Supero BPN-SAS3-217HD Backplane Manuel utilisateur

Rev. 1.0

BPN-SAS3-217HD Backplane

USER'S GUIDE

20 120 1

1 2 3

1 4

REV:1.00

1222

A C

26 51

100

+ +

+++

12 7

1 2

A37

B32

A33

B33

A37

A32

B32

A33

B33

A37

B37

A32

B32

A33

B33

A37

B37

A32

B32

A33

B33

BAR CODE

DESIGNED IN USA

J28 J27

JP56

JP57

JP54

JP55

JP40

JP36

JP38

J25

U49

U46

C179 C146

D55

D51

D63

D62

D61

D60

D59

D58

D57

D56

C89

R350

R260

R49

R50

TP1

U45

U60

U65

F23

F25

C266

C197

C119

C198

C199 C200 C201C203 C206

C207 C3

C44C5 C92

MH1

MH2

MH4

JPW1

JPW4

JP69

JP70

JP71

JF4

JF3

JF2

JF1

C246

Q869 Q867

Q872

Q875

Q876

Q879 Q880

JPI2C1

JPW3

JPW2

forall power "ON"

Close:LEDtest

Open:Default

UPGRADE#1

FAN1

UPGRADE#2

FAN3

PSON (1-2)

SPIPROG HEADER

J25:SERIALDEBUG

JP36

Open:Default

Close:Anyone button

FAN2

FAN4

SUPER ®

BPN-SAS3-217HD Backplane User’s Guide

Manual Revision 1.0

Release Date: January 22, 2015

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and

documentation, is the property of Supermicro and/or its licensors, and is supplied only under a

license. Any use or reproduction of this product is not allowed, except as expressly permitted by

the terms of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO

USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all

claims will not exceed the price paid for the hardware product.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

Preface

iii

Table of Contents

Contacting Supermicro.......................................................................................iv

Returning Merchandise for Service.....................................................................v

Chapter 1 BPN-SAS3-217HD Safety Guidelines

1-1 ESD Safety Guidelines ................................................................................... 1-1

1-2 General Safety Guidelines .............................................................................. 1-1

1-3 An Important Note to Users ............................................................................ 1-2

1-4 Introduction to the BPN-SAS3-217HD Backplane .......................................... 1-2

Chapter 2 Connectors, Jumpers and LEDs

2-1 Front Connectors ............................................................................................ 2-1

2-2 FrontJumpersandPinDenitions.................................................................. 2-4

Explanation of Jumpers .................................................................................. 2-4

2-3 Front LED Indicators ....................................................................................... 2-5

2-4 Rear Connectors and LED Indicators............................................................. 2-6

2-5 SAS/SATA Ports .............................................................................................. 2-8

BPN-SAS3-217HD Backplane User’s Guide

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: +1 (408) 503-8000

Fax: +1 (408) 503-8008

Email: [email protected] (General Information)

[email protected] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: +31 (0) 73-6400390

Fax: +31 (0) 73-6416525

Email: [email protected] (General Information)

[email protected] (Technical Support)

[email protected] (Customer Support)

Web Site: www.supermicro.nl

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 235

Taiwan (R.O.C)

Tel: +886-(2) 8226-3990

Fax: +886-(2) 8226-3992

Email: [email protected]

Web Site: www.supermicro.com.tw

Preface

Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required be-

fore any warranty service will be rendered. You can obtain service by calling your

vendor for a Returned Merchandise Authorization (RMA) number. When returning to

the manufacturer, the RMA number should be prominently displayed on the outside

of the shipping carton, and mailed prepaid or hand-carried. Shipping and handling

charges will be applied for all orders that must be mailed when service is complete.

For faster service, RMA authorizations may be requested online (http://www.super-

micro.com/support/rma/).

Whenever possible, repack the backplane in the original Supermicro box, using the

original packaging materials. If these are no longer available, be sure to pack the

backplane in an anti-static bag and inside the box. Make sure that there is enough

packaging material surrounding the backplane so that it does not become damaged

during shipping.

This warranty only covers normal consumer use and does not cover damages in-

curred in shipping or from failure due to the alteration, misuse, abuse or improper

maintenance of products.

Duringthewarrantyperiod,contactyourdistributorrstforanyproductproblems.

BPN-SAS3-217HD Backplane User’s Guide

Notes

1-1

Chapter 1: Safety Guidelines

Chapter 1

BPN-SAS3-217HD Safety Guidelines

To avoid personal injury and property damage, carefully follow all the safety steps

listed below when accessing your system or handling the components.

1-1 ESD Safety Guidelines

Electrostatic Discharge (ESD) can damage electronic components. To prevent dam-

age to your system, it is important to handle it very carefully. The following measures

are generally sufcient to protect your equipment from ESD.

•Use a grounded wrist strap designed to prevent static discharge.

•Touch a grounded metal object before removing a component from the antistatic

bag.

•Handle the backplane by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

•When handling chips or modules, avoid touching their pins.

•Put the backplane and peripherals back into their antistatic bags when not in

use.

1-2 General Safety Guidelines

•Always disconnect power cables before installing or removing any components

from the computer, including the BPN-SAS3-217HD backplane.

•Disconnect the power cable before installing or removing any cables from the

BPN-SAS3-217HD backplane.

•Make sure that the BPN-SAS3-217HD backplane is securely and properly

installed on the motherboard to prevent damage to the system due to power

shortage.

1-2

BPN-SAS3-217HD Backplane User's Guide

1-3 An Important Note to Users

All images and layouts shown in this user's guide are based upon the latest PCB

Revision available at the time of publishing. The card you have received may or

may not look exactly the same as the graphics shown in this manual.

1-4 Introduction to the BPN-SAS3-217HD Backplane

The BPN-SAS3-217HD backplane has been designed to utilize the most up-to-date

technology available, providing your system with reliable, high-quality performance.

This manual reects BPN-SAS3-217HD Revision 1.00, the most current release

available at the time of publication. Always refer to the Supermicro web site at

www.supermicro.com for the latest updates, compatible parts and supported con-

gurations.

2-1

Chapter 2: Connectors, Jumpers and LEDs

20 120 1

1 2 3

1 4

REV:1.00

1222

A C

26 51

100

+ +

+++

12 7

1 2

A37

B32

A33

B33

A37

A32

B32

A33

B33

A37

B37

A32

B32

A33

B33

A37

B37

A32

B32

A33

B33

BAR CODE

DESIGNED IN USA

J28 J27

JP56

JP57

JP54

JP55

JP40

JP36

JP38

J25

U49

U46

C179 C146

D55

D51

D63

D62

D61

D60

D59

D58

D57

D56

C89

R350

R260

R49

R50

TP1

U45

U60

U65

F23

F25

C266

C197

C119

C198

C199 C200 C201C203 C206

C207 C3

C44C5 C92

MH1

MH2

MH4

JPW1

JPW4

JP69

JP70

JP71

JF4

JF3

JF2

JF1

C246

Q869 Q867

Q872

Q875

Q876

Q879 Q880

JPI2C1

JPW3

JPW2

forall power "ON"

Close:LEDtest

Open:Default

UPGRADE#1

FAN1

UPGRADE#2

FAN3

PSON (1-2)

SPIPROG HEADER

J25:SERIALDEBUG

JP36

Open:Default

Close:Anyone button

FAN2

FAN4

Chapter 2

Connectors, Jumpers and LEDs

2-1 Front Connectors

1. Main Power Connector: JPW1

2. Secondary Power Connector:

JPW2

3. Secondary Power Connector:

JPW3

4. Secondary Power Connector:

JPW4

5. Chassis Fan Connector: Fan1

JP54

6. Chassis Fan Connector: Fan2

JP55

7. Chassis Fan Connector: Fan3

JP56

8. Chassis Fan Connector Fan4

JP57

9. Power Supply SM Bus Connec-

tor: JPI2C1

10. MB-A hot plug connector: JF1,

JF2

11. MB-B hot plug connector: JF3,

JF4

12. Backplane to front panel connec-

tor for MB-A: J27

13. Backplane to front pannel con-

nector for MB--B: J28

14. Upgrade #1 JP70

15. Upgrade #2 JP71

16. MCU Debug port J25

17. MCUrmwareupgradeportJP69

11 1

15 1

11 1

Figure 2-1. Front Connectors

16 1

2-2

BPN-SAS3-217HD Backplane User's Guide

1. - 4. Power Supply Connectors

These connectors, designated JPW1, JPW2, JPW3, and JPW4 supply power to the

two motherboard nodes in the chassis.

5. - 8. Chassis Fan Connectors

These connectors, designated JP54, JP55, JP56 and JP57 supply power to the

chassis. cooling fans.

20 120 1

1 2 3

1 4

REV:1.00

1222

A C

26 51

100

+ +

+++

12 7

1 2

A37

B32

A33

B33

A37

A32

B32

A33

B33

A37

B37

A32

B32

A33

B33

A37

B37

A32

B32

A33

B33

BAR CODE

DESIGNED IN USA

J28 J27

JP56

JP57

JP54

JP55

JP40

JP36

JP38

J25

U49

U46

C179 C146

D55

D51

D63

D62

D61

D60

D59

D58

D57

D56

C89

R350

R260

R49

R50

TP1

U45

U60

U65

F23

F25

C266

C197

C119

C198

C199 C200 C201C203 C206

C207 C3

C44C5 C92

MH1

MH2

MH4

JPW1

JPW4

JP69

JP70

JP71

JF4

JF3

JF2

JF1

C246

Q869 Q867

Q872

Q875

Q876

Q879 Q880

JPI2C1

JPW3

JPW2

forall power "ON"

Close:LEDtest

Open:Default

UPGRADE#1

FAN1

UPGRADE#2

FAN3

PSON (1-2)

SPIPROG HEADER

J25:SERIALDEBUG

JP36

Open:Default

Close:Anyone button

FAN2

FAN4

FAN4 FAN3 FAN2 FAN1

Cables

BPN-SAS3-217HD

Backplane

System Fans

Figure 2-2. Default Conguration - Fans Connected Directly to the Backplane

9. Power Supply SM Bus Connector

The 5-pin connector, designated JPI2C1, connects the power supply SMbus to

the MCU.

10- 11. Motherboard to Backplane Connectors

JF1 and JF2 connect motherboard A to the backplane on the chassis. JF3 and

JF4 connect motherboard B to the backplane.

12-13. Backplane to Front Panel Headers

J27 and J28 connect by cables to the chassis front control panels--J27 connects

to the panel for serverboard A, J28 connects to the panel for serverboard B.

14-15. Upgrade Connectors #1 - #2

These connectors are designated JP70 and JP71. They are for the manufacturer's

diagnostic use only.

16. Debug MCU

J25isaporttodebugtheMCUrmware.

17. Upgrade MCU

JP69isaporttoupgradetheMCUrmware.
