Swann Advanced Quad Processor Manuel utilisateur

Retail

Security Kit

Advanced-Series

MMONSK5221110E

222

Your security kit contains...

• 1xMonochromaticCCTVSecurityMonitor

• 4xMiniatureSecurityCameraswithIRLEDs

• 4xCameraConnectionCables

• 1x9VPowerAdapter

• MountingHardware,SecurityStickersandOperatingInstructions

If your kit is missing any of these components, contact Swann.

Our contact details are printed on the back cover of this booklet.

A Brief Introduction to the Retail Security Kit

Wehaveatendency,inthismodernworld,toovercomplicatethings.Carswith

computer-controlledbeverageholders,cellphoneswithscreensbiggerthanyour

pockets,refrigeratorswithInternetconnections...whycan’tthingsjustbesimple?



Well,we’vebeenworkingon that. PresentingtheRetail Security Kit - asimple

solutiontoacomplexproblem.Buildingonalegacyoftried-and-truetechnology,

we’vedevelopedasecuritymonitoringsystemthat’sstreamlinedandrobust,pow-

erfulyeteasytoinstallandoperate.Ifyouwanttorecordaswellasmonitor,well,

that’seasy,too-justaddarecordingdevice!

Connection Guide

Using a standard A/V

cable (not included), you

can connect the AV Out

to an additional monitor

orarecordingdevice.

RearofMonitor

Use only the supplied

poweradapter.Avoidusing

multiple double-adapters

orpower-boards.

Connectthecamera’sconnectionstotheend

ofthecameraconnectioncablebycolor.We

suggest connecting and testing all cameras

andpoweringonthemonitorbeforephysically

installingcamerasorrunningcables.

Repeat for all four cameras.

Theorderthatthecameras

arepluggedindetermines

the order that they’ll be

shown when you change

channel or engage Auto-

Switchingmode.

Thechannelsconnections

are arranged from left

to right, when viewed

from the rear. Thus, the

leftmost connection

is channel 1, and the

rightmostchannel4.

Connect one camera to

eachofthecamerainputs.

444

Layout

PowerInput

(9V) Camera

Connections

A/V

Outputs

V-Hold

Microphone

Lens

IRLEDs

Power

Switch

Contrast

Brightness

Volume

Channel

Switch

Auto-SwitchingIndicatorLED

Microphone: Thecamera’sear. Actually,

themicrophoneisinsidethecamerahous-

ing - the little hole is to let some sound

in.Thecloserthisistowhatyouwantto

hear-andthemoredirectlyitisaimedat

it-theclearertheaudiowillbe.

Lens: Thecamera’seye.Tofocusthecam-

era, twist the lens clockwise or counter-

clockwise.

IR LEDs: Theseemitlightwhichisinvisible

tothehumaneye,butwhichthecamera

cansee.Thesearewhatprovidesthelim-

itednightvision.

Focusing:Simplytwistthelensclockwise

tofocusonsomethingnearertothecam-

era, and counter-clockwise to focus on

somethingfartheraway.Trialanderroris

theonlywaytoreallygetagoodfocus,so

it’sworthplayingwithuntilyoundwhat

worksbestforyoursituation.

For details about the monitor’s

functionality, see page 5 (opposite).

Operating the Monitor

Power Switch: ForturningthemonitorONandOFF.Thisisthemasterswitch-

whilstthemonitorisoff,thecameraswillalsobeoff,andinformationwillnotbe

sentthroughtheA/VOUTports.

Contrast: Foralteringthedynamicrange(thedifferencebetweentheblackest-

blackandthewhitest-white)oftheimageonthescreen.Toolow,andtheimage

will“greyout”.Toohigh,andtheimagewilllooklikeanabstractblackandwhite

artwork.Somewherearoundthemiddleisusuallythebestbet.

Brightness:Howbrighteverythingonthescreenappearstobe.Ifthisistoolow,

largesectionsofthescreenmay“blackout”.Toohigh,andareaswill“whiteout”.

Notethatthissettingwon’taffecthowwellthecamerassee,justhowthescreen

displaystheimages.

Volume: Altershowloudtheaudiowillseemtobe.Ifyourcamerasareinclose

proximitytothemonitor,youmayhearahighpitchedsqueal-thisis“feedback”.

Toavoidit,simplyreducethevolume.

Channel Switch:Forswitching“up”onechannel.Oncethemonitorhascycled

throughallfourconnectedcameras,itwillselectAuto-Switchingmode.

Green LED (Auto-Switching Indicator):WhenthisLEDison,thisindicatesthat

themonitorisinautomaticswitching(Auto-Switch)mode.

Power Input: For connecting the supplied (and only the supplied) 9V power

adapter.

Camera Connections: Specialized camera connection plugs. Each plug sends

powertothecamera,atthesametimeasitreceivesaudioandvideofromthe

camera.Becarefulwhen insertingtheseplugs-they’llonlygoinwhenthey’re

properlyoriented.Forcingthepluginwhenitisn’tcorrectlyorientedmaybend

pinsand/ordamagetheconnection.

A/V Outputs:Forconnectinganadditionalmonitor(mostlikelyatelevisionor

otherscreenwithacompositevideoinput)orarecordingdevice,suchasaVCR.

Theyellowplugcarriesvideo,andthewhiteplugcarriesaudio.

V-Hold:Ifyoundtheimageonthescreenisrollingorﬂickering,thenthisindicates

youprobablyneedtoadjustthevertical hold(v-hold).Alittleadjustmenttothis

knobcanmakeabigdifference!Whenadjustingthissetting,justdoitslowlyand

carefully-therightsettingissomewhereaboutthemiddle.

666

Tips and Tricks

• Therearetwoscrewholesonthebaseof

eachcamera.

• Usinganappropriatetypeofscreworbolt,

use these holes to afx the camera to a

surface.

• Thenpivotthecameratofacethedirection

ofyourchoice.

NOTE: Itisimportanttohavethecamerauprightrelativetowhatyouwantthe

camerato view-the camerasimagecannotbeipped.Ifthecameraisupside

down,soisthepicture!Forthis reason,mounting thecameraon theceilingis

highlyimpractical.Wesuggestmountingthecamerahighonawall,sothatitcan

bealignedtobeuprightrelativetoyoursubject.

The lens on the front of your camera has adjustable focus.

Thus,itisimportantwheninstallingyourcamerastofocusyour

cameras.

Tocorrectlyfocusthecamera,itwillneedtobeconnectedto

themonitor.Connectitnearbywhilstinstallingthecamera,or,

ifthemonitorandcablesarealreadyinplace,getanassistant

tohelpyou.

Turn clockwise to focus on something farther away

Turn counter-clockwise to focus on something nearer

NOTE:Becautiouswhenfocusingonsomethingclosertothecamera

that you haven’t gone past the optimum focus point. If you keep

turningthelenscounter-clockwise,itwilleventuallyunscrewentirely

andcomeout!Thisishighlyundesirable,asitwilldirectlyexposethe

imaging sensor. Moisture, dust and other ne particles and liquids

inside the camera housing will dramatically and negatively affect

performance.

Troubleshooting & Technical Specifications

Problem: There’snoimageonthemonitor.

Solution: Ensure the power is connected, using the supplied power adaptor.

Checkthevideocableiscorrectlyattached,atboththemonitorandthecamera.

Checkthatthelenscaphasbeenremovedfromthecamera.Double-checkthat

themonitorissettotherightchannel.Trypluggingthecameraintoadifferent

channel.Checkthebrightness/contrastsettings.

Problem:Theimageisblurry.

Solution:Checkthatthecameraisinfocusbyrotatingthelensbothways,to

seeiftheimagebecomesclearer.Checkthatthelensisclean.Ifnot,cleanwith

thecornerofascratch-freecloth,suchasthoserecommendedforcleaningLCD

screens.

Problem:Theimageistoobrightortoodark.

Solution:Adjustthebrightness/contrastsetting.Ensurethecamerashaveenough

light(iftoodark)orarenotlookingdirectlyintoastronglightsource(iftoolight).

The cameras have built in infrared LEDs, the range in low-light conditions or

darknessislimitedtoapproximately3m/9ft.Objectsoutsidethisrangewillnotbe

visibleatall,andifthere’snothingwithinthisrange,thescreenwillsimplyappear

black.

Problem:Thecameracannotseeoutawindow-allIseeiswhite!

Solution: There are six infrared LEDs mounted around the camera lens. If the

cameraisplacedtoonearawindow,theinfraredbeamswillbounceback,washing

out the image. We do not recommend using the supplied cameras to monitor

outdoorareas.

Problem:Theimageisnotswitching.

Solution:Pressthechannelswitchbutton

Problem:AllIhearisahighpitchedsqueal!

Solution: The camera is mounted too close to the monitor, and the built-in

microphoneispickingupsoundfromthemonitor,causingfeedback.Tryturning

downthevolumeonthemonitor.Ifthisdoesnotsatisfactorilyxtheproblem,

disconnectthewhiteRCAplugfromtheoffendingchannel.

Problem: TheImageisUpsideDown

Solution: Thiswillhappenwhenthecamerasaremountedupsidedowntothe

ceiling.Unfortunately, thereisnowaytoipthevideosignalcomingfromthe

camera.Ratherthanmountingontheceiling,wesuggestmountingthecamera

onthewallashighaspossible,sothecameracanbeuprightrelativetoimage

beingtaken.

888
