Layout, and Schematic ....................................................................... 10

4.1 Board Layout ...................................................................................................... 11

List of Figures

1 Original Test Setup for HPA639 A Evaluation Board .................................................................. 6

2 Top Layer................................................................................................................... 11

3 Second Layer .............................................................................................................. 12

4 Third Layer ................................................................................................................. 13

5 Bottom Layer............................................................................................................... 14

6 Top Assembly.............................................................................................................. 15

7 Bottom Assembly.......................................................................................................... 16

8 bq24650EVM Schematic ................................................................................................. 17

List of Tables

1 I/O Description............................................................................................................... 2

2 Control and Key Parameters Settings.................................................................................... 3

3 Recommended Operating Conditions.................................................................................... 3

1 Introduction

1.1 Features

• Synchronous switch-mode battery charge controller for solar power

SLUU444A–August 2010–Revised October 2010 bq24650EVM Synchronous, Switch-Mode, Battery Charge Controller for

Solar Power

Introduction

www.ti.com

• Resistor-programmable up to 26-V battery voltage

• Input operating range: 5 V–28 V

• LED indication for charge status

• Test points for key signals available for testing purposes; easy probe hook-up.

• Jumpers available; easy-to-change setting

1.2 General Description

The bq24650 is a highly integrated switch-mode battery charge controller. It provides input voltage

regulation, which reduces charge current when input voltage falls below a programmed level. When the

input is powered by a solar panel, the input regulation loop maintains the panel at maximum power output.

The bq24650 offers a constant-frequency, synchronous PWM controller with high-accuracy current and

voltage regulation, charge preconditioning, charge termination, and charge status monitoring.

The bq24650 changes the battery in three phases: preconditioning, constant current, and constant

voltage. Charge is terminated when the current reaches one-tenth of the fast charge rate. A

programmable fast-charge timer provides a safety backup. The precharge timer is fixed at 30 minutes.

The bq24650 automatically restarts the charge cycle if the battery voltage falls below an internal threshold

and enters a low, quiescent-current sleep mode when the input voltage falls below the battery voltage.

The bq24650 supports the battery from 2.1 V to 26 V with VFB set to a 2.1-V feedback reference. The

charge current is programmed by selecting an appropriate sense resistor. The bq24650 is available in a

16-pin, 3.5x3.5 mm2, thin QFN package.

For details, see the bq24650 data sheet (SLUSA75).

1.3 I/O Description

Table 1. I/O Description

Jack Description

J1–VIN Positive input

J1–PGND Negative input

J2–VSYS Connected to system

J2–VOUT Connected to charger output

J2–PGND Ground

J2–TS Temperature qualification voltage Input

2bq24650EVM Synchronous, Switch-Mode, Battery Charge Controller for SLUU444A–August 2010–Revised October 2010

Solar Power Submit Documentation Feedback

MPPSET

R17

V = 1.2 V 1 +

R19

æ ö

´ç ÷

è ø

OUT

R13

V = 2.1 V 1 +

R15

æ ö

´ç ÷

è ø

www.ti.com

Introduction

1.4 Control and Key Parameters Settings

Table 2. Control and Key Parameters Settings

Jack Description Factory Setting

JP1 Select external TS input or internal valid TS setting Jumper ON 1-2 (external TS)

1-2 : External TS input

2-3 : Internal valid TS setting

JP2 The pullup power source supplies the LEDs when JP2 ON. LED has no Jumper ON (LED power available)

power source when JP2 is OFF.

JP3 TERM_EN setting Jumper ON 2-3 (enable termination)

2-3 : Connect TERM_EN to VREF to enable termination

1-2 : Connect TERM_EN to GND to disable termination

JP4 Charger enable/disable setting. MPPSET is pulled to GND and the charger Jumper OFF (disable charger)

is disabled when JP4 OFF; charger is enabled when JP4 is ON.

1.5 Recommended Operating Conditions

Table 3. Recommended Operating Conditions

Symbol Description Min Typ Max Unit Notes

Supply voltage, VIN Input voltage 5 20 28 V

Battery voltage, VOUT Voltage applied at VOUT terminal 2.1 12.6 26 V

of J2

Supply current Maximum input current 0 8 A

Charge current, Ichrg Battery charge current 0 2 8 A For charge current above 2 A, replace R6

and L1 with high-current rating

components

Operating junction temperature range, TJ0 125 °C

The bq24650EVM board requires a regulated supply approximately 1 V minimum above the regulated

voltage of the battery pack to a maximum input voltage of 28 Vdc. The charge voltage is programmed via

a resistor divider from the battery to ground, with the midpoint tied to the VFB pin.

R13 and R15 can be changed to regulate output between approximately 2.1 V to 26 V.

(1)

It is set at 12.6 Vdc from the factory.

A solar panel has a unique point on the V-I or V-P curve, called the maximum power point (MPP), at

which the entire photovoltaic (PV) system operates with maximum efficiency and produces its maximum

output power. The constant voltage algorithm is the simplest maximum power point tracking (MPPT)

method. The bq24650 automatically reduces charge current, so the maximum power point is maintained

for maximum efficiency.

If the solar panel or other input source cannot provide the total power of the system and bq24650 charger,

the input voltage drops. Once the voltage sensed on the MPPSET pin drops below 1.2 V, the charger

maintains the input voltage by reducing the charge current.

(2)

It is set at 17.8 Vdc from the factory.

SLUU444A–August 2010–Revised October 2010 bq24650EVM Synchronous, Switch-Mode, Battery Charge Controller for

Solar Power

CHARGE

40 mV

I =

Introduction

www.ti.com

Battery current is sensed by resistor RSR connected between SRP and SRN. The full-scale differential

voltage between SRP and SRN is fixed at 40 mV.

(3)

It is set at 2 Adc from the factory.

4bq24650EVM Synchronous, Switch-Mode, Battery Charge Controller for SLUU444A–August 2010–Revised October 2010

Solar Power Submit Documentation Feedback

www.ti.com

Test Summary

2 Test Summary

2.1 Definitions

This procedure details how to configure the HPA639 A evaluation board. The following naming

conventions are followed on the test procedure.

VXXX : External voltage supply name (VADP, VBT, VSBT)

LOADW: External load name (LOADR, LOADI)

V(TPyyy): Voltage at internal test point TPyyy. For example, V(TP1) means the voltage at TP1.

V(Jxx): Voltage at jack terminal Jxx.

V(TP(XXX)): Voltage at test point XXX. For example, V(MPPSET) means the voltage at the test point

which is marked as MPPSET.

V(XXX, YYY): Voltage across point XXX and YYY.

I(JXX(YYY)): Current going out from the YYY terminal of jack XX.

Jxx(BBB): Terminal or pin BBB of jack xx

Jxx ON : Internal jumper Jxx terminals are shorted

Jxx OFF: Internal jumper Jxx terminals are open

Jxx (-YY-) ON: Internal jumper Jxx adjacent terminals marked as YY are shorted

Measure:→A,B Check specified parameters A, B. If measured values are not within specified limits the

unit under test has failed.

Observe: →A,B Observe if A, B occur. If they do not occur, the unit under test has failed.

Assembly drawings have location for jumpers, test points and individual components.

2.2 Safety

1. Safety Glasses are to be worn.

2. This test must be performed by qualified personnel who are trained in electronics theory and

understand the risks and hazards of the assembly to be tested.

3. ESD precautions must be followed while handling electronic assemblies and performing this test.

4. Precautions must be observed to avoid touching areas of the assembly that may get hot or present a

shock hazard during testing.

2.3 Quality

1. Test data can be made available on request from Texas Instruments.

2.4 Apparel

1. Electrostatic smock

2. Electrostatic gloves or finger cots

3. Safety glasses

4. Ground ESD wrist strap.

2.5 Equipment

2.5.1 Power Supplies

Power Supply #1 (PS#1): a power supply capable of supplying 30 V at 3 A is required.

SLUU444A–August 2010–Revised October 2010 bq24650EVM Synchronous, Switch-Mode, Battery Charge Controller for

Solar Power

BQ24650 EVM

HPA639

VIN

PGND

VSYS

PGND

VOUT

APPLICATION CIRCUIT

TP2

Iin

Power supply

Iout

Isys

ILoad #1

Load #2

LEDPWR

/STAT1 /STAT2

JP3 TEST POINTS

D4 D5

JP2JP4

TERM_EN

SATATUS

SETTINGS

JP1

External

Internal

DIS

Test Summary

www.ti.com

2.5.2 Loads

LOAD#1 A 30-V (or greater), 5-A (or greater) electronic load that can operate at constant current and

constant voltage mode.

LOAD#2: An HP 6060B 3-V to 60-V/0A to 60-A, 300-W system dc electronic load or equivalent.

2.5.3 Meters

Seven Fluke 75 multimeters (equivalent or better) or four equivalent voltage meters and three equivalent

current meters.

The current meters must be capable of measuring 5-A+ current.

2.6 Equipment Setup

1. Set the power supply #1 (PS#1) for 21-V ±500-mVdc, 2.5-A ±0.1-A current limit, and then turn off

supply.

2. Connect the output of PS#1 in series with a current meter (multimeter) to J1 (VIN, PGND).

3. Connect a voltage meter across J1 (VIN, PGND).

4. Connect Load#1 in series with a current meter to J2 (VOUT, PGND). Turn off Load#1.

5. Connect Load#2 in series with a current meter to J2 (VSYS, PGND). Turn off Load#2.

6. Connect a voltage meter across J2 (VOUT, PGND).

7. Connect a voltage meter across J2 (VSYS, PGND).

8. Check all jumper shunts. JP1: connect 1-2 (External TS); JP2: ON; JP3: connect 2-3 (Enable

TERM_EN); JP4: OFF.

Figure 1. Original Test Setup for HPA639 A Evaluation Board

6bq24650EVM Synchronous, Switch-Mode, Battery Charge Controller for SLUU444A–August 2010–Revised October 2010

Solar Power Submit Documentation Feedback

www.ti.com

Test Summary

2.7 Procedure

2.7.1 Power Supply and VREF

Ensure that Section 2.6 steps are followed.

Disconnect LOAD#1#2. Turn on PS#1.

Measure →V(J2(VSYS)) = 21 V ±500 mV

Measure →V(J2(VOUT)) = 0 V ±500 mV

Measure →V(TP(VREF)) = 3.3 V ±200 mV

Measure →V(TP(REGN)) = 0 V ±200 mV

2.7.2 Charger Enable and Battery Detection

Connect 2-3 of JP1 (Internal TS); Short JP4 (Charger Enable)

Measure →V(TP(VREF)) = 3.3 V ±200 mV

Measure →V(TP(REGN)) = 6 V ±200 mV

Observe →V(J2(VOUT))=12.6 V ±500 mV

Observe →D4 (/STAT1) OFF, D5 (/STAT2) OFF

2.7.3 Charge Current/Voltage Regulation and Battery Temperature Qualification

Reconnect LOAD#2, and turn on. Use the constant voltage mode. Set the output voltage to 8 V.

Measure →I(J2(VOUT)) = 0.2 A ±100 mA

Observe →D4 (/STAT1) ON, D5 (/STAT2) OFF

Increase the voltage of LOAD#2 to be 10.5 V.

Measure →I(J2(VOUT)) = 2 A ±200 mA

Observe →D4 (/STAT1) ON, D5 (/STAT2) OFF

Open 2-3 of JP1

Measure →I(J2(VOUT)) = 0 A ±100 mA

Observe →D4 (/STAT1) OFF, D5 (/STAT2) OFF

Connect 2-3 of JP1 (Internal TS)

Measure →I(J2(VOUT)) = 2 A ±200 mA

Observe →D4 (/STAT1) ON, D5 (/STAT2) OFF

2.7.4 Charger Termination

Increase the voltage of LOAD#2 slowly to approximately 12.6 V.

Observe →I(J2(VOUT)) decreases from 2 A while V(J2(VOUT)) becomes constant.

Observe →I(J2(VOUT)) drops to zero when it is less than 0.2 A.

2.7.5 Maximum Power Point, Input Voltage Regulation

Connect the output of the Load#1 in series with a current meter (multimeter) to J2 (SYS, PGND). Ensure

that a voltage meter is connected across J2 (SYS, PGND). Resume other status as in Section 2.7.3.

(Short JP1, JP4, set LOAD#2 to 10.5 V.)

SLUU444A–August 2010–Revised October 2010 bq24650EVM Synchronous, Switch-Mode, Battery Charge Controller for

Solar Power

Test Summary

www.ti.com

2.7.6 Final Step

Turn on the power of Load#1. Set the load current to 1 A. Increase the load current slowly and observe

the following.

Observe →V(J1(VIN)) = 17.8 V ±500 mV.

Keep increasing I(J2(VSYS)),

Observe →I(J2(VOUT)) decreases from 2 A toward 0 A while V(J1(VIN)) become constant 17.8 V ±500

mV. Ensure that I(J2(VOUT))= 0 A ±100 mA and →(J2(VSYS)) = 2.4 A ±200 mA.

2.7.7 Test Complete

Turn off the power supply, and remove all connections from the unit under test.

8bq24650EVM Synchronous, Switch-Mode, Battery Charge Controller for SLUU444A–August 2010–Revised October 2010

Solar Power Submit Documentation Feedback

www.ti.com

PCB Layout Guideline

3 PCB Layout Guideline

1. It is critical that the exposed thermal pad on the backside of the bq24650 package be soldered to the

PCB ground. Ensure that sufficient thermal vias are right underneath the IC, connecting to the ground

plane on the other layers.

2. The control stage and the power stage must be routed separately. At each layer, the signal ground and

the power ground are connected only at the thermal pad.

3. Charge current sense resistor must be connected to SRP, SRN with a Kelvin contact. The area of this

loop must be minimized. The decoupling capacitors for these pins must be placed as close to the IC as

possible.

4. Decoupling capacitors for VREF, VCC, REGN must make the interconnections to the IC as short as

possible.

5. Decoupling capacitors for BAT must be placed close to the corresponding IC pins, and make the

interconnections to the IC as short as possible.

6. Decoupling capacitor(s) for the charger input must be placed close to the Q1A drain and Q1B source.

7. Take the EVM layout for design reference.

SLUU444A–August 2010–Revised October 2010 bq24650EVM Synchronous, Switch-Mode, Battery Charge Controller for

Solar Power

Bill of Materials, Board Layout, and Schematic

www.ti.com

4 Bill of Materials, Board Layout, and Schematic

Bill of Materials

001 RefDes Value Description SIZE PART NUMBER MFR

3 C1, C2, C7 10 µF Capacitor, Ceramic, 35V, X7R, 10% 1210 STD STD

3 C3, C5, C8 1.0 µF Capacitor, Ceramic, 35V, X7R, 10% 805 STD STD

1 C4 2.2 µF Capacitor, Ceramic, 35V, X7R, 20% 1210 STD STD

3 C6, C11, C12 0.1 µF Capacitor, Ceramic, 50V, X7R, 10% 603 STD STD

0 C9, C13 Open Capacitor, Ceramic, 50V, X7R, 10% 603 STD STD

2 C10, C16 1.0 µF Capacitor, Ceramic, 16V, X7R, 10% 805 STD STD

1 C14 0.1 µF Capacitor, Ceramic, 16V, X7R, 10% 603 STD STD

2 C15, C17 22 pF Capacitor, Ceramic, 50V, X7R, 10% 603 STD STD

2 D1, D3 PDS1040-13 Diode, 10A 40V Schottky Barrier Rectifier PowerDI 5 PDS1040-13 Diodes

1 D2 ZLLS350-7 Diode, Schottky, 1.16A, 40-V SOD-523 ZLLS350-7 Zetex

2 D4, D5 LTST-C190GKT Diode, LED, Green, 2.1V, 20mA, 6mcd 603 LTST-C190GKT Lite On

1 J1 ED120/2DS Terminal Block, 2 pin, 15A, 5.1mm 0.40 x 0.35 inch ED120/2DS OST

1 J2 ED120/4DS Terminal Block, 4 pin, 15A, 5.1mm 0.80 x 0.35 inch ED120/4DS OST

2 JP2, JP4 PEC02SAAN Header, 2 pin, 100mil spacing 0.100 inch x 2 PEC02SAAN Sullins

2 JP1, JP3 PEC03SAAN Header, 3 pin, 100mil spacing 0.100 inch x 3 PEC03SAAN Sullins

1 L1 10 µH Inductor, SMT, 102mΩ, 7.0A, 20% 0.255 x 0.270 inch IHLP2525CZER100M01 Vishay

IHLP2525CZEB100M01

1 Q1 Si7288-T1 FET, Dual N Chan, 40V, 20A, 19 mΩSO8-PowerPak SI7288DP-T1 Vishay/

Siliconix

1 Q2 2N7002-7-F MOSFET, N-ch, 60V, 115mA, 1.2ΩSOT23 2N7002-7-F Diodes

2 R1, R2 3.9 Resistor, Chip, 1/4W, 5% 1206 STD STD

1 R3 10 Resistor, Chip, 1/8W, 5% 805 STD STD

0 R4, R8 Open Resistor, Chip, 1/8W, 5% 805 STD STD

1 R5 2.2 Resistor, Chip, 1/10W, 5% 603 STD STD

1 R6 0.02 Resistor, Metal Film, 1/4 watt, 0.1%, Axial 1206 WSLP1206R0200FEA Vishay

2 R7, R10 0 Resistor, Chip, 1/10W, 5% 603 STD STD

1 R9 5.23K Resistor, Chip, 1/10W, 1% 603 STD STD

1 R11 100 Resistor, Chip, 1/10W, 5% 603 STD STD

1 R12 30.1k Resistor, Chip, 1/10W, 1% 603 STD STD

2 R13, R17 499k Resistor, Chip, 1/10W, 1% 603 STD STD

1 R14 10k Resistor, Chip, 1/10W, 5% 603 STD STD

2 R15, R18 100k Resistor, Chip, 1/10W, 1% 603 STD STD

0 R16 Open Resistor, Chip, 1/10W, 5% 603 STD STD

2 R20, R21 10k Resistor, Chip, 1/8W, 5% 805 STD STD

1 R19 36k Resistor, Chip, 1/8W, 5% 805 STD STD

0 TP1, Open Test Point, 0.020 Hole 0.020" STD STD

TP3–TP7

0 TP2 Open Adaptor, 3.5-mm probe clip (or 131-4244-00) 0.200 inch 131-5031-00 Tektronix

1 U1 BQ24650RVA IC, High Efficiency Synchronous Switch-Mode Fast QFN16[RVA] BQ24650RVA TI

Charge Controller for Solar Power

10 CE, GND, TP-5002 Test Point, White, Thru Hole Color Keyed 0.100 x 0.100 inch 5002 Keystone

MPPSET,

REGN,

STAT1,

STAT2, TS,

TERM_EN,

VCC, VREF

1 – PCB, 3 In x 3 In x 0.062 In HPA639 Any

4 Bumper foot (install after final wash) 0.440 x 0.2 SJ-5303 3M

4 Shunt, 100-mil, Black 0.100 929950-00 3M

10 bq24650EVM Synchronous, Switch-Mode, Battery Charge Controller for SLUU444A–August 2010–Revised October 2010

Solar Power Submit Documentation Feedback

Autres manuels pour bq24650EVM

Table des matières

Autres manuels Texas Instruments Matériel informatique

Texas Instruments

Texas Instruments TMDXEVM6472 Manuel utilisateur

Texas Instruments

Texas Instruments TMDSCNCD2800157 Manuel technique

Texas Instruments

Texas Instruments ADS41 Series Manuel utilisateur

Texas Instruments

Texas Instruments UCD3138PFCEVM-026 Manuel utilisateur

Texas Instruments

Texas Instruments TMS320DM646x Manuel utilisateur

Texas Instruments

Texas Instruments BT-MSPAUDSOURCE-RD Manuel utilisateur

Texas Instruments

Texas Instruments TPS3801 Manuel utilisateur

Texas Instruments

Texas Instruments BoosterPack BOOSTXL-ADS7142-Q1 Manuel utilisateur

Texas Instruments

Texas Instruments TMAG5170D Manuel utilisateur

Texas Instruments

Texas Instruments MSP430F51 Manuel utilisateur

Texas Instruments

Texas Instruments DS125RT410 Manuel utilisateur

Texas Instruments

Texas Instruments DEM-DAI1802 Manuel utilisateur

Texas Instruments

Texas Instruments DRV603EVM Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink CC2640 Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink CC2651R3SIPA Manuel utilisateur

Texas Instruments

Texas Instruments Hercules RM48 Manuel utilisateur

Texas Instruments

Texas Instruments TMS320C6000 DSP Manuel utilisateur

Texas Instruments

Texas Instruments Motor Control Manuel utilisateur

Texas Instruments

Texas Instruments BQ25185EVM Manuel utilisateur

Texas Instruments

Texas Instruments bq27220 Manuel du produit

Texas Instruments

Texas Instruments LMG342XEVM-04X Manuel utilisateur

Texas Instruments

Texas Instruments LDC3114-Q1 Manuel utilisateur

Texas Instruments

Texas Instruments AM335 Series Mode d’emploi

Texas Instruments

Texas Instruments Chipcon Products CC2431 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur

Texas Instruments bq24650EVM Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques
