Swann 4 Channel DVR4-2000 Manuel utilisateur

™

Advanced security made easy

plug&playsecurity

www.swannsecurity.com

Product Code SW343-2K4

EAN 9325481012061

Security Recording

System with Internet &

iPhone* Viewing

4 Channel DVR4-2000™ &

4 x PNP-150™ Cameras

easy web connection

for remote viewing

30 days

continuous recording+

500

view & record

Channels

latest recording technology

fast playback, use less hard drive

easily backup video

incidents to flash drive

30ft 9m

good night vision

BNC cable x 4

50ft 15m

weather resistant

anti-corrosive casing

easily connects

to your TV

view live video on your

3G iPhone*

iPhone

View on your TV with easy set-up

No need for a professional installer with easy set-up & viewing on your

existing TV’s AV channel

Have peace of mind even when you’re away

Equipped with remote viewing software to view over the internet on

PC or download a free ‘app’ for live streaming on your 3G iPhone*

Set & forget by recording continuously from from 4 cameras for

over 30 days+

H.264 compression means less storage needed & higher image quality

Home or business security at an affordable price, with no ongoing fees

View & record 4 channels simultaneously to really know what’s

happening

Protect the people you care about & reduce the cost of crime

A state of the art solution for any home or business wanting complete

protection

+ Based on the lowest recording settings

*3G enabled iPhones, Microsoft Windows Mobile 6.0 or higher or Symbian S60 Third Edition mobile

phones or later. See www.swannsecurity.com for more details

View anywhere

on your iPhone*

Monitor & iPhone not included

View & Record

™

Advanced security made easy

plug&playsecurity

www.swannsecurity.com

™

Please note that the information contained within this document is subject to change without notiﬁcation.

All trademarks remain properties of their respective owners.

+ based on the lowest recording settings

Security Recording System with

Internet & iPhone* Viewing

4 Channel DVR4-2000™ &

4 x PNP-150™ Cameras

contents

all installation accessories included

• DVR4-2000™

• 500GB Hard Drive (installed)

• Remote Control

• PNP-150™ Camera x 4

• BNC cable 50ft / 15m x 4

• BNC to RCA Video Cable

• Software CD

• Power Adapters

• Mouse

• Mounting Screws & Plugs

• Operating Instructions

• Theft Deterrent Stickers x 4

View anywhere

on your iPhone*

speciﬁcations

DVR specifications

Video

Video Format NTSC or PAL

Video Inputs 4 Composite BNC Inputs

Video Outputs 2 Composite BNC Outputs

Display Resolution NTSC: 704 x 480 / PAL: 704 x 576

Display Frame Rate NTSC: 120fps / PAL: 100fps

Audio

Audio Input 1 RCA Input

Audio Output 1 RCA Output

Recording

Compression Format H.264

Recording Resolution NTSC: D1 (704*480), HD1

(704*240), CIF (352*240)

PAL: D1 (704*576), HD1

(704*288), CIF (352*288)

Recording Frame Rate NTSC: 30 fps D1, 60 fps HD1,

120 fps CIF / PAL: 25 fps D1,

50 fps HD1, 100 fps CIF

Recording Modes Manual / Motion / Schedule / Sensor

Multiplex Operation Triplex

HDD Interface / Memory Type SATA

Hard Drive Support Up to 1TB

Network

LAN Connection Yes

Network Interface RJ45

Network Protocol TCP/IP, DDNS

Remote Operation Yes

General

Operating Power DC 12V

Dimensions 12.4” x 8.9” x 2.4” /

315mm x 225mm x 60mm

Weight 4.4lbs / 2kg

Backup Method USB to Flash Drive

Mouse Support Yes

Remote Control Yes

Remote Control Battery Type 2 x AAA

Camera

Video

Image Sensor 1/3” CMOS

Video Quality 400 TV Lines

Number of Effective Pixels NTSC: 510 x 492 / PAL: 628 x 582

Minimum Illumination 0 Lux (IR on)

Day / Night Mode Color during day /

switches to B&W at night

White Balance Automatic

Signal / Noise Ratio > 50dB

Electronic Shutter 1/60 - 1/15,000 NTSC

1/50 - 1/15,000 PAL

Gain Control Automatic

Backlight Compensation Yes

Wide Dynamic Range No

Lens 6mm

Viewing Angle 53 degrees

Night Vision

Night Vision Distance Up to 30ft / 9m

IR Cut Filter No

Number of Infra-Red LEDs 30

Infra-Red Wavelength 850nm

Infra-Red LED Life 10,000 hours

General

Indoor / Outdoor Indoor / Outdoor

Operating Power DC 12V

Operating Temperature 14°F ~ 122° / F -10°C ~ 50°C

Body Construction ABS Plastic

Dimensions - Camera 5.5” x 2.8” x 2.8”

140mm x 70mm x 70mm

Dimensions - Stand 4.5” x 2.3” x 2.3”

120mm x 60mm x 60mm

Weight – Camera 0.4lbs / 180g

Weight – Camera & Stand 0.5lbs / 235g

Cable Length 50ft / 15m

Packaging

Pack Weight TBA

Pack Dimensions (HxWxD) TBA

Master Pack Quantity TBA

Master Pack Dimensions (HxWxD)

TBA
