SUTO S110 Manuel
English
Instruction and operation manual
S110
Power Meter
Dear Customer,
Thank you for choosing our product.
The operating instructions must be read in full and carefully observed
before starting up the device. The manufacturer cannot be held liable for
any damage which occurs as a result of non-observance or non-
compliance with this manual.
Should the device be tampered with in any manner other than a
procedure which is described and specified in the manual, the warranty
is cancelled and the manufacturer is exempt from liability.
The device is destined exclusively for the described application.
S TO offers no guarantee for the suitability for any other purpose. S TO
is also not liable for consequential damage resulting from the delivery,
capability or use of this device.
2 S110
Table of contents
1 Safety Instructions......................................................................4
2 Registered Trademarks................................................................5
3 Application.................................................................................6
4 Features....................................................................................6
5 Technical Data............................................................................6
5.1 General................................................................................6
5.2 Electrical Data.......................................................................7
5.3 Input Signals........................................................................7
5.4 Output Signals......................................................................7
5.5 Accuracy .............................................................................7
6 Dimensional Drawing (in mm).......................................................8
7 Determination of the Installation Point...........................................9
8 Installation ................................................................................9
8.1 Installation Requirements.......................................................9
8.2 Installation Procedure ...........................................................9
8.3 Voltage and Current Connection............................................10
8.3.1 3-Phase / 4-Wire Connection..........................................10
8.3.2 3-Phase / 3-Wire Connection..........................................10
8.3.3 1-Phase / 2-Wire Connection..........................................11
8.4 Electrical Connection............................................................11
8.4.1 Connection to S330 / S331.............................................12
8.4.2 Connection of the Rogowski Coils.....................................12
9 Signal Output...........................................................................14
9.1 Modbus Interface ................................................................14
9.2 Connect Modbus/RT Devices to a Master...............................15
9.2.1 Modbus/RT Cable Length..............................................15
9.2.2 Modbus/RT Wiring and Cable Type.................................15
9.2.3 Daisy-Chain using RS-485 Splitter...................................16
9.2.4 Topology of Modbus/RT Daisy-Chain...............................17
10 Optional Extra Accessories........................................................19
11 Maintenance...........................................................................19
12 Disposal or Waste....................................................................19
13 Appendix: Modbus Commands..................................................20
13.1 Command Request.............................................................20
13.2 Configure Meter.................................................................21
13.3 Command List...................................................................22
13.4 Modbus Register List..........................................................25
13.5 Harmonics Calculations.......................................................36
13.6 Power, Energy and Power Factor..........................................36
S110 3
1 Safety Instructions
1 Safety Instructions
Please check if this instruction manual matches with the
product type.
Please observe all notes and instructions indicated in this
manual. It contains essential information which have to be
observed before and during installation, operation and
maintenance. Therefore this instruction manual has to be read carefully
by the technician as well as by the responsible user / qualified personnel.
This instruction manual has to be available at the operation site of the
power meter at any time. In case of any obscurities or questions,
regarding this manual or the product, please contact the manufacturer.
WA NING!
Dangerous Voltage levels!
Any contact with energized parts of the product, may
lead to a electrical shock which can lead to serious
injuries or even death!
•Consider all regulations for electrical installations.
•The system must be disconnected from any power supply during
maintenance work.
•Any electrical work on the system is only allowed by authorized
qualified personal.
ATTENTION!
Permitted operating parameters!
Observe the permitted operating parameters, any
operation exceeding this parameters can lead to
malfunctions and may lead to damage on the
instrument or the system.
•Do not exceed the permitted operating parameters.
•Make sure the product is operated in its permitted limitations.
•Do not exceed or undercut the permitted storage and operation
temperature.
•The product should be maintained frequently, at least annually.
4 S110
1 Safety Instructions
General safety instructions
•It is not allowed to use the product in explosive areas.
•Please observe the national regulations before/during installation
and operation.
emarks
•It is not allowed to disassemble the product.
ATTENTION!
Measurement values can be affected by malfunction!
The product must be installed properly and
frequently maintained, otherwise it may lead to
wrong measurement values, which can lead to wrong
results.
Storage and transportation
•Make sure that the transportation temperature of device is
between -30°C ... +70°C.
•For transportation it is recommended to use the packaging which
comes with the device.
•Please make sure that the storage temperature of the device is
between -40°C ... +85°C.
•Avoid direct V and solar radiation during storage.
•For the storage the humidity has to be <90%, no condensation.
2 egistered Trademarks
S TO®
Registered trademark of S TO iTEC
MODB S®
Registered trademark of the Modbus Organization, Hopkinton, SA
HART®
Registered trademark of the HART Communication Foundation, Austin,
SA
PROFIB S®
Registered trademark of the PROFIB S ser Organization, Karlsruhe,
Germany
S110 5
3 Application
3 Application
The power meter is designed to measure the actual power consumption
in kW and accumulate the energy consumption in kWh of a 3-phase load.
Additionally other measured parameters such as current, voltage, cos phi
etc. are available as well.
4 Features
•Measures active and reactive power, frequency, voltage, currents,
power factor.
•Accumulates active energy [kWh].
•3-phase 3-wire, 3-phase 4-wire, 1-phase 2-wire measurement
•Modbus / RT output.
5 Technical Data
5.1 General
Parameters
(rms values)
Voltage of each phase and average voltage [V]
Current of each phase and average current [A]
Active Power [kW]
Reactive Power [kvar]
Apparent Power [kVA]
Energy (per phase and summery)
Power factors
Frequency [Hz]
Total Harmonic Distortion [%]
Nominal voltage range 100 V ... 500 V
Power range up to 2500 kW (depends on Rogowski coil)
Frequency range 50 / 60 Hz
Harmonic up to 52th
Sampling rate 8 k/sec
Available clamp sensors Rogowski coil 1 ... 100 A
10 ... 1000 A
30 ... 3000 A
Operating temperature -25 ... +55°C
6 S110
5 Technical Data
Storage temperature -40 ... +85°C
Protection class IP20 conforming to IEC 60629
Dimensions 145 mm x 40 mm x 90 mm (L X W X H)
Weight 210 g
5.2 Electrical Data
Power supply 24 VDC
5.3 Input Signals
Rogowski Coil 0 mV ... 333 mV
5.4 Output Signals
Modbus output See chapter 9.1
5.5 Accuracy
Voltage:
Current:
Power factor:
Frequency:
Active/Apparent Power:
Reactive Power:
Active Energy:
Reactive Energy:
0.2% (100 ... 500 V)
0.5% (1% ... 120% of range)
0.005 from 10 ... 120%
0.01% from 45 ... 65 Hz
IEC62053-22 Class 0.5
IEC62053-21 Class 2
IEC62053-22 Class 0.5s
IEC62053-21 Class 2
S110 7
7 Determination of the Installation oint
7 Determination of the Installation Point
It is possible to install the power meter directly into the connection box
on the compressor or into the connection cabinet where the power
supply for the compressor is coming from.
8 Installation
Please make sure that all components listed below are included in your
package.
Qty Description Item No.
1 Power meter D554 0130
3 Rogowski coils S554 0140 or S554 0141 or S554 0142
1 Instruction manual No P / N
8.1 Installation equirements
ATTENTION!
Wrong measurement is possible, if the device is not
installed correctly.
•The device is for indoor use only! At an outdoor installation, the
device must be protected from solar radiation and rain.
•It is strongly recommend not to install S110 in wet environment.
8.2 Installation Procedure
Installation of the S110 hat rail mountable
The S110 is hat rail mountable and recommended to be installed either
in the power distribution cabinet or in the connection box of the
compressor.
S110 9
