Teltonika WORKER BADGE PLUS Manuel utilisateur
GH5200
WORKER BADGEPLUS
Quick Start Guide
Full product instructions
in different languages
can be found under this
QR code
Manufacturer:
TELTONIKA TELEMATICS, UAB
Saltoniškių st. 9B-1, LT-08105,
Vilnius, Lithuania
GETTING STARTED
Micro-SIM
card insertion/
removal must
be performed
when device
is turned o.
Otherwise
Micro-SIM
card might be
damaged or
device will not
detect it.
!
Preparing GH5200 for use:
1. Remove the cover.
2. Insert Micro-SIM card as shown with PIN request disabled. Make
sure that Micro-SIM card cut-o corner is pointing forward to slot.
3. Insert the battery as shown to device. Position the battery in place
where it does not obstruct other components.
4. Reattach the cover and tighten the screw.
CONFIGURE YOUR DEVICE
PC PREPARATION (WINDOWS)
1. Please download Teltonika COM port drivers from here:
https://wiki.teltonika-mobility.com/wikibase/images/d/d0/
TeltonikaCOMDriver.zip
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button.
5. Setup will continue installing the driver and eventually the
conrmation window will appear. Click Finish to complete the setup.
CONFIGURATOR (WINDOWS)
At rst the device will have default factory settings set unless you order
pre-congured device. These settings should be changed according to
the user’s needs. Main conguration can be performed via Teltonika
Congurator software:
https://wiki.teltonika-mobility.com/view/GH5200_Stable_rmware
Congurator operates on Microsoft Windows OS and uses prerequisite
MS .NET Framework. Make sure you have the correct version installed:
MS .NET Framework 4.6.2 or newer.
DEVICE CONNECTION AND CONFIGURATION (WINDOWS)
• Turn On device by connecting Micro-USB cable or pressing Power
On button for 2 sec. When device is turned on LED’s should start
blinking.
• For conguration can be used Bluetooth (Device Bluetooth is
enabled by default,
• default password 5555) connection:
• Connect device to Teltonika Congurator.
• Most important congurator section is GPRS – where all your server
and GPRS settings can be congured and Data Acquisition – where
data acquiring parameters can be congured. Detailed device
conguration instructions using Teltonika Congurator can be found
in the GH5200 conguration wiki page:
https://wiki.teltonika-mobility.com/view/GH5200_Conguration
• After you have nished conguring the device, press Save to device
button .
• When conguration is saved, then charge device battery to full.
• Disconnect device from USB cable and perform the testing.
GNSS
GNSS
GPS, GLONASS,
GALILEO, BEIDOU,
SBAS, QZSS, DGPS
Receiver 33 channel
Tracking
sensitivity 165 dBM
Accuracy < 3 m
GNSS receiv-
er start
times
Hot < 1s, Warm <
25s, Cold < 35s
MODULE
Name Teltonika TM2500
Technology GSM/GPRS/GNSS/
Bluetooth
CELLULAR
Cellular
technology
GSM/GPRS Multi-
Slot Class 12 (85.6
kbps (DL) / 85.6
kbps (UL))/ GPRS
Mobile Station-
Class B
CHARACTERISTICS
2G bands
Quad-band GSM
850 / 900 / 1800 /
1900 MHz
Data
support SMS (text)
POWER
Internal
batteries
Li-Ion battery
internal battery
Operating
voltage +4.5.. +5.5V
Battery
voltage 3.7 V
Nominal
Capacity 1050 mAh
Power 3.885 Wh
Charging
temperature
range
0..+45°C
Discharge
Temperature
range
-20..+58°C
Temperature
Storage
range
-20 to +60°C for
1 month; -5 to
+30°C
for 6 months
Current
consumption
(operation/
idle)
GPRS: max
average95.57 mA;
Nominal: average
45.10 mA; GNSS
sleep: average
10.12 mA; Deep
Sleep: average
3.02 mA; Online
Deep Sleep:
average 3.78 mA;
Ultra Deep Sleep:
average 1.82 mA.
Humidity
(operation,
storage,
transport)
Relative
humidity:
≤85% (no
condensation)
CONNECTIVITY
Bluetooth
Compliant with
Bluetooth 4.0
version + LE
Supported
peripherals
Temperature,
humidity,
movement,
magnet sensors,
beacon
INTERFACE
GNSS, GSM
antenna Internal High Gain
USB 2.0 Micro-USB
SIM Micro-SIM, eSIM
possibility
Memory
Memory 128 MB
internal ash
memory (220‘000
records)
Button(s) 5 Congurable
buttons
SENSORS AND COMPONENTS
Gyroscope No
Accelerometer Yes
LED 3 Bi-Color LEDs
FEATURES
Conguration and
rmware update
FOTA WEB (Cloud-based rmware over the air
solution); Teltonika congurator (USB)
Scenarios
Tracking on Move/Stop, RealTime tracking,
Alarm button, Man-Down Detection, Home
Zone, Proximity Detection, Amber Alert, Inside
Tracking, Movement/No Movement Events,
Auto Geofence, Manual Geofence, Over Speed-
ing, Action On Call, Power On/O event, Event
on a Pressed Button, On Demand tracking via
button press, Beacon On Demand tracking,
Xiaomi Mi Band 2 heart rate measurement and
heart rate range exit alerts, Race Mode, Univer-
sal Beacons/Sensors support
Protocols UDP, TCP, SMS
Data sending Main, Duplicate, Backup servers
Security
Conguration password,
SMS login and password,
Authorized GSM numbers list, TLS/DTLS 1.2
Sleep Modes GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra
Deep Sleep, Low power mode
Time
Synchronization GNSS, NTP, NITZ
GPRS commands Conguration, Debug
PHYSICAL SPECIFICATION
Dimensions 95 x 64 x 11 mm (L x W x H)
Device + case + battery weight 80 g
Ingress Protection Rating IP30
This message contains information on how to operate GH5200 safely.
By following these requirements and recommendations, you will avoid
dangerous situations. Please read these instructions carefully and
follow them strictly before operating the device! Failure to comply with
the warning may result in serious injury or possible damage to property.
Limit the use of device in
vehicles
Please follow all restric-
tions. Wireless devices
can interfere with other
electronic equipment in
vehicles.
Interference
All wireless devices are
sensitive to electromagnet-
ic interference, as a result
wireless devices aect the
performance of each other.
SAFETY INFORMATION
Road safety rst
Comply with local trac
laws, always hold your
hands on a steering wheel
when using a device. Your
safety is of utmost impor-
tance when you drive.
Operate the device in
suitable conditions
Do not use the device
where mobile connectivity
is forbidden.
Limit the use of device in
hospitals
Please follow all restric-
tions. Turn o the device
in the vicinity of medical
devices when required.
Be cautious near amma-
ble materials and liquids
Charging precautions
SELV LPS chargers, personal
computers or laptops that
device will be connect-
ed to must comply with
the requirements of IEC
60950:2005 standard.
Use only original bat-
teries
Using uncertied manu-
facturer or dierent type
batteries may cause the
device to malfunction or
even explode.
Use batteries safely
Protect batteries from
moisture. Place them in a
cool and dry place when
storing. Avoid extensive
!
!
!
!
operation at high tem-
peratures. Do not attempt
charging battery directly
from the electrical mains.
All utilised batteries shall
comply with IEC 62133.
Power supplies
Power supply circuits used
to charge the device connec-
tion must have safeguards,
which prevent power
leakage, short circuits or in-
correct electrical grounding.
Any used switches ought
to be installed in a readily
accessible location. Power
must be uninterrupted and
the distance between the
contacts must be 3 mm or
larger.
Other
In order to prevent device
from mechanical damage it
is advisable to transport it in
a shock–resistant packaging.
If device stopped working
properly regardless of the
settings only a qualied
specialist can help. It is
recommended to contact
your local seller or your
UAB Teltonika manager in
such a case.
Use the right screwdriver
In order to prevent device’s
cover from mechanical
damage it is recommended
to use screwdriver, which
is included in the package.
Do not use electrical screw-
drivers.
Remove device safely
Device must be discon-
nected from computer or
charger by unplugging the
magnetic USB cable from
the device.
Do not short circuit the
battery or charging con-
tacts. Exposing the metal
strips of the battery to a
close contact with a metallic
object, such a coin, a clip
or a set of keys can cause
accidental short-circuiting
and damage battery and
other components.
To be able to disconnect
the charging cable from the
mains as quickly as possible
in the event of a failure, con-
nect the power supply unit
where it is easily accessible.
Charging precautions
Do not attempt to charge a
wet device.
If you notice any visible
damage to your GPS tracker
or charging cable, do not
use it.
Battery should not be
disposed of with general
household waste.
Bring damaged or worn-out
batteries to your local recy-
cling center or dispose them
to battery recycle bin found
in stores.
Never place the GPS tracker
near an open re or hot
surfaces.
!
!
!
!
!
!
