StarTech.com SV221MICROUA Manuel utilisateur

USB KVM Switch

SV221MICROUA Instruction Manual

Actual product may vary from photo

2 Port USB KVM Switch with Integrated Cables and Audio Switching

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting Computers to the KVM Switch

Installing the Windows Management Software (Optional) . . . . . . . . . . . . . . . .3

Using the Windows Management Software . . . . . . . . . . . . . . . . . . . . . . . . . .3

Hot Key Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Using the KVM Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Instruction Manual

IInnttrroodduuccttiioonn

Thank you for purchasing a StarTech.com personal 2 port USB KVM switch. This KVM

has a small footprint with integrated cables that won’t clutter your workspace, and

includes audio switching so you only need one set of speakers. You can use

customizable keyboard hotkeys to switch computers, or the push-button interface on the

from of the KVM.

FFeeaattuurreess

• Supports USB peripherals for easy installation

• Audio switching support eliminates the need for two sets of speakers

• Hotkey switching with customizable key combinations

• Integrated cable design prevents clutter and avoids hassles

BBeeffoorreeYYoouuBBeeggiinn

System Requirements

• One set of USB console peripherals (keyboard, mouse) and speakers (optional)

• Computers must have an available USB port, and a sound card (optional)

• Computers must have a CD-ROM or other compatible optical drive for optional

software installation (Windows only)

Contents

This package should contain:

• 1 x KVM Switch

• 1 x Installation CD

• 1 x User Manual

Instruction Manual

IInnssttaallllaattiioonn

Please read this section thoroughly before installing the KVM switch.

Connecting Computers to the KVM Switch

1. Remove any existing keyboards, mice, monitors, and speakers from the computers

that you wish to use with the KVM switch.

2. Connect a USB keyboard to the console port on the front of the KVM switch, marked

with a keyboard icon (see above).

3. Connect a USB mouse to the console port on the front of the KVM switch, marked

with a mouse icon (see above).

4. Connect a monitor to the console port on the front of the KVM switch, marked Monitor

(see above).

5. Connect a microphone to the pink connector on the side of the KVM switch, also

marked with a microphone icon (optional, see above).

6. Connect speakers to the green connector on the side of the KVM switch, also marked

with a speaker icon (optional, see above).

7. Connect the integrated cable for computer 1 (corresponds to the LED indicator on the

top of the KVM, as marked) to the USB, video, speaker, and microphone connectors

on the computer. If you need assistance in identifying any ports, please consult the

documentation for your computer. If you are not using the audio switching feature and

did not connect a microphone and speakers to the KVM, you do not need to connect

the microphone and speaker connectors to the computer.

8. Connect the integrated cable for computer 2 (corresponds to the LED indicator on the

top of the KVM, as marked) to the USB, video, speaker, and microphone connectors

on the computer. If you need assistance in identifying any ports, please consult the

documentation for your computer. If you are not using the audio switching feature and

did not connect a microphone and speakers to the KVM, you do not need to connect

the microphone and speaker connectors to the computer.

Instruction Manual

Console USB Mouse

Console USB Keyboard

Console Monitor

Selection Button Speaker/Mic

Integrated Cable

(Computer 1)

Integrated Cable

(Computer 2)

9. Power on computer 1 and computer 2. You can now use the KVM switch.

(!) NOTE: If you experience problems with Windows detecting the KVM switch, you may

wish to connect the devices you will be using at the KVM console, restart the machine,

and re-attach the KVM switch. This will allow Windows to configure itself to use USB

input devices.

(!) NOTE: If at any time during the installation process Windows warns you about a driver

file not being digitally signed, this is normal. Choose to continue the installation to

complete the detection process.

Installing the Windows Management Software (Optional)

The software included with the KVM switch is designed for use with computers that use

Windows 98, 98SE, ME, 2000, XP, or Server 2003. This software allows you to configure

custom hotkey sequences for KVM features and provides a software menu you can use

to switch computers, as an alternative to keyboard hotkeys or the push-button selector on

the top of the KVM.

1. Once you have installed the KVM switch following the instructions above, insert the

CD that came in the package in your computer’s CD-ROM or other optical drive. The

KVM software installation should start automatically. If it doesn’t, open My

Computer and double click the icon for the CD-ROM drive. Double click the

USBKVMIn.exe file to start the setup program.

2. Walk through the setup process by accepting the default settings and choosing Next

whenever prompted. Windows may warning you during the install process that the

driver being installed is not digitally signed. If this occurs, choose to continue the

installation. When the setup routine is complete, setup will notify you with a final

screen. Click Finish to complete the setup process.

3. The software will now load each time Windows starts. You can open the

configuration menu by double-clicking one of the following icons:

Using the Windows Management Software

The management software allows you to configure custom hotkeys, turn the status

buzzer indictor off or on, and use the autoscan feature. You can access the software by

double clicking its icon on the taskbar, or you can right-click it once and choose the

Settings option from the menu. You can also use this menu to activate Auto Scan and

switch active computers.

Instruction Manual

Hot Key Configuration

This setting configures custom key configurations that you can use to switch between

PCs on the KVM. By default, the [Ctrl] + [Alt] + [1] hotkey sequence is active, where

the [1] key is the number of the KVM port you wish to access. To use the custom hotkey

feature, all keys must be pressed simultaneously. You can change the command key

from the default to any letter or number on the keyboard. Control keys such as [Tab],

[Esc], and [Num Lock] cannot be used.

Turn On Buzzer

When checked, activates the audible notification when the port is changed.

Fix Audio Port at PC

When checked, locks audio input to the selected port regardless of which KVM port is

active. When unchecked, audio input is selected along with the KVM port.

Auto Scan Period

Sets the amount of time the Auto Scan feature will wait between switching ports.

Selectable between 10 ~ 60 seconds.

NOTE: Although there are options to change hotkeys for ports 3 and 4, they are inactive

on this product.

Instruction Manual

Using the KVM Switch

Once you have completed the installation process, you can use the following methods to

select a KVM port:

Selection Button: You can switch between ports by press the button on the top of

the KVM.

Universal Hotkey: The command [Scroll Lock] - [Scroll Lock] can be used

with any operating system, including Windows computers with the KVM management

software installed. This toggles control to the next KVM port.

Customized Hotkey: If you are using Windows-based computers and have installed

the KVM management software, you can use the [Ctrl] + [Alt] + [1] sequence to

switch computers. The [1] key corresponds to the key you have configured in the

software (see the previous section for details).

(!) NOTE: You cannot use either keyboard hotkey sequence to select a port that does not

have the USB cable connected or where the computer is powered off.

(!) NOTE: Mac users will need to use an IBM-compatible USB keyboard for the console

since most Apple keyboards do not have a [Scroll Lock] key.

Instruction Manual

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Instruction Manual

Revised: 10 May 2005 (Rev. A)

AAbboouuttSSttaarrTTeecchh..ccoomm

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer

Parts”. Since 1985, we have been providing IT professionals with the

quality products they need to complete their solutions. We offer an

unmatched selection of computer parts, cables, server management

solutions and A/V products and serve a worldwide market through our

locations in the United States, Canada, the United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our products

and to access exclusive interactive tools such as the Parts Finder and the

KVM Reference Guide. StarTech.com makes it easy to complete almost

any IT solution. Find out for yourself why our products lead the industry in

performance, support, and value.

Table des matières

Autres manuels StarTech.com Changer

StarTech.com

StarTech.com DisplayPort MSTDP124DP Manuel utilisateur

StarTech.com

StarTech.com MSTCDP122HD Manuel utilisateur

StarTech.com

StarTech.com ST7CU35122 Manuel utilisateur

StarTech.com

StarTech.com 8STMSTCDP123DP Manuel utilisateur

StarTech.com

StarTech.com CPNT410IR Manuel utilisateur

StarTech.com

StarTech.com DisplayPort SV231QDPU34K Manuel utilisateur

StarTech.com

StarTech.com 8STICUSB23216FD Manuel utilisateur

StarTech.com

StarTech.com HB31C3A1CME Manuel utilisateur

StarTech.com

StarTech.com POEINJ2GI Manuel utilisateur

StarTech.com

StarTech.com IES81000POE Manuel utilisateur

StarTech.com

StarTech.com SV231DD2DUA Manuel utilisateur

StarTech.com

StarTech.com SV211HDUA4K Manuel utilisateur

StarTech.com

StarTech.com SV431USBAE Manuel utilisateur

StarTech.com

StarTech.com SV431DVIUAGB Manuel utilisateur

StarTech.com

StarTech.com SV431HDU3A2 Manuel utilisateur

StarTech.com

StarTech.com 5G4AINDNP-USB-A-HUB Manuel utilisateur

StarTech.com

StarTech.com 129N-USBC-KVM-DOCK Manuel utilisateur

StarTech.com

StarTech.com SV431DLU3A Manuel utilisateur

StarTech.com

StarTech.com SV231DDVDUA Manuel utilisateur

StarTech.com

StarTech.com HB30A3A1CST Manuel utilisateur

StarTech.com

StarTech.com SV231DD2DUA Manuel utilisateur

StarTech.com

StarTech.com VS421HD4KA Manuel utilisateur

StarTech.com

StarTech.com DH5102E Manuel utilisateur

StarTech.com

StarTech.com IES101GP2SFW Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
