Instruction and Operation Manual
S606
Stationary Breathing Air Quality Analyzer
Dear Customer,
Thank you for choosing our product.
Please read the manual in full and carefully observe operating
instructions stated before you start up the device. The manufacturer
cannot be held liable for any damage that occurs as a result of non-
observance or non-compliance with this manual.
Should the device be tampered with in any manner other than a
procedure which is described and specified in the manual, the warranty
is void and the manufacturer is e empt from liability.
The device is destined e clusively for the described application.
SUTO offers no guarantee for the suitability for any other purpose.
SUTO is also not liable for consequential damage resulting from the
delivery, capability or use of this device.
2 S606
Table of Contents
1 Safety Instructions.............................................................................5
2 Registered Trademarks........................................................................8
3 Application........................................................................................8
4 Features...........................................................................................8
5 Technical Data...................................................................................9
5.1 General Data...............................................................................9
5.2 Operating Conditions.....................................................................9
6 Dimensions......................................................................................11
7 Installation on Site............................................................................12
7.1 Select Installation Location...........................................................12
7.2 Mount on the Wall.......................................................................13
7.3 Electrical Connections..................................................................14
7.3.1 Power Supply.......................................................................15
7.3.2 RS-485 Networking (Modbus/RTU)..........................................15
7.3.3 TCP/IP Networking (Modbus/TCP)............................................15
7.3.4 Alarm Outputs......................................................................16
7.4 Compressed Air Connection..........................................................17
7.5 Water Filling Connector................................................................18
7.6 Calibration Connector..................................................................19
8 Setup..............................................................................................20
9 Operation and Configuration...............................................................20
9.1 Main Screen...............................................................................22
9.1.1 Quick Buttons and Icons........................................................22
9.1.2 Icons in the Status Bar..........................................................22
9.2 Value Screen..............................................................................23
9.3 Graphic Screen...........................................................................23
9.4 Menu........................................................................................24
9.4.1 Sensor Settings ...................................................................24
9.4.2 System Setting.....................................................................25
9.4.3 Service Company Information.................................................26
9.4.4 Calibration of Gas Sensors.....................................................27
9.4.5 Files....................................................................................28
9.4.6 Logger Setting.....................................................................29
9.4.7 Alarm Setting.......................................................................30
9.4.8 Communication....................................................................31
10 Software Installation.......................................................................32
11 Firmware Updates...........................................................................33
12 Calibration.....................................................................................35
12.1 Calibration for DP Sensor and Oil Sensor......................................35
12.2 Calibration for O2,CO, CO2 Sensor..............................................35
12.2.1 Calibration Gases................................................................36
12.2.2 Calibration Procedure...........................................................37
S606 3
13 Optional Accessories........................................................................43
14 Maintenance...................................................................................43
15 Disposal or Waste...........................................................................43
16 Warranty.......................................................................................43
17 Appendi - Modbus Holding Register Table..........................................44
17.1 Modbus Interface......................................................................44
17.2 Modbus Register Table...............................................................45
4 S606
1 Safety Instructions
Safety Instructions
Please check if this instruction manual matches the
product type.
Please observe all notes and instructions indicated in this
manual. It contains essential information which must be
observed before and during installation, operation and
maintenance. Therefore this instruction manual must be read carefully
by the technician as well as by the responsible user / qualified
personnel.
This instruction manual must be available at the operation site of the
flow sensor at any time. In case of any obscurities or questions,
regarding this manual or the product, please contact the manufacturer.
WARNING!
Compressed air!
Any contact with quickly escaping air or bursting
parts of the compressed air system can lead to
serious injuries or even death!
•Do not e ceed the ma imum permitted pressure range. (See
sensors label and/or the specifications written in this manual.)
•Only use pressure tight installation material.
•Avoid that persons get hit by escaping air or bursting parts of the
instrument.
•The system must be pressure less during maintenance work.
WARNING!
Voltage used for supply!
Any contact with energized parts of the product may
lead to an electrical shock which can lead to serious
injuries or even death!
•Consider all regulations for electrical installations.
•The system must be disconnected from any power supply during
maintenance work.
•Do not e ceed the permitted operating parameters as specified in
the data sheet, this manual or written on the instrument.
•Make sure the product is operated in its permitted limitations.
S606 5
1 Safety Instructions
•Do not e ceed or undercut the permitted storage and operation
temperature, pressure and humidity.
•The product should be maintained and calibrated frequently, at
least annually. For more information, contact customer support.
General safety instructions
•It is not allowed to use the product in e plosive areas.
•Please observe the national regulations before/during installation
and operation.
Remarks
•It is not allowed to disassemble the product.
•Always check the compressed air connectors in terms of stability
and tightness.
ATTENTION!
Measurement values can be affected by malfunction!
The product must be installed properly and frequently
maintained. Otherwise it may lead to wrong
measurement values, which can lead to wrong results.
•The instrument must be operated within or better than
compressed air quality Class 4.4.4 according to the ISO8573-1. If
the air quality cannot reach the specified Class, the device may
show wrong measurement values or even may get damaged.
•Do not e ceed the ma imum operation temperature or pressure.
•Avoid condensation inside the instrument caused by the supplied
air or gas because it harms the instrument and affects the
accuracy.
•It is recommended that before any operation you e amine the
instrument in terms of the measurement accuracy and deviations.
To do this, you may use high efficiency filters for oil vapor and
particle, and the instrument should show low values close to zero.
Additionally, it is recommended you e amine the dew point
measurement to ensure it is working correctly. To do this, you may
use a dry gas with a defined dew point value which should be
reached within several minutes. Or you may use any reference
meter. Only after doing these e aminations, you can rely on the
measurement results after the instrument have been used for
other measurement cycles.
6 S606
1 Safety Instructions
•Always perform a visual inspection in prior to every measurement
before connecting compressed air. If any loose objects are found,
do not connect the compressed air because it may lead to a
damage or injuries.
Storage and transportation
•Make sure that the transportation temperature is between
-10°C ... +50°C.
•For transportation it is recommended to use the packaging which
comes with the sensor.
•Please make sure that the storage temperature of the sensor is
between -10°C ... +50°C.
•Avoid direct UV and solar radiation during storage.
•For the storage the humidity must be <90%, no condensation.
ATTENTION!
Equipment may get damaged!
Please make sure that your measuring point is free
of excessive contamination/dirt. This should be
maintained before every measurement.
•Observe the measuring point always before measurement if it is
free of contamination like water drops, oil drops or other rough
contamination.
•Should water hit the inner electronics, the senors could be
seriously damaged.
•Any rough contamination of particles, water, oil or other impurities
may damage the instrument or affect the accuracy.
•Check your measurement point with the enclosed test kit, by
purging air in prior to the use of the instrument through the test
kit. A clean tissue may help to identify oil, water or any other
lubricants in the air.
S606 7
2 Registered Trademarks
2 Registered Trademarks
SUTO®Registered trademark of SUTO iTEC
MODBUS®Registered trademark of the Modbus Organization,
Hopkinton, USA
3 Application
The S606 is a stationary device to continually monitor the breathing air
quality. It can measure O2, CO, CO2, H2O, Oil, and ensures the breathing
air quality to meet the international standard such as EN 12021, CSA
Z180.1-0, and more. The S606 provides a safe and healthy
environment for the operator.
The S606 is mainly used in the industrial environment. It can not be
used in hazardous or e plosive environment and it is not suitable for
permanent outside applications.
4 Features
•All-in-one device measures O2, CO, CO2, H2O, and Oil.
•Measures additionally the temperature and pressure.
•Visible alarm notification and fle ible alarm threshold
configuration.
•Modbus/RTU (RS-485) and Modbus/TCP (Ethernet) interface are
supported.
•Remote monitoring can be easily realized through a 4G dongle and
the free software.
•User-friendly display with all important information.
•Compressed air connection via 6 mm tube.
•Integrated data logger saves data for later analysis.
•Robust housing and easy installation.
8 S606
5 Technical Data
5 Technical Data
5. General Data
Power supply 100 ... 240 VAC, 50/60 Hz, 50 VA
Display Touchscreen, Size: 5”
Resolution: 800 480 p
Data logger Internal, 30-million values
Interface USB
Ethernet (Modbus/TCP)
RS-485 (Modbus/RTU)
4G/LTE Modem (Optional)
Output 1 internal Relay
8 channel relay module(optional)
Process connection Micro quick connector, full pass through, male
(1.5 m hose with coupling included)
Housing material Sheet steel, powder-coated on the outside
Protection class IP54 (cover closed)
Dimension 600 600 250 mm
Approvals FCC, EC
Weight 34 kg
5.2 Operating Conditions
Measuring medium Compressed breathing air
Humidity of the medium < 40%, non condensation
Temperature of the medium 0°C ... +45°C
Operation pressure 0.4 ... 1.5 MPa(g)
For higher pressure need pressure
reducer e ternally
Storage & Transport temperature -10°C … + 50°C
Ambient temperature 0°C … +50°C
Ambient humidity 0... 90% rH
Sample flow rate 6 LPM@4 MPa(g), depends on input
pressure
S606 9
5 Technical Data
Sample rate 1 sample/sec
5.3 Measurement Data
Oil Vapor
Measuring range 0.001 ... 5.000 mg/m³
(Based on 1000 hPa(a), 20°C, 0% relative humidity)
Accuracy 5% of reading ± 0.003 mg/m³
Resolution 0.001 mg/m³
Sensor principle Photo ionization detector
UV lamp lifetime 6,000 working hours or 1 year, whichever comes
first
Oil Mist and Particle Sensor (Only for version S606-C)
Measuring range 0.0 ... 5.0 mg/m³
(Based on 1000 hPa(a), 20°C, 0% relative humidity)
Accuracy 15% of reading ± 0.1 mg/m³
Resolution 0.1 mg/m³
Sensor principle Oil mist and Particle sensor
O2 Sensor
Measuring range 0 … 25%
Accuracy ±(1% of reading + 0.05%)
Resolution 0.1%
Sensor principle Optical o ygen sensor
CO Sensor
Measuring range 0 … 20 ppm
Accuracy ±(5% of reading + 1 ppm)
Resolution 0.1 ppm
Sensor principle Electrochemical sensor
CO2 Sensor
Measuring range 0 … 1000 ppm
Accuracy ±(1% of reading + 25 ppm)
Resolution 1 ppm
Sensor principle NDIR sensor
10 S606
Table des matières
Autres manuels SUTO Instrument de mesure
Manuels Instrument de mesure populaires d'autres marques
Endress+Hauser
Endress+Hauser Proline Promag 50 Caractéristiques techniques
Siemens
Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces
KLINGER
KLINGER CMF V Series Manuel utilisateur
EXFO
EXFO FTB-2 Manuel d'exploitation et d'entretien
Keysight
Keysight M8290A Manuel utilisateur
ADTEK
ADTEK MW-5 Manuel utilisateur
