Teltonika TAT140 Guide d'installation
TAT140
Asset Tracker PLUS LTE
Quick Manual v1.1
Quick Manual v1.1 // TAT140 2
Telematics
CONTENT
Know your device................................................................................................................................................................................................3
Set up your device ..............................................................................................................................................................................................4
PC Connection (Windows)..................................................................................................................................................................................5
How to install USB drivers (Windows) ..............................................................................................................................................................5
Conguration.......................................................................................................................................................................................................6
Quick SMS conguration....................................................................................................................................................................................8
MOUNTING RECOMMENDATIONS................................................................................................................................................................. 10
LED indications................................................................................................................................................................................................. 11
Basic characteristics ........................................................................................................................................................................................ 11
Safety information .......................................................................................................................................................................................... 13
Certication and Approvals ............................................................................................................................................................................ 14
Warranty ........................................................................................................................................................................................................... 15
Warranty disclaimer ....................................................................................................................................................................................... 15
Quick Manual v1.1 // TAT140 3
Telematics
KNOW YOUR DEVICE
BATTERY
ON/OFF
BUTTON
MICRO-USB
MICRO-SIM
SLOT
Quick Manual v1.1 // TAT140 4
Telematics
SET UP YOUR DEVICE
HOW TO INSERT MICRO-SIM CARD AND CONNECT THE BATTERY
4
1COVER REMOVAL 3TURN ON
2MICRO-SIM CARD INSERT ATTACHING COVER BACK
Remove the cover. Insert Micro-SIM card as
shown with PIN request
disabled or read our Wiki1
how to enter it later in
Teltonika Congurator2.
Make sure that Micro-
SIM card cut-o corner is
pointing forward to slot.
1 wiki.teltonika.lt/index.
php?title=TAT140_Security_info
2 wiki.teltonika.lt/view/Teltonika_
Congurator
Flip the switch to ON. After conguration, see PC
Connection (WINDOWS)1.
When it is done, reattach the
cover and push it in place.
1 Page 5, “PC Connection
(Windows)”
Quick Manual v1.1 // TAT140 5
Telematics
PC CONNECTION (WINDOWS)
HOW TO INSTALL USB DRIVERS (WINDOWS)
1. Please download COM port drivers from here1.
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button.
5. Setup will continue installing the driver and eventually the conrmation window will appear. Click Finish to complete the
setup.
1 wiki.teltonika-mobility.com/images/d/d0/TeltonikaCOMDriver.zip
1. Power-up TAT140 device. LED should start blinking, see ‘’LED indications’’1.
2. Connect your device to computer using Micro-USB cable:
• You will need to install USB drivers, see ‘’How to install USB Drivers (WINDOWS)“2
3. You are now ready to use the device on your computer.
1 Page 11 “LED indications”
2 Page 5, “PC Connection (Windows)”
Quick Manual v1.1 // TAT140 6
Telematics
MS .Net requirements
Operating system MS .NET Framework version Version Links
Windows Vista
Windows 7
Windows 8.1
Windows 10
MS .NET Framework 4.6.2 32 and 64 bit www.microsoft.com1
1 dotnet.microsoft.com/en-us/download/dotnet-framework
At rst TAT140 device will have default factory settings set. These settings should be changed according to the users needs. Main
conguration can be performed via Teltonika Congurator1software. Get the latest Congurator version from here2. Congurator
operates on Microsoft Windows OS and uses prerequisite MS .NET Framework. Make sure you have the correct version installed.
1 wiki.teltonika-gps.com/view/Teltonika_Congurator
2 wiki.teltonika-gps.com/view/Teltonika_Congurator_versions
CONFIGURATION
Quick Manual v1.1 // TAT140 7
Telematics
Downloaded Congurator will be in compressed archive.
Extract it and launch Congurator.exe. After launch software
language can be changed by clicking 🌐 in the right bottom
corner.
Conguration process begins by pressing on connected device.
TAT140
Various Status window1 tabs display information about GNSS2,
GSM3, I/O4, Maintenance5and etc. TAT140 has one user
editable prole, which can be loaded and saved to the device.
After any modication of conguration the changes need to
be saved to device using Save to device button. Main buttons
oer following functionality:
Load from device – loads conguration from device.
Save to device – saves conguration to device.
Load from le – loads conguration from le.
Save to le – saves conguration to le.
Update rmware – updates rmware on device.
Read records – reads records from the device.
Reboot device – restarts device.
Reset conguration – sets device conguration to
default.
Most important congurator section is GPRS – where all
your server and GPRS settings6 can be congured and Data
Acquisition7 – where data acquiring parameters can be
congured. More details about TAT140 conguration using
Congurator can be found in our Wiki8.
After connection to Congurator Status window will be
displayed.
TAT140
1 wiki.teltonika-gps.com/view/TAT140_Status_info
2 wiki.teltonika-gps.com/view/TAT140_Status_info#GNSS_Info
3 wiki.teltonika-gps.com/view/TAT140_Status_info#GSM_Info
4 wiki.teltonika-gps.com/view/TAT140_Status_info#I.2FO_Info
5 wiki.teltonika-gps.com/view/TAT140_Status_info#Maintenance
6 wiki.teltonika-gps.com/index.php?title=TAT140_GPRS_settings
7 wiki.teltonika-gps.com/index.php?title=TAT140_Data_acquisition_
settings
8 wiki.teltonika-gps.com/index.php?title=TAT140_Conguration
Quick Manual v1.1 // TAT140 8
Telematics
QUICK SMS CONFIGURATION
Default conguration has optimal parameters present to ensure best performance of track quality and data usage.
Quickly set up your device by sending this SMS command to it:
Note: Before SMS text, two space symbols should be inserted.
GPRS SETTINGS:
2001 – APN
2002 – APN username (if there are no APN username,
empty eld should be left)
2003 – APN password (if there are no APN password,
empty eld should be left)
SERVER SETTINGS:
2004 – Domain
2005 – Port
2006 – Data sending protocol (0 – TCP, 1 – UDP)
« setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0»
1 2 3 4 5 6
1
2
3
4
5
6
Quick Manual v1.1 // TAT140 9
Telematics
DEFAULT CONFIGURATION SETTINGS
IMPORTANT CONFIGURATION NOTES
MOVEMENT AND IGNITION
DETECTION:
DEVICE MAKES A RECORD ON MOVING
IF ONE OF THESE EVENTS HAPPEN:
Time intervals and default I/O elements can be changed by using Teltonika Congurator1.
1 wiki.teltonika-mobility.com/view/Teltonika_Congurator
We strongly recommend testing the network connection from device to the server before
adjusting TAT140 conguration to your needs. Use the following steps to perform this test:
• Congure these parameters: APN, server Domain and server Port;
• Save conguration to the device by clicking on a Save to device button;
• Initiate connection by pressing the Test Connection button.
At this point, TAT140 will create one high-priority record and initiate connection to the server
immediately.
If connection was not initiated, it can mean any of the following:
• Improperly inserted SIM Card
• Incorrect values are set to these elds: APN, Domain or Port;
• GPRS functionality disabled by GSM provider;
• No GSM coverage;
• Server cannot be reached.
Try solving this problem before proceeding with further device conguration.
VEHICLE MOVEMENT
will be detected by
accelerometer
DEVICE MAKES A RECORD ON
STOP IF:
28800 s 28800 s
28800
Seconds passes
28800
Seconds passes
Quick Manual v1.1 // TAT140 10
Telematics
Periodic: This mode is used to get positioning data at xed
intervals. Conguration range is from 360 to 259200 (in
seconds).
Scheduler: This mode is used to get positioning data at xed
schedule. Device can send positioning data up to 6 times on
set days.
We recommend mounting the TAT140 in such a way that the GNSS antenna is pointed at the sky and the device itself is not covered
by various obstructions that would interfere with the reception of the GNSS x.
More details about device conguration using Teltonika Congurator can be found in the Teltonika wiki knowledge base
wiki.teltonika-mobility.com
MAIN RULES OF SETTING SCHEDULE:
• Intervals between dierent times must be at least 6
minutes;
• Days of the week must be selected and highlighted for
the device to send records according to the set schedule.
MOUNTING RECOMMENDATIONS
