Targus Wireless RF Mouse Manuel utilisateur
Targus Wireless
RF Mouse
USER’S GUIDE
Making Your Mobile Life Easier.
Making Your Mobile Life Easier.
Visit our Web site at: www.targus.com
Features and specifications are subject to change without notice. ©2002 Targus Corp.
400-0078-001A
2
Targus Wireless RF Mouse
Introduction
Congratulations on your purchase of a Targus
Wireless RF Mouse. This ergonomically designed
mouse uses a radio frequency (RF) link that enables
you to use the mouse anywhere within 3 feet of its
receiver. No line-of-sight between the mouse and its
receiver is required.
This user’s guide describes how to connect the
mouse receiver to your computer, install default
software drivers and set up the radio link for the
following RF mouse models:
•PAUM005 – Mini 3-button RF Optical Mouse with
scrolling wheel
•PAUM006 – Mini 3-button RF Mouse with scrolling
wheel
In addition to this user’s guide, depending on the RF
mouse model that you purchased, this package
contains:
PAU M005 PAUM006
•Mouse
•Receiver
•2 AA batteries
•Three inch USB
extension cable
•Optional charger
base available
(part number
252-0013-001A)
•Mouse
•Receiver
•2 AAA batteries
Targus Wireless RF Mouse 3
System Requirements
To use the RF mouse, your computer must meet the
following hardware requirements and run one of the
operating systems listed below.
NOTE: The third button and the scrolling wheel only work with
the operating systems listed above. If you use the RF mouse
with a different operating system, it will lose its enhanced
features and function as a standard, two-button mouse.
Connecting the Mouse
Receiver and Installing the
Device Drivers
To connect the mouse receiver:
1Turn off your computer.
2Plug the standard USB end of the cable into an
available USB port on your computer.
You are now ready to install the device drivers for
your operating system.
Hardware Operating System
•PC with a Pentium®processor or
equivalent and a hard disk drive
•Windows®98/Me/
2000/XP
•USB version 1.1 interface
Targus Wireless RF Mouse 4
Windows®98/Me Operating Systems
1Turn on your computer.
The Add New Hardware Wizard appears.
If it does not, the operating system has installed the
default driver automatically. No other steps are
necessary.
2Click Next.
The locate driver screen appears.
3Select “Search for the best driver for your
device. (Recommended),” and then click Next.
The wizard searches for the appropriate device
driver.
4Click Next.
5Click Finish to complete the driver installation.
You are now ready to install the batteries in the
mouse, set the radio frequency channel, and
establish a communications link between the mouse
and its receiver. See “Establishing a
Communications Link (All RF Mouse Models)” on
page 6.
Targus Wireless RF Mouse 5
Windows®2000/XP Operating Systems
1Turn on your computer.
The Found New Hardware Wizard appears.
If it does not, the operating system has installed the
default driver automatically. No other steps are
necessary.
2Click Next.
The wizard searches for the appropriate device
driver.
3Click Next.
4Click Finish to complete the driver installation
You are now ready to install the batteries in the
mouse, set the radio frequency channel, and
establish a communications link between the mouse
and its receiver. See “Establishing a
Communications Link (All RF Mouse Models)” on
page 6.
Using the RF Mouse
Installing the Batteries
1Remove the battery cover from the bottom of the
mouse by pressing the battery cover tab and
siding it off.
NOTE: If you have a model PAUM005 RF mouse, the battery
cover is also the top cover of the mouse.
Targus Wireless RF Mouse 6
2Insert the supplied batteries, making sure that
the positive (+) and negative (-) ends of each
battery match the polarity indicators inside the
battery housing.
3Slide the battery cover back into position until it
“clicks” firmly into place.
If you have a model PAUM005 RF mouse, the
optical sensor, located on the bottom of the mouse,
glows red.
WARNINGS: When replacing the batteries, you may use
alkaline or other heavy-duty NiMH batteries. Never use an
alkaline with a NiMH battery in a device.
Avoid mixing new and used batteries in a device.
Establishing a Communications Link (All
RF Mouse Models)
The RF mouse has 256 identification codes that
allow the mouse and its receiver to operate without
interference from other radio frequency devices.
To set the identification code and establish a radio
link between the mouse and the receiver:
1Press and release the link button, located on the
bottom of the RF mouse.
2Press and release the link button on the
receiver.
Targus Wireless RF Mouse 7
The receiver’s status light flashes while it scans the
identification codes for the mouse. Once a code is
selected, the status light stops flashing.
3Press and release the screen scroller (middle)
button.
You are now ready to use the RF mouse.
NOTE: You must reestablish the communications link every
time you change the batteries.
Operating Hints
For optimal performance and RF reception:
•Place the receiver at least 8 inches (20 cm) away
from all electrical devices, such as your monitor,
speakers or external storage devices.
•Avoid using the RF mouse on a metal surface.
Metals, such as iron, aluminum or copper, shield
the radio frequency transmission and may slow
down the mouse’s response time or cause the
mouse to fail temporarily.
•The RF mouse will enter a suspend mode at the
same time your computer does. To wake the
mouse, press and release the screen scroller
(middle) button.
•If your computer has a metal case that contains
aluminum or magnesium, use the RF mouse to the
side. The display panel may interfere with the radio
frequency signal if you use the mouse directly in
front of the computer.
Targus Wireless RF Mouse 8
If you are using an optical RF mouse (model
PAUM005):
•Never use the RF mouse on a glass or mirrored
surface as these surfaces will cause the mouse to
fail temporarily.
•To maximize battery life, use the RF mouse on a
white, or light colored surface. Dark surfaces cause
the mouse’s light emitter diode (LED) light to glow
brighter, which causes the battery to discharge
more rapidly.
Comfortable Usage
Research suggests that physical discomfort and
injury to nerves, tendons, and muscles may be
related to repetitive motion, an improperly set up
work area, incorrect body posture, and poor work
habits.
To reduce the risk of injury, follow these precautions:
•Stand, stretch, and move around several times
every hour.
•Switch hands while performing tasks. Use shortcut
keys to avoid repetitive or awkward mouse
movements.
•Relax your shoulders and keep your elbows at your
sides. Adjust the keyboard’s position so that you
don’t have to stretch to reach it.
Targus Wireless RF Mouse 9
•Adjust your position so that you don’t have to bend
your wrists to type; avoid placing your wrists on a
sharp edge.
If you feel discomfort or numbness in your hands,
wrists, arms, shoulders, neck, or back while typing,
consult a qualified medical professional.
Specifications
NOTE: Specifications are for all models unless indicated
otherwise.
Models
PAUM005
PAUM006
Button Count
3 with scrolling wheel
ID Selections
256
Electromagnetic Characteristics (EMC)
CE - Type acceptance: ETS 300 220 short range
devices
VCCI approval (Japan) - PAUM006 only
Distance Between Mouse and Receiver
PAUM005Up to 3 feet (1 m)
PAUM006Up to 5 feet (1.6 m)
Mouse Carrier Frequency
27 MHz
Targus Wireless RF Mouse 10
Dimensions
Mouse:
PAUM005 3.86 x 2.32 x 1.5 inches
(98 x 59 x 38 mm)
PAUM006 3.82 x 2.24 x 1.25 inches
(97 x 57 x 32 mm)
Receiver:
PAUM005 1.96 x 0.86 x 0.59 inches
(50 x 22 x 15 mm)
PAUM006 2.48 x 0.86 x 0.66 inches
(63 x 22 x 17 mm)
Weight
Mouse (without batteries):
PAUM005 3.74 ounces (106 grams)
PAUM006 3.25 +/-.35 ounces (92 +/- 10 grams)
Receiver:
PAUM005 .56 ounces (16 grams)
PAUM006 .98 ounces (28 grams)
Receiver Interface
USB version 1.1
Operating Voltage
Mouse (powered by batteries):
PAUM005 3.6V DC
PAUM006 3V DC
Receiver: 4.5 to 5.5V DC
(powered by the USB port)
