Swann PRO-530 Manuel utilisateur

SWDVK-825508

EASILY CONNECT TO TV OR LCD MONITOR

POWERFUL 65ft / 20m NIGHT VISION

VIEW LIVE ON SMARTPHONE INCLUDING IPHONE,

ANDROID, BLACKBERRY, WINDOWS MOBILE 6 & MORE*

600TVL

CLEAR RESOLUTION ¹ȫ³” SUPER CMOS

600 TV LINES SWANN TRU COLOR VIDEO SENSOR

UPnP

TRANSFER INCIDENT VIDEO

TO FLASH DRIVE

WEATHERPROOF IP67 CAMERA WITH

CABLE THREADED THROUGH STAND

EASY CONNECTION TO THE INTERNET**

H.264

DETER PREVENT CRIME, VANDALISM & MORE

SIMULTANEOUSLY VIEW & RECORD

60 DAYS+CONTINUOUS RECORDING

TO 500GB HDD

FAST, EFFICIENT RECORDING & PLAYBACK

500GB

CHANNELS

SEE MORE WITH 58 DEGREE ANGLE LENS

For more information on this product visit www.swann.com

Monitoring Kit

Smartphone Security

Monitoring System

DVR8-2550™Networking Digital Video Recorder

& 8 x PRO-530™ Day/Night Cameras

SwannView App

Free Download

Android Market

www.swann.com/swannview

Available on the

App Store *

Advanced-Series

Internet & Smartphone Viewing

Value for money security system for home or

business

• View & record simultaneously from 8 high resolution cameras at resolutions

up to D1 (7 fps per channel) & frame rates up to real time (CIF)

• Includes 8 day/night, indoor/outdoor high resolution 600TVL SwannTruColor

cameras with cable threaded through the stand for easy mounting & added

protection

• Set and forget by recording from 8 cameras for 60 days+ onto a massive

500GB hard drive, even longer with motion detection

• View live or playback on your regular TV or use VGA connection to view on

an LCD monitor

• Setting up remote viewing has never been easier with UPnP network

conﬁguration**

• Surveillance in the palm of your hand with live viewing on 3G-enabled

Smartphones including iPhone, iPad, Android, BlackBerry, Windows Mobile 6,

Symbian OS and more*, with remote notiﬁcation via email

2XU3URPLVH

Swann stands by its Lifetime Support promise to make

advanced security easy to use, install and maintain.

Everything is in the pack but if you need it, Swann’s help

desk is available with extended hours for the life of the

product. Swann products are also backed by a 12 month

manufacturer’s warranty.

Smartphone Security

Monitoring System

DVR8-2550™ Networking DVR &

8 x PRO-530™ Day/Night Cameras

For more information on this product visit

www.swann.com

What’s in the box

• DVR8-2550™

• 500GB Hard Drive (installed)

• Remote Control (with Batteries)

• PRO-530™ Cameras x 8

• BNC Cables 50ft / 15m x 8

• Mouse

• Ethernet Cable

• BNC to RCA Video Cable

• Software CD

• Power Adapter

• Operating Instructions

• Theft Deterrent Stickers x 4

Speciﬁcations

DVR8-2550

Video

Video Signal Type NTSC or PAL

Video Inputs 8 Composite BNC Inputs

Video Outputs 2 Composite BNC Outputs, VGA Out

Display Resolution NTSC: 704x480 / PAL: 704x576

Display Frame Rate Real Time NTSC 30 fps/channel, PAL: 25 fps/channel

Audio

Audio Input 4 RCA Inputs

Audio Output 2 RCA Outputs

Recording

Compression Format H.264

Recording Resolution NTSC: D1 (704x480), HD1 (704x240), CIF (352x240)

PAL: D1 (704x576), HD1 (704x288), CIF (352x288)

Recording Frame Rate NTSC: D1 (60 fps), HD1 (120 fps), CIF (240 fps)

PAL: D1 (50 fps), HD1 (100 fps), CIF (200 fps)

Recording Modes Manual / Motion / Schedule

Multiplex Operation Multiplex

HDD Interface / Type 500GB SATA HDD (installed)

Hard Drive Support Up to 2TB

Network

LAN Connection Yes

Network Interface RJ45 Ethernet

Network Protocol TCP/IP, DDNS, UPnP

Dynamic DNS Yes (dyndns, 3322)

Remote Operation Via http using IE (ActiveX) or NetViewer Software (included)

General

Operating Power DC 12V

Dimensions 12.4” x 8.9” x 2.4” / 315mm x 225mm x 60mm

Weight 4.4lbs / 2kg

Backup Method USB to Flash Drive / Network

Mouse Yes (uses 2 x AAA batteries, included)

Remote Control Yes (USB x 1)

PRO-550

Video

Image Sensor ¹⁄³” SwannTruColor (STC)

Video Quality 600 TV Lines

Number of Effective Pixels 728 x 488

Minimum Illumination 0 Lux (IR on) / 0.1 Lux (IR off)

Day / Night Mode Color during day / switches to B&W at night

IR Cut Filter Auto

Backlight Compensation Yes

Lens 4.8mm

Viewing Angle 58 degrees

Night Vision

Night Vision Distance Up to 65ft / 20m

Number of Infra-Red LEDs 24

Infra-Red LED Life 10,000 hours

General

Indoor / Outdoor Indoor / Outdoor

Operating Power DC 12V

Operating Temperature -4°F ~ 113°F / -20°C ~ 45°C

Body Construction Aluminum

Dimensions – Camera & Stand 6.5” x 4.5” x 3.15” /

165mm x 115mm x 67mm

Weight – Camera & Stand 1.02lbs / 465g

Cable Length 60ft / 18m

Codes

Swann Code SWDVK-825508

UPC 815849011397

Theft

Deterrent

Stickers

Installation is easy

Do-it-Yourself

Installing this Swann product is simple. For

instructions, tips and videos see the operating

instructions in this pack or visit

www.swann.com

Professional Installation

Need extra help?

We have an installer in your region!

For more visit

www.swann.com

Stream live video footage

from anywhere in the world

One of the great features of this product is its remote viewing

capabilities. You can view your home or business from anywhere

in the world via broadband Internet connection on PC or on your

Smartphone* via the SwannView app.

BlackBerry

Nokia

HTC

Samsung

iPhone iPad

iPhone®Android®BlackBerry®

SwannView app

DOWNLOAD FROM

Symbian OS®

Windows Mobile®

Also compatible with

USE WITH

oid

www.swann.com/swannview

or use the disk in the pack

Available on the

App Store

Please note that the information contained within this document is subject to change without notiﬁcation.

All trademarks remain properties of their respective owners.

+ 60 days recording achieved using lower settings, default settings give 14 days recording

** Applies to modems that have UPnP function *Monitor and mobile phones not included
