SV1107IPEXT

KVM over IP with Virtual Media

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital de-

vice, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com. Where

they occur these references are for illustrative purposes only and do not represent an endorse-

ment of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. Regardless of any direct acknowl-

edgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols

contained in this manual and related documents are the property of their respective holders.

Instruction Manual

Table of Contents

Introduction ................................................................................... 1

Features ......................................................................................1

Package Contents .......................................................................1

Hardware Requirements..............................................................2

Hardware Guide ..........................................................................3

Computer Preliminary Setup........................................................ 5

SV1107IPEXT Preliminary Setup ................................................. 6

Windows XP and 2000 ................................................................7

Windows Vista™..........................................................................7

SV1107IPEXT Initial Conﬁguration .............................................. 8

Hardware Setup ............................................................................. 11

Installation ...................................................................................11

(Optional) Mounting to a Cabinet/Rack ......................................13

Normal Logon..............................................................................14

Administration ............................................................................... 16

Network .......................................................................................17

Access Ports................................................................................17

IP Address...................................................................................18

DNS Server .................................................................................18

IP Change Notiﬁcation.................................................................18

Security .......................................................................................19

Overview......................................................................................19

Filtering........................................................................................20

User Station Filtering – IP Addresses .........................................20

Instruction Manual

User Station Filtering – MAC Addresses.....................................21

Custom SSL Certiﬁcates .............................................................21

User Management.......................................................................22

Customization..............................................................................24

Firmware .....................................................................................24

Using the SV1107IPEXT................................................................ 26

Required Equipment....................................................................26

Connecting from your Local Network ..........................................26

Using The Windows Client...........................................................27

The Windows Client Control Panel ..............................................29

Hotkey Setup ...............................................................................30

Video Adjustment ........................................................................32

The Message Board ....................................................................34

Compose Panel ...........................................................................34

Message Display Panel ...............................................................34

User List Panel ............................................................................34

Virtual Media ...............................................................................36

The Java Applet ............................................................................. 37

Navigation....................................................................................38

The Java Applet Toolbar ..............................................................39

Troubleshooting............................................................................. 45

General Operation .......................................................................45

The Java Applet...........................................................................45

The Windows Client.....................................................................46

Mouse Synchronization Procedures............................................47

Technical Support ......................................................................... 49

Warranty Information .................................................................... 49

Instruction Manual

Introduction

The SV1107IPEXT Server Remote Control KVM over IP with Virtual Me-

dia capability enables simple management of remote servers from any-

where in the world, through remote administrative control, while providing

a convenient way to monitor computers and servers over a network, or

over the Internet.

The SV1107IPEXT Server Remote Control KVM over IP also offers the

ability to transfer ﬁles to the server from a remote location, as well as the

ability to upload ﬁles to a Virtual Media USB 2.0 RAM port. The Virtual

Media port acts as a virtual USB port, allowing ﬁles and data to be ac-

cessed as if it originated from a local USB port - simplifying software or

operating system updates and installs via an Internet connection.

Features

USB virtual media port for disk emulation and ﬁle transfers, including•

complete remote application and operating system installations

SSL 128bit encryption•

Flash upgradable•

Package Contents

1 x 6’ CAT5 cable•

1 x Power adapter•

1 x SV1107IPEXT unit•

1 x USB console cable•

1 x USB KVM cable set•

1 x User manual•

1 x Virtual Media USB Cable (Mini B to A)•

1 x Mounting bracket•

Instruction Manual

Hardware Requirements

For best results, we recommend that the computers used to access the

SV1107IPEXT control unit have at minimum a Pentium III 1 GHz proces-

sor, with the screen resolution set to 1024 x 768.

Browsers must support 128-bit SSL data encryption•

Recommended Internet connection speed: at least 128 kbps•

For the browser-based Windows Client, you must have DirectX® 7.0 or•

higher installed

For the browser-based Java Applet, you must have Sun’s Java Runtime•

Environment Version 6 Update 3 or higher.

Your router and ISP must support Port Forwarding to allow access from•

the Internet.

Video

The SV1107IPEXT unit supports the following resolutions and refresh

rates:

Operating System Support

Windows® 2000 or more recent

Linux: RedHat 9 +, SuSE 10+, Mandriva (Mandrake) 2007 +

UNIX: AIX .3+, FreeBSD 6+

Novell: Netware 6 +

Resolution Refresh Rates

640x480 60, 72, 75, 85

720x400 70

800x600 56, 60, 72, 75, 85

1024x768 60, 70, 75, 85

1152x864 75

1280x1024 60, 75

Instruction Manual

Hardware Guide

12 3 4 5

Component Description

1 Reset Switch

System Reset: Pressing and holding this switch in for

more that three seconds performs a system reset

Restore Factory Default Settings: Power off the

SV1107IPEXT, then press and hold the reset switch

for at least 3 seconds while reconnecting power

Please Note: This will not reset users or passwords

210/100 Mbps

LED

ORANGE: Indicates 10 Mbps connection

GREEN: Indicates a 100 Mbps connection

3 Link LED Flashes GREEN to indicate that a Client program is

accessing the device.

4 Power LED ORANGE: SV1107IPEXT unit is powered and ready

to operate.

5LAN Port The network Ethernet cable connection

Instruction Manual

Hardware Guide - Cont’d

Please Note: if you are using a wireless keyboard/mouse set, connect

the receiver to the Keyboard port of the KVM cable

Component Description

1 Power Jack The power adapter connection

2 PC/KVM Port The connection for the cable that links the

SV1107IPEXT to your computer

3USB Console

Port

This is the connection for the local console cable

(USB keyboard, monitor, and USB mouse). Each port

is color coded and marked with an appropriate icon

for identiﬁcation*

4Virtual Media

Port

The connection for the virtual media cable that

connects the SV1107IPEXT to a USB port on your

computer - allowing ﬁle transfers to occur

5 LAN Port The network Ethernet cable connection

1234

Instruction Manual

Computer Preliminary Setup

Find your computer’s IP address and default Gateway by doing the follow-

ing:

Click on1. Start, then RUN.

Enter2. CMD in the text box.

Click on [3. OK] or press the [Enter] key.

When the command line window opens, Type4. ipconﬁg, then press

Enter:

Look for the heading that says Ethernet adapter5. Local Area

Connection:

Write down the IP Address and Default Gateway. If the ﬁrst three6.

groups of numbers of your IP Address happens to be 192.168.0,

proceed to Hardware Set Up.

Exit the command line by clicking on the “X” on the top right corner of7.

the Command line window SV1107IPEXT preliminary setup

Instruction Manual

SV1107IPEXT Preliminary Setup

Connect the SV1107IPEXT and your computer to your network using the

following diagram. This is a preliminary set up, so no other connections

are needed.

Most home networks use automatic IP Addressing, and the SV1107I-

PEXT is provided with a default ﬁxed IP address of 192.168.0.60. There-

fore, to log in for the ﬁrst time, you must have your computer and the

SV1107IPEXT on the same network.

Be sure to write down your existing settings prior to changing anything so

you can return to them after the initial set up.

The instructions on the following pages will explain how to put your com-

puter and SV1107IPEXT on the same network; the ﬁrst set of instructions

cover Windows XP and 2000, the second set explains Windows Vista™.

SV1107IPEXT

Ethernet Cable (Supplied)

Router

Table des matières

Autres manuels StarTech.com Changer

StarTech.com

StarTech.com StarView SV431USB Manuel utilisateur

StarTech.com

StarTech.com IES101002SFP Manuel utilisateur

StarTech.com

StarTech.com ST7300USBM Manuel utilisateur

StarTech.com

StarTech.com P2DD46A22-KVM-SWITCH Manuel utilisateur

StarTech.com

StarTech.com 8 Port StarView CAT5 UTP KVM Manuel utilisateur

StarTech.com

StarTech.com PDU08C13GB Manuel utilisateur

StarTech.com

StarTech.com STARVIEW SV431DVIUAHR Manuel utilisateur

StarTech.com

StarTech.com ES3116 Manuel utilisateur

StarTech.com

StarTech.com DS52000 Manuel utilisateur

StarTech.com

StarTech.com VS221HDQ Manuel utilisateur

StarTech.com

StarTech.com ENTERPRISE CLASS SV1653DXI Manuel utilisateur

StarTech.com

StarTech.com IES61002POE Manuel utilisateur

StarTech.com

StarTech.com SV431USBAE Manuel utilisateur

StarTech.com

StarTech.com ST4202USB Manuel du système

StarTech.com

StarTech.com SV841HDI Manuel utilisateur

StarTech.com

StarTech.com SV231DPDDUA2 Manuel utilisateur

StarTech.com

StarTech.com POEINJ4G Manuel utilisateur

StarTech.com

StarTech.com StarView SV231 Manuel utilisateur

StarTech.com

StarTech.com MSTDP122DP Manuel utilisateur

StarTech.com

StarTech.com VS122HDMIU Manuel utilisateur

StarTech.com

StarTech.com HB30AM4AB Manuel utilisateur

StarTech.com

StarTech.com SV441DUSBI Manuel utilisateur

StarTech.com

StarTech.com 35BAYFWUSB Manuel

StarTech.com

StarTech.com ST4300PBU3 Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
